Hunter Internet Thermostat Instructions de montage

(continued)

Table of Contents

PROGRAMMING

INTRODUCTION

INSTALLATION

Read This Before Installing Thermostat 5

What You Need 8

Remove Old Thermostat 8

Wire Labeling 9

Mount Wallplate and Thermostat 10

Connect Wires and Mount Thermostat to Wallplate 11

Option Menu 12

Remote Sensor Channel Set-Up (does not apply to thermostat model 44660) 14

Setting Time and Day 16

12 Hr. / 24 Hr. Time Format 17

Programming Introduction 18

Personal Program Schedule 19

Programming 21

Weekday/Weekend Programming 22

7-Day Programming 25

Everyday Programming 27

Program Options 29

Table of Contents (continued)

PROGRAMMING (continued)

OPERATIONS

Programmable Fan 29

System Selection Key 31

Fan Key 31

Reviewing the Current Temperature Setting 32

Temporary Manual Override 33

Permanent Manual Override 34

Vacation (Programmable) Hold 35

Auto Season Changeover 36

Home Today 37

Energy Monitor 39

Filter Monitor 40

SPAN Settings 41

Auto Recovery 42

Keyboard Lock 43

Backlighting (INDIGLO®Night-Light) 44

Low Battery Warning 45

Error Mode 45

Problems & Solution 46

TROUBLESHOOTING

OPERATIONS (continued)

Technical Support 47

Technical Support 48

WIRING DIAGRAMS

Read This Before Installing Thermostat

IMPORTANT

1Read the entire installation section of this Owner’s

Manual thoroughly before you begin to install or oper-

ate your Hunter Thermostat.

Remove the Mylar label from the LCD display window.

INSTALLATION

2All installation is normally performed at your

thermostat.

ARMCHAIR PROGRAMMING

3You can program your thermostat before installation by

inserting the batteries and following the instructions

starting on page 16. This can be done while you relax in

your favorite chair and is a very good way to familiarize

yourself with all the functions of your Hunter Thermostat.

SYSTEM COMPATIBILITY

4Your Thermostat is designed to operate with most

gas, oil, electric, or 2-wire hot water heating and air

conditioning systems. It will also operate single-stage heat

pumps that do not have auxiliary or emergency heat. These

have 24 volt or millivolt control systems and represent

most central heating, air conditioning, or space heating

units in the United States.

This thermostat will not control 120/240 Volt systems or

millivolt systems.

COMPRESSOR PROTECTION

5The thermostat provides a 3.5 minute delay after shut-

ting o the heating or cooling system before it can be

restarted. This feature will prevent damage to your com-

pressor caused by rapid cycling.

TEMPERATURE RANGE

6Your thermostat can be programmed between 45°F

and 95°F (7°C and 35°C). However, it will display room

temperatures from 15°F to 99°F (-9°C and 37°C). “HI” will

be displayed if the temperature is higher than 99°F (37°C),

and “LO” will be displayed if the temperature is lower than

15°F (-9°C).

AUTO RECOVERY

7Your thermostat is set from the factory to gradually

recover the room temperature from an energy saving

program to your comfort program. Therefore, the ther-

mostat may turn your system on several minutes prior to

your programmed time. This operation is normal, but can

be turned o. Refer to the Options Menu information on

pages 16.

OPERATION

8NOTE: The INDIGLO®Night-Light will not function when

the battery power is low.

BATTERY WARNING

9Two fresh AA alkaline batteries should provide well

over one year of service. However, when the batteries

become drained, the Low Battery Indicator will ash on the

display. when this message occurs, install new alkaline bat-

teries. You have appoximately one minute to change the

batteies and keep the thermostat’s clock and program set-

tings. Once the batteries have become too low to ensure

proper operation, your system will be turned o, and the

display will be cleared except for the ashing Low Battery

Indicator on the LCD display.

CAUTION: When only the battery Icon ashes on the

display, the display, the thermostat is shut down and your

system will no longer operate. In this condition, there is no

REMOTE SENSORS (does not apply to thermostat model

44660)

1Your thermostat can support 3 remote sensors that

will measure the temperature from three dierent

locations - two indoor and one outdoor. To congure your

thermostat to work with the remote sensors, follow the

instructions for Sensor Channel selection on page 14 of

this manual. To congure the remote sensors, consult the

Remote Sensor Instruction Manual.

NOTE (does not apply to thermostat model 44660)

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must ac-

cept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reason-

able protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accor-

dance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit dierent

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician

for help.

INSTALLATION

Wall Mounting Plate Thermostat Cover

What You Need

This thermostat includes two #8 slotted screws and two wall

anchors for mounting. To install your thermostat, you should

have the following tools and materials.

CAUTION: Do not remove any wiring from existing thermo-

stat before reading the instructions carefully. WIRES MUST

BE LABELED PRIOR TO REMOVAL.

■

IMPORTANT! Turn o the power to the furnace at the

main power panel or at the furnace.

■

Remove existing thermostat cover. See Figure 1. Some ther-

mostats will have screws or other locking devices that must

rst be removed. Once wall mounting plate is exposed, look

for wires.

Ifwiresarenotvisible,they maybeconnectedtothebackofthe

wallplate. Again, look for screws, tabs, etc. Some models have

doors that open to expose wires and mounting screws. (See

Figure 1).

Remove Old Thermostat

TYPICAL HOME THERMOSTATS

Figure 1

■

Slotted Screwdriver(s)

■

Electric drill and 3/16" bit

■

Phillips Screwdriver

■

Two 1.5 V (AA) size alkaline batteries

■

Hammer

(continued)

Wire Labeling

■

Each wire coming from the wall to the existing thermo-

stat is connected to a terminal point on that thermostat.

Each of these terminal points is usually marked with a

code letter as shown in Table A on the next page.

■

IMPORTANT! BEFORE DISCONNECTING ANY WIRES, AP-

PLY THE SELF-ADHESIVE LABELS PROVIDED TO THE WIRE

AS SHOWN IN TABLE A and B ON PAGES 12-13. (For ex-

ample, attach the label marked W to the wire that goes

to the W or H terminal on your existing thermostat.)

IGNORE THE COLOR OF THE WIRES since these do not

always comply with the standard.

■

After labeling wires, disconnect them from the existing

thermostat terminals.

■

Remove existing wallplate. To make sure wires do not

fall back into wall opening, you may want to tape them

to the wall.

■

If hole in wall is larger than necessary for wires, seal this

hole so that no hot or cold air can enter the back of the

thermostat from the wall. This air could cause a false

thermostat reading.

INSTALLATION

Mount Wallplate and Thermostat

■

Remove the wallplate from your thermostat by pressing

the release tab on the bottom of the thermostat. (See

Figure 2.)

■

Position wallplate on wall and pull existing wires

through large opening. Then level for appearance. Mark

holes for plastic anchors provided if your existing holes

do not line up with those on the Hunter wallplate.

■

Drill holes with 3/16" bit and gently tap anchors into

the opening. Insert mounting screws provided into wall

anchor and tighten. (See Figure 3.) holes until ush with

wall.

■

Reposition wallplate to wall, pulling wires through large

opening. Insert provided mounting screws into wall an-

chors and tighten.

W/B

Y/O

RC1

Figure 3

Figure 2
