Hunter 44550 Manuel utilisateur

OwnerÕs Manual Model 44550

SINCE 1 8 8 6

AUTO SAVER 550

Ask Your Local Retailer for

Other Quality Products from Hunter

To locate your nearest Hunter Dealer, call 1-800-4HUNTER,

or visit The Hunter Fan Company website: www.hunterfan.com

Fans

Air Purifiers Humidifiers

Introduction

Model Information:

Model Number ____________________________________

Serial Number _____________________________________

Date Purchased____________________________________

Where Purchased___________________________________________________________

CONGRATULATIONS!

Your new Hunter electronic thermostat will provide years of

reliable service. By saving energy, your thermostat will pay for

itself during its first season of use. Thank you for buying a

Hunter product!

Please read this manual for complete instructions on installing

and operating your thermostat.

If you require further assistance, call Hunter Technical Support

at 901-745-9222 from 8 a.m. to 5 p.m. Central Time.

44550

Table of Contents

Read This Before Installing Thermostat 6

Features 8

What You Need 10

Remove Old Thermostat 10

Wire Labeling 11

Mount Wallplate and Thermostat 12

Selector Switches 14

Setting Time and Day 16

Auto Programming 17

Personal Program Schedule 18

Manual Programming 19

Weekday / Weekend Programming 19

7-Day Programming 21

Reviewing Programs 22

Reviewing the Current Temperature Setting 23

System Selector Switch 24

Fan Switch 24

(continued)

INTRODUCTION

INSTALLATION

PROGRAMMING

OPERATIONS

4-5

OPERATIONS (continued)

SAFETY FEATURES

TROUBLESHOOTING

WIRING DIAGRAMS

Temporary Manual Override 24

Permanent Manual (Vacation) Override 25

Auto Season Changeover 26

Home Today 26

Energy Monitor 28

Filter Monitor 29

Auto Recovery 30

Keyboard Lock 31

Backlighting 31

Low Battery Warning 32

Error Mode 33

Auto Cut-Off 33

Problems & Solutions 34

Technical Support 35

Heat / Cool Systems 36

Single-Stage Heat Pump Systems 37

Heat Only / Cool Only Systems 38

Table of Contents (continued)

IMPORTANT

Read the entire installation section of this Owner’s

Manual thoroughly before you begin to install or

operate your Hunter Thermostat.

REMOVE THE MYLAR LABEL FROM THE LCD DISPLAY WINDOW.

INSTALLATION

All installation is normally performed at your

thermostat.

ARMCHAIR PROGRAMMING

ou can program your thermostat before installation by

inserting the batteries and following the instructions

starting on page 16. This can be done while you relax in

your favorite chair and is a very good way to familiarize

yourself with all the functions of your Hunter Thermostat.

Note: At initial power-up this thermostat is programmed at 68°F

(20°C) for Heat and 78°F (26°C) for Cool. Any change to the set

temperature will be treated as a Permanent Manual Override. See

page 25 for more information. Press Auto Program to load the

built-in energy saving programs.

OPERATION

our Thermostat is designed to operate with most gas,

oil, electric or 2-wire hot water heating and air

conditioning systems. It will also operate single-stage heat

pumps that do not have auxiliary or emergency heat.

These have 24-volt or millivolt control systems and

represent most central heating, air conditioning, or space

heating units in use in the United States.

This Hunter Thermostat will NOT control multi-stage heat

pumps or 110/220 Volt systems.

COMPRESSOR PROTECTION

he thermostat provides a 3.5 minute delay after

shutting off the heating or cooling system before it can

be restarted. This feature will prevent damage to your

compressor caused by rapid cycling. Note that this delay

also applies to the heating system control. It does not

provide a delay when there are power outages.

TEMPERATURE RANGE

our thermostat can be programmed between 40°F

and 95°F (4°C and 35°C). However, it will display room

temperatures from 32°F to 99°F (0°C and 37°C). “HI” will

be displayed if the temperature is higher than 99°F (37°C),

and “LO” will be displayed if the temperature is lower than

32°F (0°C).

NOTE: The thermostat will automatically change to the Cool

mode if the thermostat measures a temperature over 99°F

(37°C). “Hi” will be displayed on the LCD, and the Cooling

system will turn On. Similarly, the thermostat will

automatically change to the Heat mode if the temperature is

below 32°F (0°C). “LO” will be displayed on the LCD, and the

Heating system will turn On.

Read This Before Installing Thermostat 6-7

Read This Before Installing Thermostat (continued)

POWER FAILURE

henever the main power is interrupted or fails, the

battery power retains the programs and current time.

AUTO RECOVERY

Your thermostat is set from the factory to gradually recover

the room temperature from an energy saving program to

your comfort program. Therefore, the thermostat may turn

your system on several minutes prior to your programmed

time. This operation is normal, but can be turned off. Refer to

the Selector Switches information on pages 14-15.

BATTERY WARNING

resh alkaline batteries should provide over one year of

service. However, when the batteries become drained,

“BATT” will alternate on the display with the current time.

When this message occurs, install 2 new AA batteries. You

have approximately 1 minute to change the batteries and

keep thermostat’s clock and program settings. Once the

batteries have become too low to ensure proper operation,

your system will be turned Off, and the display will be

cleared except for “BATT” flashing on the LCD display.

CAUTION: Once the “BATT” only display occurs, the

thermostat is shut down, and your system will no longer

operate. In this condition, there is no temperature control of

your dwelling.

NOTE: The INDIGLO

night-light will not function when the

thermostat is in low battery condition.

NOTE: If you plan to be away from the premises over 30

days, we recommend that you replace the old batteries with

new alkaline batteries prior to leaving.

Features

HOME TODAY: Overrides energy-

saving program temperatures while

you are at home for the day.

ENERGY: Measures and

displays heating and

cooling system operating

time for Today, Yesterday,

This Week, Last Week, or

Total. By monitoring your

energy usage, you can

program the thermostat to

optimize energy savings.

Temperature Keys: Keys

for raising or lowering

temperature settings.

Soft-touch

programming keypad,

see details below.

Light Bar: Activates INDIGLO®

night-light to allow display

viewing in the dark.

System Switch: System

selector switch for Cool,

Off, Heat or Auto.

Fan Switch: Fan switch for

Automatic or Continuous

On fan operation.

Battery Door: Front-

access battery door

allows easy battery

changes.

Alpha-numeric display shows time, day,

temperature, program number, and other

feature information as required.

8-9

COOL AUTOOFF HEAT

AUTOONFAN

M T W Th F Sa Su SETTEMP

PM C

TEMP

AUTO COOLHEAT

Usage TodayYesterdayThis Week LastWeekTotal

1234

HOME

TODAY

ENERGY

Provides permanent

temperature setting by

overriding stored

programs. It also returns

the thermostat to current

program control from

manual override or Home

Today mode.

For entering minute of day.

Enters Program Mode for

reviewing and changing

weekday, weekend, or

daily programs.

Selects the day

or days to review

or change in

Program Mode.

Returns display to

current time and

temperature.

Automatically

programs the

thermostat to its

built-in E

NERGY

TAR

compliant

program

settings. See

page 17.

For entering day of week.

Reviews filter usage in

hours and minutes. Also

resets filter counter to zero.

For entering hour of day.

MIN

AUTO

PROGRAM

HOLD

CLEAR

HOUR

PROG

DAY

FILTER

PROG

DAY RETURN

As an E

NERGY

TAR

Partner, Hunter Fan

Company has determined

that this programmable

thermostat meets the

NERGY

TAR

®guidelines for

energy efficiency.

10-11

INSTALLATION

This thermostat includes two #8 slotted screws and two wall

anchors for mounting. To install your thermostat, you should have

the following tools and materials.

■Slotted Screwdriver(s)

■Phillips Screwdriver

■Hammer

■Electric drill and 3/16" bit

■Two 1.5 V (AA) size alkaline batteries

What You Need

CAUTION: Do not remove any wiring from existing

thermostat before reading the instructions carefully.

WIRES MUST BE LABELED PRIOR TO REMOVAL.

■IMPORTANT! Turn off the power to the furnace at the main

power panel or at the furnace.

■Remove existing thermostat cover. See Figure 1. Some

thermostats will have screws or other locking devices that must

first be removed. Once wall mounting plate is exposed,

look for wires.

If wires are not visible, they may be connected to the back of

the wallplate. Again, look for screws, tabs, etc. Some models

have doors that open to expose wires and mounting screws.

(See Figure 1).

Remove Old Thermostat

TYPICAL HOME THERMOSTATS

Figure 1

Wall Mounting Plate Thermostat Cover
