Hunter 44273 Manuel utilisateur

Owner’s Manual

Models

44273

44279

Form# 44129-01

20120723

English

5-1-1Programmable

Weekdays-Saturday-Sunday

INSTALLATION

5 MINUTE

44129-01 • 07/23/2012

At A Glance

Know Your ermostat � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3

Setup

Setting Day and Time ��10

Scheduling

Scheduling Introduction � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12

Personal Scheduling Charts � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14

Setting Your Schedule� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14

Temporary Temperature Change� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 18

Turning Oﬀ Scheduling � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 20

Save Away��22

Features

Alerts ��24

Menu Options ��28

Additional Features ��32

ermostat Assistance

Troubleshooting and Support� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 33

Technical Support��35

Warranty

1 Year Guarantee ��36

Table Of Contents

Your thermostat has been pre-programmed from the factory with no

programming necessary. We recommend using these pre-programmed settings

for a few days before altering them as they offer maximum energy saving

benets. If you do decide to alter your programs, use the charts on page 13

to write out your scheduled times and temperatures. After you have recorded

your preferences, follow the instructions on page 14 to alter your temperature

settings.

There is no need to program the thermostat at the wall where it is mounted!

Remove the thermostat from the backplate by gripping the sides rmly and

pulling it straight off. This allows you to program the thermostat in comfort.

After you have programmed your thermostat, no other setting changes are

necessary unless you wish to browse through the menu to see how you may

further adjust the independent settings of your thermostat to meet your lifestyle.

The features section starting on page 28 of this manual will describe these

settings. Most settings have been preset for optimal performance.

If you need any assistance with installion or setup of your new

Hunter Thermostat, please call us, our technical support staff is

ready to help!

USA: 1-888-830-1326

Canada: 1-866-268-1936

Hours of operation are from 7:00 am to 7:00 pm Monday - Friday and 8:00

am to 5:00 pm on Saturday, Central Time. You may also contact us over the

Internet at:

www.HunterFan.com

Know Your ermostat

44129-01 • 07/23/2012

1. Allows Schedule Setup for altering scheduled programs.

2. Sets the Save Away feature for when you will not be home during a regularly

programmed time.

3. Conrms completion of an action or returns you to the Home screen.

4. Allows access to the advanced features of the thermostat.

5. Moves you forward or backward while setting up features or schedules.

6. Adjusts time and temperature settings as well as moving up or down

menu lists.

7. Indicates whether the system is set to Heat, Cool, or Off.

8. Shows if the fan is set to Auto or On modes.

9. Allows you to switch between Heat, Cool, and Off modes.

10. Allows you to switch between fan Auto and On mode.

Know Your ermostat

Save

Away

Schedule

Back Done/

Home Menu Next

910

Know Your ermostat

44129-01 • 07/23/2012

1. Holds 2 “AA” Batteries.

2. HE/HG Switch - allows you to set your furnace to Gas/Oil or Electric, based

on the type of system you have.

3. Allows your thermostat to operate your HVAC system* properly by indicating

the system type that you have.

*Conventional System: Uses a condensing unit for cooling and a

separate furnace system for heating.

*Heat Pump System: Uses the condensing unit for both heating

and cooling.

NOTE: If you are unsure of your system type it may be necessary

to contact our technical support department at 1-888-830-1326, your

HVAC manufacturer, or a local HVAC technician to determine this.

Improper selection of your system type could cause the thermostat to not

operate your system properly.

Know Your ermostat

44129-01 • 07/23/2012

1. Shows the current day of the week or weekend.

2. Indicates the thermostat is running in schedule mode.

3. Will show when your heat pump or system is reporting a problem to the

thermostat.

4. Indicates the current room temperature.

5. C will display when in Celsius mode. Nothing will display when set to

Fahrenheit.

6. Flashes when the furnace lter should be checked for replacement.

7. On when the current schedule period is running.

8. Indicates the current active schedule period.

9. Low battery warning, replace the batteries in the thermostat.

10. Indicates the fan is running when displayed.

11. Shows the current mode of the fan, Auto or On.

12. Indicates the current time in AM (A) or PM (P).

13. On when the current operating mode, heat or cool, is running.

14. Current operating mode, heat or cool.

15. Indicates the thermostat is running in save away mode.

16. Current Set temperature the thermostat is scheduled to run.

Know Your ermostat

Wed

Auto

Filter

10:05

At Home

Heat to

Know Your ermostat

44129-01 • 07/23/2012

Setting Day and Time

Once you install the batteries, the thermostat will prompt you to set the

current day and time.

1. You will notice that “Mon” will be ashing at the top left of your

screen. Use the or buttons to move to your current day of the

week and press the Next button to advance to the next step.

2. Use the or button to change between am(A) and pm(P). Choose

Next to advance.

3. Next you will select your current hour by using the or buttons.

The Next button advances you to the next step.

4. Set your minutes using the or and press Done/

Home to nish or Back if

you need to make a correction to a previous step.

5. When nished, the thermostat will show “Updated!” to conrm your

settings are saved.

6. Your thermostat will next prompt you to set your programming, see

page 14 step 2 if you wish to alter your programs at this time.
