Huawei EG8147X6 Manuel de programmation

1 | P a g e

Huawei GPON

(EG8147X6)

Troubleshooting

Manual

Provided by: NAYAtel Access

2 | P a g e

Huawei GPON (with internal router - Wi-Fi 6) Model – EG8147X6

Huawei EG8147X6 is an Optical Network Terminal (ONT) that operates on

GPON technology. This device features

•4-Gigabit Ethernet Ports

•1-POTS Port

•1-RF Video Port

•1-USB Port

•2.4G and 5G Wi-Fi 6 connectivity

3 | P a g e

Back side ports’ sequence on Huawei GPON (EG8147X6) ONT

TEL Port

Telephone Port

LAN 1 - LAN 4

Gigabit Ethernet Ports

USB

USB Port

Power

Input Power Port

ON/OFF

Power ON/OFF Button

CATV

RF TV-Port

4 | P a g e

Light

Status

Indication

Power

Always On

The device is powered on

Off

Power supply is cut off

WLAN

Always On

WLAN function is enabled

Blinks

Data is being transmitted on WLAN port

PON

Always On

In case of any other status, contact NAYAtel Support

LOS

Always Off

LAN1-LAN4

Green Stable

Ethernet connection established

Green Blinking

Data getting transmitted

TEL

Off

Telephone number not configured

Green Stable

Number configured

Green Blinking

Call in progress

5 | P a g e

Configuring Wi-Fi on ONT device

Connect your computer, phone or laptop to any LAN port on your ONT device using an Ethernet

cable or to Wi-Fi network of Huawei ONT. Access ONT web interface by entering the following

IP address on browser.

192.168.18.1

Username: Epuser

Password: userEp

You can enter the password written on the back of device.

Step 1

Go to Advanced>WLAN>WLAN 2.4G Basic Network Settings and set the SSID (Network name).

Enable the SSID by checking the box. Similarly set the SSID for 5G network as well.

6 | P a g e

7 | P a g e

Step 2:

Set the Authentication mode to WPA/WPA2 PreSharedKey and Encryption mode to AES. Set the

Wi-Fi security key (WPA PreSharedKey). Password should be 8 to 63 characters. Repeat the

same process for 5G network settings.

8 | P a g e

9 | P a g e

Step 3:

After setting SSID (network name) and password, click on apply button at the end of setting to

apply and save the changes.

Step 4:

Go to 2.4G Advanced Network Settings. Change the regulatory domain to “Pakistan”, channel to

“Automatic” setting and channel width to “20MHz”. Click on apply button to save the changes.

10 | P a g e
