Huawei D105 Manuel utilisateur

Wonderful Communication, Mobile Life.

Welcome to HUAWEI D105 Wi-Fi/LAN Adapter

HUAWEI D105 Wi-Fi/LAN Adapter

User Guide

This page is left in blank for note or memo use!

rights reserved.

No part of this document may be reproduced or transmit-ted

in any form or by any means without prior written consent of

Huawei Technologies Co., Ltd.

The product described in this manual may include

copy-righted software of Huawei Technologies Co., Ltd and

possible licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble,

decrypt, extract, reverse engineer, lease, assign, or

sub-license the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by

respective copyright holders under licenses.

Trademarks and Permissions

HUAWEI, and are trademarks or registered trademarks

of Huawei Technologies Co., Ltd.

Other trademarks, product, service and company names

mentioned are the property of their respective owners.

Notice

Some features of the product and its accessories described

herein rely on the software installed, capacities and settings

of local network, and may not be activated or may be limited

by local network operators or network service providers, thus

the descriptions herein may not exactly match the product or

its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or

modify any information or specifications contained in this

manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT

AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY

KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED

TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND

FITNESS FOR APARTICULAR PURPOSE, ARE MADE IN RELATION

TO THEACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO

CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR

ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL

DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA,

GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import

laws and regulations and will obtain all necessary

governmental permits and licenses in order to export,

re-export or import the product mentioned in this manual

including the software and technical data therein.

Notice

Read the safety precautions carefully to ensure the

correct and safe use of your wireless device.

Do not switch on your device when the

device use is prohibited or when the device

use may cause interference or danger.

Do not use your device while driving.

Follow the rules or regulations in hospitals

and health care facilities. Switch off your

device near medical apparatus.

Switch off your device in an aircraft. The

device may cause interference to control

signals of the aircraft.

Switch off your device near high-precision

electronic devices. The device may affect

the performance of these devices.

Do not attempt to disassemble your device

or its accessories. Only qualified personnel

are allowed to service or repair the device.

Do not place your device or its accessories

in containers with strong electromagnetic

field.

Do not place magnetic storage media near

your device. Radiation from the device may

erase the information stored on them.

Do not put your device in a

high-temperature place or use it in a place

with flammable gas such as a gas station.

Keep your device and its accessories away

from children. Do not allow children to use

your device without guidance.

Use approved accessories only to avoid

explosion.

Observe the laws or regulations on device

use. Respect others’ privacy and legal

rights when using your device.

Safety Precautions

Quick Start 1

Appearance………………………………………………..1

PC Configuration Requirements……………………….. 1

Installation………………………………………………….2

Dial-up Access……………………………………………. 3

Restoring the Factory Defaults…………………………..4

Using the Management Page 5

Management Page Overview…………………………….5

Viewing Status Info………………………………………..5

Configuring Your Computer 7

Wireless Configuration……………………………………7

Configuring the PC Network……………………………...8

Basic Settings 9

Network Settings…………………………………………..9

Internet Settings………………………………………….10

Wireless Settings 12

Basic Settings…………………………………………….12

Security Settings…………………………………………14

Advanced Settings……………………………………….16

Security & NAT 18

Firewall Settings………………………………………….18

MAC/IP/Port Filtering……………………………………18

Port Forwarding………………………………………….18

DMZ……………………………………………………….19

Administration 20

Management……………………………………………..20

Log………………………………………………………..20

System……………………………………………………21

Advance 22

Advanced Routing……………………………………….22

UPnP……………………………………………………...22

Troubleshooting 23

Abbreviations 25

Warnings and Precautions 26

Table of Contents

The supported functions and actual appearance

are subject to your product purchased. The

following pictures are displayed for illustration

purpose only. For details of your product selection,

consult your service provider.

Appearance

Indicator

Status

Power

Steady on and in red: The device is switched

on successfully.

Indicator

Status

LAN

Powered device connected to the

associated port and the Ethernet interface

is ready to work.

Blinking in yellow green: Data is being

transmitted.

WLAN

Steady on and in yellow green: The WLAN

is enabled.

Blinking in yellow green: Data is being

transmitted.

USB

Steady on and in yellow green: The USB

interface is ready to work.

PC Configuration Requirements

The recommended PC configurations for using the device

are as follows:

CPU: Pentium 500 MHz or above

Memory: 128 MB RAM or above

Hard disk: 100 MB or above available space

Operating System: Windows 2000, Windows XP,

Windows Vista or Windows 7

LCD resolution: 800*600 pixel or above, recommended

1024*768 pixel

Quick Start

Note

USB Interface

Power On/Off

Power Interface

Ethernet Interface

Power Indicator

WLAN Indicator

LAN Indicator

USB Indicator

Interface: standard USB interface

Internet Browser: Internet Explorer 6.0 or Internet

Explorer 7.0, Firefox 1.5 or Firefox 2.0, Safari 3.0

Installation

Step 1: Connect with the data card through

the USB interface.

Use the specified data card to connect with the

device.

Step 2: Connect to a PC through an Ethernet

cable or WLAN.

If the indicator of the Ethernet interface connecting with

a network cable is on, the PC lineate connection is

successful. The Ethernet cable cannot be longer than

100 meters (328 feet). To achieve better effect, use the

shielded cable.

Whether the PC wireless connection is successful,

please check your PC connected through WLAN. For

details, please see “Configuring Your Computer”.

If connect your device to one PC with the Ethernet cable

and other PCs with WLAN simultaneously, you have

constructed a LAN and can share the local resources.

Step 3: Connect to the power adapter.

Use a power adapter that is compatible with

the device; otherwise, the device may be

damaged.

Please use the AC/DC power supply

defined in the specifications of the charger.

An improper power voltage can cause fire

or malfunction of the charger.

Note

WLAN

Power Adapter

Step 4: Place the device.

To prevent electrical devices from being

interfered by wireless signals, place

electrical devices one meter away from the

device.

Do not put the data card in the slot and

please turn the USB interface connected

with the data card upright when the device

is running.

The device can be placed horizontally or vertically on a

table. Place the device on a higher place or near the

window, so it can receive stronger signals.

Step 5: Power On/Off.

Press the Power key to switch on the device; press and

hold the Power key to switch off the device.

Dial-up Access

By default, the device dials up to access the Internet as

required. You can directly use the network services such

as web browsing, and receiving or sending emails.

Make sure that the data card is connected to the

device, or else you cannot use the Internet service

and some management pages are unavailable.

Logging In to the Management Page

Start the Internet browser and enter the address

http://192.168.1.1 in the address bar.

Enter the Account and Password, and then click Apply.

The default value is admin.

To avoid the configuration conflict, only one user is

allowed to log in to the management page at a

time.

Note

Accessing the Internet

Click Basic Settings >Internet Settings,

choose 3.5G Client.

If you are required to enter the PIN code, enter the

correct one. If you fail to enter the correct PIN or

PUK code, the network-related functions are

unavailable.

The SIM card is supplied by the service provider.

For details, contact your service provider.

When the Save PIN Code check box is selected,

the Auto validation is enabled.

If Auto validation is enabled, the PIN code is

recorded and automatically validated after each

restart.

If PPP Connection is Manual, click Connect/

Disconnect to connect to or disconnect from the

network.

If PPP Connection is Auto or On Demand, refresh

the page to view the current network connection

status.

Wait for several minutes. If you are notified that

the connection is successful, you can start the

browser and enter the website address to access

the Internet.

Restoring the Factory Defaults

If you need to reconstruct the network or you forget the

changes of some parameters, you can choose to restore

factory defaults and reconfigure the device.

Reset: Press and hold

it for 2 seconds to

restore the factory

defaults.

Note: After this

operation, all

configurations are

restored to the defaults.

Note

Reset

Table des matières

Autres manuels Huawei Modem

Huawei

Huawei EC325 Manuel utilisateur

Huawei

Huawei E3372 Manuel d'instructions

Huawei

Huawei Mobile Broadband USB Stick Manuel utilisateur

Huawei

Huawei GL08D Manuel utilisateur

Huawei

Huawei E270 Mode d’emploi

Huawei

Huawei E220 Manuel utilisateur

Huawei

Huawei E8278 Manuel utilisateur

Huawei

Huawei B932 series Manuel utilisateur

Huawei

Huawei SmartAX MT883 Manuel utilisateur

Huawei

Huawei Maxis E5832 Manuel utilisateur

Huawei

Huawei E600 Manuel utilisateur

Huawei

Huawei E510 Manuel utilisateur

Huawei

Huawei E181 HSPA Manuel utilisateur

Huawei

Huawei E3372 Manuel utilisateur

Huawei

Huawei B315s Manuel utilisateur

Huawei

Huawei E587 Caractéristiques techniques

Huawei

Huawei EC167 Manuel utilisateur

Huawei

Huawei E160G Manuel utilisateur

Huawei

Huawei Maxis E5832 Manuel utilisateur

Huawei

Huawei E1556 Manuel utilisateur

Huawei

Huawei EchoLife HG612 Manuel utilisateur

Huawei

Huawei HiLink E3131 Caractéristiques techniques

Huawei

Huawei K4505 Manuel utilisateur

Huawei

Huawei EC1261 Instructions de montage

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
