HTC Amadeus Manuel utilisateur

HTC CONFIDENTIAL

HTC confidential

Service Manual

for Amadeus

HTC Proprietary

Confidential Treatment Requested

Rev. A01

Nov 03, 2004

HTC Corp.

Engineering Mobility

HTC CONFIDENTIAL

HTC confidential

TITLE: Service Manual for Amadeus

REV.

NO. DATE CONTENTS DEP. REVISED

APP

’

D STGE.PER.

A01 11/03 First reversion TSC

HTC CONFIDENTIAL

HTC confidential

Table of contents

Chapter 1 - Introduction 5

1.1History

Chapter 2 - Product Specifications 6

Chapter 3 -ServicingTools 8

Chapter 4 - Assembling and Disassembling 9

4.1Disassembling

4.2Assembling 17

4.3MBPre-Assembling 23

4.4LCDPre-Assembling 25

Chapter 5 - Diagnostic Programs 26

5.1ListofTestItems(DiagnosticsinSDcard)

5.2 Test Procedure

5.3 Test Procedure and Description

Chapter 6 - Leakage current Measurement on MB 30

6.1 Leakage current measurement with Fixture

6.2 Battery Capacity Test

Chapter 7 - Software Upgrade procedure 36

7.1 Software upgrade 36

7.2 Smartphone Reset 42

7.4SoftwareBackuptoSDcard 43

Chapter 8 - RF Antenna test spec and criteria 44

8.1 Antenna Test Specification

8.2 Antenna Test Criteria

HTC CONFIDENTIAL

HTC confidential

Chapter 9 -InspectionCriteria 47

9.1Definition

9.2InspectionArea

9.3Criteria

Chapter 10 - Trouble Shooting 48

Chapter 11 - Labeling Plan 55

Chapter 12 -Sparepartslist 57

12.1 Spare parts list for repair

12.2AccessorySparepartslist

12.3Boardlevelpartslist

Chapter 13 -BoardLevelRepair 59

13.1 Problem Identification &Troubleshooting

13.2 Components to be Replaced

HTC CONFIDENTIAL

HTC confidential

Chapter 1 – Introduction

This manual provides the technical information to support the service activities of Amadeus. It

contains highly confidential information, so any or all of this document should not be revealed to

any third party.

1.1 History

Reversion Update item Pages effected

A01 First release N/A

HTC CONFIDENTIAL

HTC confidential

Chapter 2 - Product Specifications

Function Specification

Platform  Microsoft Smart Phone 2003

Dimensions  107.76 (L) x 46.83 (W) x 19.58 (T) mm

Weight  106.5g with battery

CPU  TI OMAP 730 tri-band GSM/GPRS solution

Memory  SDRAM：32MB

 Flash ROM：64MB

GSM Function  Tri-band 900/1800/1900

 GPRS, Class B

 Multi-slot class 10

Display  2.2 inch, 176x220 dots resolution

 64K colors TFT Transflective LCD

 Dot Pitch：66um x 198 um

 LED back Light

Keyboard/Button  One Power Button (On the Top)

 One Numeric Dialing Keypad(12 buttons)

 Two soft key button

 One Home/connection quick list button

 One Back button

 Send/Phone button

 End Phone button

 One 5- way navigation keypad

 One Camera Capture button

 Volume up button (Long Press as voice record)

 Volume down button(long press as Voice command/Dial.

Interface  3.0 V SIM Card.

 One mini-USB connector (Slave USB, Power IN)

 One Infrared IrDA SIR.

 One Mini SD memory card slot

 One external antenna connector.

 Earphone/microphone jack with stereo sound,2.5diameter

Power  Rechargeable battery, Li-Ion 1050 mAH

 Talk：3.5 ~ 4 hours

 Standby：140 hours

 AC Adapter:

- AC input rating：100 ~ 240 VAC, 50/60 HZ

- DC Output rating: 5VDC,1A

 Ambient Light Sensor for LED power consumption

Device to device

connectivity  Bluetooth

 Infrared IrDA SIR

 USB mini-B plug and receptacle

CMOS Camera  Color

 Resolution: VGA

 Min. 5 Lux

 Preview Mirror

HTC CONFIDENTIAL

HTC confidential

Notification  One Bi-color LED (Green and Red) for GSM STANDBY, GSM standby,

GSM network status, Event Notification, Power charging status.

 One Blue LED for Bluetooth connectivity status.

 Vibration for notification and Incoming call.

 Notification by LED, Sound, Message, Vibration Motor.

Accessories  Bundle:

 AC adapter w/ DC_In via mini USB plug

 USB Sync cable

 Stereo wired headset with Microphone

 Standard Battery

 User Manual, Quick Start Guide, Sync. Software CD

 Option

 Car Adapter

 Traveler Charger with back up battery charging slot

 Car kit with Car Stereo Mute function

 Carrying case

HTC CONFIDENTIAL

HTC confidential

Chapter 3 - Servicing Tools

This chapter provides information for the servicing tools for Amadeus.

List of Servicing Tools

No. Item Use Remark

1 Disassembly tools Plastic stick for dismantle the unit

Cleaning wipers

Philips Screw driver

Protective Film

Tweezers

Air Gun

Clean Bench (Mandatory)

2 Mini USB cable For Synchronization Test

3 Mini SD Memory Card For SD card test

4 Headset For Hand free / Recording test

5 AC Adapter Power supply to Amadeus

6 Diagnostic Test Program Test Program for Functional Test

7 Software Upgrade tools For software version upgrade or re-flash

8 Label Printer & Scanner For Printing & Scanning regulation label when

housing or M/B is changed.

9 Battery Test Jig For Main Battery judgement.

HTC CONFIDENTIAL

HTC confidential

Chapter 4 - Assembling and Disassembling

4.1 Disassembling

Tools needed for Assembling and Disassembling

the Smart Phone

1. Glove & Lens Cleaning Tissue.

2. Plastic type tweezer.

3. Philip Screw Driver #0.

4. Philip Screw Driver type T5

5. Special Made Plastic Stick

Front side

Remove antenna rubber, battery cover, battery

from unit

Release the antenna radiator by insert in the

plastic stick into the gap between antenna and

frame (housing)

HTC CONFIDENTIAL

HTC confidential

The same method applied to the left side

Release the antenna

Unfasten 6 screws located on the back side

Insert in plastic stick into the gap between

upper cover and housing to release three

hooks which fix them.
