HTC S720 Manuel utilisateur

Smart

Quick Start Guide

Contents

1. What’s in the Box? ...................................................................................................3

2. Your Phone at a Glance ...........................................................................................4

3. Setting up your Phone ............................................................................................9

4. Setting up an E-mail Account ...............................................................................12

5. Personalizing your Phone .....................................................................................13

6. Browsing the Web ..................................................................................................15

7. Using the Camera ..................................................................................................16

8. Using Pictures & Videos ........................................................................................17

9. Protecting your Phone ..........................................................................................18

10. Knowing Status Indicators ....................................................................................20

11. Learn More .............................................................................................................22

1. What’s in the Box?

Getting

Started Disc

Smartphone

User Manual and

Quick Start Guide

Battery

Mini-USB

Stereo Headset

USB Sync Cable

Splitter

Adapter

AC Adapter

Pouch

2. Your Phone at a Glance

Item Function

1. Speaker Listen to phone call.

Light Sensor

Sense dark conditions and activate a backlight under the keypad and the QWERTY keyboard

automatically, glowing in dark.

Display Screen The display screen shows important information, such as upcoming appointments, number of new

messages, and your tasks.

NAVIGATION

CONTROL/ENTER Use to scroll left, right, up, or down. Press the center to use as the ENTER button.

5. Left SOFT KEY Press to perform the command shown in the label above the button.

6. HOME Press to go to the Home screen or press and hold to open Comm Manager.

7. TALK

Press to dial a phone number or answer a call. Press and hold to activate/deactivate speakerphone

mode

8. Key Press to change input modes or press and hold to choose an input mode or symbols from the list.

9. Key Press to add a space or press and hold to display a list of symbols.

10. END Press to end a call, or press and hold to lock the phone keypad and the keyboard.

11. BACK Press to go back to the previous screen, or backspace over characters.

12.

Right

SOFT KEY Press to perform the command shown in the label above the button.

13. Keyboard Slide out to reveal, while slide in to hide the QWERTY keyboard with 36 keys and two soft keys.

14. LED Indicators The LED indicators notify you of the battery, network, and connectivity status of your phone. For

more information, see the table at the end of this section.

25 26

21 23

Item Function

15. POWER

Press and hold (about 3 seconds) to turn the phone on and off. Or press and quickly release

the POWER button to display the Quick List, which allows you to change profiles, open

Comm Manager, and enable/disable key lock and enable/disable device lock.

16. Volume Adjustment

Slider

Slide this up or down to increase or decrease the earpiece volume during a call. Drag and

hold the slider down to launch Voice Speed Dial and record voice tags.

17. microSD Slot Insert a microSD memory card for storing data.

18. Speaker Listen to audio media or phone call when using speakerphone mode.

19. Self-Portrait Mirror Turn the back side of your phone to face yourself so that your image reflects on the mirror

when taking self-portrait shots.

20. Back Cover Remove to insert or replace battery.

21. Car Antenna Connector Connect your phone to the car antenna while in a car to have better reception quality.

22. Camera Lens

23. CAMERA Press to open the Camera program. If already running, press to capture an image or start

recording a video clip.

24. Microphone Speak into the microphone when receiving or making a phone call or during voice recording.

25. Battery Cover Latch Slide this latch to release the battery cover.

26. Strap Holder Attach a strap for carrying your device.

27.

Sync Connector/

Earphone Jack

Use for synchronizing data, recharging the battery, connecting the earphone to listen to

audio media, or connecting the phone’s hands-free kit.

LED indicator lights

Various colours that might display in the two LED Indicators are summarized here.

Left LED Status

Solid Green Battery is fully charged.

Blank Battery case is empty or the phone is off.

Solid Amber Battery is charging or the phone is using ActiveSync to synchronize with a PC.

Solid Red Battery is not installed while the phone is charging/synchronizing or battery is over-

discharged.

Flashing Green Phone is connected to the network.

Flashing Red

Battery very low (less than 10%) or battery fault. Check if the battery is properly installed

and its exposed copper part is properly aligned with the protruding copper conductor of

the phone body.

Right LED Status

Flashing Blue Bluetooth mode set to On or Visible mode.

3. Setting up your Phone

With the following simple steps, you can easily set up and start using your phone.

1 Install and charge the battery

New batteries are shipped partially charged. Before you start using your phone, it is recommended that

you install and charge the battery.

To install the battery

1. Slide the battery cover latch to release the back cover.

2. Insert the battery by aligning the exposed copper

part of the battery pack with the protruding copper

conductor.

3. Gently push the battery into place.

4. Replace the back cover.

To charge the battery

Some batteries perform best after several full charge/discharge cycles. You can charge the battery in

one of the following ways:

• Connect your phone directly to an electrical outlet using the AC adapter.

• Connect your phone to the USB port on your PC using the USB sync cable.

Charging is indicated by a solid Amber light on the LED indicator. A charging icon ( ) also appears on

the display screen. After the battery has been fully charged, the LED indicator becomes Green.

Slide the battery cover latch

to open the back cover.

2 Install the microSD card

You can install a microSD (Secure Digital) card on your phone to have an alternative storage place for

your images, video, music, and other phone data.

• Slide in the microSD card into the slot with its gold

contacts facing up and gently push until it clicks

securely in place.

To remove, press the microSD card brieﬂy inward and

release it to pop out of the slot.

3 Turn on your phone

Press and hold the POWER button to turn on the phone.

4 Install and Set Up ActiveSync or Windows Mobile Device Center

To synchronize your phone with a PC running Windows XP or earlier version of Windows, ActiveSync is the

choice. ActiveSync synchronizes information between your phone and your PC, keeping information up-

to-date on your phone as well as on the PC. Before you connect your phone to your PC, you must install

ActiveSync on the PC. ActiveSync is already installed on your phone.

1. Insert the Getting Started Disc into the CD drive of your PC.

2. Follow the instructions on the installation wizard screen to install ActiveSync.

3. Connect the USB cable to the phone and plug it into the USB port of your PC.

Turn on your phone. When the PC detects a USB connection, it starts the Synchronization Setup

Wizard. Follow the instructions on the screen and select the items you want to synchronize.
