HP Pro Tablet 610 Manuel

HP Pro Tablet 610 and HP Omni10

Maintenance and Service Guide

IMPORTANT! This document is intended for

HP authorized service providers only.

Development Company, L.P.

Bluetooth is a trademark owned by its

proprietor and used by Hewlett-Packard

Company under license. Intel and Core are

U.S. registered trademarks of Intel

Corporation. Microsoft and Windows are

U.S. registered trademarks of Microsoft

Corporation. SD Logo is a trademark of its

proprietor.

The information contained herein is subject

to change without notice. The only

warranties for HP products and services are

set forth in the express warranty statements

accompanying such products and services.

Nothing herein should be construed as

constituting an additional warranty. HP shall

not be liable for technical or editorial errors

or omissions contained herein.

Second Edition: April 2014

First Edition: October 2013

Document Part Number: 737637-002

Product notice

This guide describes features that are

common to most models. Some features may

not be available on your tablet.

Not all features are available in all editions

of Windows 8. This tablet may require

upgraded and/or separately purchased

hardware, drivers, and/or software to take

full advantage of Windows 8 functionality.

See for http://www.microsoft.com details.

Software terms

By installing, copying, downloading, or

otherwise using any software product

preinstalled on this tablet, you agree to be

bound by the terms of the HP End User

License Agreement (EULA). If you do not

accept these license terms, your sole remedy

is to return the entire unused product

(hardware and software) within 14 days for

a refund subject to the refund policy of your

place of purchase.

For any further information or to request a

full refund of the tablet, please contact your

local point of sale (the seller).

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not

place the device directly on your lap or obstruct the device air vents. Use the device only on a hard, flat

surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface,

such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact

the skin or a soft surface, such as pillows or rugs or clothing, during operation. The device and the AC

adapter comply with the user-accessible surface temperature limits defined by the International

Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Product description ........................................................................................................... 1

2 External component identification ..................................................................................... 4

Finding your hardware and software information ......................................................................... 4

Locating hardware .................................................................................................... 4

Locating software ....................................................................................... 4

Front ....................................................................................................................................... 5

Back ....................................................................................................................................... 6

Top edge ................................................................................................................................ 7

Back edge ............................................................................................................................... 8

Labels ..................................................................................................................................... 9

3 Illustrated parts catalog .................................................................................................. 10

Locating the serial number, product number, and model number .................................................. 10

Tablet major components ........................................................................................................ 11

Miscellaneous parts ................................................................................................................ 13

Sequential part number listing .................................................................................................. 14

4 Removal and replacement preliminary requirements ...................................................... 16

Tools required ....................................................................................................................... 16

Service considerations ............................................................................................................ 16

Plastic parts ............................................................................................................ 16

Cables and connectors ............................................................................................ 16

Grounding guidelines ............................................................................................................. 17

Electrostatic discharge damage ................................................................................. 17

Packaging and transporting guidelines ....................................................... 18

Workstation guidelines .............................................................. 18

5 Removal and replacement procedures ............................................................................ 20

Back cover ............................................................................................................................ 20

Power button board ................................................................................................................ 22

Volume button board .............................................................................................................. 23

Front-facing webcamera ......................................................................................................... 25

Light sensor board .................................................................................................................. 27

Rear-facing webcamera .......................................................................................................... 28

Audio board ......................................................................................................................... 30

Vibrator module ..................................................................................................................... 32

Battery .................................................................................................................................. 33

Wireless antennas .................................................................................................................. 35

SIM/card reader board .......................................................................................................... 37

Speakers ............................................................................................................................... 38

Display panel cable ............................................................................................................... 40

System board ........................................................................................................................ 42

6 Using Setup Utility (BIOS) ................................................................................................ 46

Starting Setup Utility (BIOS) ..................................................................................................... 46

Updating the BIOS ................................................................................................................. 46

Determining the BIOS version ................................................................................... 47

Downloading a BIOS update .................................................................................... 47

7 Specifications .................................................................................................................. 49

8 Backing up, restoring, and recovering ............................................................................ 50

Creating a Microsoft recovery drive (select models only) ............................................................. 50

Using Windows Refresh for quick and easy recovery .................................................................. 51

Removing everything and reinstalling Windows ......................................................................... 51

Backing up data using File History ........................................................................................... 52

9 Power cord set requirements .......................................................................................... 53

Requirements for all countries .................................................................................................. 53

Requirements for specific countries and regions ......................................................................... 53

10 Recycling ...................................................................................................................... 55

Index ................................................................................................................................. 56

1 Product description

Category Description HP Pro Tablet 610 HP Omni10

Product Name HP Pro Tablet 610 ×

HP Omni10 ×

Processor Intel Quad Core Z3795 1.60-GHz (turbo

up to 2.39-GHz) processor

Intel Quad Core Z3775 1.46-GHz (turbo

up to 2.39-GHz) processor

Intel Quad Core Z3770 1.46-GHz (turbo

up to 2.40-GHz) processor

Panel 10.1-in, AntiGlare (AG), light-emitting

display (LED), WUXGA (1920×1200) ,

multitouch, capacitive, Gorilla glass 3

TouchScreen (with antismudge and air-

bonding, Windows 8

compliant); .ultraslim; 16:10 aspect ratio,

typical brightness: 400 nits; 18-bit color

depth with FRC; ≥80/80/80/80

viewing angle; UWVA Dual-link eDP

interface

××

Graphics Intel Graphics Media Accelerator

Support for HD playback, streaming, and

recording at 1080p at 30fps

Support for DX11

××

Memory Support for 2048-MB (1024-MB × 2), 8-

GB at 1600-MHz LPDDR3 128M × 32 ×

2 memory IC

××

Mass storage Support for embedded MultiMediaCard

(eMMC) NAND flash (v4.51)

Support for 64- or 32-GB eMMC mass

storage memory

××

Category Description HP Pro Tablet 610 HP Omni10

Audio and video One digital microphone

Stereo speakers

2.0-MP front-facing webcamera

with webcamera activity light

8.0-MP rear-facing webcamera with auto-

focus

××

Sensors ●Ambient light sensor

●Accelerometer

●eCompass

●Gyro

●Hall-effect sensor

××

Wireless networking Integrated wireless option: Mitsumi

DWM-W095A WiFi+BT 4.0 combination

module with 2 antenna

Bluetooth: Class 1 Bluetooth 4.0+LE

Wifi: 802.11a/b/g/n 2×2 multiple-

input and multiple-output (MIMO)

××

External expansion Integrated micro SD card, support SDXC

in DDR50, SDR25 and SDR12 mode

××

Ports ●Audio: 3.5-mm headphone/

microphone combo jack, support

NA type headset only

●HDMI type-D connector

●Power connector

●Micro USB 2.0 type AB connector

(support for host mode only)

××

Keys ●Power

●Volume down

●Volume up

××

Power requirements Support for 2-cell, 3.10-WHr, 4.19-AHr,

Li-ion battery (non-removable)

Support for 18-W (12-V/1.5-A) non-PFC

AC adapter with DC plug and localized

cable plug support

××

Security Software-based Trusted Platform Module

(TPM) solution

××

2 Chapter 1 Product description

Category Description HP Pro Tablet 610 HP Omni10

Operating system Preinstalled: Microsoft Windows 8.1

(32-bit)

××

Serviceability End user replaceable part: AC

adapter

××

2 External component identification

Finding your hardware and software information

Locating hardware

To find out what hardware is installed on the tablet:

1. On the Start screen, type control panel, and then select Control Panel.

2. Select System and Security, and then in the System area, tap Device Manager. A list

displays all the devices installed on the tablet.

Locating software

To find out what software is installed on the tablet:

▲Swipe from the left until the arrow appears, and then tap the arrow in the lower-left corner of

the screen.

– or –

Swipe up from the bottom to display the Apps screen.

4 Chapter 2 External component identification
