HP J3102A Manuel utilisateur

HP AdvanceStack Switch

Ethernet Module

Installation Guide

HP J3102A

HP Customer Support Services

How to get the latest software

You can download a compressed file ( j3100a.exe) containing the latest

version of the HP Switch 2000 software, proprietary MIB, and a software

download utility file (update.exe) from the HP BBS, HP FTP Library Service,

CompuServe, and the World Wide Web. After you download the file, extract

the file by typing

filename

/x and pressing [Enter].For example: j3100a.exe /x

[Enter].

HP BBS

Set your modem to N-8-1, set speed up to 14400 bps, and with your

telecommunication program (e.g., Windows Terminal) dial (208) 344-1691 to

get the latest software for your HP networking product.

HP FTP Library Service

1) FTP to Internet IP Address ftp ftp.hp.com

2) Log in as anonymous and press [Enter] at the password prompt.

3) Enter bin to set the transfer type to binary.

4) Enter cd /pub/networking/software

5) Enter get

filename

to transfer the file to your computer, then quit.

CompuServe

1) Login to CompuServe.

2) Go to the “hp” service.

3) Select “HP Systems, Disks, Tapes, etc”.

4) Select “Networking Products” library.

5) Download the compressed file named J3100.exe, and then quit.

World Wide Web

http://www.hp.com/go/network_city

Select the Support section, then ‘‘Software Downloads and Patches’’.

Download the file you need and extract it by typing:

filename

Do you have questions about designing your expanding network? From this

web site, you can also download the Designing HP AdvanceStack

Workgroup Networks Guide which addresses capacity planning, or dial

1-800-752-0900 to receive a copy through the mail.

(over for more services)

Perforate

Obtain the latest console code (j3100a.exe) from:

HP FTP Library: ftp ftp.hp.com

World Wide Web: http://www.hp.com/go/network_city

HP BBS: (208) 344-1691

(over)

HP FIRST Fax Retrieval Service

HP FIRST is an automated fax retrieval service that is available 24 hours a

day, seven days a week. HP FIRST provides information on the following

topics:

Product information

Troubleshooting instructions

Technical reviews and articles

Configuration information

To access HP FIRST, dial one of the following phone numbers:

Location Phone Number

U.S. and Canada Only Dial 1 (800) 333-1917 with

your fax machine or

touch-tone phone and

press 1.

Outside the U.S. and

Canada Dial 1 (208) 344-4809 from

your fax machine and

press 9.

To receive a list of currently available documents, enter document number

19941. The information you requested will be sent to you by return fax.

Additional HP Support Services

In addition to the above services, you can purchase various HP telephone

support services which provide you expert HP technical assistance:

Network Phone-In Support provides you support at an hourly rate. In the

USA, call 1-800-790-5544. In other countries, please contact your local HP

Response Center to see if this service is available in your country.

HP SupportPack Comprehensive Network Support provides complete

problem resolution for medium to large interconnected local and wide

area networks. Contact your HP Authorized Reseller or the nearest HP

Sales and Support Office for more information.

CompuServe: Go to the hp service

Select HP Systems, etc

Select Networking Products

Download the file named J3100.exe

Network Phone-In

Support (Hourly): 1-800-790-5544

HPAdvanceStackSwitch

EthernetModule

Installation Guide

Reproduction, adaptation, or translation without

prior written permission is prohibited, except as

allowed under the copyright laws.

The information contained in this document is

subject to change without notice.

HEWLETT-PACKARD COMPANY MAKES NO

WARRANTY OF ANY KIND WITH REGARD

TO THIS MATERIAL, INCLUDING, BUT NOT

LIMITED TO, THE IMPLIED WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR

A PARTICULAR PURPOSE. Hewlett-Packard

shall not be liable for errors contained herein

or for incidental or consequential damages in

connection with the furnishing, performance,

or use of this material.

Hewlett-Packard assumes no responsibility for

the use or reliability of its software on equipment

that is not furnished by Hewlett-Packard.

See the warranty card included with the product.

A copy of the specific warranty terms applicable

to your Hewlett-Packard product and

replacement parts can be obtained from your

HP sales and service office or HP-authorized

reseller.

Publication Number

5966-5118

Edition 1

September 1996

Applicable Product

HP J3102A

Hewlett-Packard Company

8000 Foothills Boulevard, m/s 5551

Roseville, California 95747-5551

http: //www.hp.com/go/network_city

HP AdvanceStack Switch

Ethernet Module

For the HP AdvanceStack Switch 2000

At A Glance

The HP AdvanceStack Switch Ethernet Module (HP J3102A) is an optional

component that you can add to an HP AdvanceStack Switch 2000 to provide

either of the following:

Four 10Base-T ports

Three 10Base-T ports and one (optional) 802.3-compatible trans-

ceiver port for other media types (such as ThinLAN, or fiber-optic)

For information on transceiver types and availability, contact your

Hewlett-Packard networking representative.

Features: The HP AdvanceStack Switch Ethernet Module can en-

hance your Switch 2000 in the following ways:

You can use the module to connect different 802.3 media types to

your Switch 2000.

You can add, change, or remove a module without shutting down the

entire switch.

You can install up to six Ethernet modules in your Switch 2000,

enabling you to ‘‘fully load’’ the switch with up to 24

Ethernet/IEEE 802.3 ports.

10Base-T Ports

Connector

Extractor Handle

Cover Plate Over Slot for

Optional Transceiver

Figure 1. The HP AdvanceStack Switch Ethernet Module

iii

Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Installing a Module in an Unused Slot . . . . . . . . . . . . . . . . 2

Customizing the Port Configuration . . . . . . . . . . . . . . . . . 8

Rebooting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . 9

Removing or Replacing a Module . . . . . . . . . . . . . . . . . . 10

Adding, Replacing, or Removing a Transceiver . . . . . . . . . . . 12

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Customer Support Services . . . . . . . . . . . . . . . . . . . . . . . 14

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Electromagnetic . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Overview

Note Before you install the HP AdvanceStack Switch Ethernet Module into

the Switch 2000, you may want to install an optional HP

802.3-compatible transceiver in the transceiver slot in the module.

(Refer to the instructions you received with the transceiver.)

If a transceiver is installed, it replaces the first 10Base-T port as port 1,

as long as no active network is connected to the built-in RJ-45 port 1. If

the Switch 2000 detects the link beat signal on the built-in RJ-45 port 1, it

automatically selects that connector to use for port 1.

You can install an Ethernet Module into the Switch 2000 in any one of the six

module slots, as follows:

1. Insert the Ethernet Module in a Switch 2000 slot (page 2).

2. Customize the configuration for the module ports (unless the default

port configuration is satisfactory for your network application - see

page 8).

3. Reboot the switch (page 9).

Other, optional procedures include:

Hot-Swapping one module for another; that is, replacing one module

with another without turning off power to the switch (page 10)

Using the hot-swap process to install a transceiver into a module

that has already been installed in the switch (page 12)

Installation
