Release Notes

hp StorageWorks

Edge Switch

Product Version: FW V05.02.00-13

HAFM Notebook SW V07.01.00-09

HAFM 1U Appliance SW V07.02.00-09

Fourth Edition (December 2003)

Part Number: AA–RTDZD–TE/958–000284–004

These Release Notes contain late-breaking and supplemental information for the

HP StorageWorks Edge Switch 2/24 and Edge Switch 2/32.

For the latest version of these Release Notes and other edge switch documentation, access the

HP storage website at:

http://www.hp.com/country/us/eng/prodserv/storage.html

2Edge Switch Release Notes

Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited

to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be

liable for errors contained herein or for incidental or consequential damages in connection with the furnishing,

performance, or use of this material.

This document contains proprietary information, which is protected by copyright. No part of this document may be

photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.

The information contained in this document is subject to change without notice.

Microsoft®, Windows®, and Windows 2000® are U.S. registered trademarks of Microsoft Corporation.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The

information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties

for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products.

Nothing herein should be construed as constituting an additional warranty.

Printed in the U.S.A.

Edge Switch Release Notes

Fourth Edition (December 2003)

Part Number: AA–RTDZD–TE/958–000284–004

About this Document

3Edge Switch Release Notes

About this Document

These Release Notes contain late breaking and supplemental information for the

HP StorageWorks Edge Switch 2/24 and Edge Switch 2/32.

Be sure to read these Release Notes before installing an edge switch. This

information is periodically updated and available on the World Wide Web at:

http://www.hp.com/country/us/eng/prodserv/storage.html

This section describes the content reflected in this document, including:

■Release Notes Information, page 4

■Intended Audience, page 5

■Firmware Version 05.02.00-13, page 5

■Other Edge Switch Documentation, page 5

■CD-ROM Directory Structure, page 7

■Supported Configurations, page 8

■Cable Requirements, page 9

■Important Information, page 10

■Known Issues, page 18

Release Notes Information

4Edge Switch Release Notes

Release Notes Information

These Release Notes cover the following major topics:

■Embedded Web Server access to modify zones is limited to first 255 zones,

page 18

■SNMP trap reports incorrect FRU position, page 18

■Certain Unauthorized Devices may Increase Response Time for Fabric

Operations Under Specific Conditions with the Edge Switch 2/24, page 18

■CTP Events for Edge Switch 2/24 Show Incorrect FRU Number, page 19

■HSG80 Transparent Mode Not Supported with IBM AIX, page 19

■HSG80 Transparent Mode Not Recommended with Controller in SCSI-3

Mode with HP-UX Operating Systems, page 19

■ISL Disconnect Causes NOS Error with the OpenVMS Operating Systems,

page 20

■Support for Speed Auto-Negotiate, page 20

■Ports May Accumulate Spurious Events, page 21

■Firmware Downloaded to the Edge Switch 2/24 Using HAFM Can

Occasionally Time Out, page 21

■Adding a Defective ISL Connection May Cause all ISLs to Segment Between

the Two Switches or Directors, page 21

■Possible Switch Reset After Power Failure or Power Off Sequence, page 22

■Erroneous Error Message When No Firmware File Selected, page 22

■A Device Cannot Send Frames to Itself After the Active Zone Set Is

Deactivated, page 22

Intended Audience

5Edge Switch Release Notes

Intended Audience

This document is intended for customers who purchased the HP StorageWorks

Edge Switch 2/24 and Edge Switch 2/32.

Firmware Version 05.02.00-13

Firmware Version 05.01.00-24 is the initial firmware released with the Edge

Switch 2/24 and Edge Switch 2/32. A copy of the latest version of the firmware,

05.02.00-13 (as of this date), is contained on the HP StorageWorks Edge Switch

Documentation and Firmware CD (Part Number 524-000001-003).The latest

firmware is also available on the HP website at:

http://www.hp.com/country/us/eng/prodserv/storage.html.

You need to upgrade Version 05.01.00-24 to Version 05.02.00-13 if Version

05.02.00-13 is not preloaded on the edge switch. For more information on

upgrading firmware versions, refer to the appropriate HP StorageWorks Edge

Switch Service Manual. The features of this firmware version are detailed in the

accompanying manuals.

Other Edge Switch Documentation

6Edge Switch Release Notes

■HP StorageWorks Edge Switch Rack Mount Kit Installation Instructions,

AA-RT4MC-TE/958-000293-001

■HP StorageWorks Edge Switch 2/32 Flexport Upgrade Instruction,

AA-RS33C-TE/958-000291-001

■HP StorageWorks Edge Switch 2/32 Installation Guide,

AA-RSTZC-TE/958-000290-001

■HP StorageWorks Edge Switch 2/32 Service Manual, AA-RS2GC-TE

■HP StorageWorks Edge Switch 2/32 Product Manager User Guide,

AA-RS2HC-TE

■HP StorageWorks CLI Reference Guide for Directors and Edge Switches,

AA-RQ7AD-TE

■HP StorageWorks SNMP Reference Guide for Directors and Edge Switches,

AA-RQ7BD-TE

■HP StorageWorks SAN High Availability Planning Guide, AA-RS2DC-TE

■HP StorageWorks SAN Design Guide, AA-RMPNJ-TE

■HP StorageWorks Embedded Web Server User Guide, AA-RTDRB-TE

■

HP StorageWorks HA-Fabric Manager User Guide, AA-RS2CD-TE

■

HP StorageWorks HAFM Server for Windows 2000 Installation Guide,

AA-RT4KC-TE

■

HP StorageWorks HA-Fabric Manager Server Installation Guide,

AA-RU5FA-TE/958-000324-000

■

HP StorageWorks HA-Fabric Manager Release Notes,

AA-RUR6B-TE/958-000288-006

■

HP StorageWorks Director and Edge Switch Glossary, AA-RU5JA-TE

CD-ROM Directory Structure

7Edge Switch Release Notes

CD-ROM Directory Structure

The HP StorageWorks Edge Switch Documentation and Firmware CD contains

the following items:

CD-ROM Directory Structure for Edge Switch 2/24 and Edge Switch 2/32

Documentation

■Manuals.pdf – (HP StorageWorks Edge Switch 2/24 and Edge Switch 2/32

Documentation; links to all documents below and search function)

■Docs

— README.TXT – (HP Doc Structure; late breaking doc changes)

— AA-RTDWB-TE/958-000283-001 – (HP StorageWorks Edge Switch

2/24 Installation Guide)

— AA-RTDXB-TE – (HP StorageWorks Edge Switch 2/24 Service Manual)

— AA-RTDYB-TE – (HP StorageWorks Edge Switch 2/24 Product

Manager User Guide)

— AA-RSTZC-TE/958-000290-001 – (HP StorageWorks Edge Switch 2/32

Installation Guide)

— AA-RS2GC-TE – (HP StorageWorks Edge Switch 2/32 Service Manual)

— AA-RS2HC-TE – (HP StorageWorks Edge Switch 2/32 Product Manager

User Guide)

— AA-RQ7AD-TE – (HP StorageWorks CLI Reference Guide for Directors

and Edge Switches)

— AA-RQ7BD-TE – (HP StorageWorks SNMP Reference Guide for

Directors and Edge Switches)

— AA-RS2DC-TE – (HP StorageWorks SAN High Availability Planning

Guide)

— AA-RMPNJ-TE – (HP StorageWorks SAN Design Guide)

— AA-RS2CD-TE – (HP StorageWorks HA-Fabric Manager User Guide)

— AA-RTDRB-TE – (HP StorageWorks Embedded Web Server User

Guide)

— AA-RT4KC-TE – (HP StorageWorks HAFM Server for Windows 2000

Installation Guide)

— AA-RU5FA-TE/958-000324-000 – (HP StorageWorks HA-Fabric

Manager Server Installation Guide)

Supported Configurations

8Edge Switch Release Notes

— AA-RU5JA-TE – (HP StorageWorks Director and Edge Switch Glossary)

■Firmware

— HPQ_HAF_v05.01.00-24.bin – (HP StorageWorks edge switch preloaded

Firmware)

— HPQ_HAF_v05.02.00-13.bin – (HP StorageWorks edge switch

Firmware)

— firmwareupdate.txt – (Instructions for updating Firmware)

■Acrobat

— RP505ENU.EXE – (Windows installation file for Acrobat Reader 5.0

with Search)

Supported Configurations

Operation of multiple switches in a fabric topology is subject to the following

topology limits. Consider the impact of these limits when planning the fabric.

Note: For more information about planning the fabric, refer to

HP StorageWorks

SAN High Availability Planning Guide

■Fabric Elements – Each fabric element is defined by a unique domain ID that

ranges between 1 and 31; therefore, the theoretical limit of interconnected

switches in a single fabric is 31. The supported limit of interconnected

switches in a single fabric is 24. Because this number is subject to change,

contact your HP authorized service representative for the current number of

interconnected switches supported in a single fabric.

■Inhomogeneous fabric – To determine if interoperability is supported for a

product, or if restrictions apply, refer to the product publications, or contact

your HP authorized service representative.

■Number of Interswitch Links (ISLs) – The maximum supported number of

ISLs for edge switches is all available switch ports. For redundancy, at least

two ISLs should connect any two switch-class fabric elements. Because this

number is subject to change, contact your HP authorized service

representative for the current number of ISLs supported per switch.

Cable Requirements

9Edge Switch Release Notes

■Hop Count – The Fibre Channel theoretical limit of ISL connections

traversed (hop count) in a single path through a fabric is 7. The maximum

supported hop count in a single path through a fabric is 3. Because this

number is subject to change, contact your HP authorized service

representative for the current hop count supported by a single fabric path.

Note: The hop count is equal to the number of ISL connections traversed in a single

path, not the total number of ISL connections between devices.

Cable Requirements

Note: Please note that optical cables for the Edge Switch 2/24 and Edge

Switch 2/32 must be ordered separately.

For cables measuring up to 500 meters (1 Gbps) or 300 meters (2 Gbps), use

multi-mode Fibre Channel cables. For longer cables, use single-mode Fibre

Channel cables.

Multi-mode optical cables are connected to short-wave optical transceiver

modules in a switch. Single-mode optical cables are connected to long-wave

optical transceiver modules in a switch. Multi-mode cables should use 50/125

optical fibers, and single-mode cables typically use 9/125 optical fibers for

distances up to 10 km.

Verify that connectors interfacing with the Edge Switch 2/24 and Edge

Switch 2/32 use LC Duplex connectors with a PC finish. In addition, the

connector at the opposite end of the cable must use either LC or SC type,

depending on the requirements of the connected device.

Important Information

10 Edge Switch Release Notes

Important Information

This section describes important information related to the Edge Switch 2/24 and

Edge Switch 2/32.

HAFM and Firmware Version Compatibility

Table 1 lists the minimum version of HAFM that can run with the various versions

of firmware for the directors and edge switches.

Upgrading from an Earlier Version of Firmware

Upgrading to firmware Version 05.02.00-13 is nondisruptive to attached devices.

The edge switch or director is not required to be offline before performing an

upgrade operation. Limitations to upgrades are clearly identified if there are any

limitations to performing the operation.

Before upgrading firmware, it is highly recommended that you back up the edge

switch or director configuration in the event that a failure should occur. Refer to

the switch or director Product Manager user guide for more information.

Embedded Web Server (EWS) also provides an option to print or save product

configuration to a file. Refer to the HP StorageWorks Embedded Web Server User

Guide for more information.

Table 1: HAFM and Firmware Compatibility

Firmware Version HAFM Version (Minimum)

01.01.02 04.00.01 (HP EFCM)

01.02.02-06 04.01.02-14 (SDCM)

01.03.00-35 04.02.00-40 (HP EFCM)

01.04.00-01 04.02.00-40 (SDCM)

02.00.00-33 06.00.00-45 (HP EFCM)

02.00.02-01 06.00.02-06

04.01.02-04 06.03.01-05

05.01.00-24 07.01.00-09 (Notebook Server)

05.01.00-24 07.02.00-09 (1U Appliance)

05.02.00-13 07.01.00-09 (Notebook Server)

05.02.00-13 07.02.00-09 (1U Appliance)

Autres manuels pour 316095-B21 - StorageWorks Edge Switch 2/24

Table des matières

Autres manuels HP Changer

HP SN8000B Manuel utilisateur

HP Officejet Pro 7500 Series Manuel utilisateur

HP AA-RWF3A-TE Manuel utilisateur

HP SN3000B Manuel utilisateur

HP ProCurve 2520G-PoE Manuel utilisateur

HP ProCurve 2824 Manuel utilisateur

HP FlexNetwork 7506X Instructions de montage

HP J1473A Manuel utilisateur

HP StorageWorks 2/16 - SAN Switch Manuel utilisateur

HP A3100-8 v2 EI Manuel utilisateur

HP FlexFabric 7900 Series Manuel utilisateur

HP StorageWorks 2/16-EL Instructions d'utilisation

HP 2920 Series Manuel utilisateur

HP ProCurve 6120G/XG Manuel utilisateur

HP 316095-B21 - StorageWorks Edge Switch 2/24 Mode d’emploi

HP 5820X Series Manuel utilisateur

HP Procurve Series 4100GL Manuel utilisateur

HP A7340A - Surestore FC 1Gb/2Gb Switch 16B Mode d’emploi

HP FlexFabric 7900 Series Manuel d'installation

HP AdvanceStack 100Base-T Hub-8TXE Manuel d'installation et d'exploitation

HP JG726A Manuel utilisateur

HP FlexFabric 7900 Series Manuel d'installation

HP Cisco MDS 9216 - Fabric Switch Manuel utilisateur

HP StorageWorks 2/140 - Director Switch Mode d’emploi

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
