HP NetServer LXr 8000

Installation Guide

for

Compaq®4000/7000 Racks

HP Part Number 5967-6631

Printed in October 1998

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose. Hewlett-Packard shall not

be liable for errors contained herein or for incidental or consequential damages in

connection with the furnishing, performance, or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its software

on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copyright. All

rights are reserved. No part of this document may be photocopied, reproduced, or

translated to another language without the prior written consent of Hewlett-

Packard Company.

Compaq®is a registered trademark of Compaq Computer Corporation.

APC®is a registered trademark of American Power Conversion Corporation.

Hewlett-Packard Company

Network Server Division

Technical Marketing / MS 45S-LE

10955 Tantau Avenue

Cupertino, CA 95014 USA

Audience Assumptions

The user guide is for the person who installs, administers, and troubleshoots

network servers. Hewlett-Packard Company assumes you are qualified in the

servicing of computer equipment and trained in recognizing hazards in products

with hazardous energy levels.

iii

Contents

1 Introduction.......................................................................................................1

HP NetServer LXr 8000 – Compaq Rack Precautions ......................................4

2 Overview............................................................................................................5

3 Installation.........................................................................................................7

Preparation.........................................................................................................7

Marking the Installation Holes........................................................................7

Installing the Rack Nuts.................................................................................8

Mounting the Slides........................................................................................9

Installing the NetServer....................................................................................11

4 Warranty and Support....................................................................................19

HP Repair and Telephone Support..................................................................19

Index ....................................................................................................................21

1 Introduction

This document describes how to mount an HP NetServer LXr 8000 into a

Compaq®model 4000- or 7000-series rack enclosure. Refer to the HP NetServer

LXr 8000 Installation Guide that came with the NetServer for instructions on

adding accessories to and configuring the NetServer. The HP NetServer LXr 8000

is shown in Figure 1-1.

Figure 1-1. HP NetServer LXr 8000

Chapter 1 Introduction

WARNING To prevent the rack from tipping over and causing equipment

damage or bodily injury, be sure that the stabilizing, anti-tip

feature is installed on this rack enclosure (see Figure 1-2).

To prevent the rack from tipping over and causing equipment

damage or bodily injury, do not extend more than one piece of

equipment at a time out of the front of the rack enclosure.

Be sure that the stabilizing, anti-tip feature is installed on the rack enclosure in

which you are installing the HP NetServer LXr 8000. This feature consists of two

"feet" at the front of the base of the enclosure and, if you are installing this

NetServer in a single rack enclosure, two "feet" each on the left and right sides of

the enclosure (see Figure 1-2).

Chapter 1 Introduction

Figure 1-2. Single Rack Enclosure With the Anti-Tip

Stabilizing Feature Installed

Chapter 1 Introduction

HP NetServer LXr 8000 – Compaq Rack

Precautions

CAUTION If this NetServer is not installed according to these

instructions, damage to the NetServer or accessories may

result. Damage due to improper installation is not covered by

the HP Warranty. Observe the precautions listed in this section

to maintain the NetServer’s reliability.

When the HP NetServer LXr 8000 is installed in a Compaq rack enclosure, certain

requirements must be addressed to assure that the needs of the NetServer are met.

These requirements are:

•The NetServer is installed in a Compaq model 4000- or 7000-series rack

enclosure. This NetServer is not supported in any other non-HP rack

enclosure.

•If you choose to use a door on this enclosure, only a Compaq model

4000- or 7000-series door may be used. No other door may be used. The

enclosure may be used with the door open, closed, or removed.

•Mass storage devices listed in the Tested Products List (located on the

HP NetServer Navigator CD-ROM) are used exclusively in the NetServer.

•Use HP rack accessories. (HP rack accessories are not optimized for

Compaq rack enclosures.)

Compaq rack accessories have not been tested with HP NetServer products,

but components such as monitors, keyboards, switchboxes, and PDUs often

work.

NOTE This NetServer will not work with Compaq PDUs; the power

connectors are incompatible. An appropriate PDU must be ordered.

•Use APC®uninterruptible power supplies (UPS) with HP NetServers.

APC offers mounting kits for Compaq rack enclosures.

This NetServer is not supported in a rack enclosure under circumstances other than

those listed above.

See the "Warranty and Support" section of this document for additional support

considerations.

2Overview

The steps required to install the NetServer in the rack are summarized below:

NOTE This is only a summary; detailed instructions are provided on the

following pages.

•Measure and mark the appropriate holes on all four rack columns.

•Install four rack nuts on each of the two front rack columns.

•Insert two rack nuts on each of the two rear rack columns.

•Attach the slides to the columns.

•Extend the slides.

•Remove power supply modules from the NetServer.

•Lift the NetServer onto the slides.

•Secure the NetServer to the slides.

•Remove the lifting handles from the NetServer.

•Install the power supply modules in the NetServer.

•Push the NetServer back into the rack enclosure.

•Secure the NetServer to the two front columns.

Chapter 2 Warranty and Support

Terms used in this document are defined in the table below.

Term Definition

Rack nut Single nut designed to clip behind the rack column and

accept a screw through the hole in the column.

Slide Extendible side bracket that is attached to the rack

enclosure columns, onto which the NetServer is mounted.

Consists of a stationary component, and an extendible

member (see Figure 3-3). Allows access to the NetServer

after it is installed in the rack chassis.

Slide mounting flange Mounting flange located at either end of the slide (see

Figure 3-3).

Rack (rack enclosure) The equipment enclosure into which the NetServer will be

installed.

EIA unit Industry standard measurement (1.75 inches / 44.45 mm),

consisting of four vertical mounting holes in a rack column.
