WLAN antennas

12.

Power/standby LED indicator

Integrated microphone

13.

Wireless on/off LED indicator

Wireless on/off button with LED indicator

14.

ExpressCard/54 slot or optional Smart Card Reader

Volume mute button with LED indicator 15.

Upgrade Bay (DVD-ROM drive or weight saver)

Secure Digital/MultiMedia Card slot

16.

(2) USB 2.0 ports

Stereo speakers

17.

RJ-45/Ethernet port

Touchpad with scroll zone

18.

Security lock slot

Touchpad pick buttons

19.

Power button with LED indicator

Touchpad on/off tap zone with LED indicator

20.

Volume down function key

10.

Hard drive activity / HP 3D DriveGuard LED indicator

21.

Volume up function key

11.

Battery charging LED indicator

Stereo headphone/line out

DisplayPort

Stereo microphone/line in

VGA/external monitor connector

QuickSpecs

HP 6360t Mobile Thin Client

Overview

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 1

Not used for HP 6360t

RJ-11/modem port

eSATA/USB 2.0 combo port

Power connector

(1) USB 2.0 port

Battery release latch

Secondary battery connector

Docking connector

Solid state drive, memory, and wireless compartments under

bottom cover

Bottom cover release latch

Vents

Battery bay

At A Glance

Genuine Windows Embedded Standard 2009 or Genuine Windows Embedded Standard 7 featuring File Based Write Filter,

Enhanced Write Filter, Remote Desktop Protocal, Internet Explorer and Windows Media Player

All new design with bead-blast aluminum display enclosure, magnesium-reinforced chassis, wear-resistant

tungsten-colored HP DuraFinish, HP DisplaySafe frame, precision latches, and keyboard in full aluminum deck

Administrator control over read/write access to Solid State Module and USB attached memory devices

2 GB, 4 GB, or 8 GB Solid State Module for reliability, durability and increased battery life

Full-sized keyboard with bottom-case drain, integrated touchpad

Widescreen 13.3-inch diagonal LED-backlit HD display with 16:9 aspect ratio

Choice of primary battery to optimize run-time or weight: 9-cell (100 WHr) or 6-cell (55 WHr)

Combine primary battery with optional secondary battery options

Easily hot dock with one of the optional HP docking stations

HP Thin State Tools to configure thin clients via a USB flash drive or over the network

HP Remote Graphics Software (RGS)

HP Device Manager to track, configure, upgrade, clone and manage hundreds or thousands of thin clients

VGA and DisplayPort 1.1 for dual external-monitor support, including high-definition displays

QuickSpecs

HP 6360t Mobile Thin Client

Overview

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 2

Integrated 802.11 a/b/g/n or b/g/n wireless connectivity

Integrated Secure Digital/MultiMedia Card slot

Optional integrated DVD-ROM drive

Optional integrated Smart Card Reader

QuickSpecs

HP 6360t Mobile Thin Client

Overview

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 3

Processors

Intel Celeron B810 Processor (1.6 GHz, 2 MB L3 cache, 1 core/2 threads, 35W)

NOTE:

Processor speed denotes maximum performance mode; processors will run at lower speeds in

battery optimization mode.

Operating System

Preinstalled

Genuine Windows Embedded Standard 2009

Genuine Windows Embedded Standard 7 Service Pack 1

Chipset

Mobile Intel HM65 Express Chipset

Graphics

Intel HD Graphics

Microsoft DirectX 9 with Windows Embedded Standard 2009

Microsoft DirectX 10 with Windows Embedded Standard 7

Display

Internal

13.3-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)

Optional HP Privacy Filter

External

Up to 32-bit per pixel color depth

VGA

port supports resolutions up to 1920 x 1200 at 75 Hz, and lower

resolutions at up to 100 Hz.

DisplayPort

supports resolutions up to 2560 x 1600, 30-bit color depth at 60

Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120 Hz.

NOTE:

Resolutions are dependent upon monitor capability, and resolution and

color depth settings.

Memory

Standard

DDR3 PC3-10600 SDRAM (1333 MHz)

Two SODIMM slots supporting dual-channel memory

2 GB, 4 GB, and 8 GB SODIMMs

Maximum

Upgradeable to 16 GB with 8 GB SODIMMs in slots 1 and 2

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same size and

speed in both memory slots.

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we recommend HP

branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower

memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or

Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your

configuration, so that above 3 GB all memory may not be available due to system resource requirements.

QuickSpecs

HP 6360t Mobile Thin Client

Standard Features (availability may vary by country)

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 4

Communications

Integrated Intel 82579V Gigabit

Network Connection

Optional 56K V.92 modem

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for

Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,

connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download

transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is

subject to country regulatory approval.

Wireless Devices

Secure, integrated wireless LAN options featuring support for the latest industry standards. Wireless LAN

is factory configurable only.

All 802.11 integrated

wireless LAN options

Wi-Fi certified

Cisco Compatible Extensions support

Wired Equivalent Privacy (WEP) support up to 128-bit keys

Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,

PEAP-MSCHAPv2, and LEAP

Advanced Encryption Standard (AES) support

Dual antennas integrated in the display enclosure

Broadcom 43224AGN

802.11a/b/g/n

WiFi Adapter

Integrated support for 802.11a, b, g, and n

Up to 300 mbps data rate

Broadcom 4313GN

802.11b/g/n

WiFi Adapter

Integrated support for 802.11 b, g, and n

Up to 72 mbps data rate

Keyboard

The HP keyboard with bottom-case drain is designed using a Mylar film that minimizes the risk of damage

to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key

layout with desktop keyboard features, such as the isolated cursor control keys, editing keys, both left

and right control and alt keys, and 12 function keys. US and International key layouts are available. Other

features include hotkeys for instant access to power conservation and brightness, and 19.05 x 19.05 mm

key pitch (center-to-center spacing).

Pointing device

Touchpad with on/off tap zone

Storage

Internal Storage Device

2 GB, 4 GB, or 8 GB Solid State Module

Optional Fixed Optical

Drive

DVD-ROM Drive

QuickSpecs

HP 6360t Mobile Thin Client

Standard Features (availability may vary by country)

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 5

Expansion card slots

ExpressCard/54 slot

Supports ExpressCard/54

Optional Integrated

Smart Card Reader

(replaces ExpressCard/54

slot)

Compatible with ISO 7816 compliant Smart Cards

PC/SC interface support

Secure Digital/MultiMedia

Card slot

Supports SD (Secure Digital), SDHC, SDXC, MultiMedia Card, and MultiMedia

Card+

Interfaces

VGA

One

DisplayPort

One

Stereo microphone in

One

Stereo headphone/line

out

One

Power connector

One

RJ-11/modem (optional)

One

RJ-45/Ethernet

One

Combo eSATA/USB 2.0

One

USB 2.0

Three

Docking connector

One

Secondary battery

connector

One

Audio/Visual

HD Audio

Integrated stereo speakers

Integrated microphone

Button for volume mute; function keys for volume up and down

Stereo headphone/line out

Stereo microphone/line in

QuickSpecs

HP 6360t Mobile Thin Client

Standard Features (availability may vary by country)

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 6

Software

(Preinstalled)

Windows Embedded

Standard 2009

Enhanced Write Filter

File Based Write Filter

Internet Explorer 7

Windows Media Player 11

TeemTalk Emulation

Symantec Endpoint Protection Firewall

Microsoft Remote Desktop Protocol (RDP) 7.0

Microsoft Firewall

.NET Framework 3.5

Citrix XenApp 12

VMWare View 4.01

WinDVD

Windows Embedded

Standard 7

Service Pack 1

Enhanced Write Filter

File Based Write Filter

Internet Explorer 8

Windows Media Player 12

TeemTalk Emulation

Microsoft Remote Desktop Protocol (RDP) 7.1

Microsoft Firewall

.NET Framework 3.5

Citrix XenApp 12

VMWare View 4.5

Manageability

Solution

HP ThinState Capture

HP Device Manager

Altiris Deployment Solution (Windows Embedded Standard 2009 only)

Adobe Flash Player 10

Additional software

available

from the web

Citrix XenApp plug-in for hosted app

Broadcom Wireless Utility

VMWare Viw Client 4.5 (Windows Embedded Standard 2009 only)

Security

Standard Features

Setup Password

Power-On Password

Security Lock Slot

HP Privacy Filter (must be purchased separately)

Power Supply

External 65-watt Smart AC adapter

6-foot (1.8-meter) power cord included; total length including external AC adapter is 12 feet (3.66 meter)

HP Fast Charge

* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast

Charge does not apply to the HP 9-cell battery.

QuickSpecs

HP 6360t Mobile Thin Client

Standard Features (availability may vary by country)

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 7

Battery

Primary battery

HP 9-cell (100 WHr) Li-Ion battery

HP 6-cell (55 WHr) Li-Ion battery

Optional HP ST09

Extended Life Notebook

Battery

9-cell (73 WHr) Li-Ion battery

Optional HP BB09 Ultra

Extended Life Notebook

Battery

9-cell (100 WHr) Li-Ion battery

Battery Life

9-cell (100 WHr)

Up to 11 hours and 45 minutes

with optional

HP BB09 Ultra Extended

Life Notebook Battery

Up to 24 hours

6-cell (55 WHr)

Up to 6 hours and 30 minutes

NOTE:

Battery life will vary depending on the product model, configuration, loaded applications, features,

use, wireless functionality and power management settings. The maximum capacity of the battery will

naturally decrease with time and usage. See MobileMark07 battery benchmark

http://www.bapco.com/products/mobilemark2005

for additional details.

System Standby Time

Up to 1 week

Power Conservation

Standby

ACPI compliance

Docking and Stands

HP 90W Docking Station

HP 120W Docking Station

HP USB 2.0 Docking Station

HP Essential USB 2.0 Port Replicator

HP LAN and USB Travel Hub

NOTE:

Some HP Docking stations may not support every feature of some HP Notebook models. Please

refer to the individual docking station documentation for specific information about supported features.

Service and Support

HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x 24

hardware technical phone support (depending on model). Warranty upgrades are also available. HP Care

Pack Services extend service contracts beyond the standard warranties. To choose the right level of

service for your HP product, use the HP Care Pack Services Lookup Tool at:

http://www.hp.com/go/lookuptool

. Additional HP Care Pack Services information by product is available

at:

http://www.hp.com/hps/carepack

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

QuickSpecs

HP 6360t Mobile Thin Client

Standard Features (availability may vary by country)

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 8

NOTE:

Options/capabilities listed in the QuickSpecs represent those capabilities available through Base Units or Build to Order

configurations. The various product features and capabilities will vary in terms of configurable vs. aftermarket options (AMOs). There

may be options and capabilities available through CTO that are not available as AMOs.

Expansion

HP 90W Docking Station

VB041AA#xxx

HP 120W Docking Station

NZ222AA#xxx

HP USB 2.0 Docking Station

AY052AA#xxx

HP Essential USB 2.0 Port Replicator

AQ731AA#xxx

HP LAN and USB Travel Hub

BM868AA#xxx

Power

HP ST09 Extended Life Notebook Battery

QK639AA

HP BB09 Ultra Extended Life Notebook Battery

QK640AA

HP CC09 Notebook Battery

QK643AA

HP 90W Smart Auto/Truck Adapter

ED493AA

Carrying Cases

HP Basic Carrying Case

AJ078AA

HP Business Nylon Case

BP848AA

HP Professional Slim Top Load Case

AY530AA

Security

HP Notebook Combo Lock

AY475AA#xxx

HP Keyed Cable Lock

BV411AA

Input/Output Devices

HP USB Optical Travel Mouse

RH304AA

HP USB Keyboard & Mouse Bundle

RC465AA#xxx

HP Pocket Whiteboard

QL796AA#xxx

Memory

HP 2 GB PC3-12800 (DDR3 1600 MHz) SODIMM

H2P63AA

HP 4 GB PC3-12800 (DDR3 1600 MHz) SODIMM

H2P64AA

HP 8 GB PC3-12800 (DDR3 1600 MHz) SODIMM

H2P65AA

NOTE:

Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or Linux. With

Windows 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so

that above 3 GB all memory may not be available due to system resource requirements. Due to system

limitations, DDR3-1600 MHz memory will only be supported at DDR3-1333 MHz.

QuickSpecs

HP 6360t Mobile Thin Client

Options (availability may vary by country)

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 9

System Unit

Dimensions

(HxWxD)

1.32 in (at front) x 12.68 in x 8.66 in

33.7 mm (at front) x 322 mm x 220 mm

Weight

Starting at 4.31 lb (1.96 kg) without optical drive

or 4.64 lb (2.11 kg) with optical drive

NOTE:

Height varies depending upon where on the notebook the measurement is made. Weight includes

6-cell battery and WLAN. Weight varies by configuration and components.

Stand-Alone Power

Requirements

(AC Power)

Nominal Operating Voltage

18.5 V

Average Operating Power

TBD W

Max Operating Power

< 65W

Temperature

Operating

32° to 95° F (0° to 35° C) (not writing optical)

41° to 95° F (5° to 35° C) (writing optical)

Non-operating

-4° to 140° F (-20° to 60° C)

Relative Humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb

temperature

Shock

Operating

125 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random Vibration

Operating

0.75 grms

Non-operating

1.50 grms

Altitude

(unpressurized)

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Industry Standard

Certifications

Yes

CSA

Yes

FCC Compliance

Yes

ENERGY STAR®

N/A

EPEAT

N/A

ICES

Yes

Australia / NZ A-Tick

Compliance

Yes

CCC

Yes

Japan VCCI Compliance

Yes

KCC

Yes

BSMI

Yes

CE Marking Compliance

Yes

NOTE:

For accessibility information on HP products, please visit:

http://www.hp.com/accessibility

QuickSpecs

HP 6360t Mobile Thin Client

Technical Specifications

DA - 14049 Worldwide — Version 12 — August 3, 2012

Page 10

Table des matières

Autres manuels HP Serveur

HP RDX REMOVABLE DL380 Instructions d'utilisation

HP ProLiant SL230s Manuel utilisateur

HP 9000 rp7420 Manuel utilisateur

HP Tc4100 - Server - 256 MB RAM Mode d’emploi

HP DL360 - ProLiant - Photon Manuel utilisateur

HP A9834-9001B Manuel utilisateur

HP ProLiant DL380 Generation 7 (G7) Instructions d'utilisation

HP Cluster Platform Express v2010 Manuel utilisateur

HP LC2000r - NetServer - 128 MB RAM Manuel utilisateur

HP L1000 - 9000 - 0 MB RAM Manuel utilisateur

HP D7171A - NetServer - LPr Manuel utilisateur

HP t5710 - Thin Client Manuel utilisateur

HP D7171A - NetServer - LPr Manuel d'exploitation et d'entretien

HP Sa3110 - VPN Server Appliance Manuel du propriétaire

HP BladeSystem bc2200 - Blade PC Instructions de montage

HP ML350T06 - E5520 Sff Us Svr Instructions d'utilisation et de sécurité

HP EX475 - MediaSmart Server - 512 MB RAM Manuel utilisateur

HP ProLiant DL320 Generation 5p Manuel utilisateur

HP t820 Manuel utilisateur

HP ProLiant DL580 Generation 3 Manuel utilisateur

HP BL920s Gen9 Instructions de montage

HP Integrity BL870c Instructions d'utilisation

HP DL385 - ProLiant - G5 Instructions d'utilisation

HP Integrity rx8640 Manuel utilisateur

Manuels Serveur populaires d'autres marques

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

Milestone

Milestone Husky IVO 350T Manuel utilisateur

Planet

Planet NAS-7410 Manuel utilisateur

Lenovo

Lenovo ThinkSystem SR635 V3 Manuel utilisateur

Dell

Dell PowerEdge HS5610 Manuel
