Etherlink IIIB ISA Network Interface
Card (10BT)
3C509B-TP
Installation Guide
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft
Corporation.
MMXTM is a trademark of Intel Corporation.
Pentium® is a registered trademark of Intel Corporation.
Hewlett-Packard France
Commercial Desktop Computing Division
38053 Grenoble Cedex 9
France
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
1 Connecting to a Netware 3.12 Server
Windows for
Workgroups
Requirements
• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.
• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.
DOS ODI - File Name: 3C5X9.COM Size: 42KB Date: 7/21/96
• DOS and MS-Windows for Workgroups 3.11 media.
• Novell Netware server 3.12 that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
• Netware client for DOS and MS-Windows.
Device Configuration
• I/O Base Address 300
• Interrupt Request Level 10
• Boot PROM Disabled
• Transceiver Type Auto Select
• Network Driver Optimization Windows or OS/2 Client
• Maximum Modem Speed 9600 Baud
• Plug and Play Compatibility Disabled
• Full Duplex Disabled
Procedure
1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B
adapter card into an ISA slot.
2Power on the machine and allow it to boot to a DOS prompt.
3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s
website) and execute 3C5X9CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
6Remove the 3com cards driver diskette and insert Netware client for DOS
and MS-Windows disk 1.
7Execute INSTALL.EXE and set lines 1-5 as listed below;
8C:\NWCLIENT
9YES
10 YES
C:\WINDOWS
11 NO
12 3COM Etherlink III Parallel Tasking Family.
13 Highlight option 6 to continue with installation.
14 When prompted, insert the corresponding disks to complete file transfer
and driver installation.
15 When the install utility is finished, press <CRTL><ALT><DEL> to restart
the machine.
16 After windows loads, open the “NETWORK” folder, double-click the
“NETWORK SETUP” icon.
17 Select “Networks”, and verify that “Novell Netware (Workstation Shell 4.0
and above)” is listed under “Install Windows support for the following
network only:” and click on “OK.”
1 Connecting to a Netware 3.12 Server
Windows 95 SR2
Windows 95 SR2 Requirements
• HP Vectra with Windows 95 SR2 installed.
• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.
File Name: Elnk3.VXD Size: 30KB Date: 7/18/96
• Windows 95 SR2 media.
• Novell Netrware 3.12 server that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
Device Configuration
• I/O Base Address 300
• Interrupt Request Level 10
• Boot PROM Disabled
• Transceiver Type Auto Select
• Network Driver Optimization Windows or OS/2 Client
• Maximum Modem Speed 9600 Baud
• Plug and Play Compatibility Disabled
• Full Duplex Disabled
Procedure
1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B
adapter card into an ISA slot.
2Power on the machine and restart Windows 95 SR2 in MS-DOS Mode.
3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s
website) and execute 3C5X9CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Remove the 3com cards driver diskette and restart the machine.
7After windows loads, click on “Start,” to “Settings” and over to “Control
Panel.”
8Double click on “Network” and select “Add.”
1 Connecting to a Netware 3.12 Server
Windows 95 SR2
9Choose to add an adapter, click on “Add” then on “Have Disk.”
10 Insert the 3C509B drivers diskette and set path to “A:\” and hit enter. (If
you have a Hewlett-Packard pre-loaded HDD, set the path statement to
“C:\LANDRV\3C509B\WIN95\”)
11 High light the adapter labeled “3Com Etherlink III ISA (3C509/3C509B) in
ISA Mode” and press “OK.”
12 At the “Network” dialogue box, click on the “Identification” folder.
13 Enter your “Computer Name,” “Workgroup,” and “Computer
Description.” (If you do not have a Computer name, Workgroup name and
Computer description, contact your network administrator)
14 Approve the “Basic Configuration Resources” by clicking on “OK.”
15 When prompted, set the path to your Windows 95 SR2 files and click on
“OK.”
16 Click on “YES” to complete installation and restart the machine.
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
2 Connecting to a Netware 4.11 Server
Windows for
Workgroups
Requirements
• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.
• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.
DOS ODI - File Name: 3C5X9.COM Size: 42KB Date: 7/21/96
• DOS and MS-Windows for Workgroups 3.11 media.
• Novell Netware server 4.11 that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
• Netware client for DOS and MS-Windows.
Device Configuration
• I/O Base Address 300
• Interrupt Request Level 10
• Boot PROM Disabled
• Transceiver Type Auto Select
• Network Driver Optimization Windows or OS/2 Client
• Maximum Modem Speed 9600 Baud
• Plug and Play Compatibility Disabled
• Full Duplex Disabled
Procedure
1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B
adapter card into an ISA slot.
2Power on the machine and allow it to boot to a DOS prompt.
3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s
website) and execute 3C5X9CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
6Remove the 3com cards driver diskette and insert Netware client for DOS
and MS-Windows disk 1.
7Execute INSTALL.EXE and set lines 1-5 as listed below;
8C:\NWCLIENT
9YES
10 YES
C:\WINDOWS
11 NO
12 3COM Etherlink III Parallel Tasking Family.
13 Highlight option 6 to continue with installation.
14 When prompted, insert the corresponding disks to complete file transfer
and driver installation.
15 When the install utility is finished, press <CRTL><ALT><DEL> to restart
the machine.
16 After windows loads, open the “NETWORK” folder, double-click the
“NETWORK SETUP” icon.
17 Select “Networks”, and verify that “Novell Netware (Workstation Shell 4.0
and above)” is listed under “Install Windows support for the following
network only:” and click on “OK.”
2 Connecting to a Netware 4.11 Server
Windows 95 SR2
Windows 95 SR2 Requirements
• HP Vectra with Windows 95 SR2 installed.
• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.
File Name: Elnk3.VXD Size: 30KB Date: 7/18/96
• Windows 95 SR2 media.
• Novell Netrware 4.11 server that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
Device Configuration
• I/O Base Address 300
• Interrupt Request Level 10
• Boot PROM Disabled
• Transceiver Type Auto Select
• Network Driver Optimization Windows or OS/2 Client
• Maximum Modem Speed 9600 Baud
• Plug and Play Compatibility Disabled
• Full Duplex Disabled
Procedure
1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B
adapter card into an ISA slot.
2Power on the machine and restart Windows 95 SR2 in MS-DOS Mode.
3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s
website) and execute 3C5X9CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Remove the 3com cards driver diskette and restart the machine.
7After windows loads, click on “Start,” to “Settings” and over to “Control
Panel.”
8Double click on “Network” and select “Add.”
2 Connecting to a Netware 4.11 Server
Windows 95 SR2
9Choose to add an adapter, click on “Add” then on “Have Disk.”
10 Insert the 3C509B drivers diskette and set path to “A:\” and hit enter. (If
you have a Hewlett-Packard pre-loaded HDD, set the path statement to
“C:\LANDRV\3C509B\WIN95\”)
11 High light the adapter labeled “3Com Etherlink III ISA (3C509/3C509B) in
ISA Mode” and press “OK.”
12 At the “Network” dialogue box, click on the “Identification” folder.
13 Enter your “Computer Name,” “Workgroup,” and “Computer
Description.” (If you do not have a Computer name, Workgroup name and
Computer description, contact your network administrator)
14 Approve the “Basic Configuration Resources” by clicking on “OK.”
15 When prompted, set the path to your Windows 95 SR2 files and click on
“OK.”
16 Click on “YES” to complete installation and restart the machine.
