TokenLink Velocity PCI Network
Interface Card
3C339
Installation Guide
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
orconsequentialdamagesinconnectionwiththefurnishing,performance,oruse
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Microsoft®, Windows®and MS-DOS®are registered trademarks of Microsoft
Corporation.
MMXTMis a trademark of Intel Corporation.
Pentium® is a registered trademark of Intel Corporation.
Hewlett-Packard France
Commercial Desktop Computing Division
38053 Grenoble Cedex 9
France
© 1998 Hewlett Packard Company
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
1 Connecting to a Netware 3.12 Server
Windows for
WorkgroupsRequirements
•HP Vectra VE7/VE8 with DOS and MS-Windows for Workgroups 3.11 in-
stalled.
•3COM 3C339TokenRing card and drivers disk
DOS ODI - File Name: tlvmp339.dos
DOS and MS-Windows for Workgroups 3.11 media.
•Novell Netware server 3.12 that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
•Netware client for DOS and MS-Windows.
Device Configuration
•I/O Base Address DC00
•Interrupt Request Level 10
•Boot PROM Disabled
•Transceiver Type Auto Select
•Network Driver Optimization Windows or OS/2 Client
•Maximum Modem Speed 9600 Bps
•Full Duplex Disabled
Procedure
1With the HP Vectra VE7/VE8 set to PNP enabled, turn the machine off
install the 3COM 3C339 adapter card into an PCI slot.
2Power on the machine and allow it to boot to a DOS prompt.
3Insert the 3COM drivers diskette and execute 3C339CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Removethe3COMcardsdriverdisketteandinsertNetwareclientforDOS
and MS-Windows disk 1.
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
7Execute INSTALL.EXE.
8Specify the settings as listed below:
❒C:\NWCLIENT
❒Yes
❒Yes
❒C:\WINDOWS
❒No
❒3Com Fast Etherlink/Etherlink III Bus Master
9Under the heading “Select the driver for your network board”, insert the
3Com 3C339 drivers disk and set the path to “A:\NETWARE\CLIENT.”
(If you have an HP preloaded HDD, set path to
“C:\Masters\LanDrv\3C339\NWCLIENT\)
10 Press “Enter” to continue the installation.
11 When prompted, insert the corresponding disks to complete file transfer
and driver installation.
12 Whenthe installutility isfinished, press<CRTL><ALT><DEL> torestart
the machine.
13 After Windows loads, open the “NETWORK” folder, double-click the
“NETWORK SETUP” icon.
14 Select“Networks”, andverifythat “NovellNetware(Workstation Shell4.0
and above)” is listed under “Install Windows support for the following
network only:” and click on “OK.”
1 Connecting to a Netware 3.12 Server
Windows 95 SR2
Windows 95 SR2Requirements
•HP Vectra VE7/VE8 with Windows 95 SR2 installed.
•3COM 3C 339 Token Ringcard and drivers disk
•Windows 95 SR2 media.
•Novell Netrware 3.12 server that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
Device Configuration
•I/O Base Address 300
•Interrupt Request Level 10
•Boot PROM Disabled
•Transceiver Type Auto Select
•Network Driver Optimization Windows or OS/2 Client
•Plug and Play Compatibility Disabled
•Full Duplex Disabled
Procedure
1With the HP Vectra VE7/VE8 turned off install the 3COM 3C339 adapter
card into an PCI slot.
2Power on the machine and restart Windows 95 SR2 in MS-DOS Mode.
3Insertthe 3COMdrivers diskette(downloadedfrom 3COM’swebsite) and
execute 3C3X9CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Remove the 3COM cards driver diskette and restart the machine.
7After Windows loads, click on “Start,” to “Settings” and over to “Control
Panel.”
8Double click on “Network” and select “Add.”
9Choose to add an adapter, click on “Add” then on “Have Disk.”
10 Insert the 3C339 drivers diskette and set path to “A:\” and hit Enter.
1 Connecting to a Netware 3.12 Server
Windows 95 SR2
(If you have a Hewlett-Packard pre-loaded HDD, set the path statement
to “C:\MASTERS\LANDRV\3C509B\”)
11 Highlight the adapter labeled “3Com Token Ring in PCI Mode” and press
“OK.”
12 At the “Network” dialogue box, click on the “Identification” folder.
13 Enter your “Computer Name,” “Workgroup,” and “Computer
Description.”
(If you do not have a Computer name, Workgroup name and Computer
description, contact your network administrator.)
14 Approve the “Basic Configuration Resources” by clicking on “OK.”
15 When prompted, set the path to your Windows 95 SR2 files and click on
“OK.”
16 Click on “YES” to complete installation and restart the machine.
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
2 Connecting to a Netware 4.11 Server
Windows for
WorkgroupsRequirements
•HP Vectra VE7/VE8 with DOS and MS-Windows for Workgroups 3.11 in-
stalled.
•3COM 3C339TokenRing card and drivers disk
DOS ODI - File Name:tlvmp339.dos
DOS and MS-Windows for Workgroups 3.11 media.
•Novell Netware server 3.12 that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
•Netware client for DOS and MS-Windows.
Device Configuration
•I/O Base Address DC00
•Interrupt Request Level 10
•Boot PROM Disabled
•Transceiver Type Auto Select
•Network Driver Optimization Windows or OS/2 Client
•Maximum Modem Speed 9600 Bps
•Full Duplex Disabled
Procedure
1With the HP Vectra VE7/VE8 set to PNP enabled, turn the machine off
install the 3COM 3C339 adapter card into an PCI slot.
2Power on the machine and allow it to boot to a DOS prompt.
3Insert the 3COM drivers diskette and execute 3C339CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Removethe3COMcardsdriverdisketteandinsertNetwareclientforDOS
and MS-Windows disk 1.
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
7Execute INSTALL.EXE.
8Specify the settings as listed below:
❒C:\NWCLIENT
❒Yes
❒Yes
❒C:\WINDOWS
❒No
❒3Com Fast Etherlink/Etherlink III Bus Master
9Under the heading “Select the driver for your network board”, insert the
3Com 3C339 drivers disk and set the path to “A:\NETWARE\CLIENT.”
(If you have an HP preloaded HDD, set path to
“C:\Masters\LanDrv\3C339\NWCLIENT\)
10 Press “Enter” to continue the installation.
11 When prompted, insert the corresponding disks to complete file transfer
and driver installation.
12 Whenthe installutility isfinished, press<CRTL><ALT><DEL> torestart
the machine.
13 After Windows loads, open the “NETWORK” folder, double-click the
“NETWORK SETUP” icon.
14 Select“Networks”, andverifythat “NovellNetware(Workstation Shell4.0
and above)” is listed under “Install Windows support for the following
network only:” and click on “OK.”
2 Connecting to a Netware 4.11 Server
Windows 95 SR2
Windows 95 SR2Requirements
•HP Vectra VE7/VE8 with Windows 95 SR2 installed.
•3COM 3C 339 Token Ringcard and drivers disk
•Windows 95 SR2 media.
•Novell Netrware 4.11 server that supports Net BEUI, NWLink IPX/SPX,
andNWLink NetBIOS transfer protocols.
Device Configuration
•I/O Base Address DC00
•Interrupt Request Level 10
•Boot PROM Disabled
•Transceiver Type Auto Select
•Network Driver Optimization Windows or OS/2 Client
•Plug and Play Compatibility Disabled
•Full Duplex Disabled
Procedure
1WiththeHPVE7/VE8turnedoffinstallthe3COM3C339adaptercardinto
an PCI slot.
2Power on the machine and restart Windows 95 SR2 in MS-DOS Mode.
3Insertthe 3COMdrivers diskette(downloadedfrom 3COM’swebsite) and
execute 3C3X9CFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Remove the 3COM cards driver diskette and restart the machine.
7After Windows loads, click on “Start,” to “Settings” and over to “Control
Panel.”
8Double click on “Network” and select “Add.”
9Choose to add an adapter, click on “Add” then on “Have Disk.”
2 Connecting to a Netware 4.11 Server
Windows 95 SR2
10 Insert the 3C339 drivers diskette and set path to “A:\” and hit Enter.
(If you have a Hewlett-Packard pre-loaded HDD, set the path statement
to “C:\MASTERS\LANDRV\3C509B\”)
11 Highlight the adapter labeled “3Com Token Ring in PCI Mode”
12 and press “OK.”
13 At the “Network” dialogue box, click on the “Identification” folder.
14 Enter your “Computer Name,” “Workgroup,” and “Computer
Description.”
(If you do not have a Computer name, Workgroup name and Computer
description, contact your network administrator.)
15 Approve the “Basic Configuration Resources” by clicking on “OK.”
16 When prompted, set the path to your Windows 95 SR2 files and click on
“OK.”
17 Click on “YES” to complete installation and restart the machine.
