Honeywell MM14CHCSCS Manuel utilisateur
OWNER’S MANUAL
Voltage rating: 120V~60Hz
Power rating : 1400W(Cooling)
Power rating : 1350W(Heating)
Portable Air Conditioner
Model: MM14CHCSCS
Customer Support : 1-800-474-21477
For product inquiries or support : www.honeywellportableac.com Made in China
Read these instructions before use
THANK YOU.....................................................................................................
INDEX .............................................................................................................. 1
2
3
4
6
7
13
15
16
USER TIPS........................................................................................................
SAFETY ............................................................................................................
PARTS DESCRIPTION.....................................................................................
INSTALLATION.................................................................................................
10
USE & OPERATION..........................................................................................
CLEANING & MAINTENANCE..........................................................................
TROUBLESHOOTING GUIDE...........................................................................
14
WATER DRAINAGE..........................................................................................
TECHNICAL SPECIFICATIONS.........................................................................
17
SERVICE AND WARRANTY .............................................................................
2.
1.
3.
4.
5.
6.
7.
8.
10.
9.
11.
12.
SECTION PAGE
Read all instructions carefully before setting up and operating the unit. Please keep
this instruction manual for future reference. This manual is designed to provide you
with important information needed to setup, operate, maintain and troubleshoot your
portable air conditioner. Failure to follow these instructions may damage and/or impair
operation and void the warranty.
1
INDEX
2
THANK YOU
Congratulations on your purchase of this versatile Honeywell Portable Air Conditioner.
Honeywell Portable Air Conditioners are ideal for spot cooling. The compressor,
condenser and evaporator are housed in a compact unit. The air is filtered, dehumidified
and cooled while a flexible air outlet hose sends heat outside. The air conditioner
includes a window venting kit. No permanent installation is needed so the unit is easy to
move from room to room and offers a truly flexible air conditioning solution.
Auto Evaporation System - The unit automatically evaporates the condensate through
the air outlet hose. No need to empty the drainage tank except in very high humidity
conditions.
This Honeywell model MM14CHCS is equipped with a built-in Heat Pump, This efficient
technology allowed the MM14CHCS to convert cooling to heating for year around
comfort at the touch of a button or from the included remote control.
Please read the instructions carefully.
Cooling, Dehumidifying function Fan function
Important : After transporting the unit, place it UPRIGHT for 20 min.
before use to allow the refrigerant to stabilize.
Check that the unit is complete with all accessories as outlined in this
instruction manual.
Follow installation instructions to set up your unit.
Plug the unit into a properly grounded circuit.
To ensure optimal efficiency of the product, we recommend keeping doors and
windows closed when it is used as an air conditioner or dehumidifier.
If the product is being used with the fan function only, please position the unit near an
open window so that outside air is drawn into the unit, the air circulates in the room and
then exits via the door.
3
USER TIPS
4
SAFETY
READ AND SAVE THESE INSTRUCTIONS
Improper handling can cause serious damage to the appliance.
WARNING
7.
6.
5.
4.
3.
2.
1.
Unplug the unit when stored or not in use.
If service is needed contact an authorized service agent.
Always turn off and unplug the unit when cleaning or servicing.
DO NOT place objects on or sit on the unit.
This appliance is not intended for use by children. Children should be supervised
and should not play on or around the appliance.
DO NOT cover the air intake and exhaust when in use.
DO NOT operate the unit with a damaged plug or loose socket point. If the power
cord is damaged, it must be replaced by the manufacturer or an authorized service agent.
5
SAFETY
Use caution to prevent tripping on cord.
DO NOT use in areas where gasoline, paint or other flammable goods are stored.
11. Basic safety precautions should always be followed when using electrical appliances.
10.
DO NOT run the power cord under carpeting and rugs.
8.
9.
PARTS DESCRIPTION
124
5
3
x 1
x 1
x 2 x 1
Installation Kit :
1. Window Bracket Kit.............................
2. Window Bracket Panel Adapter..........
3. Plastic Screws....................................
4. Hose Connector..................................
5. Plastic Hose........................................
1 Set
1 Piece
2 Pieces
1 Piece
1 Piece
6
1. Control Panel ( Incl. Signal Receptor)
2. Air Outlet
3. Handle
4. Caster
5. Water Drain Cap (De-humidifier mode)
6. Air Filter
7. Back grill
8. Water drain Cap (Air Conditioning Mode)
9. Power Supply Cord
10. Hose Connector
11. Remote Control (Batteries not included)
1
2
6
7
5
4
310
11
9
8
1
2
Plastic Screw
7
INSTALLATION
Push-in Rotate
=
Install the plastic hose with window bracket adapter and hose connector on both sides.
Ensure proper fit on both ends.
Adjust the window bracket as per width or height of your window and insert a plastic screw
to fix at the desired position.
Note : Do not install the window
bracket to your window. This step
is required only to adjust it to the
size of your window. The bracket
should be removed from the window
after the size is adjusted.
Connect the plastic hose to the hose connector on back of the unit.
4
8
INSTALLATION
Connect the window bracket to the opposite end of the plastic hose. Ensure that
connections are tight and installed properly.
5Connect the window bracket to the window.
The Portable Air Conditioner is now ready to use.
9
NOTE:
1. The supplied exhaust hose can be extended from 12 inches (1 feet) to 47 inches
(3.9 feet).
RECOMMENDEDNOT RECOMMENDED
Warning:
• The length of the exhaust hose is designed acording to the product specifications.
Do not replace or lengthen it with any other pipe or hose as this could cause the
unit to malfunction.
• Make sure the back of the unit is at least 20 inches away from a wall.
Do not place the unit in front of curtains or drapes as this could obstruct the airflow.
MIN.
20”
35 cm
MAX. 100 cm
INSTALLATION
2. Do not bend (to the extent shown below) the exhaust hose.
A bent hose will block exhaust air and cause the unit to malfunction or shut-off.
