Honeywell HW4CEDAWW0 Manuel utilisateur

Model / Modèle / Modelo:

HW4CEDAWW0

Portable Air Conditioner

User Manual

Read and save these instructions before use

Climatiseur portatif

Mode d’emploi

Lire ces consignes avant l’utilisation de l’appareil et les conserver

Aire Acondicionado Portátil

Manual del Usuario

Lea y guarde estas instrucciones antes de usar la unidad

Customer Support:

Assistance Au Client:

Servicio de atencion a clientes:

Web: www.jmatek.com

USA: 1-800-474-2147 | [email protected]

CANADA^: [email protected]

^ Canada Customer Support service available for models sold in Canada only.

^ Le Service Client Canadien est disponible uniquement pour les modèles vendus sur le territoire Canadien.

^ Servicio de Atención A Clientes en Canadá disponible solo para modelos vendidos en Canadá.

•

DO NOT operate the unit with a damaged plug or loose wall

outlet. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed persons in

order to avoid a hazard.

DO NOT cover the air intake and exhaust when in use.

DO NOT place objects on or sit on the unit.

Always turn off and unplug the unit when cleaning or servicing.

DO NOT use the appliance if it is damaged.

If service is needed contact an authorized service agent.

Unplug the unit when stored or not in use.

DO NOT pull or carry the appliance by the power cord.

DO NOT pinch the power cord in the door and DO NOT pull it

along edges or sharp corners.

DO NOT run the power cord under carpeting and rugs.

Use caution to prevent tripping on cord.

DO NOT use the device in the following cases:

- Near a ﬁre source

- In areas where gasoline, paint or other ﬂammable

goods are stored

- In an area where the water can be projected

DO NOT touch the plug or the device with wet hands.

Basic safety precautions should always be followed when using

electrical appliances.

This appliance has been manufactured for use in domestic

environments and should not be used for other purposes.

SAFETY

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND

KEEP FOR FUTURE REFERENCE. IN CASE THERE IS ANY

INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH

VERSION AND ANY OTHER LANGUAGE VERSION OF THE

CONTENT OF THIS MATERIAL, THE ENGLISH VERSION SHALL

PREVAIL.

WARNING:

SAFETY (CONTINUED)

Only use the installation kit provided to install this unit.

DO NOT attempt to extend the hose or install this unit using

other methods other than those shown in this manual.

Improper installation will void any existing warranties.

DO NOT use an extension cord with this unit.

This appliance can be used by children aged from 8 years and

above, and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

Never insert your ﬁngers or rods into the air outlet. Take special

care to warn children of these dangers.

The manufacturer is not liable for injury caused to persons or

property damage due to non-compliance with maintenance

instructions and improper use of the appliance.

The appliance shall be installed in accordance with national

wiring regulations.

The appliance is not to be used by persons (including children)

with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given

supervision or instruction.

Children should be supervised to ensure that they do not play

with the appliance.

Electrical equipment and installations regulated by national

legislation must be followed.

The appliance should be transported upright.

DO NOT turn on the appliance for at least one hour before ﬁrst

use.

It is essential that the appliance is connected to an efﬁcient

ground connection checked by a qualiﬁed electrician.

•

SAFETY (CONTINUED)

•

Stagnation of possible leaks of refrigerant gas in unventilated

rooms could lead to ﬁre or an explosion hazard should the

refrigerant come in contact with electric heaters, stoves or other

sources of ignition.

Use care when storing the appliance to prevent mechanical

faults.

Only persons authorized by an accredited agency certifying their

competence to handle refrigerants in compliance with sector

legislation should work on refrigerant circuits.

DO NOT use means to accelerate the defrosting process

or to clean the unit other than those recommended by the

manufacturer.

Flammable substances or pressurized containers (e.g. aerosol

cans) should be kept a minimum of 1.7 feet (50 cm) away from

heat or ﬁre.

Use only implements recommended by the manufacturer for

defrosting or cleaning.

DO NOT operate your air conditioner in a wet room such as a

bathroom or laundry room.

This appliance should be used in a room that allows for good

ventilation between the unit and any walls/furniture or other

objects. The room size should correspond to the room area as

speciﬁed for operation by the manufacturer and the appliance

should be well kept to prevent mechanical damage.

Keep ventilation openings clear of obstructions.

Do not pierce or burn the refrigerants.

Be aware that refrigerants may not contain an odor.

Do not modify this appliance in any way so as to avoid danger.

All working procedures that affect safety shall only be carried out

by competent persons.

SYMBOL NOTE EXPLANATION

WARNING

This symbol shows that this

appliance uses a ﬂammable

refrigerant. If the refrigerant

is leaked and exposed to

an external ignition source,

there is a risk of ﬁre.

CAUTION

This symbol shows that the

operation manual should be

read carefully.

CAUTION

This symbol shows that a

service personnel should be

handling this equipment with

reference to the installation

manual.

CAUTION

This symbol shows that

information is available such

as the operating manual or

installation manual.

R290/R32 SAFETY

R290

R32

A2L

R290/R32 SAFETY

Read the instructions carefully before using the appliance.

R290/R32 refrigerant gas complies with UL60335-2-40 /

UL60335-1.

This appliance contains a certain number of grams (see rating

label at the back of the unit) of R290/R32 refrigerant gas. The

maximum refrigerant charge amount is not greater than R290

0.304kg / R32 1.84 kg based on UL60335-2-40.

When defrosting or cleaning, do not use any method other than

those recommended by the manufacturer.

Do not place the appliance in a room with continuous sources

of ignition (e.g. open ﬂame, operating gas appliance or working

electrical heater).

Do not pierce and do not burn.

Do not perforate any part of the refrigerant circuit.

Refrigerant gas may be odorless.

The appliance must be installed, used and stored in an area that

is greater than R290 gas: 15 m²; R32 gas: 4 m².

Accumulation of possible refrigerant leaks in an unventilated

room could lead to ﬁre or explosion should the refrigerant

come in contact with electric heaters, stoves or other sources of

ignition.

The appliance must be stored in a way to prevent mechanical

damage and in a well-vented area.

Only individuals authorized by an accredited organization

certifying their competence to handle refrigerants in compliance

with industry legislation should work on the refrigerant circuit.

Servicing shall be performed only as recommended by the

manufacturer.

All working procedures that affect safety means shall only be

carried by competent persons.

Additional warnings for appliances with R290/R32 refrigerant gas.

•

Repair must be performed based on the recommendations from the manufacturer.

Maintenance and repair that requires the assistance of other qualiﬁed personnel must be

performed under the supervision of specialists in the use of ﬂammable refrigerants.

This marking indicates that this product should not be disposed with other household

waste throughout the US. To prevent possible harm to the environment or human

health from uncontrolled waste disposal, recycle it responsibly to promote the

sustainable reuse of material resources. To return your used device, please use return

and collection systems or contact the retailer where the product was purchased. They

can take this product for environmentally safe recycling.

Transport of equipment containing ﬂammable refrigerants must

comply with local transport regulations.

Marketing of equipment using signs must comply with local

regulations.

Disposal of equipment using ﬂammable refrigerants must

comply with national regulations.

The storage of equipment should be in accordance with the

manufacturer’s instructions.

Storage package protection should be constructed such that

mechanical damage to the equipment inside the package will

not cause a leak of the refrigerant charge.

The maximum number of pieces of equipment permitted to be

stored together will be determined by local regulations.

Transportation, marking and storage for units.

R290/R32 SAFETY

THANK YOU

USER TIPS

Congratulations on your purchase of this Honeywell Portable Air Conditioner.

Regarding the information pertaining to the installation, handling, servicing, cleaning and disposal

of the appliance, please refer to the below section of the manual.

Portable Air Conditioners are ideal for spot cooling. The compressor, condenser and evaporator

are housed in a compact unit. The air is dehumidiﬁed and cooled while a ﬂexible Hose sends heat

outside. The air conditioner includes a window venting kit. No permanent installation is needed. The

unit is easy to move from room to room and offers a truly ﬂexible air conditioning solution.

Auto Evaporation System - The unit automatically evaporates the condensate through the Hose.

There is no need to empty the drainage tank except in very humid conditions. Read and follow the

instructions carefully.

To ensure optimal efﬁciency of the product, keep doors and windows closed when it is used as an air

conditioner or dehumidiﬁer. If the product is being used with the fan function only, an open window

could improve air circulation.

Important:

Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.

Manually adjust the air vent located at the front of the unit to adjust the direction of air ﬂow.

Follow installation instructions to set up the unit.

Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.

•

Fan Operation

Cooling, Heating* and Dehumidifying

Operation

*Applicable for models with Heating feature only.

PARTS DESCRIPTION

1) Air Outlet 7) Remote Control

2) Control Panel

(Includes signal receptor)

8) Power Supply Cord

3) Handle 9) Air Intake Connector

4) Casters 10) Lower Drain Plug with Plastic Cap

(Air Conditioning Mode)

5) Upper Grill

6) Exhaust Hose Connector

3EN

INSTALLATION

It is important that the installation instructions below are followed for successful installation of this

Portable Air Conditioner. Please call Customer Support if you have any difﬁculties or questions

regarding these installation procedures.

Installation Kit:

Installation Steps:

The Exhaust Hose and Window Bracket Panel Adapter are pre-assembled inside the package.

The Exhaust Hose and Exhaust Hose Connector require assembly. Please follow the below

steps:

Expand the unassembled end of hose 4” to 8” then carefully thread Hose connections .

Rotate the Hose connector counter clockwise for 3 or 4 turns until threading is complete.

1. Window Bracket Kit (1 Set) 4. Hole Covers (2 Pieces)

2. Window Bracket Panel Adapters (2 Pieces) 5. Exhaust Hoses (2 Pieces)

3. Exhaust Hose Connectors (2 Pieces) 6. Butterﬂy Screws (2 Pieces)

1 3

x1 x2 x2

Exhaust Hose:

Length: 12" to 47" (30 cm to 120 cm)

5 3

x2 x2

4 5

4" to 8"

(10 cm to 20 cm)

1.2.

Table des matières

Langues :

Autres manuels Honeywell Climatiseur

Honeywell

Honeywell MN09 Series Manuel utilisateur

Honeywell

Honeywell CL30XC Manuel utilisateur

Honeywell

Honeywell HJ12CESV Series Manuel utilisateur

Honeywell

Honeywell CL60PM Series Manuel utilisateur

Honeywell

Honeywell CL25AE Manuel utilisateur

Honeywell

Honeywell MP08 Series Manuel utilisateur

Honeywell

Honeywell CL30XCWW Manuel utilisateur

Honeywell

Honeywell MN10 Series Manuel utilisateur

Honeywell

Honeywell HM2CESSWK8 Manuel utilisateur

Honeywell

Honeywell MM14CCSBB Manuel utilisateur

Honeywell

Honeywell CO25AE Manuel utilisateur

Honeywell

Honeywell HJ0CESWK7 Manuel utilisateur

Honeywell

Honeywell CL151 Manuel utilisateur

Honeywell

Honeywell CL610PM Manuel utilisateur

Honeywell

Honeywell HC09CESAWK Manuel utilisateur

Honeywell

Honeywell CS071AE Manuel utilisateur

Honeywell

Honeywell R-MM14CCS Manuel utilisateur

Honeywell

Honeywell CS10PE Manuel utilisateur

Honeywell

Honeywell R-MM14CHCSCS Manuel utilisateur

Honeywell

Honeywell HF Series Manuel utilisateur

Honeywell

Honeywell MN12CES Manuel utilisateur

Honeywell

Honeywell CL201AE Manuel utilisateur

Honeywell

Honeywell AMH-10000E Manuel utilisateur

Honeywell

Honeywell CO30XE Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
