ASSEMBLY INSTRUCTION

824-024V80

READ AND SAVE THIS INSTRUCTION FOR FUTURE USE

824-024V80 110-120V~,60HZ

EN:STAND FAN WITH REMOTE CONTROL

FR:VENTILATEUR SUR PIED A TÉLÉCOMMANDE

Specifications/Spécifications

IN220901728V01_US_

MODÈLE N°

TENSION NOMINALE PUISSANCE

NOMINALE

IMPORTANT SAFEGUARDS

When using an electrical appliance, basic safety precautions should

always be observed, including the following:

READ ALL INSTRUCTIONS BEFORE USING

WARNING: To reduce the risk of fire, electrical shock, or

injury to person:

1. This fan is for household use only.

2. Before using for the first time, please check that your voltage is in

accordance with the product nameplate requirements.

3. Please check the power cord and plug for any damage before use.

4. Always turn the fan OFF and unplug it from the electrical outlet when not

in use.

5. Caution is necessary when the appliance is used near children.

6. Do not run the power cord under carpeting and do not cover the cord

with throw rugs. Do not route cord under furniture or appliances. Arrange

cord away from traffic areas so that it will not be tripped over.

7. Do not operate any fan with a damaged cord or plug. Discard fan or

return to an authorized service facility for examination and or repair.

8. If the fan’s power supply cord is damaged, it must be replaced by the

manufacturer or its service agent to avoid a safety hazard.

9. Use the fan in a well-ventilated area. When in use, place the fan at least

8 inches from any walls to ensure proper air flow. The fan must not be

located immediately below or beside a curtain.

10. Do not obstruct the airflow with any objects or place anything inside the

fan opening.

11. Do not use in areas where curtains could be sucked in.

12. Only place the fan on a hard, flat, dry floor.

13.Do not use in extreme temperatures, humidity, or dusty environments.

14.Do not place heavy objects on the fan.

15. Do not place the fan directly below a power outlet or you risk the cord

being sucked in.

16.When the fan is oscillating do not manually turn the fan to avoid

damage.

17. Always turn off the power supply before unplugging the power cord

from the electrical outlet to prevent a short circuit, fire or electric shock.

18. Do not twist or pull the power cord.

19. Do not unplug the fan if your hands are wet, there is danger of electric

shock.

20. Children under 8 should not operate the fan.

21. This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

22. Children should be supervised to ensure that they do not play with the

appliance.

23. Ensure that the fan is switched off from the supply mains before

removing the guard.

24. To reduce the risk of fire or electric shock, do not use this fan with any

solid-state speed control device.

25. Please unplug or disconnect the appliance from the power supply

before servicing.

26. This product employs overload protection (fuse). A blown fuse

indicates an overload or short-circuit situation. If the fuse blows, unplug the

product from the outlet. Replace the fuse as per the user servicing

instructions (follow product marking for proper fuse rating) and check the

product. If the replacement fuse blows, a short-circuit may be present and

the product should be discarded or returned to an authorized service

facility for examination and /or repair.

Warning:

This appliance has a polarized plug (one blade is wider than the other). To

reduce the risk of electric shock, this plug is intended to fit in a polarized

outlet only one way. If the plug does not fit fully into the electric receptacle,

reverse the plug. If it still does not fit, contact a qualified electrician. Do not

attempt to subvert this safety feature.

To Change the fuse

The following should ONLY be conducted by a qualified professional:

1. Grasp plug and remove from the electrical receptacle. Do not unplug

by pulling on the cord.

2. Open the fuse cover by sliding the fuse access cover on the top of the

plug toward the blades as shown in the diagram below.

3. Remove fuse carefully. Push the fuse from the other side or turn fuse

holder upside down to remove fuse.

4. Risk of fire. Replace the fuse only with 5 Amp, 125 Volt fuse.

5. Close fuse cover by sliding the fuse access cover on the top of the plug

away from the blades.

6. Risk of fire. Do not replace the polarized plug as it contains a safety

device that should not be removed.

Discard product if the polarized plug is damaged.

Structure and parts

1. Front grill

2. Blade fasten nut

3. Blade

4. Grill fasten nut

5. Back grill

6. Dam-board

7. Motor cover

8. Back control box

9. Control panel

10. Bolt

11. Power cable

12. Adjustable tube

13. Fixing tube clamp

14. Tube

15. Base

16. Gasket

17. L shape screw

Assembly Instructions

The fan is packaged with its grills un-attached. You must attach the grills

before operating the fan.

WARNING: Never operate the fan without its foundation and other

parts. The fan must only operate in the up-right position, and any

other position will be hazardous.

Do operate the fan only in upright position; any other position could create

a hazardous situation.

Assemble the foundation and other parts of the appliance in the following

sequence:

a). Unpack the fan and remove all parts from the package

b). Use the grill fasten nut(4) for the back grill(5) to attach the back grill(5)

to the fan head, and then use the blade fasten nut(2) for the fan leaf to hold

the fan leaf in place.

c). To attach the front grill(1) to the back grill(5), you must use the grill ring

carefully to hold them together, and fasten the grill ring with the screw

provided.

d).insert the tube(14) into the base’s hole(15), place the gasket(16) under

the base(15) and tighten L shape screw(17).

e). Loosen fixing tube clamp(3), then pull up adjustable tube(12), and

tighten fixing tube clamp(13), then put the adjustable tube(12) into control

panel(9), and tighten bolt(10).

Operating Instructions

Control panel Remote control

1. Before using the fan, make sure that it is on a flat and stable surface.

Damage may occur if the fan is placed on an incline or decline.

2. Set all the switches to the “OFF” position, and then insert the plug

directly into a standard AC socket-outlet. Be sure that the plug fits tightly

into the socket-outlet.

3. Press “power button”on the remote or on control panel to start the fan.

And the power screen will be lighted on.

Press “speed button”to select the fan speed level: The screen will show

F1,F1,F2,F3 to make a circle.

Press Mode button to select the fan mode: “NORMAL”wind, “NATURAL”

wind , “SLEEP”wind.

Press timer button to set timer from 1hour to 15 hour.

To stop the fan, just press the button “OFF”on remote or “ ” on control

panel.

4. If you want to increase the blast area in your room, press ‘Swing button”

on remote, and the fan will oscillate and blast your room in large scope. To

stop oscillating, just press it again. Moving the fan head either up or down

will change the direction of the wind.

5. Remove the plug from the socket-outlet to completely shut the fan off.

Cleaning / Maintenance Instructions

To safely take care of your fan, please remember to follow these

instructions below:

1. Always remove the plug from the socket-outlet, and allow the fan to stop

completely before cleaning the fan.

2. Do not allow water to drip on, or enter into the fan housing.

3. Always use a soft cloth, moistened with a mild soap solution.

4. Do not use any of the following agents as a cleaner: Gasoline, Thinners,

or Benzene.

5. In case of malfunction or doubt, do not try to repair the fan yourself, it

may result in a fire hazard or electric shock.

FAN Cleaning

Clean the fan grill, housing and base with a soft damp cloth. Do not attempt

to remove the fan blades. Please use caution around the motor housing

area. Do not allow the motor, or other electrical components to be exposed

to water.

FAN Storage

When storing your fan in the off-season, it is important to keep it in a safe

dry location. It is important to protect the fan head from any dust. We

strongly recommend using the original box, when storing the fan away.

If you have any questions, please contact our customer

care center.

Our contact details are below:

001-877-644-9366

customerservice@aosom.com

PRÉCAUTIONS IMPORTANTES

Lors de l'utilisation d'un appareil électrique, des précautions de base doivent

toujours être prises, notamment les suivantes :

LIRE TOUTES LES INSTRUCTIONS AVANT D'UTILISER L'APPAREIL

AVERTISSEMENT : pour réduire les risques d'incendie, de choc

électrique ou de blessure :

1. Ce ventilateur est destinéàun usage domestique uniquement.

2. Avant la première utilisation, veuillez vérifier que votre tension est conforme

aux exigences de la plaque signalétique du produit.

3. Veuillez vérifier si le cordon d'alimentation et la prise ne sont pas

endommagés avant l'utilisation.

4. Éteignez toujours le ventilateur et débranchez-le de la prise électrique

lorsque vous ne l'utilisez pas.

5. La prudence est de rigueur lorsque l'appareil est utilisé à proximité

d'enfants.

6. Ne faites pas passer le cordon d'alimentation sous une moquette et ne

recouvrez pas le cordon d'un tapis àpoils longs, d'un tapis de course ou d'un

revêtement similaire. Ne faites pas passer le cordon sous les meubles ou les

appareils électroménagers. Placez le cordon àl'écart des zones de circulation

afin que personne ne puisse trébucher dessus.

7. Ne faites pas fonctionner un ventilateur dont le cordon ou la fiche est

endommagé. Jetez le ventilateur ou renvoyez-le à un service autorisé pour

examen et/ou réparation.

8. Si le cordon d'alimentation du ventilateur est endommagé, il doit être

remplacépar le fabricant ou son agent de service afin d'éviter tout risque de

sécurité.

9. Utilisez le ventilateur dans un endroit bien ventilé. Lorsqu'il est utilisé,

placez le ventilateur àau moins 8 pouces de tout mur pour assurer une bonne

circulation d'air. Le ventilateur ne doit pas être placé immédiatement en

dessous ou àcôtéd'un rideau.

10. N'obstruez pas la circulation de l'air avec des objets ou ne placez rien à

l'intérieur de l'ouverture du ventilateur.

Table des matières

Langues :

Autres manuels HOMCOM Ventilateur

HOMCOM

HOMCOM 824-003 Manuel utilisateur

HOMCOM

HOMCOM B31-394 Guide d'installation

HOMCOM

HOMCOM 820-297V90 Manuel utilisateur

HOMCOM

HOMCOM 824-058V70 Guide d'installation

HOMCOM

HOMCOM 824-055V90 Guide d'installation

HOMCOM

HOMCOM 824-012V70 Manuel utilisateur

HOMCOM

HOMCOM 824-006V90 Manuel utilisateur

HOMCOM

HOMCOM 824-051V91 Guide d'installation

HOMCOM

HOMCOM 824-026V70 Manuel utilisateur

HOMCOM

HOMCOM 824-049V80 Guide d'installation

HOMCOM

HOMCOM 824-049V80 Manuel utilisateur

HOMCOM

HOMCOM 824-032V70 Guide d'installation

HOMCOM

HOMCOM 824-062V90 Manuel utilisateur

HOMCOM

HOMCOM 824-060V90 Manuel utilisateur

HOMCOM

HOMCOM 824-014V70 Manuel

HOMCOM

HOMCOM 824-013V70 Manuel utilisateur

HOMCOM

HOMCOM 824-043V70 Guide d'installation

HOMCOM

HOMCOM B31-390V80 Guide d'installation

HOMCOM

HOMCOM B31-391 Guide d'installation

HOMCOM

HOMCOM 824-023V70 Manuel utilisateur

HOMCOM

HOMCOM 824-046V80 Guide d'installation

HOMCOM

HOMCOM 824-018 Manuel utilisateur

HOMCOM

HOMCOM B31-395V80 Guide d'installation

HOMCOM

HOMCOM 824-021 Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
