Introduction

Thanks for choosing our Aspect Wi-Fi Analyst. This

system gathers and automatically uploads accurate

and detailed weather data to Weather Underground,

where you can access and upload your weather data.

This product offers professional weather observers

or serious weather enthusiasts robust performance

with a wide range of options and sensors.

The Aspect Wi-Fi Analyst transmits indoor/

outdoor temperature, humidity, wind and rain data.

Both sensors are fully assembled and calibrated

for your easy installation. They send data at a

low power radio frequency to the Main Console

from up to 150m/450 feet away (line of sight).

A high-speed processor is embedded in the

Main Console which analyses real-time data.

This can be published to Weather Underground

through your home Wi-Fi router.

The Main Console can also synchronise with an

internet time server to keep the time and weather

data time stamp at high precision. The colour

background LCD display shows informative weather

readings with advanced features, such as high/

low alert alarm, different weather index, and MAX/

MIN records. With calibration and moon phase

features, this system is truly a remarkably personal yet

professional weather station for your own backyard.

This instruction manual contains useful information

on the proper use and care of this product. Please

read this manual thoroughly to fully understand and

enjoy its features, and keep it handy for future use.

4 of 20

Overview

Main Console

LCD Display

1. Table stand

2. SNOOZE

3. CHANNEL

4. HISTORY

5. MAX/MIN

6. WIND

7. INDEX

8. BARO

9. RAIN

10. LCD display

11. CLOCK SET

12. ALARM

13. Wall mount

14. ALERT

15. 

16. 

17. Power jack

18. 12/24

19. °C/°F

20. BARO UNIT

21. SENSOR/Wi-Fi

22. REFRESH

23. Battery compartment

24. OFF/LO/HI

25. RESET

1. Indoor/CH temperature and humidity

2. Weather forecast

3. Time, calendar the moon phase

4. Wind direction then speed

5. Outdoor temperature then humidity

6. Barometer

7. Rainfall

8. Weather index

5 of 20

5-in-1 Wireless Outdoor Sensor

Rain Gauge

1. Rain collector

2. Tipping bucket

3. Rain sensor

4. Drain holes

Temperature/Humidity Sensor

1. Louvre shield Sensor casing

2. Temperature and humidity

sensor (inside the louvre shield)

Wind Sensor

1. Wind cups (anemometer)

2. Wind vane

1. Rain collector

2. Balance indicator

3. Antenna

4. Wind cups

5. Mounting pole

6. Louvre shield

7. Wind vane

8. Mounting base

9. Mounting clamp

10. Red LED indicator

11. RESET

12. Battery door

13. Screws

Overview (continued)

6 of 20

Install Batteries:

1. Unscrew the battery door at bottom of

unit and insert the batteries according

to the +/- polarity indicated.

2. Screw the battery door compartment on tightly.

Ensure the water tight o-ring is properly

aligned in place to ensure water resistance.

The red LED will begin ﬂashing every 12 seconds.

Assembly of Stand and Pole:

Positioning: Install the 5-in-1 Wireless Outdoor Sensor in an

open location with no obstructions above and around the sensor

for accurate rain and wind measurement. Install the sensor with

the smaller end facing the South to properly orient the wind

direction vane. Secure the mounting stand and bracket (included)

to a post or pole, and allow minimum 1.5m off the ground.

Installation and Setup

5-in-1 Wireless Outdoor Sensor

1. Insert the top side

of the pole to the

square hole of the

weather sensor.

Ensure the pole

and sensor's

indicator align.

2. Place the nut in the

hexagon hole on the

sensor, then insert

the screw in other

side and tighten it

with a screw driver.

3. Insert the other

side of the pole to

the square hole of

the plastic stand.

Ensure the pole and

stand indicator align.

4. Place the nut in

the hexagon hole

of the stand, then

insert the screw

in other side and

then tighten it with

a screw driver.

7 of 20

Install Backup Battery:

1. Remove the battery door of the Main Console.

2. Insert a new button cell battery.

3. Replace the battery door.

Backups from Battery:

Time and Date

Max/Min and Past 24 Hours Records

Alert Setting Values

Offset Value of Weather Data and

Sensor Channel History

Built-in Backups:

Router Settings

Weather Server Settings

Main Console Power-up:

1. Plug the power adaptor to power

up the Main Console.

2. Once the Main Console has powered, up, all

the segments of the LCD will be shown.

3. The Main Console will automatically start AP Mode

If no display appears on the LCD after you plug the

adaptor, press RESET using a pointed object.

Setting LCD Viewing Angle: Press or in

Normal Mode to adjust LCD viewing angle to

ﬁt table stand or wall mount situation.

Main Console Pairing

After inserting batteries, the Main Console will

automatically search and connect the wireless

5-in-1 Wireless Outdoor Sensor (the sensor

antenna icon blinking). Once the connection is

successful, the antenna icon and readings for

outdoor temperature and humidity, wind speed,

wind direction and rainfall will appear on the LCD.

Changing Batteries and Manual Pairing

Whenever batteries are changed in the

5-in-1 Wireless Outdoor Sensor,

pairing must be done manually.

1. Replace all the batteries in the sensor.

2. Press SENSOR/Wi-Fi on the Main Console.

3. Press RESET on the

5-in-1 Wireless Outdoor Sensor

Installation and Setup (continued)

Wi-Fi Connection Setup

To connect this Aspect Wi-Fi Analyst to Wi-Fi, it

must be registered with Weather Underground.

Weather Underground setup instructions

are correct as of January 2019. Refer to

https://www.wunderground.com/ for details

if their registration process has changed.

with Weather Underground:

1. Visit https://www.wunderground.com/ and click

JOIN in the top right corner and follow the prompts

to create an account. Note that your email address

must be validated by Weather Underground before

proceeding. If you already have an account with

Weather Underground you can simply LOG IN.

2. After logging in to your account, click MYPROFILE

and select MYWEATHERSTATIONS in the menu.

On the following page, click ADDANEWPWS.

8 of 20

Installation and Setup (continued)

Wi-Fi Connection Setup (continued)

On the next page, note it is essential to jot down the LONGITUDE/LATITUDE for your reference later.

3. After noting the LONGITUDE/LATITUDE, follow the prompts to complete registration

of your Aspect Wi-Fi Analyst with Weather Underground.

After submitting your details, note it is essential to jot down your STATION ID and STATION KEY/PASSWORD.

4. When you ﬁrst power up the Main Console, or press and hold the SENSOR/Wi-Fi for 6

seconds in Normal Mode, the Main Console LCD will show AP and the Wi-FiIconto

signify that it has entered AP (Access Point) Mode, and is ready for Wi-Fi settings.

5. Using your device, connect to the Main Console via Wi-Fi. In the device Wi-Fi connection settings,

select the Main Console SSID (PWS-XXXXXX) and wait several seconds for connection.

6. Once connected, open the web browser on your device, type 192.168.1.1 into the

address bar and press ENTER to access the Main Console setup interface.

7. Enter the following information into the Main Console setup interface. If you choose

not to use Weather Underground, leave the check boxes unchecked.

When Wi-Fi setup is complete, your device should resume your default Wi-Fi connection.

During AP Mode, you can press and hold SENSOR/Wi-Fi for 6 seconds to stop

AP Mode and the Main Console will restore your previous setting.

9 of 20

Installation and Setup (continued)

Wi-Fi Connection Status

Time Server Connection Status

After the Main Console has connected to the internet, it will attempt to connect to

the internet time server to obtain the UTC time. Once the connection succeeds and the

Main Console time has been updated, the SYNC icon will appear on the LCD.

Time Zone: To display the time of your time zone, change the time zone in

Clock Setting Mode from '00' (default) to your time zone (e.g. 08 for Perth).

1. Press and hold CLOCK SET for 2 seconds to enter Clock Setting Mode.

2. Press or to enter your time zone, then press and hold CLOCK SET to conﬁrm and exit.

The time will automatically synchronise with internet time server at 12:00AM and 12:00PM per

day. Also you can press REFRESH to get the internet time manually within 1 minute.

Calibration

Press ADVANCED at the top of web interface

to enter the advance setting page, this page

allow you to set and view the calibration

data. Firmware can also be updated here.

1. User may enter or change the

offset and gain values for different

measurement parameters while current

offset and gain values are shown

next to their corresponding boxes

2. Once completed, press APPLY in the

Setup page. To change offset values,

input the new value and press APPLY

Calibration of most parameters is

not required, with the exception

of Relative Pressure, which

must be calibrated to sea-level to

account for altitude effects.

10 of 20

Installation and Setup (continued)

Viewing Live Weather Data

To view live data from the wireless outdoor sensor in a web browser, visit https://www.wunderground.com/,

and enter your STATION ID in the search box. Weather information will show on the next page.

Firmware Update (Desktop Only)

The Main Console supports OTA ﬁrmware update

capability. Firmware may be updated through any

desktop web browser with Wi-Fi connectivity. Update

function is not available through mobile devices.

Two types of ﬁrmware updates are available, namely

Function Firmware and Wi-Fi Firmware, and are

located at the bottom of the ADVANCED page.

1. Download the latest version ﬁrmware

to your desktop computer.

2. Set the Main Console into AP Mode then

connect your desktop to the Main Console (refer

to Wi-Fi Connection Setup for more details).

3. To update Function Firmware, click BROWSE

in Function Firmware section and browse

to the location of the ﬁle you downloaded in

Step1 above. To update the Wi-Fi Firmware,

click BROWSE in Wi-Fi Firmware section.

4. Click the corresponding UPLOAD to start

transferring the ﬁrmware ﬁle to the Main Console

(indicated by a transfer completion %).

5. After the transfer, update process is indicated

on the Main Console as completion %. It

will restart once the update is complete.

Function Firmware and Wi-Fi Firmware

cannot be updated at the same time, you

need to update each one by one.

Keep power connected during the

ﬁrmware update process.

Ensure your desktop Wi-Fi connection

is stable during update process.

Once update process has started, do not

operate desktop or Main Console.

During ﬁrmware update, the Main Console will

stop uploading data. It will reconnect to your

Wi-Fi router and upload the data again once the

update has succeeded. If the Main Console

cannot reconnect to your Wi-Fi router, please

close the Setup page to start again.

After ﬁrmware updates, user might need to input the

Weather Underground ID and password again.

Table des matières

Autres manuels Holman Station météorologique

Holman

Holman 1110H Manuel utilisateur

Holman

Holman Aspect WS5029 Manuel utilisateur

Holman

Holman WS3022C Manuel utilisateur

Holman

Holman ASPECT Wi-Fi Solar Pro WS5091W-MKii Manuel utilisateur

Holman

Holman iWeather WS5029 Manuel utilisateur

Holman

Holman WS5019 Manuel utilisateur

Holman

Holman iWeather Manuel utilisateur

Holman

Holman WeatherWHIZ WS5001 Manuel utilisateur

Holman

Holman Foresight Manuel utilisateur

Holman

Holman iWeather WS2813A Manuel utilisateur

Holman

Holman iWeather WS5029 Manuel utilisateur

Holman

Holman Aspect Wi-Fi Solar Pro Manuel utilisateur

Holman

Holman HELIOS WS5095W Manuel utilisateur

Holman

Holman WS5056C Manuel utilisateur

Holman

Holman FORESIGHT PRO WEATHER ANALYST Manuel utilisateur

Holman

Holman weatherWHIZ WS5061 Manuel utilisateur

Holman

Holman iweather WS109A Manuel utilisateur

Holman

Holman Aspect Wi-Fi Solar Manuel utilisateur

Manuels Station météorologique populaires d'autres marques

Auriol

Auriol AHFL 433 A1 Manuel utilisateur

NexSens

NexSens G2-HYDROMET Manuel utilisateur

Hyundai

Hyundai WS 2202 Manuel utilisateur

IROX

IROX HBVR761 UV-X Manuel utilisateur

La Crosse Technology

La Crosse Technology C86371 Manuel utilisateur

ADE

ADE WS 1711 Manuel utilisateur

Auriol

Auriol z29592 Manuel utilisateur

Auriol

Auriol 296289 Manuel utilisateur

Hyundai

Hyundai WS 2266 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-2210 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-811561 Manuel utilisateur

Ventus

Ventus W177 Manuel utilisateur

National Geographic

National Geographic VA Colour RC Manuel utilisateur

Renkforce

Renkforce 1208067 Manuel utilisateur

Levenhuk

Levenhuk Discovery Report WA40 Manuel utilisateur

Instant Transmission

Instant Transmission MA 10410 Manuel utilisateur

Lutron Electronics

Lutron Electronics PHB-318 Manuel utilisateur

WAREMA

WAREMA EWFS Weather station eco Manuel utilisateur
