HMS Anybus AS-Interface Master Manuel utilisateur

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

How to configure an Anybus AS-Interface

Master module

www.anybus.com HMS Industrial Networks AB

Page 1 (19)

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

www.anybus.com HMS Industrial Networks AB

Page 2 (19)

More info about the network and products

This document gives a brief description of how to configure an Anybus Master product for AS-Interface. For

further information about the products, please consult the HMS homepage, www.anybus.com. The latest

manuals etcetera can be downloaded from that location.

For more information regarding AS-Interface network please see the AS-Interface webpage,

http://www.as-interface.net.

Document history

Revision Date Description Responsible

1.00 2008-01-25 Created Thorbjörn Palm

1.01 2008-02-04 Minor revision Thorbjörn Palm

1.02 2008-02-15 Minor update Thorbjörn Palm

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

www.anybus.com HMS Industrial Networks AB

Page 3 (19)

Contents

1Solution overview .....................................................................................................................................4

2Applicable Anybus products ...................................................................................................................5

3Requirements ............................................................................................................................................5

4Anybus configuration...............................................................................................................................6

4.1 Anybus-M Master and PCI Master configuration.............................................................................6

4.2 Anybus X-gateway configuration .....................................................................................................7

5AS-Interface configuration......................................................................................................................9

5.1 Configuration using the Configuration Button .................................................................................9

5.2 Configuration using the Terminal Interface....................................................................................10

5.3 Memory Mapping ...........................................................................................................................14

6Testing .....................................................................................................................................................15

6.1 Monitoring using the Terminal Interface ........................................................................................15

6.2 Monitoring using ModScan32 ........................................................................................................18

6.3 Web interface..................................................................................................................................19

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

1Solution overview

This application note describes how to configure an Anybus AS-Interface Master module and how to set up

the AS-Interface network. Below you can find an overview of the system described in this document. Other

nodes may be attached to the network, but are not necessary.

The configuration is described in two steps.

1. The Anybus Master module configuration is explained.

2. The configuration of the AS-Interface network is described.

Note: This document is valid for all Anybus AS-Interface Master products, however sections written in

italics describe the configuration of a specific product.

The contents describe step by step how a configuration is done. This document assumes the reader is familiar

with industrial communication, AS-Interface networks and Anybus X-gateway.

Modbus-TCP

Anybus X-gateway

Other network

i.e. Modbus-TCP

AS-Interface

Master

Example of AS-Interface

network

AS-Interface

ModScan

AS-Interface

Anybus AS-Interface

Master PCI

Figure 1 Hardware connection overview.

www.anybus.com HMS Industrial Networks AB

Page 4 (19)

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

www.anybus.com HMS Industrial Networks AB

Page 5 (19)

2Applicable Anybus products

The following table specifies the relevant Anybus products for this document.

Description Name / Type

Anybus-M Master AS-Interface (Module software version higher than 2.04)

Anybus-M Master PCI AS-Interface (Module software version higher than 2.04)

Anybus X-gateway Master AS-Interface (Module software version higher than 2.04)

3Requirements

The following equipment is needed to setup a successful configuration.

Description Name / Type Version

Terminal software HyperTerminal, TeraTermPro 5.1, 2.3

X-gateway Interface Addendum X-gateway AS-Interface Master

Interface Addendum

2.10

X-gateway User Manual X-gateway User Manual 1.11

Master Fieldbus Appendix Anybus-M Master AS-Interface

Fieldbus Appendix

2.00

Power supply 24VDC n.a. n.a

Configuration cables n.a. n.a.

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

www.anybus.com HMS Industrial Networks AB

Page 6 (19)

4Anybus configuration

In the following chapters the configuration of the Anybus-M Master, PCI Master and X-gateway

AS-Interface Master are explained.

4.1 Anybus-M Master and PCI Master configuration

The Anybus-M Master and Anybus PCI Master are configured via the host application interface using the

mailbox interface. Refer to the Anybus-M Fieldbus Appendix for details.

The Anybus AS-Interface Master can also be auto configured by the Configuration Button and the Terminal

Interface. Please see section 5 AS-Interface configuration for details.

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

4.2 Anybus X-gateway configuration

Use the HyperTerminal on a PC to configure the X-gateway. Connect a serial cable between the PC and the

config port on the X-gateway (make sure that it is not connected to the AS-Interface Master). Start the

HyperTerminal and open the “File” menu and click on new, choose the desired COM port and then click on

OK. The following window will appear.

Figure 2 Configuring the connection in the HyperTerminal.

Make sure the settings are identical to those shown in the window above. Alternatively download a

HyperTerminal session file from the HMS website1, double click on it and select COM port.

Connect and press ESC and the following menu will appear.

Figure 3 Anybus X-gateway main menu.

Press 6 and enter the desired configuration.

1www.anybus.com

www.anybus.com HMS Industrial Networks AB

Page 7 (19)

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

The figure below shows an example; in this case an AS-Interface Master to Modbus-TCP Slave X-gateway is

used. 20 bytes of I/O data on the Modbus-TCP side and 312 bytes of I/O data on the AS-Interface side are

configured. Also byte mode is used in this configuration.

Note: The Input and Output data size is always set to 312 bytes and cannot be changed.

Data Representation:

This mode can be set to Byte Mode

or Nibble Mode.

Figure 4 The X-gateway configuration.

The next step is to set the X-gateway in running mode.

Running: AS-Interface network is

running and exchanging data.

Idle DE Active: AS-Interface

network is idle, but the

communication is still active.

Idle DE Inactive: AS-Interface

network is idle and no data exchange

messages are issued.

Figure 5 Changing Operation mode of the X-gateway.

Choosing 9 from the main menu the X-gateway can be set to Running, Idle DE Active or Idle DE Inactive.

Set the Operation Mode to Running.

www.anybus.com HMS Industrial Networks AB

Page 8 (19)

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

www.anybus.com HMS Industrial Networks AB

Page 9 (19)

5AS-Interface configuration

The AS-Interface Master configuration can be done in several ways.

1 The Configuration Button enables the auto configuration as described in section 5.1 Configuration using

the Configuration Button.

2 The Terminal Interface can also be used to configure the AS-Interface Master as described in section 5.2

Configuration using the Terminal Interface. Using this alternative it is possible to change the slave

parameters.

3 The configuration can also be done by using mailbox commands. Please see the Master Fieldbus

Appendix. Note: This alternative is usable only by Anybus-M AS-Interface Master and Anybus-M PCI AS-

Interface Master.

In the end of this chapter, section 5.3 Memory Mapping, the memory mapping is described in detail.

5.1 Configuration using the Configuration Button

This alternative assumes the AS-Interface network is connected to the Anybus Master. Please follow the

steps below.

1Changing to Configuration mode using the Configuration Button

This is done by pressing the Configuration Button for less than 2 seconds, which will toggle the mode

between Configuration and Protected mode. The Module Status/MS LED is solid green in Configuration

mode.

2Pressing the Configuration Button to upload and save the network configuration

Push and hold the Configuration Button for more than 5 seconds, this will enable the Auto Configuration.

3Changing to Protected mode

Press the Configuration button again for less than 2 seconds to change the mode to Protected mode.

4Network running

If the configuration is successful the network is now online and running. The Running/RUN LED is now

solid green and Network Status/NS LED and Module Status LED are flashing green. Auto prog./AUP LED

is off indicating no error.

How to configure an Anybus AS-Interface Master module

SCM-7032-036

Rev 1.02

5.2 Configuration using the Terminal Interface

The AS-Interface Master can also be configured using the Terminal Interface. Please follow the steps below.

1Connecting to the AS-Interface with a Terminal software

Use for example the HyperTerminal or TeraTermPro on a PC to configure the AS-Interface Master. Connect

a serial cable between the PC and the config port on the AS-Interface Master (make sure that it is not

connected to the gateway interface). The config port is located next to the AS-Interface network connectors

on the X-gateway. Start the HyperTerminal and connect using the same parameter settings as described in

section 4.2 Anybus X-gateway configuration.

2Opening the main menu

Figure 6 Entering the menu of the AS-Interface Master.

Press enter to open the configuration menu. Now the module is set to Idle mode, until the terminal is

removed.

Figure 7 The main menu of the AS-Interface Master.

www.anybus.com HMS Industrial Networks AB
