Disassembly &
Assembly Guide
CS-200e
Version: 1.0
The Disassembly & Assembly Guide is written mainly for engineers.
Do not reproduce or duplicate.
Confidential 2
Revision History
Date Revision Description Remark
2011/6 V1.0
The first release
Confidential 3
Index
Chapter 1. Disassembly & Assembly ...............................................................................................4
1. Safety Instructions..................................................................................................................4
2. Tools.........................................................................................................................................5
3. Do not disassemble These Parts...........................................................................................6
4. Disassembly............................................................................................................................7
4-1 Case of card printer & chassis.........................................................................................7
4-2 Main Board ....................................................................................................................14
4-3 Flipper Module...............................................................................................................16
4-4 Motors............................................................................................................................18
4-5 LED and Sensor ............................................................................................................23
4-6 Flipper: Sensors, Motor & Board....................................................................................36
4-7 Button Board & LCM Board...........................................................................................40
Chapter 2. Assembly & Alignment..................................................................................................41
1. Assembly...............................................................................................................................41
1-1 Screw List......................................................................................................................41
1-2 Cam Position .................................................................................................................43
Confidential 4
Chapter 1. Disassembly & Assembly
1. Safety Instructions
•Read these instructions carefully. Save these instructions for future reference.
•Follow all warnings and instructions marked on the printer.
•Unplug the printer from the wall outlet before disassembly.
•Do not place the printer on an unstable cart, stand, or table. The printer may get damaged by a fall.
•Openings in the chassis and the bottom are provided for ventilation purposes and to ensure
reliable operation of the printer by protecting it form overheating: these openings must not be blocked
or covered.
•Placing the printer on a bed, sofa, rug, or other similar, not firm surfaces may block the openings.
The printer should never be placed near or over a radiator or heat register, proper ventilation and
cooling must be provided at all times.
•The printer should only be operated with the type of power indicated on the marking label. If you
are not sure of the type of power available in your area, consult your dealer or local power company.
•If an extension cord is used with this product, make sure that the total ampere rating of the
equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also,
make sure that the total rating of all products plugged into the wall outlet does not exceed the fuse
rating.
Confidential 5
2. Tools
Tweezers Wire Cutter
Screwdriver– minus Screwdriver– plus
Confidential 6
3. Do not disassemble These Parts
HiTi strictly prohibits anyone to disassemble the TPH (Thermal Print Head) and the Platen Motor. Both
parts need to be calibrated by a specific calibration device and cannot be repaired on site.
Fixing screws (DO NOT disassemble)
Located on the both sides of the TPH module
Fixing screws of Platen Motor (Must disassemble with care & marks)
You have to make marks for positioning of these 2 screws, otherwise a horizontal banding
(regular, thin & tiny) symptom may appear on prints
Confidential 7
4. Disassembly
4-1 Case of card printer & chassis
Maintenance Parts Replacement Procedures
Parts Name
The case of card printer & chassis Parts No.
Tools Screwdriver Procedure No. 1
Appearance view of CS-200e
L
RTOP
F
B
Confidential 8
Unscrew 4 screws that hold the upper cover (marked in red circles in the figure below)
(PS_ID_DOOR_F_RAPID_C1 56.C0104.012)
Slide down the upper cover to take it off
Confidential 9
Unscrew the corresponding screws which have been marked in circles of different colors for the
part that you are going to take off
Front (case front & ADF cover) Pink
Back Brown
Left Green
Right Blue
Confidential 10
