Hirschmann BATOne Manuel utilisateur

User Manual

Installation

Managed IP67 Wireless Switch

BATOne

Installation BATOne

Release 01 01/2019 Technical Support

https://hirschmann-support.belden.com

The naming of copyrighted trademarks in this manual, even when not specially

indicated, should not be taken to mean that these names may be considered as free in

the sense of the trademark and tradename protection law and hence that they may be

freely used by anyone.

reproduction, translation, conversion into any electronic medium or machine scannable

form is not permitted, either in whole or in part. An exception is the preparation of a

backup copy of the software for your own use.

The performance features described here are binding only if they have been expressly

agreed when the contract was made. This document was produced by Hirschmann

Automation and Control GmbH according to the best of the company's knowledge.

Hirschmann reserves the right to change the contents of this document without prior

notice. Hirschmann can give no guarantee in respect of the correctness or accuracy of

the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the

network components or the associated operating software. In addition, we refer to the

conditions of use specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product

site (www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Installation BATOne

Installation BATOne 01.01.2019

Contents

SAFETY INSTRUCTIONS

ABOUT THIS MANUAL

KEY

DESCRIPTION 14

1.1

General description 14

1.2

Device name and product code 15

1.3

Device view 16

1.4

Power supply 17

1.5

Ethernet ports 17

1.5.1 10/100 Mbit/s twisted pair port 17

1.5.2 1000 Mbit/s F/O port 17

1.5.3 Pin assignments 18

1.6

Connections for antennas 18

1.7

Display elements 18

1.7.1 Device state 18

1.7.2 Port status 19

1.8

Management interfaces 20

1.8.1 USB interface 20

1.8.2 V.24 interface (external management) 21

1.9 Signal contact 24

Installation BATOne

Release

01/2019 3

INSTALLATION 25

2.1

Checking the package contents 25

2.2

Installing and grounding the device 26

2.2.1 Installing the device 26

2.2.2 Grounding the device 26

2.3

Installing the antennas 27

2.4

Connecting the ferrite 28

2.5

Connecting the power supply and signal lines 29

2.5.1 Supply voltage (100 V AC... 240 V AC, 50 Hz / 60 Hz)30

2.5.2 Signal contact 30

2.6

Operating the device 31

2.7

Connecting data cables 31

2.8

Filling out the inscription label 32

MAKING BASIC SETTINGS 33

MONITORING THE AMBIENT AIR TEMPERATURE34

CONFIGURING THE TRANSMIT POWER 35

MAINTENANCE AND SERVICE 37

DISASSEMBLY 38

TECHNICAL DATA 39

8.1 General technical data 39

Installation BATOne

Release

01/2019

8.2

Power consumption/power output 40

8.3

Dimension drawings 41

8.4

Radio technology 42

8.5

Roaming 42

8.6

Receiving sensitivity, transmit power, and data rate of the WLAN

module version EWLAN1 43

8.6.1 IEEE 802.11b 43

8.6.2 IEEE 802.11g 43

8.6.3 IEEE 802.11a 44

8.6.4 IEEE 802.11n 44

8.7

EMC and immunity 46

8.8

Network range 47

SCOPE OF DELIVERY, ORDER NUMBERS AND

ACCESSORIES 48

UNDERLYING TECHNICAL STANDARDS 50

A FURTHER SUPPORT

Installation BATOne

Release

01/2019 5

Safety instructions

WARNING

UNCONTROLLED MACHINE ACTIONS

To avoid uncontrolled machine actions caused by data loss, configure all

the data transmission devices individually.

Before you start any machine

which is controlled via data transmission, be

sure to complete the configuration of all data transmission devices.

Failure to follow these instructions can result in death, serious

injury, or equipment damage.

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful

operation and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged or

malfunctioning the device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Internal fuses are triggered only in the case of a detected error in the

device. In case of damage or malfunction of the device, turn off the

supply voltage and return the device to the plant for inspection.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

Installation BATOne

Release

01/2019

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

Installation site requirements

Install this device in an operating site with restricted access, to which

maintenance staff have exclusive access.

Certified usage

Use the product only for the application cases described in the

Hirschmann product information, including this manual.

Operate the product only according to the technical specifications.

See Technical data on page 39.

Connect to the product only components suitable for the requirements

of the specific application case.

Requirements for connecting electrical wires

Before connecting the electrical wires, always verify that the requirements

listed are complied with.

All of the following requirements are complied with:

The electrical wires are voltage-free.

The cables used are permitted for the temperature range of the application case.

Table 1: General requirements for connecting electrical wires

Requirements for connecting data lines

Before connecting the electrical wires, always verify that the requirements

listed are complied with.

All of the following requirements are complied with:

The voltage connected complies with the requirements for a safety extra-low voltage

(Environment A - SELV) as per IEC/EN 60950-1.

Table 2: Requirements for connecting data lines

Installation BATOne

Release

01/2019 7

WARNING

ELECTRIC SHOCK

Use only Safety Extra Low Voltage circuit.

Failure to follow this instruction can result in death, serious injury,

or equipment damage.

Requirements for connecting the signal contact

Before connecting the signal contact, always verify that the requirements

listed are complied with.

All of the following requirements are complied with:

The voltage connected complies with the requirements for a safety extra-low voltage

(SELV) as per IEC/EN 60950-1.

The connected voltage is limited by a current limitation device or a fuse.

Observe the electrical threshold values for the signal contact.

See Technical data on page 39.

Table 3: Requirements for connecting the signal contact

Requirements for connecting the grounding

Before connecting the grounding, always verify that the requirements

listed are complied with.

Device variant

Requirements

All variants

The wire diameter of the ground conductor in the power supply

cable is the same size as or bigger than the wire diameter of the

power supply cables, however of at least 0.75

mm² (AWG18).

When connecting the provided cable lug, use a professional

crimping tool specified for the wire size. Follow the instructions

of the crimping tool. The pull out force of the crimped

connection is at least 135

N according to the technical standard

IEC 60352-2.

Table 4: Requirements for connecting the grounding

Requirements for connecting the supply voltage

Before connecting the supply voltage, always verify that the requirements

listed are complied with.

Installation BATOne

Release

01/2019

Device variant

Requirements

All variants

All of the following requirements are complied with:

The supply voltage corresponds to the voltage specified on the

type plate of the device.

The supply voltage conforms to overvoltage category I or II.

The supply voltage has an easily accessible disconnecting device

(e. g., a switch or a plug). This disconnecting device is clearly

identified. So in the case of an emergency, it is clear which

disconnecting device belongs to which power supply -cable.

A fuse is located in the outer conductor of the power supply.

The neutral conductor is on ground potential at both voltage

inputs. Otherwise, a fuse is also located in the neutral

conductor.

Regarding the properties of this fuse:

See Technical data on page 39.

The power supply cable is suitable for the voltage, the current

and the physical load. The wire diameter is at least

0.75 mm²(North America: AWG18).

Table 5: Requirements for connecting the supply voltage

WARNING

ELECTRIC SHOCK

Use only Safety Extra Low Voltage circuit.

Failure to follow this instruction can result in death, serious injury,

or equipment damage.

Supply voltage

The supply voltage is connected to the device casing through protective

elements exclusively.

Shielding ground

The overall shield of a connected shielded twisted-pair cable is

connected to the metal housing as a conductor.

Beware of possible short circuits when connecting a cable section

with conductive shielding braiding.

Grounding the device

Grounding the device is by means of a separate ground connection on the

device.

Ground the device before connecting any other cables.

Disconnect the grounding only after disconnecting all other cables.

Installation BATOne

Release

01/2019 9

Use toothed washers to ensure good electrical conductivity at the

connection.

Device casing

Only technicians authorized by the manufacturer are permitted to open

the housing.

Install the device in the vertical position, with the antenna connections

pointing upwards.

At ambient air temperatures > 140 °F (+60 °C):

The surfaces of the device housing may become hot. Avoid touching

the device while it is operating.

To preserve the suitability of your device for IP65/67, proceed as

follows:

Remove the provided transport protection caps and the transport

protection screws from the device.

Seal unused sockets and plugs with your desired type of protection

screws which you can order separately.

Lightning protection

Refer to the information in the “WLAN Outdoor Guide” on “Lightning

and overvoltage protection”.

You can download the manual from the Internet on the Hirschmann

product pages (http://www.hirschmann.com).

Install over voltage protector devices on every outdoor Ethernet cable.

Protect antennas installed outside with lightning protection devices (for

example lightning conductors).

Take lightning protection measures which mitigate the effects of

lightning strikes.

The installation of the device occurs in accordance with valid standards

(such as VDE 0185 and IEC 62305), and in accordance with the

lightning protection procedures recognized and proven for the

application and the environment.

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

When installing antennas, observe the regulations of the country in

which you are operating the WLAN device with regard to the general

operating permission and the maximum emission levels.

Install and operate this equipment with a minimum distance of

19.7 inches (50 cm) between the antenna and your body.

Installation BATOne

Release

01/2019

Table des matières

Autres manuels Hirschmann Changer

Hirschmann

Hirschmann OCTOPUS 8TX-EEC Manuel utilisateur

Hirschmann

Hirschmann OCTOPUS OS20 Manuel utilisateur

Hirschmann

Hirschmann OCTOPUS 8M Series Manuel utilisateur

Hirschmann

Hirschmann MSM20 Manuel utilisateur

Hirschmann

Hirschmann OCTOPUS OS20 Manuel utilisateur

Hirschmann

Hirschmann MACH 4000 Series Manuel utilisateur

Hirschmann

Hirschmann MACH1000 Series Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann RS2-4R Manuel

Hirschmann

Hirschmann RH1-TP Manuel

Hirschmann

Hirschmann GECKO Manuel utilisateur

Hirschmann

Hirschmann OS20-001000T5T5TAFUHB Manuel utilisateur

Hirschmann

Hirschmann RSP 25 Manuel utilisateur

Hirschmann

Hirschmann SPIDER 5TX Manuel

Hirschmann

Hirschmann PAT TRS 05 / PATB3 Guide de l'utilisateur

Hirschmann

Hirschmann RH1-TP Manuel

Hirschmann

Hirschmann MACH4000 Series Manuel utilisateur

Hirschmann

Hirschmann RSPE30 Manuel utilisateur

Hirschmann

Hirschmann Octopus II Manuel utilisateur

Hirschmann

Hirschmann GREYHOUND GRS1020 Manuel utilisateur

Hirschmann

Hirschmann RS20 series Manuel utilisateur

Hirschmann

Hirschmann PowerMICE Manuel utilisateur

Hirschmann

Hirschmann MACH 3001 Manuel

Hirschmann

Hirschmann RH1-TP/FL Manuel

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
