HIK VISION Pyronix Enforcer 64 Manuel utilisateur

102017855 - V01 Software V12.0

Enforcer 64

User Guide

Date: 26 February 2018

Document ID: 102017855 -V01

Contains information owned by Pyronix and/or its affiliates. Do not copy, store, transmit or

disclose to any third party without prior written permission from Pyronix.

Other product and company names may be trademarks or registered trademarks of other

companies, and are the property of their owners. They are used only for explanation, without

intent to infringe.

Intended purpose

This document provides information about using and managing the product after installation and

commissioning.

Conventions

This document uses the following conventions:

►For more information... A cross-reference to a related or more detailed topic.

Indicates a hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a hazardous situation which, if not avoided, could result in moderate injury, damage

the product, or lead to loss of data.

Indicates an important situation which, if not avoided, may seriously impair operations.

Additional information relating to the current section.

Contact

Pyronix Ltd,

Secure House,

Braithwell Way,

Hellaby,

Rotherham,

S66 8QY,

www.pyronix.com

ii Enforcer User Guide 102017855 - V01

Contents

Contents iii

System Description 5

Introduction 5

HomeControl+ App 6

Operation 7

Getting Started 7

Operating the Panel 7

Arming the System 8

Disarming the System 9

Using the Keyfob 10

Locking the Keyfob 11

Quick Arming 11

Arming and Disarming with the Tag Reader 11

Access Control 12

Special Disarm Users 12

PyronixCloud 13

Setting up PyronixCloud on the Panel 13

Setting up the PyronixCloud 13

Setting Up The HomeControl+ App 14

HomeControl+ App Icons 17

Configuration 18

Chime Feature 18

PA from Keypad 18

Fire Alarm from Keypad 18

Master Manager Menu Options 19

Entering the Master Manager Menu 20

Bypass Inputs 20

Operate User Automation Outputs 21

Date & Time 22

Change Codes 23

User Codes 23

Proximity Tags 24

Keyfobs 25

Review Log 26

Setup App Data 27

Standard Security 27

High Security 28

SMS Phonebook 29

Walk Test 30

Bell Test 30

Allow Engineer Menu 31

Block Remote Arming 31

Block UDL 32

System Sounds Demo 32

Exit Master Manager Menu 33

Reference 34

Handover Form 34

SMS Commands 34

Enforcer User Guide 102017855 - V01 iii

Inputs 36

Outputs 37

Users 38

Compliance 39

Notes 40

iv Enforcer User Guide 102017855 - V01

System Description

Introduction

The Enforcer is a wireless alarm system that has been designed with your security in mind; with quick

and easy installation and minimal maintenance, the Enforcer protects your home with a multitude of

unique features.

Taking full advantage of Pyronix’ innovative two-way wireless technology, the wireless devices on the

Enforcer are constantly communicating with each other, using the Pyronix High Security Wireless

Encryption Protocol.

The Enforcer two-way wireless devices are fully operational when the system is armed. This makes

your system more secure, compared to other wireless systems where devices are disabled for up to

five minutes after every activation to save battery - therefore compromising your security.

The Enforcer has been engineered by Pyronix as a secure, reliable and easy to use wireless alarm

system.

Battery Monitoring/Saving

Advanced technology preserves the battery life of each wireless device. The Enforcer panel also

informs you in advance of when a battery needs replacing, giving you enough time to change the

battery in the specific device before it stops working. This key feature keeps your environment fully

protected, unlike other conventional systems.

High Security Encryption

128 bit high security wireless encryption protocol and intelligent wireless jamming detection.

User Friendly Keyfobs

The two-way wireless keyfob allows you to see the status of your Enforcer via three colour LEDs:

• System armed: A RED LED will illuminate.

• System disarmed: A GREEN LED will illuminate.

• System fault: An AMBER LED will illuminate (this will flash when the keyfob is unable to arm the

system).

• Alarm activated: A flashing RED LED.

It is possible to allocate different functions to each keyfob, such as: arming or disarming different

areas, activating outputs to control external devices (such as: gates), requesting the system status

and activating PA (panic alarms).

Up to 32 wireless keyfobs can be added to your Enforcer. Each wireless keyfob has a unique ID,

which can be reported to the ARC and HomeControl+ App. These are stored in the event log of the

Enforcer individually.

User Automation Outputs

The Enforcer gives you the option to operate devices (such as: gates, lights, sprinklers.) via your

keypad or remotely via your keyfob or HomeControl+App.

HomeControl+ App and SMS notifications

Your Enforcer will provide you with real-time push notifications on your smart device or within the

HomeControl+ App, such as: that your child has returned home from school, or a leakage of water in

Enforcer User Guide 102017855 - V01 5

your property. You can also opt to receive these via SMS text messages, when a GPRSmodem is

connected to the panel.

HomeControl+ App

The Enforcer system can be remotely controlled using the HomeControl+ App. It allows you to arm

and disarm the Enforcer, check the system status and bypass inputs. It also allows you to activate

devices remotely, such as gates, lights, sprinklers and more. The HomeControl+ App and

PyronixCloud communication is fully encrypted to the highest standard and no sensitive user data is

stored on the PyronixCloud.

The HomeControl+ App is available in two versions: Android from Google Play Store and iOS from

Apple store.

6 Enforcer User Guide 102017855 - V01

Operation

Getting Started

Operating the Panel

There are four different methods that can be used in arming or disarming your alarm: using a keypad,

using a proximity tag, a keyfob or the HomeControl+ App on your smart device.

Table 1 - Button Operations

Button Description

aQuickly exit a menu.

Select Area A.

Change case when entering text.

bMove back to the previous main menu item.

Select Area B.

cMove back to the previous option in a sub-menu.

Select Area C.

Display additional information in the log.

Delete letters or numbers when entering text.

Enables chime feature.

dScroll forwards in the log.

Select Area D.

Access the user menu.

Press and hold to configure the keypad.

pTrigger PA (Panic Alarms) - only if enabled by an engineer.

fTrigger fire alarms - only if enabled by an engineer.

[] Move from one option to another while in a sub-menu.

Move through text.

tSelect items and enter into a sub-menu or option.

0Enter a space when entering text.

xScroll forwards in the main menu and sub-menus.

When you have scrolled through all the options in a menu, returns to the previous menu level.

The Master Manager Menu allows you to setup specific features by asking you a series of setup

questions:

• Main menus are in capital letters and finish with a question mark, for example, LEARN USER

CODES KEYFOBS & TAGS?.

• Sub-menus are in lower case letters and finish with a question mark, for example, User

Codes/Tags/Learn Keyfobs?.

• Programmable options are in lower case letters and do not finish with a question mark, but

instead: Yes/No, or other options, such as User / Manager.

• To navigate through the menu system, answer the questions in the main and sub-menus.

Enforcer User Guide 102017855 - V01 7

For example, if the question is: LEARN USER CODES KEYFOBS & TAGS?, pressing twill take

you into the sub-menu User Codes/Tags/Learn Keyfobs?, and pressing tagain will then take

you into the programmable options of this sub-menu. If at this point you press x, you will be

taken out of the individual option. Continue to press xand you will navigate through the sub-

menus and eventually return to the main menu.

Arming the System

There are four ways that you can arm your system.

1. Enter your User Code on the keypad. The User Code needs to be programmed in the Master

Menu.

Enforcer Enter Your Code Arm Areas Please Wait. . .

Arming Wireless

Arming [029]

Area A

Press the A, B, C or D keys to

select the area to be armed.

User

Code

User

Code

Stop Arming?

Time 10:09 c [******] [ABCD]

[******]

2. Present your tag and deselect any areas that are not to be armed, then press the tbutton.

Options 1 & 2 only function if ‘Arm Area Choice’ is selected as ‘Yes’ in the

Learn User

Codes/Tags/Keyfobs?

menu. If selected as ‘No’, then all areas allocated to your user will

arm.

3. Open the HomeControl+ App on your smart device and sign into your system with your User

Code and password details. Then touch the green (disarmed) padlock icons to turn them to red

padlock icons and arm those areas.

100%9:41 AM

8 Enforcer User Guide 102017855 - V01

For more information, contact your installer.

4. Press Îand then release, the keyfob will arm the areas it has been assigned to by your installer.

A red LED light will illuminate when the system is armed.

The keyfob buttons can be programmed in the Master Manager Menu

Learn User

Codes/Tags/Keyfobs

Disarming the System

There are four ways that you can disarm your system.

1. Enter your User Code on the keypad. The User Code needs to be programmed in the Master

Menu.

Enforcer EnforcerEnter Your Code Disarm Areas

User

Code t

Press the A, B, C or D keys to select

the area to be armed.

Time 10:09 c [******] [ABCD] Time 10:09 c

2. Present your tag and select any areas that are to be disarmed, then press the tbutton.

Options 1 & 2 only function if ‘Arm Area Choice’ is selected as ‘Yes’ in the

Learn User

Codes/Tags/Keyfobs?

menu. If selected as ‘No’, then all areas allocated to your user will

disarm.

Enforcer User Guide 102017855 - V01 9

3. Open the HomeControl+ App on your smart device and sign into your system with your User

Code and password details. Then touch the red (armed) padlock icons to turn them to green

padlock icons and disarm those areas.

100%9:41 AM

For more information, contact your installer.

4. Press Îand then release, the keyfob will disarm the areas it has been assigned to by your

installer. A green LED light will illuminate to indicate the system is disarmed.

The keyfob buttons can be programmed in the Master Manager Menu

Learn User

Codes/Tags/Keyfobs

Using the Keyfob

The wireless keyfob has four buttons that can be programmed to specific functions: no action, show

status, arm area, disarm area, latch output, timed output and PA alarm activation. This can be

customised to operate as desired (programmed in the function Change Code).

Button Default configuration

Programmed for ‘Arm Area’: one or more areas will be armed when pressed.

Programmed for ‘Disarm Area’: one or more areas will be disarmed when pressed.

10 Enforcer User Guide 102017855 - V01

Table des matières

Autres manuels HIK VISION Système de sécurité

HIK VISION

HIK VISION DS-KD8003-IME1 Manuel utilisateur

HIK VISION

HIK VISION Blazer Express 16 Manuel utilisateur

HIK VISION

HIK VISION DS-PS1-I-WB Manuel utilisateur

HIK VISION

HIK VISION NB V6 Manuel utilisateur

HIK VISION

HIK VISION DS-PEA12-P/ZJ Manuel utilisateur

HIK VISION

HIK VISION AX DS-PW32-H Series Manuel utilisateur

HIK VISION

HIK VISION DS-K2M060 Manuel utilisateur

HIK VISION

HIK VISION DS-MI9605-GA Series Manuel utilisateur

HIK VISION

HIK VISION DS-PD1-EB-WS2 Manuel utilisateur

HIK VISION

HIK VISION Pyronix EURO 46 V10 Manuel du propriétaire

HIK VISION

HIK VISION DS-K3B802BX Series Manuel utilisateur

HIK VISION

HIK VISION DS-19A08-BNG Manuel utilisateur

HIK VISION

HIK VISION DS-K1F600-D6E-F-S Manuel utilisateur

HIK VISION

HIK VISION DS-PWA96-DB-WE Manuel utilisateur

HIK VISION

HIK VISION DS-PHA20-P Manuel utilisateur

HIK VISION

HIK VISION DS-K1T604M Manuel utilisateur

HIK VISION

HIK VISION Castle/Pyronix Euro 280 Manuel utilisateur

HIK VISION

HIK VISION DS-PEA Series Manuel utilisateur

HIK VISION

HIK VISION DS-MI9605-GA Series Manuel utilisateur

HIK VISION

HIK VISION AX PRO Series Guide d'installation

HIK VISION

HIK VISION DS-PEA102S Manuel utilisateur

HIK VISION

HIK VISION DS-PEA102S Manuel utilisateur

HIK VISION

HIK VISION DS-PEA1-21 Manuel utilisateur

HIK VISION

HIK VISION DS-PWA32-K Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
