Heatmiser Senior Manuel utilisateur

Heatmiser Senior

Engineers Set-up Guide

Revision 1

This product should be installed by a qualiﬁed electrician.

Improper installation may result injury, death or property damage.

Ref. HS1

Inside Front Cover Blank

Contents

Description Page

Keypad Layout 1

Standard Terms 1

Initial Setup 2

Boiler Setup 3-4

Optimiser Zone Setup 4

Compensator Zone Setup (With Internal Sensor) 5

Compensator Zone Setup (No Internal Sensor) 6

Timer Zone 6

Vent Zone Setup 7

Inputs Explained 7

Normal Run Mode Screen 7-9

Sensor Calibration 9

Title Setup 9

Viewing Zone Setup 10

Altering Zone Setup 11

Comms Setup 11

User Code Setup 11

System Reset 12

Wiring Diagrams 13-16

1. Heatmiser Senior Keypad

Soft Keys

The Heatmiser Senior features “soft keys” which can be seen above down each side of

the LCD. If you have used a cash machine, you will be familiar with soft keys The beneﬁt

of soft keys is that the button text is displayed on the LCD and is constantly changed

as you use the control. This removes the need for dual purpose buttons which can be

confusing.

Navigating the Zones

Pressing the Left and Right arrow keys allows you to scroll through the zones set-up on

your system.

Display Back Light

To assist with programming the system, the backlight is permanently on.

2. Standard Terms

Self Learning Optimisation is a system whereby the Heatmiser control will automatically

calculate the start up time to ensure the building is up to temperature for the programmed

comfort level. It does this by monitoring the internal temperature readings, so that for

example in milder weather conditions heat up times are reduced – thus saving energy.

The Heatmiser Senior only optimises on the 1st switching level of each day.

Compensation is a system whereby the Heatmiser monitors the internal temperature

according to the preset slope setting in the control. By monitoring the internal and external

temperatures the Heatmiser can calculate the ﬂow temperature needed to maintain the

programmed room temperatures.

Pump Overrun: To help dissipate the heat from the boiler, a pump overrun time can

be set for each zone. When enabled, the pump will run on for a number of minutes

(programmable) after the zone has switched off.

Alarm/Override Inputs: The Heatmiser Senior has 5 inputs which can be used as zone

overrides or alarm input. When set as an override, the zone will override on/off when the

inputs is made or broken. The alarm input mode makes the Heatmiser Senior ﬂash an

alarm message on screen when the input is made.

LCD

1 2 3 DEL

4 5 6 0

7 8 9 OK

Preheat is the number of hours the control can come on before the programmed

switching time (when in optimising mode)

Rate of Change is the time it takes to raise the building 1ºC The factory default for this

setting is 20 minutes but the control will automatically adjust this according to the fabric

of the building.

3. Initial Set-up Procedure

This initial set-up guide has been designed to help you set-up the control to suit your

installation.

When setting up the Heatmiser Senior you must ﬁrst set-up the Boiler zone and then any

other zones thereafter.

Apart from the Boiler zones, there are 4 other types available;

Opt: The control will automatically calculate the start up time to ensure the building

is warm by the start of the programmed switching time; it does this by monitoring the

internal temperature and adjusting the amount of preheat required.

Comp: Compensator. The control will automatically calculate the ﬂow temperature

required to maintain room temperature. By monitoring the internal and external sensor

temperatures, the ﬂow temperature can be increased or decreased to suit demand. This

calculation is worked from a slope factor which can be altered on screen. The slope

factor is set to 03 as factory default, which means that for every 1ºC rise in outside

temperature the ﬂow temperature is decreased by 3ºC.

Timer: In this mode, the Heatmiser will simply work to the programmed times – and is

not dependant on any temperature settings.

Vent: In this mode, the Heatmiser works in reverse to a normal heating zone. In other

words, the output is active when the actual temperature rises above the programmed

temperature.

Begin Here . . .

• To run the set-up procedure, press Program, enter the Engineers Code of 6343

and press OK.

• Select Initial Set-up

• Conﬁrm that you wish to proceed with the set-up routine

Note: This will delete all previous set-up data

Boiler Zone Set-up

A. Boiler Flow Sensor?

a. If you have a boiler ﬂow sensor on the pipe-work, answer YES and go to step B.

If you do not have a boiler ﬂow sensor on the pipe-work, answer NO and go to step

B. Fixed or Variable – Select ﬁxed if you require a ﬁxed ﬂow temperature. One reason

to select this option is if there is a hot water zone. Select variable if you wish the

Heatmiser Senior to calculate the ﬂow temperature (compensate) depending on the

external temperature.

You should now set-up the following parameters according to whether you selected

Fixed or Variable.

C. Fixed Flow Boiler Parameters

Feature No Parameter Typical Description

1. Pump Overrun 20 minutes (00 disabled) The Pump Overrun is used to

dissipate the heat from the system

2. Fixed Flow 80ºC This is the ﬂow temperature that

will be maintained when there is a

heat demand.

3. Flow Frost 08ºC Should the ﬂow temperature drop

below this setting, even with no

demand, the boiler(s) will ﬁre.

• When you have set-up the settings listed above, you need to press OK

D. Variable Boiler Zone Parameters

Feature No Parameter Typical Description

1. Pump Overrun 20 minutes (00=disabled) The Pump Overrun is used to

dissipate the heat from the

system

2. Flow Frost 08ºC Should the ﬂow temperature

drop below this setting, even

with no demand, the boiler(s)

will ﬁre.

3. Compensation Slope 03 For every 1ºC rise in outside

temperature, the ﬂow will be

decreased by the “slope

setting”

4. Minimum Flow 40ºC This is the minimum ﬂow

setting that will be allowed by

the control

5. Maximum Flow 80ºC This is the maximum ﬂow

setting that will be allowed by

the control

6. Hysteresis 02 This is the number of degrees

above the ﬂow set temperature

that the boilers will be turned

off.

• When you have set-up the settings listed above, you need to press OK

E. No Boiler Flow Sensor Parameters

Feature No Parameter Typical Description

1. Pump Overrun 20 minutes (00=disabled) The Pump Overrun is used

to dissipate the heat from

the system

• When you have set-up the settings listed above, you need to press OK

Notes:

i. When you have set-up a zone on the Heatmiser Senior, you will be shown a display

with the relay outputs and sensor input details. Make a note of these and conﬁrm this

is how you have wired this particular zone.

ii. The settings above are typical; you should conﬁrm that they are suitable for your

installation.

Next Zone . . .

You are now prompted to set-up another zone or if you have ﬁnished conﬁguring the

Heatmiser Senior, press Finish.

We have detailed the different zone types available and their parameters below. After each

new zone, conﬁrm the wiring outputs are correct as per the information screen displayed.

The Heatmiser Senior will automatically calculate how many relays you have used and

will only offer zone types which can be set-up on the Senior with the relays and sensor

connections remaining.

Optimiser Zone Set-up

When you have selected Optimisation, you are prompted to enter the following

parameters.

No Parameter Typical Description

1 Enable the Boiler ? Yes (Press 1) When enabled, the boiler will be enabled when

No (Press 0 there is a demand for heat from this zone.

2 Pump Overrun 20 minutes The Pump Overrun is used to dissipate the

heat from the system

3 Preheat Time 03 Hours Maximum number of hours the heating can

come on before the programmed time.

4 Rate of Change 20 minutes / ºC Number of minutes to raise the building 1ºC

5 Hot Water Boost Yes (Press 1) When enabled, the Hot water output is

No (Press 0) activated for 1 hour at

6 Apply Summer Yes (Press 1) If enabled, when the summer input is made,

(Follows the Summer No (Press 0) the zone will switch into System Frost temp

Input when made) Normally disabled for HW zones

7 Override Limit 08 Hours This limits the amount of hours

the zone can be overridden

8 Override Input Yes = Override Input (Press 1) To enable an override input for this zone, select

No = Alarm Indication (Press 0) Yes here. For an alarm indication, select No.

9 External Off Enter the Ext Off Temp Should the external temperature rise above this

temperature, the zone will be turned off

10 Average Sensor Yes (Press 1) In large areas, 2 sensors can be used to take

No (Press 0) an average temperature reading.

• When you have set-up the settings listed above, you need to press OK

Compensator Zone

The Heatmiser Senior asks you to select the zone with or without an internal sensor.

With an internal sensor, the Heatmiser Senior compensates the ﬂow temperature only

when the Room temperature is within 2ºC of the set temperature. Without an internal

sensor, the Heatmiser Senior compensates whenever there is a demand for heat.

When you select a compensator zone, you are prompted to enter the following

parameters.

Compensating with an Internal Sensor

No Parameter Typical Description

1 Enable the Boiler Yes (Press 1)) When enabled, the boiler will be enabled

No (Press 0 when there is a demand

2 Pump Overrun 20 minutes The Pump Overrun is used to dissipate

the heat from the system

3 Preheat 03 hours Maximum number of hours the heating

can come on before the programmed time

4 Rate of Change 20 minutes per ºC Number of minutes to raise the building 1ºC

5 Flow Frost 08ºC Should the ﬂow temperature drop below this

setting, even with no demand, the boiler(s)

will ﬁre.

6 Compensation Slope 03 For every 1ºC rise in outside temperature,

the ﬂow will be decreased by the “slope

setting”

7 Minimum Flow According to your system This is minimum ﬂow setting that will

be allowed by the control

8 Maximum Flow 80ºC This is the maximum ﬂow setting that

will be allowed by the control

9 Pulse Time 15 seconds This is the number of seconds the Senior

will signal to open or close the valve

10 Delay Time 150 seconds This is the number of seconds the Senior

will wait after pulsing the valve.

11 Apply Summer Input Yes (Press 1) If enabled, when the summer input is made,

No (Press 0) the zone will switch into System Frost temp

13 Override Limit 08 hours This is the maximum override time

allowed

14 Override Input Yes = Override input (Press 1)

To enable an override input for this zone, select

No = Alarm indication (Press 0)

Yes here. For an alarm indication, select No.

15 External Off Enter the Ext Off Temp Should the external temperature rise above

above this setting, this zone will switch off

16 Average Sensor Yes (Press 1) In large areas, 2 sensors can be used to

No (Press 0) take an average temperature reading.

• When you have set-up the settings listed above, you need to press OK

Compensating with no Internal Sensor

No Parameter Typical Description

1 Enable the Boiler Yes (Press 1) When enabled, the boiler will be enabled

No (Press 0) when there is a demand

2 Pump Overrun 20 minutes The Pump Overrun is used to dissipate the

heat from the system

3 Flow Frost 08ºC Should the ﬂow temperature drop below

this setting, even with no demand, the

boiler(s) will ﬁre.

4 Compensation Slope 03 For every 1ºC rise in outside temperature,

the ﬂow will be decreased by the “slope

setting”

5 Minimum Flow 40 This is minimum ﬂow setting that will be

allowed by the control

6 Maximum Flow 80 This is the maximum ﬂow setting that will

be allowed by the control

7 Pulse Time 15 seconds This is the number of seconds the Senior

activate to open or close the valve

8 Delay Time 150 seconds This is the number of seconds the Senior

will wait after pulsing the valve.

9 Apply Summer Input Yes (Press 1) If enabled, when the summer input is

No (Press 0) made, the zone will switch into System

Frost temp

11 Override Input 08

To enable an override input for this zone, select

Yes here. For an alarm indication, select No.

12 Override Limit Yes = Override input (Press 1) Should the external temperature rise

No = Alarm Indication (Press 0) above this setting, this zone will switch off

13 External Off Enter the Ext Off Temp Should the external temperature rise above

this setting, this zone will switch off

• When you have set-up the settings listed above, you need to press OK

Timer Zone

The Heatmiser Senior allows you to set-up a timer zone. In this mode, the user has 4

switching periods per day available. When you select a Timer Zone you are prompted to

enter the following parameters.

Feature No Parameter Typical Description

1 Enable the Boiler Select Yes or No When enabled, the boiler will be enabled when

there is a demand

2 Apply Summer Select Yes or No If enabled, this zone will switch into summer

mode when the summer input is made

3 Override Input Yes = Override Input To enable an override input for this zone, select

No = Alarm Indication Yes here. For an alarm indication, select No.

4 Override Limit 08 hours Should the external temperature rise above this

setting, this zone will switch off

5 External Off Enter the Ext Off Temp Should the external temperature rise above this

setting, this zone will switch off

• When you have set-up the settings listed above, you need to press OK

Vent Zone

The Heatmiser Senior allows you to set-up a vent zone. In this mode, the user has 4

switching periods per day available. When you select a Vent Zone, you are prompted to

enter the following parameters.

Feature No Parameter Typical Description

1 Apply Summer Select Yes or No If enabled, this zone will switch into summer mode

when the summer input is made

2 Override Input Yes = Override Input To enable an override input for this zone, select

No = Alarm Indication Yes here. For an alarm indication, select No.

3 Override Limit 08 hours Should the external temperature rise above this

setting, this zone will switch off

4 Average Sensor Select Yes or No Should the external temperature rise above this

setting, this zone will switch off

• When you have set-up the settings listed above, you need to press OK

Inputs Explained

Inputs 1-3 are reserved as zone override or alarms depending on their conﬁguration.

Input 4 is reserved as the Holiday Input. When this input is made, all of the zones will

control to the System Frost temperature. See the User Manual for more information.

Input 5 is reserved as the Summer Input. When this input is made, all of the zones

programmed to follow this input will control to the System Frost temperature. It is normal

for hot water zones to have this input disabled. You can do this by selecting “No” to the

question Apply Summer Input during conﬁguration.

4. Normal Mode Screen Layouts

The screens displayed on your Heatmiser Senior are determined by how it was initially

set-up.

Boiler Enable Screen

This screen shows:

1. The current time and date

2. The pump and boiler enable status.

3. Note that on this screen there is only

1 menu button “Program”

Wednesday 15.12 16-08-06 23°C

Program

Pump Status

Off

Boiler Enable

Off

Table des matières

Autres manuels Heatmiser Thermostat

Heatmiser

Heatmiser Wireless Series Manuel utilisateur

Heatmiser

Heatmiser neo Stat WIFI Manuel utilisateur

Heatmiser

Heatmiser PRT-EAU1 Manuel utilisateur

Heatmiser

Heatmiser DT-ETS WiFi RF Manuel utilisateur

Heatmiser

Heatmiser DT-B Manuel utilisateur

Heatmiser

Heatmiser DS1 Manuel utilisateur

Heatmiser

Heatmiser neoX Manuel utilisateur

Heatmiser

Heatmiser TM4-TS Manuel utilisateur

Heatmiser

Heatmiser DT-W Manuel utilisateur

Heatmiser

Heatmiser touch-n Manuel utilisateur

Heatmiser

Heatmiser SP OpenTherm neoHub Mini OT Manuel utilisateur

Heatmiser

Heatmiser NetMonitor V3 Manuel d'utilisation

Heatmiser

Heatmiser PRT-E Manuel utilisateur

Heatmiser

Heatmiser PRT-W1 Manuel utilisateur

Heatmiser

Heatmiser PRT-EWTS Manuel utilisateur

Heatmiser

Heatmiser PRT-W Manuel utilisateur

Heatmiser

Heatmiser edge Manuel utilisateur

Heatmiser

Heatmiser neoStat Manuel utilisateur

Heatmiser

Heatmiser DT-WTS1 Manuel utilisateur

Heatmiser

Heatmiser Touch Series Manuel utilisateur

Heatmiser

Heatmiser PRTHW-W Manuel utilisateur

Heatmiser

Heatmiser TM1-TS WiFi RF Manuel utilisateur

Heatmiser

Heatmiser smartstat Manuel utilisateur

Heatmiser

Heatmiser Touch-HWN Manuel utilisateur

Manuels Thermostat populaires d'autres marques

EWELLY

EWELLY EW-181 Manuel utilisateur

Prolon

Prolon T1100 Instructions d'installation

Computherm

Computherm Q20 Manuel utilisateur

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Manuel utilisateur

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Manuel utilisateur

Saswell

Saswell SAS920XWHB-7-S-RF Mode d’emploi

Aircalo

Aircalo TFP1-ET85P2 Manuel utilisateur

Honeywell

Honeywell CM721 Manuel utilisateur

Carrier

Carrier DEBONAIR 33CS Manuel utilisateur

Lennox

Lennox iHarmony Zone Thermostat Instructions de montage

Gemtech

Gemtech GT7000 Mode d’emploi

Rollei

Rollei Smartes 45000 Manuel utilisateur

Sinope

Sinope TH1300RF Manuel utilisateur

Honeywell

Honeywell RLV4305 Manuel utilisateur

Honeywell

Honeywell Prestige 2.0 THX9421 Manuel utilisateur

NuTone

NuTone NTBZ48 Instructions d'utilisation d'origine

Stelpro

Stelpro MAESTRO ASMT402AD Manuel utilisateur

Honeywell

Honeywell T6811 Manuel utilisateur
