Health O Meter 2210CART Manuel utilisateur

Pelstar LLC .

11800South Austin Avenue Unit B.

Alsip, IL 60803

Phone: 708-377-0600

Toll free: 800-815-6615

Fax: 708-377-0601

www.homscales.com

Health ometer® is aregistered trademark of

Sunbeam ProductsInc., Boca Raton, FL 33431

Rev.1

Safety

Never use the cart to transport the infant.

Use only on firm and level flooring.

Cleaning

Clean the cart as required using soap and

water or a commercially available

disinfectant. Follow the instructions from the

cleaner or disinfectant manufacturer.

Specifications

Size: 32”w x 24”d x 34”h

Weight Capacity: 200 pounds

Need Help?

If you have any questions on the assembly or

use of this cart, please contact customer

service at 800-638-3722.

Model 2210CART

Neo-natal Scale Cart

For 2210KL

INSTRUCTION MANUAL

Introduction AssemblyInstructions

The 2210CART cart is designed for use with

tour 2210KL Neo-natal Scale.

Included in this kit are:

(1) Top shelf with handle

(1) Middle shelf with 8 leg posts

(1) Bottom shelf with caster inserts

(4) Fluted legs (16-1/2”) for cabinet

(4) Square legs (8”) for top shelf

(1) Cabinet back panel

(2) Cabinet side panels

(1) Cabinet door panel

(2) Cabinet door keys

(2) 4” swivel casters with brakes

(2) 4” swivel casters

You will need a rubber mallet.

(Optional: metal hammer with a block of

wood to cushion impact.)

1. Locate the bottom shelf. Place upside

down (ribbed surface up) on a level and

firm floor surface. Insert the stems of the

(2) casters with brakes on the left short

side of the shelf. Insert the other (2)

casters on the right short side. Tap

casters into socket with rubber mallet

until fully seated.

2. Turn cart right side up. Place the four

fluted legs over the corner posts so that

the channels are facing each other. Use

a rubber mallet to tap legs in place.

Make sure that legs are even and fully

seated.

3. Locate back panel and slide into grooves

of two back legs.

Casters with

brakes

Casters with

brakes

4. Take the two side panels and slide each

into place.

5. Take front panel and slide into place. The

lock should be positioned on the left as

shown.

6. Take the middle shelf and place ribbed

side down onto legs so that the posts are

fitting into the holes in the top of the legs.

Push shelf down as far as you can by

hand. Gently tap with mallet if necessary.

7. Place the four short square legs over the

corner posts on the middle shelf. Tap

gently with mallet until fully seated.

8. Take the top shelf with the handle to the

left (over the casters with brakes) as

shown and place onto legs so that the

posts are fitting into the holes in the top of

the legs. Push shelf down as far as you

can by hand. Gently tap with mallet if

necessary.

9. Position scale on top shelf so that the

white scale platform is all the way towards

the front and right safety lip. This

provides maximum access to the shelf

handle and assures that the clear cradle

does not touch any wall surface which will

affect accurate weight measurement.

10. The cabinet may be used with or without

the keys. The door has a positive latching

action when used without the key.

Handle

Casters with

brakes

Casters with

brakes

Pelstar LLC .

11800South Austin Avenue Unit B.

Alsip, IL 60803

Phone: 708-377-0600

Toll free: 800-815-6615

Fax: 708-377-0601

www.homscales.com

Health o meter® is a registered trademark of

Sunbeam Products Inc., Boca Raton, FL 33431

Rev.1

Safety

Never use the cart to transport the infant.

Use only on firm and level flooring.

Cleaning

Clean the cart as required using soap and

water or a commercially available

disinfectant. Follow the instructions from the

cleaner or disinfectant manufacturer.

Specifications

Size: 32”w x 24”d x 34”h

Weight Capacity: 200 pounds

Need Help?

If you have any questions on the assembly or

use of this cart, please contact customer

service at 800-638-3722.
