Hayter Harrier 48 BBC Guide de l'utilisateur

OWNER’S HANDBOOK

English Version

FROM SERIAL NO: 488T001001 HANDBOOK: 488142 (Rev.0.)

Issue : 22.09.99

HARRIER

CODE 488T

(Electric Start/Variable Speed)

481100MT180598A

CERTIFICATE OF CONFORMITY

I, the undersigned M.A. Wright, of:

HAYTER LIMITED, Spellbrook, Bishop’s Stortford

Herts CM23 4BU

ENGLAND

certify that the lawnmowers:

1. Machine Type No. CODE 488T

2. Category. Combustion Engine

3. Make. Hayter

4. Type. Rotary

5. Engine - Manufacturer. Briggs & Stratton

- Type. 12L887-1508-21

- Speed of rotation during test. 2950 rpm

Conforms to the specifications of Directive 84/538/EEC as adapted to technical

progress by Directive 87/252/EEC and amended by Directive 88/180/EEC.

Guaranteed maximum sound power level. 96 dB(A)

- Type of cutting device Cutterbar

- Width of cutting device 48 cm

- Speed of rotation of the cutting device 2950 rpm

TESTED AT SUDBURY, SUFFOLK, ENGLAND 23.02.98

M.A. Wright

(Technical Director)

Signed

EC DECLARATION OF CONFORMITY

Company Name HAYTER LIMITED

Company Address Spellbrook

Bishop’s Stortford

Herts. CM23 4BU

ENGLAND

Machine Type No.. CODE 488T

Models Electric Start/Variable Speed

Directives complied with: 98/37/EC

Essential Health & Safety Requirements Relating to the Design & Construction of Machinery

and Safety Components.

84/538/EEC amended by 87/252/EEC and 88/180EEC Permissible Sound Power Levels of Lawn Mowers

89/336/EEC amended by 92/31/EEC Electromagnetic Compatibility

Standards Used: EN292, EN836, ENISO14982

I declare on behalf of Hayter Limited that these machines conform to the EC Essential Health & Safety

Requirements.

Date: 19.11.98

M.A. Wright

(Technical Director)

Signed

VIBRATION INFORMATION

Lawnmower vibration information. RMS acceleration measured in 3 - axes at operators contact position on the

handlebars. CODE 488T = 5ms2

INTRODUCTION 1.3

WARRANTY 1.4

SAFETY PRECAUTIONS 1.5 - 1.9

Decals 1.9

SPECIFICATIONS 1.10

ASSEMBLY INSTRUCTIONS 1.11 - 1.13

General Assembly 1.11

Assembling the Mower for the First Time 1.12- 1.13

STARTING THE ENGINE 1.14 - 1.16

Before Starting the Engine 1.14 - 1.15

To Start the Engine 1.16

STOPPING THE ENGINE 1.17

OPERATING THE MOWER 1.18 - 1.23

Safety Notice 1.18

Height of Cut 1.18

Travel 1.19

Turning the Mower 1.19

Mowing with Grass Collection 1.20

Mowing without Grass Collection 1.21

Heavy Growth 1.21

Moving the Mower across Non-Grassed Areas 1.21

Cutterbar Operation 1.22

Mowing and Grass Care Tips 1.22 - 1.23

MAINTENANCE 1.24 - 1.32

Engine 1.24

Throttle Cable Adjustment 1.24

Carburettor Adjustments 1.25

Oil Service 1.25

Air Cleaner Service 1.26

Spark Plug Service 1.26

Keeping the Engine Clean 1.27

Grassbag 1.27

Deck Housing 1.27

CONTENTS

488142MT210999A

1.1 1.1

CONTENTS Page No.

MAINTENANCE Continued.

Securing Nuts and Bolts 1.28

Lubrication 1.28

Clutch Cable Adjustment 1.28

5 Speed Hub Adjustment 1.29

Cutterbar 1.30 - 1.31

Battery Charging 1.32

Maintenance Schedule 1.33 - 1.34

- After First 5 Hours 1.33

- Every 5 Hours or Daily 1.33

- Every 25 Hours or Every Season 1.33

- Every 50 Hours or Every Season 1.34

- Every 100 Hours or Every Season 1.34

PREPARING THE MOWER FOR STORAGE 1.35

FAULT FINDING 1.36 - 1.38

488T PARTS LIST 2.1 - 2.4

488T PARTS DIAGRAM 2.5

ENGINE ANCILLARY PARTS 2.6

WARRANTY ENGINE 2.7

NOTES 2.8

CUSTOMER INFORMATION 2.9

CONTENTS

488142MT210999A

1.2 1.2

CONTENTS Page No.

Thank you for purchasing a Hayter mower. The following pages are designed to help you

gain safe and efficient service from your machine.

IMPORTANT: This ‘Owners Handbook’ should be regarded as part of the machine as it

gives essential information regarding machine safety, operation, maintenance and

specifications. Read and understand this handbook prior to operating your machine for the

first time. Make sure you are familiar with all the controls and points of regular maintenance.

If you have any doubts, consult your Hayter authorised dealer who will be pleased to give

you assistance.

IMPORTANT: This machine is designed solely for use in a domestic grass cutting

environment. Use in any other way is considered as contrary to the intended use. Compliance

with and strict adherence to the conditions of operation, service and repair as specified in this

handbook also constitute essential elements of the intended use.

This machine should be operated, serviced and repaired only by persons who are familiar with

its particular characteristics and who are acquainted with the relevant safety procedures.

The safety precautions listed here in and all other generally recognised regulations on safety

must be observed at all times.

Any arbitrary modifications carried out to this machine may relieve Hayter Limited of

liability for any resulting damage or injury.

All Hayter mowers are robustly constructed and designed for efficient economical

performance under normal mowing conditions. Correct operation and maintenance will

ensure a long and satisfactory service life. Prior to despatch from our factory every effort is

made to ensure your machine arrives in perfect condition. Your dealer will carry out a pre-

delivery inspection to ensure that there has been no transit damage prior to installation.

Please allow your dealer to familiarise you with the controls and safety features of the

machine during installation.

Throughout this handbook all references to left hand and right hand are as viewed from

behind the handlebar, facing in the direction of forward travel.

This handbook is based on information available at the time of publication.

HAYTER LIMITED reserve the right to make changes at any time without notice.

INTRODUCTION

488142MT210999A

1.3 1.3

INTRODUCTION

340212EB221196A

WARRANTY

1.4 1.4

LIMITED WARRANTY

Hayter Limited warrants to the original user/purchaser that this unit shall be free from defects

in material and workmanship under normal use and service for a period of three years from the

date of purchase. The manufacturer of the engines furnish their own warranty and services are

provided through their authorised network (Refer to "Engine Warranty Statement"). To qualify

for the full benefit of the warranty, the warranty registration card must be returned within 60 days

of purchase. Subject to the conditions and exclusions noted in this limited warranty, we shall at

our option, repair or replace any warranted part during the applicable period. If you are in doubt

or experience any difficulty, please consult a Hayter Authorised Service Dealer for clarification.

To qualify for the extended warranty (second and third year) of the three year limited warranty

the machine must have annual services carried out by an Authorised Hayter Service Dealer.

These chargeable services should be carried out within 12 and 24 months of the date of purchase.

Excluded from the extended warranty period are those items which are subject to normal wear

and tear e.g. tyres, wheels, cutterblades, cables, batteries and other consumable wearing parts.

All consumer machines which are fitted with a genuine Hayter friction disc as original

equipment before use, are covered by a Lifetime Warranty against the engine crankshaft

bending. Note: friction washers, blade brake units and other such devices are not applicable.

Only machines fitted with a genuine Hayter friction disc, which are used in accordance with the

recommended operating and maintenance procedures, are covered.

This warranty does not apply to any unit that has been tampered with, altered, misused, abused or

used for hire, and will become invalid if non genuine Hayter parts are fitted. This warranty does

not cover minor mechanical adjustments unless they are due to defective material or

workmanship. Consult the Owner’s Handbook or a Hayter Authorised Service Dealer for

assistance when making these adjustments.

A warranty period of 90 days applies to machines used for commercial purposes.

To make a warranty claim, return the unit to a Hayter authorised dealer along with proof of

purchase stating the machine serial number and date of purchase. The service receipt(s) or this

Owners Handbook with the 1st/2nd year service boxes fully completed, must be produced as

proof of entitlement to the extended warranty period. Subject to the conditions and exclusions in

this limited warranty, the authorised dealer will, at our option, repair or replace any warranted

part within the duration of the warranty period.

This limited warranty gives you specific legal rights and is in addition to any statutory rights to

which you may be entitled and your statutory rights are not affected by this warranty. If you need

additional information concerning this written warranty, or assistance in obtaining services,

please write to : HAYTER LIMITED, Service Department, Spellbrook, Bishop’s Stortford,

Hertfordshire CM23 4BU

UK ONLY: Details of your local Hayter authorised dealer are contained in Yellow Pages or

contact:- Freephone 0800 616298.

Date.................................................................... Date.............................................................

Signed................................................................ Signed..........................................................

Issue: 12.10.00

DEALER STAMP

1st Year

Service

Record

2nd Year

Service

Record

Training:

Read the instructions carefully. Ensure that you are familiar with the controls and the

proper use of the equipment. Learn how to stop the mower quickly in an emergency.

Never allow children or people unfamiliar with these instructions to use the mower.

Never mow while people, especially children, or pets are nearby.

Keep in mind that the user is responsible for accidents or hazards occurring to other people

or their property.

Preparation:

While mowing, always wear substantial footwear and long trousers. Do not operate the

equipment when barefoot or wearing sandals.

Thoroughly inspect the area where the mower is to be used and remove all objects which may

be thrown by the machine.

WARNING: Petrol is highly flammable.

- Store fuel in containers specifically designed for this purpose.

- Refuel outdoors only and do not smoke while refuelling.

- Add fuel before starting the engine. Never remove the cap from the fuel tank or add petrol

while the engine is running or when the engine is hot. Allow the engine to cool for at least 2

minutes before refuelling.

- Do not attempt to start the engine if petrol is spilled or a smell of petrol is present. Move

the mower away from the area of spillage and avoid creating any source of ignition until

petrol vapours have dissipated.

- Always use fresh fuel. Stale fuel can block the carburettor and cause leakage.

SAFETY PRECAUTIONS

488142MT210999A

1.5 1.5

SAFETY PRECAUTIONS

THIS SYMBOL MEANS BE ALERT! YOUR SAFETY IS INVOLVED.

WHEN YOU SEE THIS SYMBOL BE ALERT TO THE POSSIBILITY

OF INJURY. CAREFULLY READ THE MESSAGE THAT FOLLOWS

AND INFORM OTHERS. EXERCISE GREAT CARE AND FOLLOW

THE ADVICE GIVEN TO AVOID POTENTIALLY HAZARDOUS

SITUATIONS.

The Harrier 48 is perfectly safe if used correctly. Failure to observe the

following simple precautions may result in serious injury.

- Replace fuel tank and container caps securely.

- Replace faulty exhaust mufflers.

Always ensure that the mower is in a safe operating condition. Frequently check all nuts,

bolts and screws for tightness. Use only genuine Hayter replacement parts.

A damaged cutterbar or loose fixing bolt are major hazards. Before use, visually inspect the

cutting mechanism to ensure that it is in good condition. A damaged cutterbar must be

replaced immediately with a genuine Hayter replacement part. A cutterbar which is slightly

worn can be re-sharpened. Ensure that both cutting edges are re-sharpened equally to main-

tain balance. An unbalanced cutterbar may cause serious damage to your machine.

Refer to “Maintenance”.

Operation:

Do not operate the engine in a confined space where dangerous carbon monoxide fumes can

collect.

Always pull the starter cord slowly until resistance is felt. Then pull the cord rapidly to avoid

kickback and prevent hand or arm injury.

Mow only in daylight or good artificial light.

Avoid using the mower on wet grass, where feasible.

Always be sure of your footing on slopes.

Walk, never run.

Mow across the face of slopes, never up and down.

Exercise extreme caution when changing direction on slopes.

Do not mow excessively steep slopes.

Use extreme caution when reversing or pulling the mower towards you.

Stop the engine if the mower has to be tilted for transportation when crossing surfaces other

than grass and when transporting the mower to and from the area to be mowed.

Never operate the mower unless the guards are securely in position and in good condition.

SAFETY PRECAUTIONS

488142MT210999A

1.6 1.6

SAFETY PRECAUTIONS Continued.

Continued.

Do not change the engine governor settings or overspeed the engine.

Disengage the rear roller drive clutch before starting the engine.

Start the engine carefully, with feet well away from the cutterbar.

Do not tilt the mower when starting the engine.

Do not put hands or feet near or under rotating parts.

Never pick up or carry a mower while the engine is running.

Stop the engine disconnect the spark plug lead and the negative battery lead:

- Before clearing blockages or unclogging the discharge chute.

- Before cleaning / checking or working on the mower.

- After striking a foreign object. Inspect the mower for damage and make repairs

before restarting and operating the mower.

- If the mower starts to vibrate abnormally (check immediately).

Stop the engine:

- Whenever you leave the mower.

- Before refuelling.

Never lift the deflector plate whilst the mower is in operation.

Never touch the engine muffler / muffler guard or cooling fins when the engine is hot.

SAFETY PRECAUTIONS

488142MT210999A

1.7 1.7

SAFETY PRECAUTIONS

WARNING: THE CUTTERBAR CAN CONTINUE TO ROTATE AFTER

THE ENGINE IS SWITCHED OFF

Continued.

Maintenance and Storage:

Keep all nuts, bolts and screws tight to ensure that the equipment is in safe operating

condition.

Frequently check fuel lines and fittings for cracks or leaks and replace if necessary.

Never check for a spark with the spark plug removed. (Use an approved tester).

Never crank the engine with the spark plug removed. If the engine is flooded, move the

throttle to the ‘fast’position and crank the engine until it starts.

Never strike the flywheel with a hammer or hard object as this may cause the flywheel to

shatter in operation. Always use the correct tools to service the engine.

Never operate the engine without a muffler guard. Inspect the muffler periodically and

replace if worn or leaking.

Never start the engine with the air-cleaner or air-cleaner cover removed.

Never store the mower with petrol in the tank within an enclosed area where fumes may reach

an open flame or spark.

Allow the engine to cool before storing in any enclosure.

To reduce the fire hazard, keep the engine, muffler, cooling fins, battery compartment and

petrol storage area free of grass, leaves, or excessive grease.

Check the grassbag frequently for wear or deterioration.

Replace worn or damaged parts for safety.

If the fuel tank has to be drained, it is essential that this be done outdoors.

SAFETY PRECAUTIONS

488142MT210999A

1.8 1.8

SAFETY PRECAUTIONS

Autres manuels pour Harrier 48 BBC

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hayter Tondeuse à gazon

Hayter

Hayter Harrier 41 410E Guide de l'utilisateur

Hayter

Hayter Harrier 56 BBC Guide de l'utilisateur

Hayter

Hayter Spirit 41 Manuel utilisateur

Hayter

Hayter Harrier 41 Electric Guide de l'utilisateur

Hayter

Hayter Hayterette 005 Guide de l'utilisateur

Hayter

Hayter HUnter 41 302N Guide de l'utilisateur

Hayter

Hayter Spirit 41 Guide de l'utilisateur

Hayter

Hayter Harrier 48/56 Pro 496G Guide de l'utilisateur

Hayter

Hayter Harrier 56 Autodrive VS ES B & S Manuel utilisateur

Hayter

Hayter Ranger 398C Guide de l'utilisateur

Hayter

Hayter Hayterette 005A Guide de l'utilisateur

Hayter

Hayter Sprint 41 616E Guide de l'utilisateur

Hayter

Hayter SST38/ST42 Manuel utilisateur

Hayter

Hayter Harrier 41 410D Guide de l'utilisateur

Hayter

Hayter Ranger 41 Push Guide de l'utilisateur

Hayter

Hayter T424 Manuel utilisateur

Hayter

Hayter Hayterette 005E Guide de l'utilisateur

Hayter

Hayter Harrier 56 BBC Guide de l'utilisateur

Hayter

Hayter Motif 41 Push Guide de l'utilisateur

Hayter

Hayter R48 Mode d’emploi

Hayter

Hayter Spirit 41 Guide de l'utilisateur

Hayter

Hayter 48 PRO Autodrive FS Manuel utilisateur

Hayter

Hayter MT313 Manuel utilisateur

Hayter

Hayter 13/30 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
