Product User’s Guide

Midsize Powered Line Array Systems

VT4888DP

VT4888DP-DA

VT4888DP-AN

VT4888DP-CN

VT4882DP

VT4882DP-DA

VT4882DP-AN

VT4882DP-CN

2VERTEC User’s Guide

JBL Professional

Section 1. Safety Instructions.....................................................................................Page 4

Section 2. Before You Begin .......................................................................................Page 7

Section 3. Introduction to VERTEC®DP Series

Midsize Powered Line Array Systems .....................................................Page 8

Specications by model

Section 4. VERTEC® DP Series Transducers.............................................................Page 10

Section 5. Enclosure Care and Maintenance ............................................................Page 11

Section 6. Suspension.................................................................................................Page 12

Safety Precautions

Industry Resources

Section 7. JBL DrivePack® Technology ....................................................................Page 15

AC Power Module, Electrical Information

Input Modules (DPIP, DPDA, DPAN, DPCN)

Protective Jackets & installation

Section 8. HiQnet System Architect™ Software Conﬁguration Guide ...................Page 28

Conguring your PC

Ethernet Network connections

Appendix A: Conguring CobraNet devices

Appendix B: Setting Microsoft Windows to standard font size

Appendix C: Setting Regional Language Options to US English

Section 9. JBL Professional Warranty .......................................................................Page 39

Section 10. Factory Contact Information ....................................................................Page 40

TABLE OF CONTENTS

4VERTEC User’s Guide

SECTION 1 : SAFETY INSTRUCTIONS

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than the other. A grounding-type plug has two blades and a third

grounding prong. The wide blade or the third prong are provided for your safety. If the provided

plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or

sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has

been damaged in any way, such as power supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

15. WARNING: To reduce the risk of re or electric shock, do not expose this apparatus

to rain or moisture.

16. Do not expose this equipment to dripping or splashing and ensure that no objects lled with

liquids, such as vases, are placed on the equipment.

17. To completely disconnect this apparatus from the AC Mains, disconnect the power supply

cord plug from the AC receptacle.

18. The mains plug of the power supply cord shall remain readily operable.

JBL Professional

THIS APPARATUS CONTAINS POTENTIALLY LETHAL VOLTAGES. TO PREVENT ELECTRIC SHOCK OR

HAZARD, DO NOT REMOVE DRIVEPACK CHASSIS, INPUT MODULE OR AC INPUT COVERS. NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WATCH FOR THESE SYMBOLS

The lightning bolt triangle is used to alert the user to the risk of electric shock.

The exclamation point triangle is used to alert the user to important operating or

maintenance instructions.

FCC COMPLIANCE NOTICE

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

CAUTION: Changes or modications not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

CSA COMPLIANCE NOTICE

CSA Certication Applies to Amplier Module Only

#!54)/.

2)3+/&%,%#42)#3(/#+

$/./4/0%.

6VERTEC User’s Guide

JBL DRIVEPACK®DECLARATION OF CONFORMITY

Safety and EMC Compliance Speciﬁcations

EN 55103-1:1997 Electromagnetic Compatibility - Product Family Standard for Audio, Video, Audio-

Visual and Entertainment Lighting Control Apparatus for Professional Use, Part 1: Emissions

EN 55103-1:1997 Magnetic Field Emissions-Annex A @ 10 cm and 1 M

EN 55022:2003 Limits and Methods of Measurement of Radio Disturbance Characteristics of ITE:

Radiated, Class B Limits; Conducted, Class A

EN 55103-2:1997 Electromagnetic Compatibility - Product Family Standard for Audio, Video, Audio-

Visual and Entertainment Lighting Control Apparatus for Professional Use, Part 2: Immunity

EN 61000-4-2:1995 + A1:1999 & A2:2001 Electrostatic Discharge Immunity (Environment E2-criteria

B, 4 kV Contact, 8 kV Air discharge)

EN 61000-4-3:2003 Radiated, Radio-frequency, Electromagnetic Immunity (Environment E2, criteria

EN61000-4-4:2005 Electrical Fast Transient/Burst Immunity (criteria B)

EN 61000-4-5:2001 Surge Immunity (criteria B)

EN 61000-4-6:1996 Immunity to Conducted Disturbances Induced by Radio-Frequency Fields

(criteria A)

EN 61000-4-11:2004 Voltage Dips, Short Interruptions and Voltage Variation

UL 60065:2003, 7th edition: Audio/Video and Musical Instrument Apparatus for Household,

Commercial and Similar General Use

IEC 60065, 2001: Audio, Video and Similar Electronic Apparatus - Safety Requirements

CAN/CSA E60065-03: Audio, Video and Similar Electronic Apparatus – Safety Requirements

JBL Professional

SECTION 2 : BEFORE YOU BEGIN

The VERTEC®DP Series systems covered by this manual are not intended for xed installation

in outdoor or high moisture environments. Moisture can damage the speaker cone and surround

and cause corrosion of electrical contacts and metal parts. Avoid exposing the speakers to direct

moisture. Keep loudspeakers out of extended or intense direct sunlight. The driver suspension will

prematurely dry out and nished surfaces may be degraded by long-term exposure to intense ultra-

violet (UV) light.

VERTEC® DP Series Midsize Powered Line Array loudspeakers can be suspended with available

array frames (P/N VT4888-AF, VT4888-SF) or they can be ground-stacked. These systems can

generate considerable energy. When placed on a slippery surface such as polished wood or

linoleum, a single speaker may move due to its acoustical energy output. Precautions should be

taken to assure that the speaker does not fall off a stage or scaffold platform on which it is placed.

While it is unlikely that a ground-stacked array will move when properly attached to its array frame,

precautions should be taken to assure that the array assembly cannot fall from any surface on

which it is placed. Hearing damage, prolonged exposure to excessive SPL VERTEC® DP Series

loudspeakers are easily capable of generating sound pressure levels (SPL) sufcient to cause

permanent hearing damage to performers, production crew and audience members. Caution should

be taken to avoid prolonged exposure to SPL in excess of 90 dB.

Package Contents

• Product User’s Guide (this document)

• JBL DrivePack® compatible loudspeaker

• CD containing System Architect™ software.

• AC Power North America/Europe Cord-Set

• Protective Jacket Set

• Warranty Card

8VERTEC User’s Guide

SECTION 3 : INTRODUCTION TO VERTEC®DP SERIES

MIDSIZE POWERED LINE ARRAY SYSTEMS

Shown:VT4888DP in own array

VERTEC®DP Series Midsize Powered Systems

The VERTEC DP Series midsize models are part of a family of powered integrated audio loudspeaker systems

featuring the JBL DrivePack® amplier modules, designed in cooperation with Crown International. The

JBL DrivePack features cutting-edge technology such as patented high efciency Class-I power amplier

circuitry. Loudspeaker components include patented JBL Differential Drive® woofers.

This guide covers the following models:

VT4882DP ....................................... 2x15” powered dual-channel subwoofer system

VT4882DP-DA ................................ with optional DPDA network input module, AES digital audio

VT4882DP-AN ................................ with optional DPAN network input module, analog audio

VT4882DP-CN ................................ with optional DPCN network input module, Cobranet™ digital audio

VT4888DP ....................................... 2x12” tri-amplied three-way full range system

VT4888DP-DA ................................ with optional DPDA network input module, AES digital audio

VT4888DP-AN ................................ with optional DPAN network input module, analog audio

VT4888DP-CN ................................ with optional DPCN network input module, Cobranet™ digital audio

JBL Professional



*",0ROFESSIONAL

6%24%#$03%2)%3-)$3):%0/7%2%$3934%-330%#)&)#!4)/.3

0RODUCT!COUSTICS 64$0 64$0

&REQUENCY2ANGED" (ZnK(Z (Z(Z

&REQUENCY2ESPONSE¢D" (ZnK(Z (Z(Z

(ORIZONTAL#OVERAGE!NGLED" DEGNOMINAL(ZnK(Z .!

6ERTICAL#OVERAGE!NGLED" 6ARIESWITHARRAYSIZEANDCONlGURATION .!

-AXIMUM0EAK/UTPUT D"30,M D"30,MπHALFSPACEGROUND

BASEDAPPLICATION

4RANSDUCER3ECTIONS

,OW&REQUENCY 4WO(MMINDIAMM

IN$UAL#OILNEODYMIUM$IFFERENTIAL$RIVE

$IRECT#OOLED

4WO(MMINDIAMM

IN$UAL#OIL$IFFERENTIAL$RIVE$IRECT

#OOLED

"ANDPASS.OMINAL)MPEDANCE /HMS,&WOOFERSWIREDINPARALLEL /HMSEACHDRIVER

-ID&REQUENCY &OUR(0,MMINWITHMM

INDIAVOICECOIL

.!

"ANDPASS.OMINAL)MPEDANCE OHMSDRIVERSWIREDINSERIESPARALLEL .!

(IGH&REQUENCY 4WO(MMINDIAMETERALUMI

NUMDIAPHRAGMMMINTHROATDIAM

ETERNEODYMIUMCOMPRESSIONDRIVERS

.!

"ANDPASS.OMINAL)MPEDANCE OHMS(&DRIVERSWIREDINSERIES .!

3YSTEM%LECTRONICS

$0)NTERNAL!MPLIlCATION

/UTPUTATLOAD $070EAK7#ONTINUOUS $03UB70EAK7#ONTINUOUS

$0/UTPUT4OPOLOGY $0#HANNEL#LASS) $0#HANNEL#LASS)

3IGNAL0ROCESSING DBX4YPE)6#ONVERSION3YSTEM0RECISIONBANDPASSlLTERSLIMITINGPREEQUALIZATION

lLTERSANDAUTOMATICSELFTESTFUNCTIONS

3YSTEM-ANAGEMENT $30BASEDLIMITERSFORMECHANICALANDTHERMALPROTECTION

3IGNAL)NPUT &8,2!CTIVE+/HMS"ALANCED+/HMS5NBALANCED

3IGNAL,OOP4HROUGH -8,2PASSIVEPASSTHROUGH

#ONTROLS 0RECISIOND"INCREMENT$ETENTEDD"INPUTATTENUATOR$0)0ONLY

!#0OWER/PERATING2ANGE !UTO3ELECT6!#6!#(Z

!#,INE6OLTAGE (Z!UTO$ETECT66¢

!#)NPUT#ONNECTOR

!#0OWER,OOPTHRU

.EUTRIK0OWER#ON"LUE.!#-0!

.EUTRIK0OWER#ON'RAY.!#-0"

!##URRENT2EQUIREMENT !PERSYSTEMAT6!PERSYSTEMAT

6

!PERSYSTEMAT6!PERSYSTEMAT

6

%NCLOSURE

"OX#ONSTRUCTION 7EDGEFRUSTUMDEGREESIDEANGLEEN

CLOSURE0LY-AX©ENGINEEREDCOMPOSITE

STRUCTURE$URA&LEXlNISHHANDLES

7EDGEFRUSTRUMDEGREESIDEANGLEEN

CLOSURE0LY-AX©ENGINEEREDCOMPOSITE

STRUCTURE$URA&LEX©lNISH

3USPENSION3YSTEM 3!&%HARDWAREINTEGRALHINGEBARSNEST

INRIGGINGTUBESONBOXENDS1UICKRELEASE

PINSWITHRESTRAININGLANYARDS

3!&%HARDWAREINTEGRALHINGEBARSNEST

INRIGGINGTUBESONBOXENDS1UICKRELEASE

PINSWITHRESTRAININGLANYARDS3USPEND

WITH64!&!RRAY&RAME3ETOFHINGE

BARS642)'INCLUDEDWITH64

$0SYSTEM

'RILLE "LACKPERFORATEDSTEELFOAMBACKED "LACKPERFORATEDSTEELFOAMBACKED

$IMENSIONS7X(X$ MMXMMXMM

vXvXv

MM8MM8MM

v8v8v

.ET7EIGHT KGLB KGLB

10 VERTEC User’s Guide

2431H High Frequency Compression Driver

JBL’s 2431H features a lightweight neodymium magnet structure, 3”

diaphragm and 1.5” exit coupled to a proprietary waveguide engineered

to be part of the system’s thermal-transfer mechanism, it is designed to

deliver crystal-clear sound with superb dynamic range. The 2431H is an

8 Ohm device. Two are included in each VT4888DP system.

2106HPL Midrange Loudspeaker

The low distortion, high output design of the VERTEC mid-range driver

ensures superb  delity and articulation in the critical midrange

frequencies. The VT4888DP’s four 2106HPL 138 mm (5.5 in) with 50

mm (2 in) dia. voice coils employ JBL’s exclusive Differential Drive®

cone transducer technology for lower weight and higher output. The

highly ef cient cooling characteristics of the mid-range drivers ensure

lower operating temperatures, greatly improved power compression

characteristics and lower harmonic distortion. 8 Ohm device.

2262H Low Frequency Loudspeaker

The 2262H is a 12” transducer engineered with JBL’s patented

Differential Drive® technology. These low frequency drivers dramatically

reduce driver weight while greatly enhancing all critical performance

parameters: frequency response, power output, and distortion.

Differential Drive technology features a unique design with heat

sinks integrated into the cast aluminum frame for a highly improved

performance to weight ratio. The dual voice coil design

places the neodymium magnets inside the voice coil assembly,

completing the magnetic circuit without the heavy surrounding steel

structure of conventional drivers. 8 Ohm device.

For more information, see JBL Tech Note Vol. 1 Number 33, “Differential

Drive Transducers”

2266H Long Excursion, Differential Drive®

Low Frequency Driver

Long Excursion 381mm (15”) transducer features 1200 watts continuous

(AES), 4800 watts peak power handling capacity. It’s the latest example

of JBL’s patented Differential Drive® Neodymium Magnet, dual voice-coil

loudspeaker technology, high peak to peak excursion capabilities, and

JBL’s exclusive Vented Gap Cooling™.

8 Ohm device.

SECTION 4 : VERTEC®DP SERIES TRANSDUCERS

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Harman Intervenants

Harman

Harman harman/kardon Go+Play Manuel utilisateur

Harman

Harman harman/kardon HK OMNI 20 Manuel utilisateur

Harman

Harman JBL 2.0 JEMBE Guide de démarrage rapide

Harman

Harman Infinity Fuze Pint Manuel utilisateur

Harman

Harman CITATION TOWER Manuel utilisateur

Harman

Harman JBL FLIP 5 Manuel utilisateur

Harman

Harman Infinity KAPPA 503CF Manuel utilisateur

Harman

Harman JBL Soundpoint SP5 Manuel utilisateur

Harman

Harman JBL Club 34F Manuel utilisateur

Harman

Harman JBL CONCERT 421F Manuel utilisateur

Harman

Harman JBL BAR 2.1 DEEP BASS Manuel utilisateur

Harman

Harman Infinity KAPPA 53XF Manuel utilisateur

Harman

Harman JBL NightLife Series Manuel utilisateur

Harman

Harman JBL Home Theater Series Manuel utilisateur

Harman

Harman JBL Professional PRX ONE Manuel utilisateur

Harman

Harman AKG LYRA Manuel utilisateur

Harman

Harman JBL BAR 5.1 SURROUND Manuel utilisateur

Harman

Harman JBL CONCERT 521 Manuel utilisateur

Harman

Harman infinity CLUBZ-750Z Manuel utilisateur

Harman

Harman JBL CRUISE Manuel utilisateur

Harman

Harman JBL ARENA Series Manuel utilisateur

Harman

Harman JBL Charge 5 Manuel utilisateur

Harman

Harman EON 510 Manuel utilisateur

Harman

Harman JBL AE Series Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
