HAMPTON BAY HDP00007 Manuel utilisateur

THANK YOU

We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this light xture. We strive to continually create

quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

Thank you for choosing Hampton Bay!

USE AND CARE GUIDE

STRATTON 3 LIGHT SEMI-FLUSH

Item # 1005 889 664

Model # HDP00007

Questions, problems, missing parts? Before returning to the store,

call Hampton Bay Customer Service

8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday

1-855-HD-HAMPTON

HAMPTONBAY.COM

Table of Contents

Safety Information .................................. 2

Warranty .......................................... 2

Pre-Installation ..................................... 3

Planning Installation ............................... 3

Tools Required .................................... 3

Hardware Included................................. 3

Package Contents ................................. 4

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation ....................................5, 6, 7

Care and Cleaning .................................. 7

Troubleshooting .................................... 7

Safety Information

□Consult a qualied electrician with any electrical questions

you may have. IMPORTANT: Inspect the wire insulation for any cuts,

abrasions, or exposed copper that may have occurred

during shipping. If there is a defect in the wire, do not

continue the assembly process. Please call our Customer

Service Team at 1-855-HD-HAMPTON.

Warranty

3-YEAR LIMITED WARRANTY

WHAT IS COVERED

The manufacturer warrants this lighting xture to be free from defects in the materials and workmanship for a period of three (3) years

from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use. If this

product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the

product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modications,

alterations, neglect or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, assembled,

or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the

product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material

or workmanship.

WHAT IS NOT COVERED

This warranty shall not apply to the nish on any portion of the product due to weathering, as this is considered normal wear. The

manufacturer does not warrant and specically disclaims any warranty, whether expressed or implied, other than the warranty contained

herein. The manufacturer specically disclaims any liability and shall not be liable for any consequential or incidental loss or damage,

including but not limited to, any labor or expense costs involved in the replacement or repair of the product.

Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.

3 HAMPTONBAY.COM

Pre-Installation

PLANNING INSTALLATION

Read all instructions before assembly.

To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. Inspect each part for defects that

may have occurred during shipping. Keep your receipt and these instructions for proof of purchase.

TOOLS REQUIRED

Safety

goggles

Phillips

screwdriver

Flathead

screwdriver

Pliers

Wire

strippers

Wire

cutters

Ladder Electrical

tape

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.

AA BB CC DD EE FF GG

Part Description Quantity

AA Wire nut 3

BB Cross bar 1

CC Outlet box screw 2

DD Lock nut 3

EE Ground screw 1

FF Nipple 1

GG Finial 1

Please contact 1-855-HD-HAMPTON for further assistance.

NOTE: This light xture requires the use of three 120V, 60Hz,

60-Watt max., medium-base type S21 (ST64) bulbs (included).

Do not exceed the recommended wattage.

Pre-Installation (continued)

PACKAGE CONTENTS

Part Description Quantity

Fixture body

Arm

Column assembly

Bulb

HAMPTONBAY.COM

Please contact 1-855-HD-HAMPTON for further assistance.

Hook

Loop

Assembly Installation

Assembling the light ﬁxture

□Carefully unpack the xture, lay out all parts on clean

surface.

This xture can be assembled up or down.

Pull the excess cord through the arm (B).

Pull the excess cord through top of the canopy assembly (A).

Attach the hooks of arms (B) to the loops of canopy

assembly (A).

Attach the other hooks of arms (B) to the loops of the xture

body (C).

□

Installing the cross bar

DANGER: Ensure the power is off at the main fuse box

prior to beginning installation.

□

Turn off the switch at the wall.

Turn the power off at the main fuse box.

Install the cross bar (BB) with nipple (FF) and lock nuts (DD) to

the outlet box using two outlet box screws (CC).

Installation (continued)

Hanging the light ﬁxture

□Push all excess wires into the outlet box.

□Raise the canopy (A) to the ceiling and secure in

place by screwing the lock nut (DD) onto the nipple (FF),

and then screw the nial (GG) to end of the nipple (FF).

House wire

black

(or red, or blue)

(HOT)

House wire

white

(NEUTRAL)

Fixture wire

smooth

(HOT)

Fixture wire

ribbed

(NEUTRAL)

Fixture wire

ground wire

(GROUND)

Ribbed line

House wire

green

(or bare wire,

or green & yellow)

(GROUND)

Install the xture bare copper ground wire (1) under the

ground screw (EE) on the cross bar (BB).

Connect the xture bare copper ground wire (1) to the green

(or bare, or green & yellow) supply ground wire (2) in the

outlet box using a wire nut (AA).

Connect the ribbed xture wire (3) to the white supply wire

(4) in the outlet box using a wire nut (AA).

Connect the smooth xture wire (5) to the black (or red, or

blue) supply wire (6) in the outlet box using a wire nut (AA).

Connecting the wires

□

HAMPTONBAY.COM

Please contact 1-855-HD-HAMPTON for further assistance.

Assembling the bulbs

□

Prior to installing the bulbs, inspect sockets for silica

packet. If packet is present, then remove and throw

away. Do not expose it to children or pets.

Install three 120V, 60Hz, 60-Watt medium-base type S21 (ST64)

bulbs (D) (included) into the sockets of the light xture.

Installation (continued)

Care and Cleaning

Troubleshooting

□Clean the light xture with a soft, dry cloth. Do not use any cleaners with chemicals, solvents, or harsh abrasives.r

Problem Possible Cause Solution

The bulb will not light. □The bulb is burned out. □Replace the light bulb.

□The power is off. □Ensure that the power supply is turned on.

□There is a faulty wire connection. □Check the wiring.

□The circuit breaker is off. □Ensure that the circuit breaker is set in the

on position.

The fuse blows or a circuit breaker

trips when the light is turned on.

□There is an exposed wire.

□There are too many items on one circuit.

□Discontinue use of the light xture.

Unplug other items on the circuit.

□Contact a qualied electrician or

call the Customer Service Team at

1-855-HD-HAMPTON.

□

Socket

Retain this manual for future use.

Questions, problems, missing parts? Before returning to the store,

call Hampton Bay Customer Service

8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday

1-855-HD-HAMPTON

HAMPTONBAY.COM
