Haier HVD024E Manuel utilisateur
Wine Cooler
User Manual-
(Features and size may vary per model)
Guide de l’Utilisateur-
(Les caractéristiques et la taille
Peuvent Varier par le Modèle)
Manual del Usuario-
(Las características y el tamaño
Pueden Variar por el Modelo)
Model #
Modèle
Para Modelo de
Enfriador de Vino
Rafraîchisseur à Vin
HVD024E
HVD042E
HVD060E
®
W
hat The World Comes Home To
TM
IMPORTANT SAFEGUARDS
When using this appliance, always exercise basic safety
precautions, including the following:
1.
Read all of the instructions before using this appliance.
2. Use this appliance only for its intended purpose as described in this use
and care guide.
3. This wine cooler must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in the
installation section.
4. Never unplug your wine cooler by pulling on the power cord.
Always grasp the plug firmly and pull straight out from the outlet.
5. Unplug your wine cooler before cleaning or before making any repairs.
Note:
If for any reason this product requires service, we strongly
recommend that a certified technician performs the service.
6. Repair or replace immediately, all electric service cords that
have become frayed or otherwise damaged. Do not use a
cord that shows cracks or abrasion damage along its length,
the plug or the connector end.
7. This wine cooler should not be recessed or built-in an enclosed cabinet.
It is designed for freestanding installation only.
8. If you are replacing an old wine cooler, and it is still around the house,
be sure to remove the door. This will reduce possibility of
danger to children.
9. Do not operate your wine cooler in the presence of explosive fumes.
10. Do not store foods in wine cooler as interior temperature may
not be cool enough to prevent spoilage or may cause bacteria growth.
SAVE THESE INSTRUCTIONS
1
English
English English
2
Thank you for using our Haier
product. This easy-to-use manual will
guide you in getting the best use of
your wine cooler.
Remember to record the model and
serial number. They are on a label in
back of the wine cooler.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain
warranty service.
DANGER
Risk of child entrapment. Before you throw away your old
wine cooler, take off the doors. Leave the shelves in place so
that children may not easily climb inside.
English
2
English English
Table Of Contents
PAGE
Important Safeguards ....................................................................1
Parts And Features ..........................................................................4
Installing Your Wine Cooler ..........................................................5
Unpacking Your Wine Cooler..................................................................5
Leveling Your Wine Cooler......................................................................5
Proper Air Circulation ............................................................................5
Electrical Requirements............................................................................6
Wine Cooler Features And Use ..........................................................7
Initial Set Up ..........................................................................................7
Temperature Adjustment..........................................................................7
Shelving ................................................................................................8
Interior Light ..........................................................................................8
Normal Operating Sounds ......................................................................8
Proper Wine Cooler Care and Cleaning ......................................9
Cleaning and Maintenance ....................................................................9
Power Interruptions ..............................................................................10
Vacation and Moving Care ..................................................................10
Troubleshooting..............................................................................11
Warranty Information ..................................................................12
3
English
3
English English
Parts And Features
1. White Wine Button/
Temperature Adj. Down
2. Red Wine Button/
Temperature Adj. Up
3. Interior Light Button
4. LED Temperature Display
5. Door Handle
6. Adjustable Leveling Legs
7. Slide-Out Shelves
(Type and number of shelves will vary
per model)
4
TEMPERATURE
1234
5
6
7
English
(Features may vary per model)
4
English English
1. Remove all packaging material. This includes the foam base and all
adhesive tape holding the wine cooler accessories inside and outside.
2. Inspect and remove any remains of packing, tape or printed
materials before powering on the wine cooler.
• Your wine cooler has four leveling legs which are located in the
front and rear corners of your wine cooler. After properly placing your
wine cooler in its final position, you can level your wine cooler.
• Leveling legs can be adjusted by turning them clockwise to raise your
wine cooler or by turning them counterclockwise to lower your wine
cooler. The wine cooler door will close easier when the leveling legs are
extended.
• To assure your wine cooler works at the maximum efficiency it was
designed for, you should install it in a location where there is proper air
circulation, plumbing and electrical connections.
• The following are recommended clearances around the wine cooler:
Sides……………2" (50mm)
Top....................2" (50mm)
Back..................2" (50mm)
• Do not over fill your wine cooler for proper internal air circulation.
Installing Your Wine Cooler
Unpacking Your Wine Cooler
Proper Air Circulation
Leveling Your Wine Cooler
5
English
5
English English
Electrical Requirement
• Make sure there is a suitable power Outlet (120 volts, 15 amps outlet)
with proper grounding to power the wine cooler.
•Avoid the use of three plug adapters or cutting off the third grounding in
order to accommodate a two plug outlet. This is a dangerous practice
since it provides no effective grounding for the wine cooler and may
result in shock hazard.
• Do not install your wine cooler in any location not properly insulated or
heated e.g. garage etc. Your wine cooler was not designed to operate
in temperature settings below 55˚ Fahrenheit.
• Select a suitable location for the wine cooler on a hard even
surface away from direct sunlight or heat source e.g. radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness
should be corrected with the leveling legs located on the front and rear
bottom corners of the wine cooler.
• Your wine cooler is designed for free-standing installation only. It is not
designed for built-in application.
Install Limitations
6
English
6
English English
Wine Cooler Features And Use
• The wine cooler is preset from the factory to automatically
accommodate temperature requirements for red or white wines. If you
store mostly white wines, press the "White Wine" button and the wine
cooler will maintain an average temperature between 45˚ to 50˚ F.
Pushing the "Red Wine" button will yield an average temperature
between 55˚ to 60˚ F.
• The wine cooler can be set to any temperature you desire to
accommodate your wine storage requirements. To set the temperature,
press both the "White Wine" and "Red Wine" buttons simultaneously
and hold for approximately 3 seconds. Now you are in temperature set
mode. Decrease the temperature by pushing the "White Wine" button
and increase the temperature by pressing the "Red Wine" button.
Pressing the appropriate button 3 times will adjust the temperature 3
degrees, press 4 times equals 4 degrees, 5 times equals 5 degrees, and
so on. Once you have selected the temperature you desire, push the
"On/Off" button. Now the wine cooler is programmed and the LED
readout will return to current internal temperature reading.
Initial Setup
Once you have plugged the unit into an electrical outlet, let the unit run for at least
30 minutes to acclimate itself before making any adjustments. During this time the
Red Wine light will stay on. Temperature inside the cooler, if not adjusted, will be at
55˚-60˚F.
Temperature Adjustments: See fig. # 1
TEMPERATURE
fig. # 1
7
English
7
English English
• There will be a 3 degree variance +/- between the temperature you
select and the temperature indicated on the LED readout.
This occurs because the wine cooler activates and deactivates
trying to maintain your desired temperature. There is often a
10˚ variance between the top and bottom shelves of the wine cooler.
Therefore, if you have set the wine cooler for 50˚ and have a
mix of red and white wines, you may want to put the white wine
on the bottom shelf where the temperature will be 45˚ F, and place the
red wine on the top shelf where the temperature will be 55˚ F.
• The shelves are designed for appearance and easy cleaning. To
accommodate different sized bottles the shelves slide out and can be
moved up or down into any of the tracks molded into the cooler
cabinet. Larger bottles or Magnums can be more easily accommodated
at the cross shelves at the bottom of the cooler. You will notice that the
shelves are designed so the bottles do not line-up directly over one
another. This allows free air movement and provides more space.
• To complement the look of your wine collection, a soft light has been
built into the wine cooler. Simply push the "On/Off" button and the
light comes on, push again for off. For maximum energy efficiency,
leave light off when not viewing your collection.
• When door is open the light will go on. Upon closing the door,
the light will go off in approximately 15 seconds.
•Boiling water, gurgling sounds or slight vibrations that are the result of
the refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.
Shelving (Type and number of shelves will vary per model)
Interior Light (see fig. #1)
8
Normal Operating Sounds You May Hear
English
8
English English
Warning: To avoid electric shock always unplug your
wine cooler before cleaning. Ignoring this warning
may result in death or injury.
Caution: Before using cleaning products, always read and
follow manufacturer’s instructions and warnings to
avoid personal injury or product damage.
General:
•Prepare a cleaning solution of 3-4 tablespoons of
baking soda mixed with warm water. Use sponge or
soft cloth, dampened with the cleaning solution, to
wipe down your wine cooler.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia,
chlorine bleach,concentrated detergents, solvents or
metal scouring pads. SOME of these chemicals may
dissolve, damage and/or discolor your wine cooler.
• Clean door gaskets every three months according to
general instructions. Gaskets must be kept clean and
pliable to assure a proper seal.
•Petroleum jelly applied lightly on the hinge side of
gaskets will keep the gasket pliable and assure a
good seal.
Proper Wine Cooler Care and Cleaning
Cleaning and Maintenance
Door Gaskets:
9
English
9
English English
Ce manuel convient aux modèles suivants
2
Table des matières
Langues :
Autres manuels Haier Refroidisseur de vin
Haier
Haier HVFM122A Manuel utilisateur
Haier
Haier HVA037-5S - 08-03 Manuel utilisateur
Haier
Haier JC-82G Manuel utilisateur
Haier
Haier HVD060E-4S Manuel utilisateur
Haier
Haier HW24WF10NG Manuel utilisateur
Haier
Haier HWVFM032 - 08-06 Manuel utilisateur
Haier
Haier HWS247FDU1 Manuel utilisateur
Haier
Haier HVW18 Service Manuel utilisateur
Haier
Haier HVD036E - 01-01 Manuel utilisateur
Haier
Haier BC112G - 30 Bottles Wine Cooler Manuel utilisateur
Haier
Haier JC-112G Manuel utilisateur
Haier
Haier HBCN05EBB - Beverage Centers - 4.6 cu. ft.... Manuel utilisateur
Haier
Haier HVF020A Manuel utilisateur
Haier
Haier HWS79GDG Manuel utilisateur
Haier
Haier BC112G - 30 Bottles Wine Cooler Manuel utilisateur
Haier
Haier HVTS16ASS Manuel utilisateur
Haier
Haier HVF030BLL Manuel utilisateur
Haier
Haier HVUE06 Manuel utilisateur
Haier
Haier HWS84GA Manuel utilisateur
Haier
Haier HVZ035AB Manuel utilisateur
