Haier HVFE040BBB Manuel utilisateur

Quality•Innovation

•Style

Double Zone Wine Cellar

Cave à vin compartiment double Zone

Enfriador de vino con Compartimiento

doble Zone

User Manual

HVFE040BBB

Guide de l’Utilisateur

Manual del Usuario Modelo

HVFE040BBB

IMPORTANT SAFEGUARDS

When using this appliance, always exercise basic safety

precautions, including the following:

1. Read all of the instructions before using this appliance.

2. Use this appliance only for its intended purpose as described in this

use and care guide.

3. This wine cellar must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions in

the installation section.

4. Never unplug your wine cellar by pulling on the power cord. Always

grasp the plug firmly and pull straight out from the outlet.

5. Unplug your wine cellar before cleaning or before making any

repairs. Note: If for any reason this product requires service, we

strongly recommend that a certified technician performs the service.

6. Repair or replace immediately, all electric power cords that have

become frayed or otherwise damaged. Do not use a cord that shows

cracks or abrasion damage along its length, the plug or the connector

end.

7. This wine cellar should not be recessed or built-in an enclosed cabi-

net.It is designed for freestanding installation only.

8. If your old wine cellar is not being used, we recommend that you

remove the door and leave the shelves in place. This will reduce

possibility of danger to children.

9. Do not operate your wine cellar in the presence of explosive fumes.

10. Do not store foods in wine cellar as interior temperature may

not be cool enough to prevent spoilage or may cause bacteria growth.

SAVE THESE INSTRUCTIONS

English

DANGER

Risk of child entrapment. Before you throw away your old wine

cellar, take off the doors. Leave the shelves in place so that chil-

dren may not easily climb inside.

Table Of Contents

PAGE

Important Safeguards ....................................................................1

Parts And Features ..........................................................................3

Installing Your Wine Cellar ............................................................4

Unpacking Your Wine Cellar ................................................................4

Leveling Your Wine Cellar ....................................................................4

Proper Air Circulation ..........................................................................4

Electrical Requirements ........................................................................5

Installation Limitations ..........................................................................5

Use of Extension Cords ........................................................................5

Wine Cellar Features And Use ............................................................6

Initial Set Up........................................................................................6

Temperature Adjustment ......................................................................6

Flex-Temperature Zone ........................................................................7

Shelving ..............................................................................................7

Interior Light ........................................................................................7

Normal Operating Sounds ..................................................................7

Proper Wine Cellar Care and Cleaning ........................................8

Cleaning and Maintenance ..................................................................8

Power Interruptions ..............................................................................8

Vacation and Moving Care ..................................................................8

Troubleshooting

............................................................................

Warranty Information

....................................................................

English

Thank you for using our Haier

product. This easy-to-use manual

will guide you in getting the best

use of your wine cellar.

Remember to record the model and

serial number. They are on a label

in back of the wine cellar.

Model number

Serial number

Date of purchase

Staple your receipt to your manual. You will need it to obtain

warranty service.

1. Red Wine Indicator

2. White Wine Indicator

3. LED Temperature Display - Upper

Compartment

4. LED Temperature Display - Lower

Compartment

5. Temperature Set Button

6. Interior Light Button

7. Temperature Adjustment (up/down)

8. Door

9. Auto Light Switch

10. Adjustable Leveling Legs

11. Slide Out Shelves(6)

Red

White Upper Lower

˚F

Red

White

Set Light

English

Parts And Features

1234

Note:This figure is only a sketch ,and may differ from the actual product.

1. Remove all packaging material. This includes the foam base and all

adhesive tape holding the wine cellar accessories inside and outside.

2. Inspect and remove any remains of packing, tape or printed

materials before powering on the wine cellar.

• Your wine cellar has four leveling legs which are located in the

front and rear corners of your wine cellar. After properly placing your

wine cellar in its final position, you can level your wine cellar.

• Leveling legs can be adjusted by turning them clockwise to raise your

wine cellar or by turning them counterclockwise to lower your wine

cellar. The wine cellar door will close easier when the leveling legs

are extended.

• To assure your wine cellar works at the maximum efficiency it was

designed for, you should install it in a location where there is proper

air circulation, plumbing and electrical connections.

• The following are recommended clearances around the wine cellar:

Sides……………2" (50mm)

Top....................2" (50mm)

Back..................2" (50mm)

• Do not over fill your wine cellar for proper wine cooling.

Note: If your wine cellar has been tilted for any reason, wait 24 hours

before plugging it in.

Installing Your Wine Cellar

Unpacking Your Wine Cellar

Proper Air Circulation

Leveling Your Wine Cellar

English

Electrical Requirement

• Make sure there is a suitable power Outlet (115 volts, 15 amps

outlet) with proper grounding to power the wine cellar.

• Avoid the use of three plug adapters or cutting off the third grounding

in order to accommodate a two plug outlet. This is a dangerous prac-

tice since it provides no effective grounding for the wine cellar and

may result in shock hazard.

• Do not install your wine cellar in any location not properly insulated

or heated e.g. garage etc. Your wine cellar was not designed to

operate in temperature settings below 55˚ Fahrenheit.

• Select a suitable location for the wine cellar on a hard even

surface away from direct sunlight or heat source e.g. radiators,

baseboard heaters, cooking appliances etc. Any floor unevenness

should be corrected with the leveling legs located on the front and

rear bottom corners of the wine cellar.

• Your wine cellar is designed for freestanding installation only. It

is not designed for built-in application.

• Avoid the use of an extension cord because of potential safety haz-

ards under certain conditions. If it is necessary to use an extension

cord, use only a 3-wire extension cord that has a 3-blade grounding

plug and a 3-slot outlet that will accept the plug. The marked rating

of the extension cord must be equal to or greater than the electrical

rating of the appliance.

Install Limitations

English

Use of Extension Cord

• The wine cellar is preset from the factory to automatically

accommodate temperature requirements for red or white wines.

• The wine cellar can be set to any temperature between 43˚and 65˚F

in either of the compartments to accommodate your wine storage

requirements. To set the temperature hold the "Set" button for about 3

seconds. You will notice the temperature display blink for the upper

compartment. Press the up or down arrow button to increase or

decrease the temperature setting. Once the desired temperature is

attained, press the "Set" button. Doing this, the electronic control

panel will memorize the setting. The temperature display will revert

back to display the inside temperature. It may take some time to

reach the set temperature.

• Once the temperature is set for the upper compartment, you will

notice the temperature display blink for the lower compartment.

Again press the up or down arrow button to increase or decrease the

temperature. Once the desired temperature is attained, press the "Set"

button. Doing this, the electronic control panel will memorize the set-

ting. The temperature display will revert back to display the inside

temperature. It may take some time to reach the set temperature.

Wine Cellar Features And Use

Initial Setup

Once you have plugged the unit into an electrical outlet, let the unit run for at

least 30 minutes to acclimatize itself before making any adjustments. During this

time, depending on the internal temperature, the red or white wine light will stay

on for the upper compartment and red or white wine light will stay on for the

lower compartment. The LED display will show the current internal temperature.

Temperature Adjustments: See fig. # 1

fig. # 1

English

Red

White Upper Lower

˚F

Red

White

Set Light

Auto-Red and Auto-White Function

•For the storage of red wines at a temperature of 57°F(13°C),press the

[Red] control pad.

For the storage of white wines at a temperature of 47°F(8.3°C),press

the [White] control pad.

•

• The shelves are designed for appearance and easy cleaning. Larger

bottles or Magnums can be more easily accommodated at the cross

shelves at the bottom of the cellar.

• To complement the look of your wine collection, a soft light has been

built into the wine cellar. Simply push the "Light" button and the light

comes on, push again for off. For maximum energy efficiency, leave

light off when not viewing your collection.

• When door is open the light will go on.Upon closing the door,the

light will go off.

• Boiling water, gurgling sounds or slight vibrations that are the result

of the refrigerant circulating through the cooling coils.

• The thermostat control will click when it cycles on and off.

Shelving

English

Interior Light See fig. #1

Normal Operating Sounds You May Hear

This offers wine lovers a whole new level of storage flexibility.

Flexi-Temp allows the top and bottom compartments to each be set

at a temperature between 43˚F - 65˚F, independent of each other.

Allowing you to store wine your way.

Flexi Temperature Zone

Warning: To avoid electric shock always unplug your

wine cellar before cleaning. Ignoring this warning

may result in death or injury.

Caution: Before using cleaning products, always read and

follow manufacturer’s instructions and warnings to

avoid personal injury or product damage.

General:

• Prepare a cleaning solution of 3-4 tablespoons of

baking soda mixed with warm water. Use sponge or

soft cloth, dampened with the cleaning solution, to

wipe down your wine cellar.

• Rinse with clean warm water and dry with a soft

cloth.

• Do not use harsh chemicals, abrasives, ammonia,

chlorine bleach,concentrated detergents, solvents or

metal scouring pads. SOME of these chemicals may

dissolve, damage and/or discolor your wine cellar.

• Clean door gaskets every three months according to

general instructions. Gaskets must be kept clean and

pliable to assure a proper seal.

• Petroleum jelly applied lightly on the hinge side of

gaskets will keep the gasket pliable and assure a

good seal.

Proper Wine Cellar Care and Cleaning

Cleaning and Maintenance

Door Gaskets:

English

• Occasionally there may be power interruptions due to thunderstorms

or other causes. Remove the power cord from AC outlet when a

power outage occurs. When power has been restored, replug power

cord to AC outlet.

• For long vacations or absences, unplug the wine cellar and clean the

wine cellar and door gaskets according to "General Cleaning" section.

Leave doors open, so air can circulate inside.

• When moving always move the wine cellar vertically. Do not move

with the unit lying down, as possible damage to the sealed system

could occur.

Note: After moving, wait for 24 hours before plugging in the

wine cellar.

Power Interruptions

Vacation and Moving Care

English

Wine Cellar Does Not Operate:

• Check if wine cellar is plugged in.

• Check if there is power in the AC outlet, by checking the circuit

breaker.

Wine appears too warm:

• Frequent door openings.

• Allow time for recently added wine to reach desired temperature.

• Check gaskets for proper seal.

• Clean condenser coils.

• Adjust temperature control to colder setting.

Wine temperature is too cold:

• If temperature control setting is too cold, adjust to a warmer setting.

Wine cellar runs too frequently:

• This may be normal to maintain constant temperature during

high temperature and humid days.

• Doors may have been opened frequently or for an extended

period of time.

• Clean condenser coils.

• Check gasket for proper seal.

• Check to see if doors are completely closed.

Moisture build up on interior or exterior

of the wine cellar:

• This is normal during high humidity periods.

• Prolonged or frequent door openings.

• Check door gaskets for proper seal.

Wine cellar door does not shut properly:

• Level the wine cellar.

• Check for blockages e.g. wine bottles, shelves.

TroubleShooting

Table des matières

Langues :

Autres manuels Haier Refroidisseur de vin

Haier

Haier HVD042M - 06-01 Manuel utilisateur

Haier

Haier JC-110GD Schéma de câblage

Haier

Haier WS50GA Manuel utilisateur

Haier

Haier HVDW15ABB - 15 Bottle Display Window Wine... Manuel utilisateur

Haier

Haier HWC-298SWA Manuel utilisateur

Haier

Haier BC112G - 30 Bottles Wine Cooler Manuel utilisateur

Haier

Haier HVFM122A Manuel utilisateur

Haier

Haier HVC15 Manuel utilisateur

Haier

Haier HVR036ALL Manuel utilisateur

Haier

Haier HWS84GA Manuel utilisateur

Haier

Haier HVW18 Service Manuel utilisateur

Haier

Haier HVF046A Manuel utilisateur

Haier

Haier JC-82G Manuel utilisateur

Haier

Haier HVTM12DABB Manuel utilisateur

Haier

Haier HVD042E-3S Manuel utilisateur

Haier

Haier HVD036E Manuel utilisateur

Haier

Haier HWS33GG Manuel utilisateur

Haier

Haier WS120GA Manuel utilisateur

Haier

Haier JC-110GD Manuel utilisateur

Haier

Haier WS49GDB Manuel utilisateur

Haier

Haier AWCE26ARS Manuel utilisateur

Haier

Haier HVD042M Manuel utilisateur

Haier

Haier JC-112G Manuel utilisateur

Haier

Haier HVTB40DPABS Manuel utilisateur

Manuels Refroidisseur de vin populaires d'autres marques

U-Line

U-Line Echelon Wine Captain 2075WC Manuel du propriétaire

Cavist

Cavist 62 Manuel utilisateur

Kenmore

Kenmore 461.99130 Manuel utilisateur

Miele

Miele KWT 6422 iG Manuel utilisateur

Danby

Danby DWC113BLSDB Manuel utilisateur

Caple

Caple Wi6128 Manuel utilisateur

Avanti

Avanti WC1001 Manuel utilisateur

Frigidaire

Frigidaire FFWC38F6LS Manuel utilisateur

Titan

Titan TT-W2454SZ Manuel d'installation

Klarstein

Klarstein Botella 166 Uno Manuel utilisateur

Costway

Costway FP10130WL Manuel utilisateur

Lemair

Lemair LWC59 Manuel utilisateur

Caple

Caple WCi46B Manuel utilisateur

Climadiff

Climadiff CLI24 Guide rapide

Viking

Viking VCWB301LSS Manuel utilisateur

Caple

Caple WC6511 Manuel utilisateur

Vinvautz

Vinvautz VZ08BHK Manuel utilisateur

AVG

AVG PRYMO PMB76SS Manuel utilisateur
