H3C RA200 Manuel utilisateur

H3C RA200 Router

Interface Moudle Guide

New H3C Technologies Co., Ltd.

http://www.h3c.com.hk

Document version: 6W102-20170510

No part of this manu al may be reprod uced or transmitted in any form or by a ny means without prior written

consent of New H3C Technologies Co., Ltd.

Trademarks

H3C, , H3CS, H3CIE, H3CNE, Aolynk, , H3Care, , IRF, NetPilot, Netflow, SecEngine,

SecPath, SecCenter, SecBlade, Comware, ITCMM and HUASAN are trademarks of New H3C Technologies

Co., Ltd.

All other trademarks that may be mentioned in this manual are the property of their respective owners

Notice

The information in this document is subject to chan ge without notice. Every ef fort has been made in the

preparation of this do cument to en sure accuracy of the co ntents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

Preface

This document provides information about RIC modules supported by the RA200 route r, including

module appearance, LEDs, port specifications, and connection methods.

This preface includes the following topics about the documentation:

•Audience

•Conventions

•Obtaining documentation

•Technical support

•Documentation feedback

Audience

This documentation is intended for:

•Network planners.

•Field technical support and servicing engineers.

•Network administrators working with the the RA200 router.

Conventions

The following information describes the conventions used in the documentation.

Command conventions

Convention Description

Boldface Bold text represents commands and keywords that you enter literally as shown.

Italic Italic text represents arguments that you replace with actual values.

[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.

{ x | y | ... }

Braces enclose a set of required syntax choices separated by vertical bars, from which

you select one.

[ x | y | ... ]

Square brackets enclose a set of optional syntax choices separated by vertical bars,

from which you select one or none.

{ x | y | ... } *

Asterisk marked braces enclose a set of required syntax choices separated by vertical

bars, from which you select a minimum of one.

[ x | y | ... ] *

Asterisk marked square brackets enclose optional syntax choices separated by vertical

bars, from which you select one choice, multiple choices, or none.

&<1-n> The argument or keyword and argument combination before the ampersand (&) sign

can be entered 1 to n times.

# A line that starts with a pound (#) sign is comments.

GUI conventions

Convention Description

Boldface Window names, button names, field names, and menu items are in Boldface. For

example, the New User window opens; click OK.

Convention Description

> Multi-level menus are separated by angle brackets. For example, File > Create >

Folder.

Symbols

Convention Description

WARNING! An alert that calls attention to important information that if not understood or followed

can result in personal injury.

CAUTION: An alert that calls attention to important information that if not understood or followed

can result in data loss, data corruption, or damage to hardware or software.

IMPORTANT: An alert that calls attention to essential information.

NOTE: An alert that contains additional or supplementary information.

TIP: An alert that provides helpful information.

Network topology icons

Convention Description

Represents a generic network device, such as a router, switch, or firewall.

Represents a routing-capable device, such as a router or Layer 3 switch.

Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that

supports Layer 2 forwarding and other Layer 2 features.

Represents an access controller, a unified wired-WLAN module, or the access

controller engine on a unified wired-WLAN switch.

Represents an access point.

Wireless terminator unit.

Wireless terminator.

Represents a mesh access point.

Represents omnidirectional signals.

Represents directional signals.

Represents a security product, such as a firewall, UTM, multiservice security

gateway, or load balancing device.

Represents a security module, such as a firewall, load balancing, NetStream, SSL

VPN, IPS, or ACG module.



Examples provided in this document

Examples in this document might use devices that differ from your devi ce in hardware model,

configuration, or software version. It is norm al that the port nu mbers, sample output, screenshots,

and other information in the examples differ from what you have on your device.

Obtaining documentation

To access the most up-to-date H3C product documentation, go to the H3C website at

http://www.h3c.com.hk

To obtain information about installation, configuration, and maintenance, click

http://www.h3c.com.hk/Technical_Documents

To obtain software version information such as release notes, click

http://www.h3c.com.hk/Software_Download

Technical support

service@h3c.com

http://www.h3c.com.hk

Documentation feedback

You can e-mail your comments about product documentation to [email protected].

We appreciate your comments.

Contents

RIC ·······························································································1

Specifications····························································································································1

RIC-4GEE/RIC-8GEE ··········································································································1

RIC-4GEF/RIC-8GEF···········································································································2

RIC-1XGEF························································································································3

Connecting an interface module to the network ················································································4

Connecting an Ethernet cable ································································································4

Connecting an optical fiber ····································································································5

Index ·····························································································9

RIC

RIC interface modules are 0.5 U high interface modules designed for RA series routers. The RIC

modules include the following models:

•RT-RIC-4GEE

•RT-RIC-8GEE

•RT-RIC-4GEF

•RT-RIC-8GEF

•RT-RIC-1XGEF

Unless otherwise specified, RT-RIC-XXX interface modules are referred to as RIC-XXXX interface

modules in this document.

Specifications

RIC-4GEE/RIC-8GEE

Port specifications

Table 1 Port specifications

Item RIC-4GEE RIC-8GEE

Connector type RJ-45

Ports 4 8

Interface type MDI/MDIX

Standard 802.3/802.3u/802.3ab

Transmission medium Straight-through and crossover Ethernet cables

Maximum transmission distance 100 m (328.08 ft) over category-5 twisted pair cables

Operating mode 10/100/1000 Mbps autosensing

Full duplex/half duplex autonegotiation

Compatible device models and slots

•RIC-4GEE: RA200 (Slot 2 to Slot 4, Slot 6, Slot 7)

•RIC-8GEE: RA200 (Slot 2, Slot 3, Slot 6, Slot 7)

LEDs

Figure 1 RIC-4GEE panel

Figure 2 RIC-8GEE panel

Table 2 LED description

LED Status Description

RUN

Steady green The interface module is operating correctly.

Flashing green (8 Hz) The interface module is being initialized.

Flashing green (1 Hz) The interface has been identified.

Off The interface module does not have power input or is faulty.

Steady green A 1000 Mbps link is present.

Flashing green The port is sending or receiving data at 1000 Mbps.

Steady yellow A 10/100 Mbps link is present.

Flashing yellow The port is sending or receiving data at 10/100 Mbps.

Off No link is present.

Connection methods

See "Connecting an Ethernet cable."

RIC-4GEF/RIC-8GEF

Port specifications

Table 3 Port specifications

Item RIC-4GEF RIC-8GEF

Connector type SFP/LC

Ports 4 8

Standard 802.3/802.3u/802.3ab

Operating mode 1000 Mbps

Full duplex

Compatible device models and slots

•RIC-4GEF: RA200 (Slot 2 to Slot 4, Slot 6, Slot 7)

•RIC-8GEF: RA200 (Slot 2, Slot 3, Slot 6, Slot 7)

LEDs

Figure 3 RIC-4GEF panel

Figure 4 RIC-8GEF panel

Table 4 LED description

LED Status Description

RUN

Steady green The interface module is operating correctly.

Flashing green (8 Hz) The interface module is being initialized.

Flashing green (1 Hz) The interface has been identified.

Off The interface module does not have power input or is faulty.

SFP

Steady green A 1000 Mbps link is present.

Flashing green The port is sending or receiving data at 1000 Mbps.

Steady yellow A 100 Mbps link is present.

Flashing yellow The port is sending or receiving data at 100 Mbps.

Off No link is present.

Connection methods

For more information about supported transceiver modules and connection methods, see

"Connecting an optical fiber."

RIC-1XGEF

Port specifications

Table 5 Port specifications

Item RIC-4GEF

Connector type SFP+/LC

Ports 1

Standard 802.3ae

Operating mode 10000 Mbps

Full duplex

Compatible device models and slots RA200 (Slot 2 to Slot 5)

LEDs

Figure 5 RIC-1XGEF panel

Table 6 LED description

LED Status Description

RUN

Steady green The interface module is operating correctly.

Flashing green (8 Hz) The interface module is being initialized.

Flashing green (1 Hz) The interface has been identified.

Off The interface module does not have power input or is faulty.

LED Status Description

LINK/ACT

Steady green A 10000 Mbps link is present.

Flashing green The port is sending or receiving data at 10000 Mbps.

Steady yellow The link is faulty.

Off No link is present.

Connection methods

For more information about supported transceiver modules and connection methods, see

"Connecting an optical fiber."

Connecting an interface module to the network

Connecting an Ethernet cable

Overview

You can connect a RIC-4GEE or a RIC-8GEE to the network through Ethernet cables as shown in

the following figure.

Figure 6 Ethernet cable

10/100 Mbps Ethernet uses category-5 twisted pair cables, and 1000 Mbps Ethernet uses

category-5 enhanced or category-6 twisted pair cables. Twisted pair cables include straight-through

cables and crossover cables.

Table 7 Ethernet cables

Cable type Feature Transmission

frequency Applicable

scenario

Category-5 Common Ethernet cables 100 MHz 100Base-T and

10Base-T networks

Category-5e

•Low attenuation and crosstalk

•Higher attenuation to crosstalk ratio (ACR)

•Less delay error and higher performance

100 MHz 1000 Mbps Ethernet

networks

Category-6

•Improved performance on crosstalk and

return loss

•Sufficient power sum ACR (PS-ACR) when

working at 200 MHz

•Bandwidth twice than that of Cat-5e cables

1 MHz to 250

MHz

Applications

requiring a

transmission speed

of more than 1 Gbps

The 10/100 Mbps Ethernet uses two pairs of cables, orange/white, orange, green/white and green

cables, to transmit and receive data, while the 1000 Mbps Ethernet uses four pairs of cables to

transmit and receive data.

For the pinouts of common twisted pair cables, see the following tables. (A and B represent the two

ends of a cable, respectively.)

Autres manuels pour RA200

Table des matières

Autres manuels H3C Routeur réseau

H3C

H3C SecPath L5000-S Manuel d'utilisation et d'entretien

H3C

H3C MSR 5660 Manuel d'utilisation et d'entretien

H3C

H3C SR6600 Series Guide d'installation

H3C

H3C S3100-52P Manuel utilisateur

H3C

H3C SR6616 Manuel utilisateur

H3C

H3C AR 46-80 Manuel utilisateur

H3C

H3C S12500R Series Guide rapide

H3C

H3C SR8800-F Manuel utilisateur

H3C

H3C S5500-SI Series Manuel utilisateur

H3C

H3C SR6604-X Manuel d'utilisation et d'entretien

H3C

H3C MSR810 Manuel d'installation

H3C

H3C MSR 30-10 Manuel utilisateur

H3C

H3C S9500 Series Instructions d'installation

H3C

H3C SR8800-X-S Manuel d'utilisation et d'entretien

H3C

H3C SR6600 SPE-FWM Manuel utilisateur

H3C

H3C WT2024-U-PWR Mode d’emploi

H3C

H3C SR6602-X Manuel utilisateur

H3C

H3C SR6600 SPE-FWM Manuel d'installation

H3C

H3C SR6600-X Manuel utilisateur

H3C

H3C S5510 Series Manuel utilisateur

H3C

H3C S5120-EI Series Manuel utilisateur

H3C

H3C H3C S5600 Series Manuel utilisateur

H3C

H3C MSR 20-20 Manuel d'installation

H3C

H3C SecPath F5010 Manuel d'utilisation et d'entretien

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
