GreenWorks MO40L01 Manuel utilisateur

40V 21’’ Brushless Lawn Mower

MO40L01

Read all safety rules and instructions carefully before operating this tool.

Owner’s Manual

TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757)

www.GreenWorksTools.com

Contents .............................................................................................................................. 2

Product specications.......................................................................................................... 2

Safety information................................................................................................................ 3

Symbols............................................................................................................................... 9

Know your lawn mower .......................................................................................................11

Assembly ........................................................................................................................... 12

Operation........................................................................................................................... 20

Maintenance ...................................................................................................................... 25

Environmentally safe battery disposal ............................................................................... 29

Troubleshooting ................................................................................................................. 30

Warranty ............................................................................................................................ 31

Exploded View................................................................................................................... 32

Parts List............................................................................................................................ 33

PRODUCT SPECIFICATIONS

40V LITHIUM-ION CORDLESS MOWER

Battery type............................................................................................ 40V Lithium-ion

No-load speed................................................................................................ 2800 RPM

Height adjustments................................................................ 1 3/8 - 3 3/4” (3.5 - 9.5 cm)

Functions......................................................... 3-in-1: Mulch, side discharge or rear bag

Unit weight (without battery) ................................................................61.46 lbs (27.88 kg)

CONTENTS

SAFETY INFORMATION

GENERAL SAFETY RULES

READ ALL INSTRUCTIONS CAREFULLY

WARNING

This symbol indicates important safety instructions. If these instructions are not followed, it could

endanger the personal safety and/or property of the operator and others. Read and understand

all instructions in this manual before attempting to operate the mower. Failure to comply with

these instructions may result in personal injury.

DANGER

This mower was built to be operated according to the rules for safe operation that are contained

in this manual. As with any type of power equipment, carelessness or error on the part of the

operator can result in serious injury. This mower is capable of amputating body parts and

throwing objects. Failure to observe the following safety rules could result in serious injury or

death.

WARNING

Basic safety precautions should always be followed when using electric lawn mowers, in order to

reduce the risk of re, electric shock, and personal injury.

WARNING

Use of this mower should be restricted to individuals who have read and understoood and will

follow the warnings and instructions that are printed in this manual and on the mower.

WARNING

– For safe operation, read and understand the instruction manual.

– To reduce the risk of electric shock, do not expose to water or operate on wet ground.

– Replace damaged parts immediately.

– Remove the battery pack before servicing or removing blade.

– Do not reach under blade guard.

– Do not operate on inclines greater than 15°.

– Do not operate within 100 ft. of people or animals. Do not mow when children or

others are around.

– Keep safety devices (guards, shields, switches etc.) in place and working.

– Look down and behind before and while moving backwards.

– Remove objects that could be thrown by the blade.

– To reduce the risk of eye injury, always wear eye protection.

– To reduce the risk of injury, inspect catcher assembly frequently and replace with

recommended replacement if there are signs of wear or deterioration.

– To reduce risk of injury to persons, remove battery pack when not in use.

– Meet CPSC blade safety requirements.

– Do not recharge batteries in a conned or unvented area.

SAFETY INFORMATION

– Do not smoke, strike a match, or cause a spark in the vicinity of the battery during

charging.

– Store indoors, and do not expose to rain or water, avoid direct sunshine.

– When servicing, use only identical replacement parts.

– Only to be used with Greenworks GMAX 40V Batteries.

See instruction manual for additional battery packs.

• Carefully read all instructions on the mower and in the manual before attempting to assemble and

operate the mower. Keep this manual in a safe place for future reference, and consult it regularly.

• Become familiar with all controls and their proper operation. Know how to stop the mower and

how to disengage the power in an emergency.

• In order to avoid contact with the blade or injury caused by a thrown object, stay in the operating

zone behind the handles, and keep children and bystanders at least 100’ (30 m) away from the

mower while it is in operation. Stop the motor immediately if someone enters the mowing area.

• Thoroughly inspect the area where the mower is to be used. Remove all stones, sticks, wire,

bones, toys, and other objects that could be tripped over or thrown by the blade. Thrown

objects can cause serious personal injury.

• Plan your mowing pattern in such a way as to avoid discharging material toward roads,

sidewalks, bystanders, etc. Do not discharge material against a wall or obstruction. Doing so

may cause the discharged material to ricochet back toward the operator.

• Always wear proper eye protection that complies with ANSI Z87.1 in order to protect your

eyes while operating or performing any adjustment or repair. Thrown objects that ricochet can

cause serious eye injury.

• Always wear a face mask or a dust mask when operating the mower in a dusty environment.

• Dress properly. Do not wear loose clothing or jewelry that can get caught in moving parts. The

wearing of protective gloves and safety footwear is recommended.

• Many injuries occur as a result of the mower being pulled over the operator’s foot during a

fall caused by slipping or tripping. Do not operate this mower in bare feet, or while wearing

sandals or lightweight (e.g., canvas) shoes. Do not hold on to the mower if you are falling.

Release the handle immediately.

• Never pull the mower back toward you while you are walking. If you must back the mower

away from a wall or an obstruction, rst look down and behind in order to avoid tripping, and

then follow these steps:

• Step back from the mower in order to fully extend your arms.

• Be sure that you are well balanced.

• Pull the mower back slowly.

• Do not use the mower for any job except that for which it is intended. Do not force the mower.

• Do not operate the mower while under the inuence of alcohol or drugs.

• Stay Alert: Do not operate the mower when you are tired. Pay attention to what you are doing.

Use common sense.

• Do not put hands or feet near rotating parts or under the cutting deck. Contact with the blade

can amputate hands and feet.

• Do not attempt to adjust the wheels or the cutting height while the motor is running.

• Avoid dangerous environments. Do not operate the mower in the rain or in wet or damp grass.

SAFETY INFORMATION

• Mow only in daylight or in good articial light. Do not rush a mowing job.

• Stop the blade when crossing gravel driveways, walkways, or roads.

• If the mower starts to vibrate excessively, stop the motor and check for the cause immediately.

Vibration is generally a sign the mower is not functioning properly.

• Stop the motor and wait until the blade comes to a complete stop before removing the grass

catcher or unclogging the chute. The cutting blade will continue to rotate for a few seconds

after the motor is shut off. Do not place any part of your body in the blade area until you are

sure that the blade has stopped rotating.

• Never operate mower without a proper trail shield, discharge cover, grass catcher, switch

control, or other safety device in place and in working order. Do not operate the mower with

damaged safety devices. Doing so can result in injury.

• Don’t force the lawn mower. It will do the job better and safer at the rate for which it was

designed.

• Always store your lawn mower indoors. When not in use, the lawn mower should be stored

indoors in a dry and locked place, out of reach of children.

• Maintain your lawn mower. Keep cutting edges sharp and clean to ensure the best

performance and safe operation.

• If lawn mower strikes a foreign object follow these steps:

• Stop lawn mower, release the bail lever.

• Remove the battery.

• Inspect for damage.

• Repair or replace any damaged components before restarting and operating the lawn mower.

• Do not charge batteries in the rain or in wet locations.

• Remove or disconnect battery before servicing, cleaning or removing material from lawn mower.

• Inspect lawn mover cord periodically and if damaged, have it repaired by an authorized

service facility.

• Use identical replacement blades only.

• Do not open or mutilate the battery. Mutilated batteries can release corrosive electrolytes

which can cause damage to the eyes or skin. It may be toxic if swallowed.

• When using, keep out of water, extended periods of direct sunlight, and do not expose to rain.

WARNING

To reduce the risk of damage and danger, never clean the tool with pressure washer or under

running water.

WARNING

Store indoors only. Always remove the battery from mower when cleaning or storing the tool.

SAFETY INFORMATION

CHILD SAFETY

Tragic accidents can occur if the operator is not aware of the presence of children.

• Keep children out of the mowing area and under the watchful care of a responsible adult.

• Do not allow children under the age of 14 to operate this mower. Children who are 14 years

of age and older must read and understand the operating instructions and safety rules in this

manual, and must be trained and supervised by a parent.

• Stay alert, and turn the mower off if a child or any other person enters the mowing area.

• Look behind and down for small children before and while moving backwards.

• Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects

that may obscure your view of a child who may run into the path of the mower.

BATTERY & CHARGER

CAUTION

Use only greenworks approved replacement batteries, other batteries may cause injury or

damage to the mower. Only to be used with Greenworks GMAX 40V Batteries.

BATTERY SAFETY RULES

• Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in

operating condition. Be aware of possible hazards when not using your battery tool or when

changing accessories. Following this rule will reduce the risk of electric shock, re, or serious

personal injury.

• Do not place battery tools or their batteries near fire or heat. This will reduce the risk of

explosion and possibly injury.

• Do not crush, drop or damage battery pack. Do not use a battery pack or charger that has

been dropped or received a sharp blow. A damaged battery is subject to explosion. Properly

dispose of a dropped or damaged battery immediately.

• Batteries can explode in the presence of a source of ignition, such as a pilot light. To reduce

the risk of serious personal injury, never use any cordless product in the presence of open

flame. An exploded battery can propel debris and chemicals. If exposed, flush with water

immediately. Do not charge battery tool in a damp or wet location. Following this rule will

reduce the risk of electric shock.

• For best results, your battery tool should be charged in a location where the temperature is

more than 42.8°F but less than 104°F. To reduce the risk of serious personal injury, do not

store outside or in vehicles.

• Under extreme usage or temperature conditions, battery leakage may occur. If liquid comes

in contact with your skin, wash immediately with soap and water. If liquid gets into your eyes,

ush them with clean water for at least 10 minutes, then seek immediate medical attention.

Following this rule will reduce the risk of serious personal injury.

• When battery pack is not in use, keep it away from other metal objects like: paper clips, coins,

keys, nails, screws, or other small metal objects that can make a connection from one terminal

to another. Shorting the battery terminals together may cause sparks, burns, or a re.

SAFETY INFORMATION

• Always remove battery pack from your tool when you are assembling parts, making

adjustments, cleaning, or when not in use. Removing battery pack will prevent accidental

starting that could cause serious personal injury.

• Always remove battery pack before storing the device. When battery becomes fully charged,

unplug the charger from the power supply and remove the battery pack from the charger.

• Always wear eye protection with side shields marked to comply with ANSI Z87.1, along with

hearing protection. Failure to do so could result in objects being thrown into your eyes and

other possible serious injuries.

• Keep battery pack dry, clean, and free from oil and grease. Always use a clean cloth when

cleaning. Never use brake fluids, gasoline, petroleum-based products, or any solvents to

clean battery pack.

PROPER BATTERY CARE

Off-season storage

To obtain the longest possible battery life, we suggest the following:

• Remove the battery pack from the charger once it is fully charged and ready for use.

For battery pack storage longer than 30 days:

• Store the battery pack where the temperature is below 80°F and away from moisture.

• Store battery packs in a 30% - 50% charged condition.

CHARGER SAFETY RULES

• Charge the battery in a dry area that is protected from the weather. Do not expose the mower

or the charger to rain. Do not charge the battery in a wet location. Operate the battery charger

in temperatures between 42.8°F and 104°F. In order to reduce the risk of electric shock, use

only the charger that is provided by the manufacturer to charge the battery.

• DO NOT MISUSE THE CHARGE CORD. Never carry the charger by the cord. Do not

disconnect the charger from the outlet or from the mower by pulling the charger cord.

• Do not use a damaged charger. Replace the charger cords or the charger immediately.

• Keep the mower and the charger away from water, heat sources (radiators, heaters, stoves,

etc.), ames, and chemicals.

• Make sure the battery pack is secured in the unit before beginning operation.

• The battery pack will become slightly warm to the touch while charging. This is normal and

does not indicate a problem.

• Do not place the charger and battery pack in an area of extreme heat or cold. They will work

best at normal room temperature.

• When batteries become fully charged, unplug the charger from the power supply and remove

the battery pack.

SAVE THESE INSTRUCTIONS

SAFETY INFORMATION

WARNING

When transporting or servicing unit, always remove the battery.

WARNING(PROPOSITION 65)

Some dust created by power sanding, sawing, grinding, drilling and other construction activities

contains chemicals known to the state of California to cause cancer, birth defects or other

reproductive harm. Some examples of these chemicals are:

• Lead from lead-based paints,

• Crystalline silica from bricks and cement and other masonry products,

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies depending on how often you do this type of work. To

reduce your exposure to these chemical: work in a well ventilated area, and work with approved

safety equipment, such as those dust masks that are specially designed to lter out microscopic

particles.

Some of the following symbols may be used on this product. Please study them and learn their

meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.

SYMBOLS

SYMBOL NAME DESIGNATION/EXPLANATION

V Volts Voltage

A Amperes Current

Hz Hertz Frequency (cycles per second)

W Watts Power

min Minutes Time

Direct Current Type or a characteristic of current

No Load Speed Rational speed, at no load

/min Per Minute Revolutions, strokes, surface speed, orbits etc.,

per minute

Safety Alert Indicates a potential personal injury hazard.

Wet Conditions Alert Do not expose to rain or use in damp locations

Read The Operator’s Manual

To reduce the risk of injury user must read and

understand operator’s manual before using this

product.

Eye Protection Always wear safety glasses with side shields that

are marked to comply with ANSI Z87.1.

Keep Hands and Feet Away Keep hands and feet away from blade and cutting

area.

No Reach Do not reach hands or feet under mower deck.

No Slope Do not operate on inclines greater than 15º. Mow

across the face of slopes, never up and down.

Keep Bystanders Away Keep all bystanders at least 100 ft. away.

Ricochet Pay attention that bystanders are not injured

through foreign objects thrown from the mower.

SYMBOLS

SAVE THESE INSTRUCTIONS

The following signal words and meanings are intended to explain the levels of risk associated

with this product.

SERVICE

Servicing requires extreme care and knowledge and should be performed only by a qualied

service technician. For service we suggest you return the product to your nearest AUTHORIZED

SERVICE CENTER for repair. When servicing, use only identical replacement parts.

WARNING

To avoid serious personal injury, do not attempt to use this product until you have read this Owner’s

Manual thoroughly and understand it completely. If you do not understand the warnings and

instructions in this Owner’s Manual, do not use this product. Call the Toll-free Helpline (1-888-909-

6757) for assistance.

WARNING

The operation of any power tool can result in foreign objects being thrown into your eyes,

which can result in severe eye damage. Before beginning power tool operation, always

wear safety goggles or safety glasses with side shields and, when needed, a full face

shield. We recommend Wide Vision Safety Mask for use over eyeglasses or standard

safety glasses with side shields. Always use eye protection which is marked to comply

with ANSI Z87.1.

SYMBOL SIGNAL MEANING

DANGER Indicates an imminently hazardous situation, which, if not

avoided, will result in death or serious injury.

WARNING Indicates a potentially hazardous situation, which, if not avoided,

could result in death or serious injury.

CAUTION Indicates a potentially hazardous situation, which, if not avoided,

may result in minor or moderate injury.

CAUTION (Without Safety Alert Symbol) Indicates a situation that may

result in property damage.

Autres manuels pour MO40L01

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels GreenWorks Tondeuse à gazon

GreenWorks

GreenWorks LME470 Manuel utilisateur

GreenWorks

GreenWorks 2507502CT Manuel utilisateur

GreenWorks

GreenWorks PRO Optimow 25 Manuel utilisateur

GreenWorks

GreenWorks 25052 Manuel utilisateur

GreenWorks

GreenWorks 25322 Manuel utilisateur

GreenWorks

GreenWorks MO09B01 Manuel utilisateur

GreenWorks

GreenWorks 2540802 Manuel utilisateur

GreenWorks

GreenWorks GD48LM41II Manuel utilisateur

GreenWorks

GreenWorks GD60LM46SP Manuel utilisateur

GreenWorks

GreenWorks MO48L4214 Manuel utilisateur

GreenWorks

GreenWorks RM1400 Manuel utilisateur

GreenWorks

GreenWorks GLM801602 Manuel utilisateur

GreenWorks

GreenWorks G40LM35 Manuel utilisateur

GreenWorks

GreenWorks MO48L2211 Manuel utilisateur

GreenWorks

GreenWorks G24X2LM46S Manuel utilisateur

GreenWorks

GreenWorks 25112 Manuel utilisateur

GreenWorks

GreenWorks MO40L04 Manuel utilisateur

GreenWorks

GreenWorks 25147 Manuel utilisateur

GreenWorks

GreenWorks LMF318 Manuel utilisateur

GreenWorks

GreenWorks MO40B00 Manuel utilisateur

GreenWorks

GreenWorks LMF320 Manuel utilisateur

GreenWorks

GreenWorks LMA125 Manuel utilisateur

GreenWorks

GreenWorks MO48L2211 Manuel utilisateur

GreenWorks

GreenWorks G48LM36 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
