MODES™ 3 LITE

• Owner’s Manual

• featuring

2-A MODES™ 3 Lite Use Positions

2- B Parts List

1 WARNING

2 Features

Pages 4-11

Pages 12-13

3-A To Open Stroller

3-B Rear Wheels

3-C Front Wheels

3 Assembly Pages 14-21

4-B Canopy

4-C To Secure Child

4-4- D ToRecline Front Seat

4-E Brakes

4-F Swivel Wheels

4-H To Attach Graco® Infant Car Seat to Toddler Seat

4-I To Attach Graco® Infant Car Seat to Stroller Frame

4-J To Fold Stroller Frame without Toddler seat

3-D Parent’s Tray

4 Use Pages 22-45

4-A To Attach/Remove Toddler Seat

5-B Replacement Parts • Warranty Information

5-C Product Registration

4-K To Fold Stroller with Toddler seat attached

5 Cleaning

5-A Care & Maintenance

Pages 46-52

Failure to follow these warnings and the

assembly instructions could result in serious injury or death.

PLEASE SAVE OWNER’S

MANUAL FOR FUTURE USE.

ADULT ASSEMBLY REQUIRED.

NEVER LEAVE CHILD

UNATTENDED. Always keep

child in view while in stroller.

AVOID SERIOUS INJURY from

falling or sliding out. Always use

seat belt or infant carseat

harness. After fastening buckles,

adjust belts to get a snug fit

around your child.

AVOID FINGER ENTRAPMENT:

Use care when folding and

unfolding the stroller. Be certain

the stroller is fully erected and

latched before allowing your

child near the stroller.

NEVER USE STROLLER ON

STAIRS or escalators. You may

suddenly lose control of the

stroller or your child may fall

out. Also, use extra care when

going up or down a step or

curb.

AVOID STRANGULATION.

DO NOT place items with a

string around your child’s neck,

suspend strings from this

product, or attach strings to

toys.

USE OF THE STROLLER with a

child weighing more than 50 lbs

(22.7 kg) or taller than 45in

(114.3cm) will cause excessive

wear and stress on the stroller.

Use the stroller with only one

child at a time.

ALWAYS check that the infant

carseat or toddler seat is

securely attached to the frame

by pulling up on it.

TO PREVENT A HAZARDOUS,

UNSTABLE CONDITION, never

place purses, shopping bags,

parcels or accessory items on

the handle (other than approved

Graco stroller bags). Never

place anything on the canopy.

TO PREVENT A HAZARDOUS,

UNSTABLE CONDITION, do not

place more than 10 lbs (4.5 kg)

in the storage basket.

TO AVOID BURNS, never put hot

liquids in the parent tray.

TO PREVENT TIPPING, do not

place more than 3lb (1.36kg) in

the parent tray.

DO NOT use storage basket as a

child carrier.

DO NOT use toddler seat in an

automobile.

DO NOT use toddler seat as a car

bed or booster seat.

DO NOT remove, reverse or carry

the toddler seat while child is in

it.

DO NOT ALLOW your child to

stand on the basket. It may

collapse and cause injury.

NEVER PLACE child in the toddler

seat with head toward footrest.

DO NOT use stroller frame without

toddler seat or carseat attached.

NEVER ALLOW YOUR STROLLER

to be used as a toy.

STROLLER TO BE USED only

at walking speed. Product not

intended for use while jogging,

skating, etc.

NEVER LIFT OR CARRY toddler

seat by the footrest.

DISCONTINUE USING YOUR

STROLLER should it become

damaged or broken.

CAREGIVER MUST always help

child get into and out of the

stroller.

CAREGIVER MUST always

ensure the brakes are engaged

when placing child into stroller.

USING GRACO® INFANT

CARSEAT WITH STROLLER:

TO AVOID INJURY TO YOUR

CHILD: THIS STROLLER IS ONLY

COMPATIBLE WITH GRACO®

SNUGRIDE® INFANT

CAR SEATS WITH CLICK CONNECT™.

Only use with

Graco® infant

car seats that

have the Click

Connect™ logo. Improper use of this stroller

with other manufacturers’ carseats may

result in serious injury or death.

READ THE MANUAL provided

with your Graco carseat before

using it with your stroller.

FALL HAZARD: Always check that

infant carseat is securely

attached to stroller by pulling up

on the carseat.

TO AVOID FALLING OUT always

ensure that the toddler seat is

securely attached on both sides

of the stroller frame.

ALWAYS SECURE your child with

the carseat harness when using

the carseat in the stroller.

If your child is already in the

carseat, check that the child is

secured with the harness.

Improper use of this stroller with a

carseat may result in serious

injury or death.

See Graco infant carseat owners

manual for maximum size of

child.

2-A MODES 3 LITE™ Use Positions

2-B Parts List

All models

On certain models

This model may not

include some

features shown

below. Check that

you have all the parts

for this model

BEFORE assembling

your product. If any

parts are missing,

call Customer

Service.

No tools required.

Harness covers

3-A To Open Stroller

1. Open stroller lock.

Be sure to place stroller on top of a piece of cardboard or some other

protective cover to prevent any damage to floor.

2. Lift handle of stroller up.

3. CHECK that the stroller is

completely latched open every

time you open the stroller and

before continuing with the rest of

the assembly steps.

SNAP!

3-B Rear Wheels

1. Brake levers point toward rear of

stroller.

2. Press down on brake assemblies

until they snap into place. CHECK

that both brake levers are pushed

down as shown.

SNAP!

3. Insert axle rod through axle

opening. Axle key must line up

with key holes.

4. Place wheel on axle.
