Graco Click Connect PD212022B Manuel utilisateur

Graco® PD212022B 11/2012

Graco® Modes TM

Click ConnectTM

Multi-Stage Lightweight Stroller

Failure to follow these warnings and the

assembly instructions could result in serious injury or death.

sPLEASE SAVE OWNER’S

MANUAL FOR FUTURE USE.

sADULT ASSEMBLY REQUIRED.

sNEVER LEAVE CHILD

UNATTENDED. Always keep

child in view while in stroller.

sAVOID SERIOUS INJURY from

falling or sliding out. Always use

seat belt or infant carseat

harness. After fastening buckles,

adjust belts to get a snug fit

around your child.

sAVOID FINGER ENTRAPMENT:

Use care when folding and

unfolding the stroller. Be certain

the stroller is fully erected and

latched before allowing your

child near the stroller.

sNEVER USE STROLLER ON

STAIRS or escalators. You may

suddenly lose control of the

stroller or your child may fall out.

Also, use extra care when going

up or down a step or curb.

sAVOID STRANGULATION.

DO NOT place items with a

string around your child’s neck,

suspend strings from this

product, or attach strings to toys.

sUSE OF THE STROLLER with a

child weighing more than 50 lbs

(22.7 kg) or taller than 45in

(114.3cm) will cause excessive

wear and stress on the stroller.

Use the stroller with only one

child at a time.

sALWAYS check that the infant

carseat or toddler seat is securely

attached to the frame by pulling

up on it.

sTO PREVENT A HAZARDOUS,

UNSTABLE CONDITION, never

place purses, shopping bags,

parcels or accessory items on the

handle (other than approved

Graco stroller bags). Never place

anything on the canopy.

sTO PREVENT A HAZARDOUS,

UNSTABLE CONDITION, do not

place more than 10 lbs (4.5 kg)

in the storage basket.

sTO AVOID BURNS, never put

hot liquids in the parent tray.

sTO PREVENT TIPPING, do not

place more than 3lb (1.36kg) in

the parent tray.

sDO NOT use storage basket as a

child carrier.

sDO NOT use toddler seat in an

automobile.

sDO NOT use toddler seat as a car

bed or booster seat.

sDO NOT remove, reverse or carry

the toddler seat while child is in

it.

sDO NOT ALLOW your child to

stand on the basket. It may

collapse and cause injury.

sNEVER PLACE child in the

toddler seat with head toward

footrest.

sDO NOT use stroller frame

without toddler seat or carseat

attached.

sNEVER ALLOW YOUR

STROLLER to be used as a toy.

sSTROLLER TO BE USED only

at walking speed. Product not

intended for use while jogging,

skating, etc.

sNEVER LIFT OR CARRY toddler

seat by the footrest.

sDISCONTINUE USING YOUR

STROLLER should it become

damaged or broken.

sCAREGIVER MUST always help

child get into and out of the

stroller.

sCAREGIVER MUST always

ensure the brakes are engaged

when placing child into stroller.

sUSING GRACO® INFANT

CARSEAT WITH STROLLER:

sUSE ONLY A GRACO®

SNUGRIDE®CLICK CONNECT™

infant carseat with this product.

(Not intended for use with

SnugRide®, SnugRide® 30,

SnugRide® 32, SnugRide® 35,

Infant Safeseat™, AUTOBABY,

LOGICO S, JUNIORBABY and

ASSURA infant car seats.)

Improper use of this stroller with

other manufacturers’ carseats

may result in serious injury or

death.

sREAD THE MANUAL provided

with your Graco carseat before

using it with your stroller.

sFALL HAZARD: Always check

that infant carseat is securely

attached to stroller by pulling up

on the carseat.

sTO AVOID FALLING OUT

always ensure that the toddler

seat is securely attached on both

sides of the stroller frame.

sALWAYS SECURE your child

with the carseat harness when

using the carseat in the stroller.

If your child is already in the

carseat, check that the child is

secured with the harness.

sImproper use of this stroller with

a carseat may result in serious

injury or death.

sSee Graco infant carseat owners

manual for maximum size of

child.

Check that you have all the parts for this model BEFORE assembling

your product. If any parts are missing, call Customer Service.

!LLMODELS

0ARTSLIST

2X 2X 2X 2X

No tools required.

To Open Stroller

CHECK that stroller is

completely latched open

before continuing.

Fasten basket around

tube as shown.

Before assembly be sure to place stroller on top of a piece of cardboard

or other protective cover to prevent damage to ﬂoor surface.

Pull out to unlock

stroller.

SNAP!

2EAR!XLE

Rotate parking stand up

and snap onto axle tube.

SNAP!

Fasten basket around rear axle

as shown.

Brake levers point toward rear

of stroller. Check that rear

axle is securely attached by

pulling on brake assembly.

2EAR7HEELS

Attach wheel as shown.

Repeat on other side.

0ARENT4RAY

SNAP!

Attach hub cap as shown.

Repeat on other side.

CHECK that wheels are securely

attached by pulling on wheels.

Push straight side of pin

through axle hole. Pin will

separate around the axle. Curved

end of pin MUST face out as

shown. Repeat on other end.

CHECK that wheels are

securely attached by pulling

on front wheels.

Front Wheels

SNAP!

To attach seat, place seat on

mounts as shown until they lock

into place on both sides of the

stroller. Seat may be placed on

stroller in either direction.

See warnings for additional

information.

MAKE SURE seat

mounts are securely

attached to the stroller on both

sides as shown.

To Attach Toddler Seat

SNAP!
