Graco Sequel 65/Sequence 65 Manuel utilisateur

Sequel™65/Sequence™65

CONVERTIBLE CAR SEAT

www.gracobaby.com

FAILURE TO PROPERLY USE THIS CHILD

RESTRAINT INCREASES THE RISK OF

SERIOUS INJURY OR DEATH IN A SUDDEN

STOP OR CRASH.

Do not install or use this child restraint

until you read and understand the

instructions in this manual.

PD349423D 10/17

1-A A Quick Guide to Your Manual

1-B Welcome to the Graco Family

1-C Right Mode of Use

1-D Before You Begin

If You Need Help

Certification

Car Seat’s Useful Life

Vehicle Seat Protection

Warm Weather Use

1-E Safety Warnings

2-A Car Seat Features

1 Important Pages 6-23

2 Features Pages 24-29

1 Important Pages 6-23

4-A Forward-Facing

4-B Installing Forward-Facing With LATCH Straps

4-C Install Forward-Facing With Vehicle Seat Belt

4 Forward-Facing Use Pages 48-61

3-A Rear-Facing

3-B Installing Rear-Facing With LATCH Straps

3-C Install Rear-Facing With Vehicle Seat Belt

3 Rear-Facing Use Pages 30-47

5-A Securing Child 5-Point Harness

5 Securing Child Pages 62-69

6 Accessories Pages 70-71

7 Moving the LATCH Strap Pages 72-74

8-A How to Remove LATCH and Top Tether

8-B Choosing Vehicle Seat Location

8-C Unsafe Vehicle Seat Locations

8-D Vehicle Seat Belts

8 Additional Information Pages 75-85

9-A Cleaning Seat Pad

9-B Cleaning Crotch Buckle

9-C Cleaning Harness and LATCH Straps

9 Cleaning Seat Pad Pages 86-92

1-A A Quick Guide to Your Manual

This car seat is for children: Rear-Facing: 4-40 lb (1.8-18 kg)

Forward Facing: 22-65 lb (10-30 kg)

• Children less than 22 lb (10 kg) MUST use this car seat rear-facing. Review section

1-C for more information.

Get to Know Your Car Seat

Review section 2-A to see all of the features of this car seat.

Car Seat Assembly (On Select Models)

Adult Assembly Required

1. Attach Cup Holders

You MUST attach cup holders. Remove

seat cover. Line up tab on bottom of

cupholder with hole in shell. Press and

snap into place. Replace cover.

What Seating Location Should I Use?

Which Installation Method Should I Use?

This car seat can be installed in your vehicle using either the vehicle seat belt OR the

LATCH system. Both are equally safe to use. DO NOT USE BOTH AT THE SAME TIME.

Vehicle Seat Belt: Review section 8 and your vehicle owner’s manual to learn how to

install your car seat with the vehicle seat belts.

LATCH: The LATCH system allows you to securely attach your safety seat in your car

without using the vehicle seat belt and possibly to get a better fit. All 2003 and newer

model year vehicles are required to have a LATCH system, although some manufacturers

began including LATCH earlier. Some vehicle owner manuals use the term ISOFIX to

identify the LATCH system.

According to accident statistics, the safest

place for your child in any vehicle is the back

seat. The center of the back seat can be the

safest during a possible side impact.

The best seating location for this car seat is one that:

• Is recommended by your vehicle owner’s manual, and

• Results in a secure installation of this car seat.

Some vehicles have specific requirements for where the car seat can be installed, so

be sure to check your vehicle owner’s manual for available seating positions, if any.

Review section 8-B, 8-C of this manual AND your vehicle owner’s manual.

LATCH consists of lower anchors and top tether anchors, which are built-

in to your vehicle, and connecting hooks that are built-in to your car seat.

Lower anchors are used INSTEAD of the vehicle’s seat belt to secure the

child seat to the vehicle. Top tethers are used IN ADDITION to the lower

anchors OR the vehicle’s seat belt to secure a forward-facing car seat to

the vehicle.

Review your vehicle’s owner manual for exact location and use.

What is LATCH?

Vehicle Top Tether

Anchor Points

Vehicle Lower

Anchor Points

Typical seat in a passenger

vehicle. Other vehicle types

may have different LATCH

locations.

Vehicle Seat Bight

continue next page

11”

(28 cm)

When Installing Rear-Facing & Forward-Facing

Vehicle Seat Belt

There are two types of vehicle seat belts

that can be used. Lap/Shoulder Seat Belt

or Lap Only Seat Belt.

Review section 3-C & 4-C of this manual

AND your vehicle owner’s manual.

LATCH System

LATCH consists of two lower anchors, which are

built-in to your vehicle, and connecting hooks that

are built-in your car seat.

Review section 3-B & 4-B of this manual AND your

vehicle owner’s manual.

If allowed by your Vehicle Owners Manual, the

center seating position may be used if the anchor

spacing is 11” (28 cm) or greater.

Does Your Car Seat Fit Your Child Correctly?

To make sure your child is secured properly, review section 3 and 4 to

understand all of the actions you need to take to properly adjust the car seat

to fit your child.

Harness Height, Rear-Facing(A)

Harness straps at or just below the child’s

shoulders and

top of head must be at least 1”

(2.5 cm) below the headrest adjustment lever

(B).

Review section 5.

Buckle Position (C)

The correct slot is the one that is closest to

your child without being underneath them.

Review section 5.

Harness Tightness (D)

If your fingers slide off the harness straps

without pinching the straps, it is tight enough.

Review section 5.

For Rear-Facing, You Need to Adjust:

continue next page
