Graco NAUTILUS 80 ELITE Manuel utilisateur

Do not install or use

this child restraint until

you read and understand

the instructions in this

manual.

FAILURE TO PROPERLY

USE THIS CHILD

RESTRAINT INCREASES

THE RISK OF SERIOUS

INJURY OR DEATH IN A

SUDDEN STOP OR CRASH.

NAUTILUS 80ELITE

CHILD RESTRAINT/BOOSTER SEAT

www.gracobaby.com

PD322826A 5/15

1-A Quick Guide to Your Manual

1-B Welcome to the Graco Family

1-C Height and Weight Guidelines

1-D Before You Begin

If You Need Help

Certification

Car Seat’s Useful Life

Vehicle Seat Protection

Warm Weather Use

1-E Safety Warnings

1 Important Pages 6-25

2 Features Pages 26-31

3-A Forward-Facing Use

3-B Install Forward-Facing with LATCH Strap

3-C Install Forward-Facing with the Vehicle Seat Belt

3 Forward-Facing Pages 32-43

4-A Booster Use

4-B Install Backed Booster

4-C Install Backless Booster

4 Booster Pages 44-57

6 Accessories Page 75-76

5-A Securing Child 5-Point Harness

5-B Securing Child Backed Booster

5-C Securing Child Backless Booster

5 Securing Child Pages 58-74

7-A How to Remove LATCH and Tether Hook

7-B Choosing Vehicle Seat Location

7-C Unsafe Vehicle Seat Location

7-D Vehicle Seat Belts

8-A Cleaning Seat Pad

8-B Cleaning Buckle Strap

8-C Cleaning Harness and LATCH Strap

7 Vehicle Information Pages 77-87

8 Care & Cleaning Pages 88-91

1-A Quick Guide to Your Manual

This car seat is for children: Forward-Facing: 22-80 lb (10-36 kg)

Booster: 30-120 lb (14-54 kg)

Car Seat Assembly (On Select Models)

Adult Assembly Required

1. Lay child restraint flat on back

Grab seat pad fabric in sitting area to

expose the gutters.

Make Sure all hands, fingers and other

objects are clear of the gutters.

2. Attach Harness Straps

Make Sure the harness straps are securely

attached within the “T”-shaped slots around

the arms as shown.

Harness

Strap

T-Slot

Arm

3. Raise Seat Back

With your other hand, raise seat back so

that both arms LOCK into the gutters. Arms

should CLICK into the gutters. Seat assem-

bly should appear as shown.

4. Attach Seat Pad Side Loops

Pull elastic loop on the seat pad through the

vehicle belt guide on side of seat and attach

to hook as shown. Repeat on other side.

Click!

continue next page

5. Remove Zip Ties

From the bottom of the seat, cut the zip ties

off. Remove the zip ties and card board.

6. Assembly Complete

Get to Know Your Car Seat

What Seating Location Should I Use?

Review section 2-A to see all of the features of this car seat.

The best seating location for this car seat is one that:

• Is recommended by your vehicle owner’s manual, and

• Results in a secure installation of this car seat.

Some vehicles have specific requirements for where the car seat can be

installed, so be sure to check your vehicle owner’s manual for available

seating positions, if any. For example, sometimes the center rear seat has a

lap belt only vehicle seat belt, which cannot be used when this car seat is in

Booster mode.

Review section 7-B, 7-C of this manual AND your vehicle owner’s manual.

Which Installation Method Should I Use?

This car seat can be installed in your vehicle using either the vehicle seat

belt OR the LATCH system. Both are equally safe to use. DO NOT USE BOTH

AT THE SAME TIME.

Vehicle Seat Belt: Review section 7 and your vehicle owner’s manual to

learn how to install your car seat with the vehicle seat belts.

LATCH: The LATCH system allows you to securely attach your safety seat

in your car without using the vehicle seat belt and possibly to get a better

fit. All 2003 and newer model year vehicles are required to have a LATCH

system, although some manufacturers began including LATCH earlier. Some

vehicle owner manuals use the term ISOFIX to identify the LATCH system.

According to accident statistics, the safest

place for your child in any vehicle is the

back seat. The center of the back seat can

be the safest during a possible side impact.
