Graco PD269300A Manuel utilisateur

TABLE OF CONTENTS

Before You Begin

Important Information..................................3-5

Warnings.................................................6-8

Basic Information................................................9

What is LATCH?...............................................10

LATCH System................................................11

Features...................................................12

Use

Height & Weight Limits....................................13

Rear-facing Installation With LATCH.........14-15

Forward-facing Installation With LATCH...16-17

Rear-facing Installation With

Vehicle Seat Belts.....................................18-19

Forward-facing Installation With

Vehicle Seat Belts....................................20-21

Placing Child in Child Restraint................22-24

Operations and Adjustments........................25-33

s(ARNESS3TRAPS

s#HEST#LIP

s"UCKLE

s2ECLINE5PRIGHT0OSITIONS

s#HANGING(ARNESS3TRAP3LOTS

sLATCH Belt Routing

s2EMOVINGLATCH from Vehicle Anchor Points

sLATCH Storage

Vehicle Seat Belts.........................................34-38

s,OCKING#LIP 37

Additional Information.................................39-47

s4ETHER3TORAGE

s#UP(OLDER

s(EAD3UPPORT"ODY3UPPORT(ARNESS#OVER

s#AREAND#LEANING

s!IRCRAFT5SE

s3ECOND(AND#HILD2ESTRAINT

s"UCKLE#LEANING0ROCESS

2EPLACEMENT 0ARTS7ARRANTY48

s,OCKING#LIP3TORAGE

s)NSTRUCTION-ANUAL3TORAGE

Special Information

IMPORTANT INFORMATION

No child restraint can guarantee protection from injury in every situation, but proper use helps

reduce the risk of serious injury or death. READ THIS MANUAL CAREFULLY.

Read and understand instruction manual

and child restraint labels.

)NFANTSLESSTHANLBSKGmust use

child restraint rear-facing.

Do not use child restraint rear-facing in a

VEHICLESEATWITHANACTIVEFRONTAIRBAG

3ECURECHILDRENINREARSEATOFVEHICLE

WHENEVERPOSSIBLE

Safety First Check List

.EVERLEAVECHILDUNATTENDED

)NSTALLCHILDRESTRAINTSECURELYWITHVEHICLE

seat belt or LATCH belt.

$ONOTUSEAFTERDATESHOWNONBACKOF

child restraint.

$ONOTALLOWANYONEBABYSITTERRELATIVES

ETCTOUSECHILDRESTRAINTWITHOUTlRST

understanding all instructions.

0LEASElLLINTHEABOVEINFORMATION4HEMODELNUMBERANDDATEOFMANUFACTURECANBEFOUND

on a label on the child restraint. Fill out the prepaid registration postcard attached to the

harness and mail it today.

Child restraints could be recalled for safety reasons. You must register this restraint to be reached

in a recall. Send your name, address, and the restraint’s model number and date of manufacture

to: Graco Children’s Products, Inc.

Attn: Customer Service, 3 Glenlake Parkway Atlanta, GA 30328

or call 1-800-345-4109 or register online at

http://www.gracobaby.com/carseatregistration

Registration Information

Model Number:

Date of Manufacture:

Purchase Date:

IMPORTANT INFORMATION CONTINUED

For recall information:

)NTHE53!PLEASECONTACTOUR#USTOMER3ERVICE$EPARTMENTWITHANYQUESTIONSYOUMAYHAVE

CONCERNINGPARTSUSEORMAINTENANCE7HENYOUCONTACTUSPLEASEHAVEYOURPRODUCTSmodel

number and date of manufactureREADYSOTHATWEMAYHELPYOUEFlCIENTLY4HESENUMBERSCAN

BEFOUNDONASTICKERONTHEUNDERSIDEOFYOURCHILDRESTRAINT

1-800-345-4109 or www.gracobaby.com

www.cpsc.gov

www.NHTSA.gov

www.seatcheck.org

If You Need Help:

s#ALLTHE53'OVERNMENTS6EHICLE3AFETY(OTLINEAT

449nnnORGOTOHTTPWWW.(43!GOV

IMPORTANT INFORMATION CONTINUED

WARNINGS - Prevent serious injury or death:

NEVER PLACE THIS CHILD RESTRAINT

REAR-FACING IN A VEHICLE SEATING

LOCATION THAT HAS AN ACTIVE FRONT

AIR BAG. If an air bag inflates, it can hit the

child and child restraint with great force and

cause serious injury or death to your child.

Refer to your vehicle owner’s manual for

information about side air bags and child

restraint installation.

WARNINGS - Prevent serious injury or death:

Failure to follow these instructions

and child restraint labels can result

in child striking the vehicle’s

interior during a sudden stop or

crash. Secure child restraint with

a vehicle seat belt or LATCH that is

properly routed as shown in this

manual.

Select a suitable location for the

child restraint in your vehicle.

Choose the correct mode of use for

the child restraint depending on

your child’s size. Infants less than

20 lbs. (9 kg) must use this child

restraint rear-facing. Serious

crippling injury or death can result

if infant faces front of vehicle. The

AAP recommends that children be

rear facing until age 2 or until they

reach the maximum rear facing

height and weight rating for their

seat.

Vehicle seat belt system MUST hold

child restraint securely. Not all

vehicle seat belts can be used with

a child restraint.

If vehicle seat belt does not hold

child restraint securely, read

“Vehicle Seat Belts” section.

Never put a child restraint in a front

vehicle seat unless recommended

by vehicle owner’s manual.

National Highway Trafﬁc Safety

Administration (NHTSA) alerts

vehicle owners that according to

accident statistics, children are safer

in the back seat. For vehicles with

air bags, refer to vehicle owner’s

manual for child restraint

installation information.

WARNINGS - Prevent serious injury or death (continued):

If child restraint is in a crash, it

must be replaced. DO NOT use it

again! A crash can cause unseen

damage and using it again could

result in serious injury or death.

DO NOT use child restraint if it is

damaged or missing parts.

DO NOT use accessories or parts

other than those provided by

Graco. Their use could alter the

performance of the child restraint.

Rear-facing child restraint must be

properly leveled:

s4OORECLINEDCANRESULTININJURY

or ejection.

s4OOUPRIGHTCANRESULTIN

breathing difﬁculties.

Insert the harness straps in the

proper slots for your child.

Never leave child unattended, even

when sleeping. Child may become

tangled in harness straps and

suffocate or strangle.

DO NOT remove LATCH system from

child restraint. If using vehicle seat

belt to secure child restraint, LATCH

connectors must be stored. (see

section “LATCH storage”)

Never attach two

LATCH connectors

to one vehicle lower

anchor point unless

speciﬁcally allowed

by the vehicle

manufacturer.

BASIC INFORMATION:

Certiﬁcation

4HISCHILDRESTRAINTMEETSOREXCEEDSALL

APPLICABLEREQUIREMENTSOF&EDERAL-OTOR

6EHICLE3AFETY3TANDARDFORUSEINMOTOR

VEHICLESANDAIRCRAFT

Unoccupied Child Restraint

Always secure child restraint with LATCH or a

VEHICLESEATBELTEVENWHENUNOCCUPIED

In a crash, an unsecured child restraint can

injure passengers.

Dangerous Vehicle Seats

Do not use child restraint on rear-facing or

SIDEFACINGVEHICLESEATS

Child Restraint Useful Life

Vehicle Seat Protection

0ROTECTVEHICLESEAT5SEACHILDRESTRAINTMAT

TOWELORTHINBLANKETUNDERANDBEHINDCHILD

restraint.

Warm Weather

#HILDRESTRAINTPARTSCANGETVERYHOTINTHESUN

or warm weather.

To avoid burns, always check before putting

child in child restraint.

STOP using this child restraint or base and

THROWITAWAYYEARSAFTERTHEDATEOF

manufacture.

,OOKFORTHISSTICKERONREAROFCHILDRESTRAINT

MODEL

Date of Manufacture

GRACO CHILDREN'S PRODUCTS, INC.

ATLANTA, GA 30328 1-800-345-4109

Made in China

PD206938A

NAME

year month day

WHAT IS LATCH?

LATCH System for Vehicles:

5NITED3TATES&EDERAL-OTOR6EHICLE3AFETY

3TANDARDSHAVEDElNEDASYSTEMFOR

INSTALLINGCHILDRESTRAINTSINVEHICLES4HE

system is called LATCH. LATCH stands for:

Lower Anchorage and Tethers for CHildren.

LATCHINTHEVEHICLECONSISTSOFATOPTETHER

anchor point and two lower anchor points.

3OMEVEHICLEOWNERMANUALSUSETHETERM

ISOFIX to identify the new child restraint

ANCHORAGESYSTEM4HISCHILDRESTRAINTWITH

LATCHCANALSOBEUSEDINVEHICLESEATING

POSITIONSEQUIPPEDWITHISOFIX.

.EWERVEHICLESMAYHAVEONEORMORESEATING

POSITIONSEQUIPPEDWITHLATCH anchor points.

)FVEHICLEISEQUIPPEDWITHLATCHTHEVEHICLE

LOWERANCHORPOINTSMAYBEVISIBLEATTHEVEHICLE

SEATCREASE)FNOTVISIBLETHEYMAYBEMARKED

with a symbol (Fig. a) or a colored dot.

See your vehicle owner’s manual for exact

locations, anchor identiﬁcation, and

requirements for use with a child restraint.

#HECKVEHICLEOWNERSMANUALFORVEHICLETOP

TETHERANCHORLOCATIONS4HEYMAYBEIDENTIlED

using one of the anchor symbols (Fig. b or Fig. c).

4YPICALSEATINA

PASSENGERVEHICLE

/THERVEHICLETYPES

MAYHAVEDIFFERENT

LATCH locations.

Vehicle

Top Tether Anchor

Points

Vehicle

Lower Anchor

Points

Vehicle

Seat Crease

(Fig. a) (Fig. b) (Fig. c)
