Graco 4Ever Manuel utilisateur

Do not install or use

this child restraint until

you read and understand

the instructions in this

manual.

FAILURE TO PROPERLY

USE THIS CHILD

RESTRAINT INCREASES

THE RISK OF SERIOUS

INJURY OR DEATH IN A

SUDDEN STOP OR CRASH.

www.gracobaby.com

PD303535A 1/15

4EVER™/4EVER™FEATURING

ALL-IN-ONE CAR SEAT

1-A Quick Guide to Your Manual

1-B Welcome to the Graco Family

1-C Right Mode of Use

1-D Before You Begin

If You Need Help

Certification

Car Seat’s Useful Life

Vehicle Seat Protection

Warm Weather Use

1-E Safety Warnings

1 Important Pages 6-25

2 Features Pages 26-31

4-A Forward-Facing Use

4-B Install Forward-Facing with LATCH Straps

4-C Install Forward-Facing with the Vehicle Seat Belt

4 Forward-Facing Pages 45-57

3-A Rear-Facing Use

3-B Install Rear-Facing with LATCH Straps

3-C Install Rear-Facing with Vehicle Seat Belt

3 Rear-Facing Pages 32-44

6-A Securing Child 5-Point Harness

6-B Securing Child Backed Booster

6-C Securing Child Backless Booster

6 Securing Child Pages 74-90

7 Moving the LATCH Strap Pages 91-94

5-A Booster Use

5-B Install Backed Booster

5-C Install Backless Booster

5 Booster Pages 58-73

9-A How to Remove LATCH and Top Tether

9-B Choosing Vehicle Seat Location

9-C Unsafe Vehicle Seat Location

9-D Vehicle Seat Belts

10-A Cleaning Seat Pad

10-B Cleaning Buckle Strap

10-C Cleaning Harness and LATCH Straps

9 Vehicle Information Pages 96-106

8 Accessories Page 95

10 Care & Cleaning Pages 107-110

1-A Quick Guide to Your Manual

This car seat is for children: Rear-Facing: 4-40 lb (1.8-18 kg)

Forward-Facing: 22-65 lb (10-30 kg)

Booster: 30-120 lb (14-54 kg)

To attach the cup holders, match the

right cup holder to the right side of the

seat and the left to the left. Align the

tab on the cup holder with the slot in

the seat and slide down.

You will hear a “Click” when they

are secured in place.

Install Cup Holders

continue next page

Get to Know Your Car Seat

What Seating Location Should I Use?

Review section 2-A to see all of the features of this infant car seat.

The best seating location for this infant car seat is one that:

• Is recommended by your vehicle owner’s manual, and

• Results in a secure installation of this car seat.

Some vehicles have specific requirements for where the car seat can be

installed, so be sure to check your vehicle owner’s manual for available

seating positions, if any. For example, sometimes the center rear seat has a

lap belt only vehicle seat belt, which cannot be used when this car seat is in

Booster mode.

Review section 9-C, 9-D of this manual AND your vehicle owner’s manual.

NEVER place this child restraint rear-facing in a vehicle

seating location that has an active front air bag.

In the event there is no back seat, review your vehicle owner’s

manual to see how to use your infant child restraint.

Which Installation Method Should I Use?

This car seat can be installed in your vehicle using either the vehicle seat

belt OR the LATCH system. Both are equally safe to use. DO NOT USE BOTH

AT THE SAME TIME.

Vehicle Seat Belt: Review section 9 and your vehicle owner’s manual to

learn how to install your car seat with the vehicle seat belts.

LATCH: The LATCH system allows you to securely attach your safety seat

in your car without using the vehicle seat belt and possibly to get a better

fit. All 2003 and newer model year vehicles are required to have a LATCH

system, although some manufacturers began including LATCH earlier. Some

vehicle owner manuals use the term ISOFIX to identify the LATCH system.

According to crash statistics, the safest

place for your child in any vehicle is the

back seat. The center of the back seat can

be the safest during a possible side impact.

LATCH consists of lower anchors and top tether anchors, which are built-

in to your vehicle, and connecting hooks that are built-in to your car seat.

Lower anchors are used INSTEAD of the vehicle’s seat belt to secure the

child seat to the vehicle. Top tethers are used IN ADDITION to the lower

anchors OR the vehicle’s seat belt to secure a forward-facing car seat to

the vehicle.

Review your vehicle’s owner manual for exact location and use.

What is LATCH?

Vehicle Top Tether

Anchor Points

Vehicle Lower

Anchor Points

Typical seat in a passenger

vehicle. Other vehicle types

may have different LATCH

locations.

Vehicle Seat Bight

continue next page

When Installing Rear-Facing or Forward-Facing

Vehicle Seat Belt

There are two types of vehicle seat belts

that can be used. Lap/Shoulder Seat Belt

or Lap Only Seat Belt.

Review section 3-C, 4-C and 9 of this

manual AND your vehicle owner’s manual

before installing.

LATCH System

LATCH consists of lower anchors, which are

built-in to your vehicle, and connecting hooks

that are built-in your car seat.

Review section 3-B, 4-B of this manual AND

your vehicle owner’s manual before installing.
