Graco Car Seat Manuel utilisateur

www.gracobaby.com

My Size™ 70

Child Restraint

Owner’s Manual

FAILURE TO PROPERLY USE THIS

CHILD RESTRAINT INCREASES THE

RISK OF SERIOUS INJURY OR DEATH IN

A SUDDEN STOP OR CRASH.

READ THIS MANUAL.

Do not install or use this child restraint

until you read and understand the

instructions in this manual.

PD247312A

TABLE OF CONTENTS

Important Information...................4-6

Warnings...................................7-10

Basic Information............................11

What is LATCH?..........................12-13

LATCH System.................................14

Before You Begin

Use

Height & Weight Limits.............15-17

Features...................................18-19

Rear-Facing Installation

With LATCH.............................20-21

Forward-Facing Installation

With LATCH.............................22-23

Rear-Facing Installation With

Vehicle Seat Belts.....................24-25

Forward-Facing Installation With

Vehicle Seat Belts.....................26-27

Placing Child in Child Restraint..28-31

Operations and Adjustments......32-40

s(ARNESS3TRAPS32

s#HEST#LIP33

s"UCKLE33

s#ROTCH3TRAP!DJUSTMENT34-35

s2ECLINE5PRIGHT0OSITIONS36-38

s2EMOVINGLATCH from Vehicle

Anchor Points...............................39

sLATCH Storage.............................40

Vehicle Seat Belts.......................41-48

s,OCKING#LIP46-47

Additional Information...............49-57

s4ETHER3TORAGE49

s"ODY3UPPORTONCERTAINMODELS50

s(EAD0ILLOWONCERTAINMODELS51

s(ARNESS#OVERSONCERTAINMODELS51

s#AREAND#LEANING52-56

s"UCKLE#LEANING0ROCESS55

s!IRCRAFT5SE56

s3ECOND(AND#HILD2ESTRAINT56

Replacement Parts...........................60

s,OCKING#LIP3TORAGE60

s)NSTRUCTION-ANUAL3TORAGE60

TABLE OF CONTENTS

Read and understand instruction

manual and child restraint labels.

)NFANTSLESSTHANLBSKGmust

use child restraint rear-facing.

Infants or toddlers 20 to 40 lbs.

KGTOKGmay be rear-facing.

Do not use child restraint rear-facing

INVEHICLESEATWITHAIRBAG

Secure children in rear seat of

VEHICLEWHENEVERPOSSIBLE

.EVERLEAVECHILDUNATTENDED

Install child restraint securely with

VEHICLESEATBELTORLATCH belt.

 Do not use after the useful life date

SHOWNONBACKOFCHILDRESTRAINT

$ONOTALLOWANYONEBABYSITTER

RELATIVESETCTOUSECHILDRESTRAINT

without ﬁrst understanding all

instructions.

No child restraint can guarantee protection from injury in every

situation, but proper use helps reduce the risk of serious injury or death.

READ THIS MANUAL CAREFULLY.

IMPORTANT INFORMATION

0LEASElLLINTHEABOVEINFORMATION4HEMODELNUMBERANDDATEOF

manufacture can be found on a label on the child restraint. Fill out the prepaid

registration postcard attached to the harness and mail it today.

Child restraints could be recalled for safety reasons. You must register this

RESTRAINTTOBEREACHEDINARECALL3ENDYOURNAMEADDRESSANDTHERESTRAINTS

model number and date of manufacture to:

Graco Children’s Products, Inc.

Attn: Customer Service, 3 Glenlake Parkway Atlanta, GA 30328

or call 1-800-345-4109 or register online at

http://www.gracobaby.com/carseatregistration

Registration Information

Model Number:

Date of Manufacture:

Purchase Date:

CONTINUED

For recall information:

#ALLTHE53'OVERNMENTS6EHICLE3AFETY(OTLINEAT

449nnnORGOTOhttp://www.NHTSA.gov

If You Need Help:

)NTHE53!PLEASECONTACTOUR#USTOMER3ERVICE$EPARTMENTWITHANY

QUESTIONSYOUMAYHAVECONCERNINGPARTSUSEORMAINTENANCE7HENYOU

CONTACTUSPLEASEHAVEYOURPRODUCTSmodel number and date of

manufactureREADYSOTHATWEMAYHELPYOUEFlCIENTLY4HESENUMBERSCANBE

FOUNDONASTICKERONTHEUNDERSIDEOFYOURCHILDRESTRAINT

1-800-345-4109 or www.gracobaby.com

www.cpsc.gov

www.NHTSA.gov

www.seatcheck.org

IMPORTANT INFORMATIONCONTINUED

NEVER PLACE THIS CHILD RESTRAINT IN A

VEHICLE SEATING LOCATION THAT HAS A

FRONT AIR BAG. If an air bag inflates, it can

hit the child and child restraint with great

force and cause serious injury or death to

your child. Refer to your vehicle owner’s

manual for information about side air bags

and child restraint installation.

WARNINGS - Prevent serious injury or death:

Failure to follow these

instructions and child restraint

labels can result in child

striking the vehicle’s interior

during a sudden stop or crash.

Secure child restraint with a

vehicle seat belt or LATCH that is

properly routed as shown in this

manual.

Select a suitable location for the

child restraint in your vehicle.

Choose the correct mode of use

for the child restraint depending

on your child’s size. Infants less

than 20 lbs. (9.1kg) must use this

child restraint rear-facing.

Serious crippling injury or death

can result if infant faces front of

vehicle.

The American Academy of

Pediatrics (AAP) recommends that

children be rear-facing until age 2

or until they reach the maximum

rear-facing height and weight

rating for their seat.

Vehicle seat belt system MUST

hold child restraint securely. Not

all vehicle seat belts can be used

with a child restraint.

If vehicle seat belt does not hold

child restraint securely, read

“Vehicle Seat Belts” section.

WARNINGS- Prevent serious injury or death:

(continued)

Never put a child restraint in a

front vehicle seat unless

recommended by vehicle owner’s

manual. National Highway Trafﬁc

Safety Administration (NHTSA)

alerts vehicle owners that

according to accident statistics,

children are safer in the rear seat.

For vehicles with air bags, refer to

vehicle owner’s manual for child

restraint installation information.

If child restraint is in a crash, it

must be replaced. DO NOT use it

again! A crash can cause unseen

damage and using it again could

result in serious injury or death.

DO NOT use child restraint if it is

damaged or missing parts.

DO NOT use accessories or parts

other than those provided by

Graco. Their use could alter the

performance of the child restraint.

Rear-facing child restraint must be

properly leveled:

s4OORECLINEDCANRESULTIN

injury or ejection.

s4OOUPRIGHTCANRESULTIN

breathing difﬁculties.

WARNINGS- Prevent serious injury or death:

(continued)

Never leave child unattended,

even when sleeping. Child may

become tangled in harness straps

and suffocate or strangle.

DO NOT remove LATCH system

from child restraint. If using

vehicle seat belt to secure child

restraint, LATCH connectors must

be stored. (see section “LATCH

storage”)

Never attach two

LATCH connectors

to one vehicle

lower anchor

point unless

speciﬁcally

allowed by the

vehicle manufacturer.

NEVER use the rear-facing LATCH

belt and the forward-facing

LATCH belt at the same time. You

can only use one LATCH belt at a

time depending on which mode

you install the child restraint.

WARNINGS- Prevent serious injury or death:

(continued)
