GoMax Electronics SP-9018 Manuel utilisateur

SP-9018

1x8VGAoverCAT5Transmitter



UserManual



SafetyandNotice



TheSP‐90181x8VGAoverCAT5Transmitterhasbeentestedforconformancetosafety

regulationsandrequirements,andhasbeencertifiedforinternationaluse.However,likeallelectronic

equipments,theSP‐9018shouldbeusedwithcare.Pleasereadandfollowthesafetyinstructionsto

protectyourselffrompossibleinjuryandtominimizetheriskofdamagetotheunit.

zFollowallinstructionsandwarningsmarkedonthisunit.

zDonotattempttoservicethisunityourself,exceptwhereexplainedinthismanual.

zProvideproperventilationandaircirculationanddonotusenearwater.

zKeepobjectsthatmightdamagethedeviceandassurethattheplacementofthisunitisona

stablesurface.

zUseonlythepoweradapterandpowercordsandconnectioncablesdesignedforthisunit.

zDonotuseliquidoraerosolcleanerstocleanthisunit.Alwaysunplugthepowertothedevice

beforecleaning.

TheSP‐90181x8VGAoverCAT5Transmitterprovidesthemostflexiblesolutionbywhichthe

highresolutionPCvideoandhighqualitystereoaudiocanbetransmittedtodifferentlocationsover

superlongdistances.Builtwith2VGAanddigital/analogaudioloopouts,localA/Vreceiverscan

provideextravideoandaudiofan‐outsthroughtypicalVGA,SPDIF,andanalogaudiocables.Thehigh

bandwidthVGAcanbetransmittedupto65meters(210feet)onthelocalports.SP‐9018alsoextends

VGAandstereoaudiosourceupto330meters(1000feet)throughcosteffectiveCAT‐5LANcables.

AccompanyingthereceiversofCV‐97VGACAT5extenderseriesequippedwiththeequalization,gain

controlandde‐skewfunctions,thevideoandaudioqualitycanbefurtherassuredandmakethe

qualityofoveralltransmissionsuperiorthantheotherVGAsplittersonthemarket.

Tobemoreflexibletoapplications,modelswith4ports(SP‐9014),12ports(SP‐9112),and16

ports(SP‐9116)RJ‐45outputsarealsoavailable.



Features

zSupportsuptoWUXGAorUXGAto300m(1,000ft)

zSupportsanalogstereoaudio

zSupportsS/PDIF

zAdjustableequalizationandgaincontrolonRXunit

zDe‐skewcompensationavailableforRGBdelaycontrol

Note:Thelengthdependsonthecharacteristicsandqualityofthecables.Higherresolutionsandlonger

transmissiondistancesrequirelowskewcables(<25ns/100m)forbestperformance.



Introduction



CAT5cable

CAT5cable

upto330m (1000ft)

VGAcable

SP-9018

VGA source

LCD#1

-917D

LCD#2

CAT5cable

LCD#3

VGAcable

CAT5cable

LCD#4

VGAcable

CAT5cable

LCD#8

LCD#7

LCD#5

VGAcable

LCD#6

VGAcable

-917D

VGAcable

917D

-917D

917D C

917D

PackageContent

z1xSP‐9018unit

z1x5V4Apoweradapter

z1xUserManual



TechnicalSpecifications

zInputVideoSignal:1.2Voltsp‐p

zVideoInputBandwidth:350MHz

zVGAConnector:D‐Sub15Pin

zS/PDIF:RCA

zAnalogstereoconnector:3.5mmphonejack

zPowerSupply:5V4A

zPowerConsumption:15Watts(max)

zRJ‐45Connector:2indicationLEDs

zRS‐232Connector:DSub‐9

zDimensions:123mmx95mmx25mm(4.8”x3.7”x1”)(LxWxH)

zWeight:400g(14oz)

SP‐9018



1. Powerjack5VDC

2. VGAInput:connectaVGAsourcehere

3. StereoaudioInput:connectaaudiosourcehere

4. SPDIFaudioInput

5. Localvideoandaudioloopout

6. Localvideoandaudioloopout

7. RJ45Outputs:linktotheCV‐97seriesreceiver



Panel Descriptions

Remote Control

12567

34



BroadcastsPCA/Vsignalsto8remotedisplaysandtwolocalreceivers

1.Switchoffalldevices,includingmonitors.

2.ConnectaVGAandaudiosource(suchasaPC)totheVGAandaudioIn.

3.Connecttothereceivers(suchasCV‐917‐RXorCV‐917D‐RX)viaRJ45connectorsbyaCAT5ecable.

4.Plugin5V4ADCpowersupply.

5.Poweronthereceiver’smonitorsandspeakers.

6.PoweronthePCsource.



Hardware Installation



1. AllthetransmissiondistancesaremeasuredusingBeldenCAT‐5e125MHzSolidcableand

ASTRODESIGNVideoSignalGeneratorVG‐859C.Thetransmissiondistanceisdefinedasthe

distancebetweentheSP‐9018andtheremoteVGAdisplay.

2. ThetransmissionlengthislargelyaffectedbythetypeofLANcables,thetypeofA/Vsources,and

thetypeofA/Vdisplay.ThetestingresultshowssolidLANcables(usuallyin300m/1000ftform)

cantransmitalotlongersignalsthanstrandedLANcables(patchcord).ShieldedSTPcablesare

bettersuitthanunshieldedUTPcables.AsolidUTPCAT5ecableshowslongertransmissionlength

thanstrandedSTPCAT6cable.Forlongextensionusers,solidLANcablesareyouronlychoice.

3. EIA/TIA‐568‐Btermination(T568B)forLANcablesisrecommendedforbetterperformance.

4. ToreducetheinterferenceamongtheunshieldedtwistedpairsofwiresinLANcable,youcanuse

shieldedLANcablestoimproveEMIproblems,whichisworseninlongtransmission.

5. BecausethequalityoftheLANcableshasthemajoreffectsinhowlongtransmissiondistancewill

bemadeandhowgoodisthereceiveddisplay,theactualtransmissionlengthissubjecttoyour

LANcables.Forresolutiongreaterthan1080ior1280x1024,aCAT‐6cableisrecommended.



Notice



TheSELLERwarrantstheSP‐90181x8VGAoverCAT5Transmittertobefreefromdefectsinthe

materialandworkmanshipfor1yearfromthedateofpurchasefromtheSELLERoranauthorized

dealer.Shouldthisproductfailtobeingoodworkingorderwithin1yearwarrantyperiod,TheSELLER,

atitsoption,repairorreplacetheunit,providedthattheunithasnotbeensubjectedtoaccident,

disaster,abuseoranyunauthorizedmodificationsincludingstaticdischargeandpowersurges.

Unitthatfailsunderconditionsotherthanthosecoveredwillberepairedatthecurrentpriceof

partsandlaborineffectatthetimeofrepair.Suchrepairsarewarrantedfor90daysfromthedayof

reshipmenttotheBUYER.Iftheunitisdeliveredbymail,customersagreetoinsuretheunitorassume

theriskoflossordamageintransit.Undernocircumstanceswillaunitbeacceptedwithoutareturn

authorizationnumber.

Thewarrantyisinlieuofallotherwarrantiesexpressedorimplied,includingwithoutlimitations,

anyotherimpliedwarrantyorfitnessormerchantabilityforanyparticularpurpose,allofwhichare

expresslydisclaimed.

Proofofsalemayberequiredinordertoclaimwarranty.CustomersoutsideTaiwanare

responsibleforshippingchargestoandfromtheSELLER.Cablesarelimitedtoa30daywarrantyand

cablemustbefreefromanymarkings,scratches,andneatlycoiled.

Thecontentofthismanualhasbeencarefullycheckedandisbelievedtobeaccurate.However,

TheSELLERassumesnoresponsibilityforanyinaccuraciesthatmaybecontainedinthismanual.The

SELLERwillNOTbeliablefordirect,indirect,incidental,special,orconsequentialdamagesresulting

fromanydefectoromissioninthismanual,evenifadvisedofthepossibilityofsuchdamages.Also,

thetechnicalinformationcontainedhereinregardingtheSP‐9018featuresandspecificationsissubject

tochangewithoutfurthernotice.



imited Warranty
