Review this Quick Reference Guide for an overview of some important features in your GMC Terrain.

More detailed information can be found in your Owner Manual. Some optional equipment described in this guide

may not be included in your vehicle. For easy reference, keep this guide with your Owner Manual in your glove box.

www.gmc.com

Instrument Panel .............2

Remote Keyless Entry

Transmitter .................4

Rear Door Safety Locks .......4

Tilt/Telescopic Steering Wheel ..4

Driver’s Seat Adjustments......5

Rear Seat Adjustments ........6

Exterior/Interior Lighting .......6

Wipers and Washers..........7

Power Programmable Liftgate...7

Audio System ...............8

Bluetooth System ...........10

Audio Steering Wheel Controls . 10

GMC IntelliLink .............11

OnStar®with 4G LTE ........12

Navigation System ..........13

Rear Seat Entertainment

System....................13

Cruise Control ..............14

Forward Collision Alert/

Lane Departure Warning......14

Driver Information Center .....15

Vehicle Personalization .......15

Climate Controls ............16

Automatic Transmission

Features ..................17

StabiliTrak/Traction

Control Systems ............17

Accessory Power Outlets .....18

Passenger Presence System ..18

Parking Brake ..............18

Wind Noise ................18

Roof Rack Cross Rails .......19

Tire Pressure Monitor ........19

Engine Oil Life System .......19

Refueling the Vehicle ........19

Roadside Assistance.........20

myGMC and OnStar

Mobile Apps................20

GMC Owner Center..........20

This

Important

Information To Be

REMOVED

AND READ

BY THE

CUSTOMER

Turn Signal Lever/

Exterior Lamp Control

Driver

Information

Center

Tilt/Telescopic Steering

Wheel Lever

Windshield

Wipers Lever

Instrument Panel

Illumination Control

Cruise Control

Buttons

Instrument Panel

Safety Belt

Reminder

Check Engine

Low Tire Pressure

Brake System

Warning

Antilock Brake

System Warning

Charging System

Oil Pressure

Airbag Readiness

Security

Fog Lamps

Cruise Control On/Set

Traction Control Off

StabiliTrak/Traction

Control Off

StabiliTrak/Traction

Control Warning

Lights On

Audio Steering

Wheel ControlsF

Express-Down

Power

Windows (All)

Power Door

Locks Button

Instrument Cluster Symbols

Refer to your Owner Manual to learn about the information being relayed by the lights, gauges and

indicators of the instrument cluster.

See In Brief in your Owner Manual.

Infotainment

System/

Navigation

SystemF

Power Door

Locks Button

StabiliTrak

Button

Center Vent

Open/Close

Control

Accessory

Power

Outlet

Rear Door

Safety Locks

Button

Hazard Warning

Flashers Button

Driver

Information

Center

Controls

Climate Controls/

Heated Seat

ButtonsF

Center Vent

Open/Close

Control

eco

Button

F Optional equipment

remote Keyless entry transmItter

Unlock

Press to unlock the driver’s door. Press

again to unlock all doors and the liftgate.

Lock

Press to lock all doors and the liftgate.

The driver’s door will not lock if open.

Liftgate

Press to open/stop/close the power

liftgateF.

Vehicle Locator/Panic Alarm

Press and release to locate your vehicle.

The turn signal lamps will ash and the

horn will sound.

Press and hold to activate the alarm. The

turn signal lamps will ash and the horn will

sound until the button is pressed again or

the ignition is turned on.

Remote Vehicle StartF

Press and release the Lock button and

then press and hold the button until the

turn signal lamps ash to start the engine

from outside the vehicle. After entering the

vehicle, turn the ignition to the On position.

– During a remote start, the engine will

run for 10 minutes.

– Press and hold the button until

the parking lamps turn off to cancel a

remote start.

Note: To change the remote lock, unlock,

and remote start settings, go to Remote Lock,

Unlock, Start in the Vehicle Settings menu.

See Keys, Doors and Windows in your Owner Manual.

With the vehicle in Park, push down the lever on the left side of the steering column to

adjust the steering wheel. The steering wheel can then be moved up or down and in or

out. After adjustment, pull up the lever to lock the steering wheel in place.

See Instruments and Controls in your Owner Manual.

rear Door safety locKs

FOptional equipment

Press the rear door Safety Locks

button located on the center of the instru-

ment panel to prevent the rear doors

from opening from the inside. Press

again for normal operation.

See Keys, Doors and Windows in your Owner Manual.

tIlt/telescoPIc steerIng Wheel

A. Seat Fore/Aft Adjustment

Lift the handle under the front of the

seat to manually slide the seat forward

or rearward.

B. Seat Height Adjustment

Press the vertical control to raise or

lower the seat.

C. Lumbar Adjustment

Press the horizontal control to adjust the

amount of lumbar support.

D. Seatback Recline Adjustment

Lift the lever to manually recline or raise

the seatback.

Manual Driver’s Seat

Power Driver’s SeatFA. Seat Adjustment

Move the front horizontal control to

move the seat forward or rearward and

to raise, lower or tilt the seat.

B. Seatback Recline Adjustment

Move the vertical control to recline or

raise the seatback.

C. Lumbar Adjustment

Press the rear horizontal control to

adjust the amount of lumbar support.

Memory Driver’s SeatF

Set Memory Positions

1. Adjust the driver’s seat and power outside mirrors to the desired position.

2. Press and hold the MEM button and button 1on the outboard side of the driver’s seat

until a beep sounds.

3. Repeat these steps using button 2for a second driver.

Recall Memory Positions

Press and hold button 1or 2until the memory position is reached.

Note: To change the memory recall and exit settings, go to Comfort and Convenience in the Vehicle

Settings menu.

See Seats and Restraints in your Owner Manual.

F Optional equipment

DrIver’sseat aDjustments

A CB

BA DC

exterIor/InterIor lIghtIng

Automatic Headlamp System

Rotate the outer band to operate the

exterior lamps.

Headlamps

Manual operation of the headlamps.

Parking Lamps

Manual operation of the parking lamps.

AUTO Automatic Headlamp System

Activates the Daytime Running Lamps

(DRLs) in the daytime and the headlamps

and other exterior lamps at night or when

necessary.

Off/On

Fog Lamps

Rotate the inner band to turn the fog lamps

on or off.

TIP: Push the lever to turn on the high beam

headlamps; pull the lever to return to low beam

operation. Pull the lever to activate the ash-to-

pass feature.

Instrument Panel Lighting

The control knob is located on the left

side of the instrument panel next to the

steering column.

Instrument Panel Brightness

Turn the knob to increase or decrease

the instrument panel lighting.

Dome Lamp

The dome lamps are controlled by a

three-position switch on the front overhead

console.

Dome Lamp Override/Off

Door Open (Default position)

See Lighting in your Owner Manual.

TIP: The second-row dome lamps also can be

turned on/off using the buttons by the lamps.

A. Seat Fore/Aft Adjustment

Lift the bar under the front of the seat

to manually slide the seat forward or

rearward.

B. Folding/Reclining Seatback

Unbuckle the rear safety belts and

place the front seatbacks in the upright

position. Lift the lever on top of each

seatback to fold down the seatback.

Lift and hold the lever to adjust the seat-

back to any of three recline positions.

See Seats and Restraints in your Owner Manual.

rear seat aDjustments

WIPers anD Washers

Windshield Wipers and Washer

Move the lever to operate the

windshield wipers.

HI Continuous High Speed

LO Continuous Low Speed

INT Intermittent

Rotate the band to adjust the delay

between wipes.

OFF

Mist

Washer Fluid

Pull the lever toward you to spray washer

uid on the windshield.

Rear Wiper and Washer

The rear wiper switch is located on the end

of the wiper lever.

A. ON Continuous Low Speed

B. OFF

C. INT Intermittent

Washer Fluid

Push the lever away from you to spray

washer uid on the rear window.

See Instruments and Controls in your Owner Manual.

PoWer Programmable lIftgateF

Programming the Liftgate Height

1. Turn the power liftgate switch to the

3/4 mode position.

2. Open the liftgate by pressing the RKE

transmitter liftgate button or the touch-

pad on the center of the liftgate.

3. Stop the liftgate at the desired height

by pressing any liftgate button. Adjust

manually to the desired height if

necessary.

4. To save the setting, press and hold the

button next to the liftgate latch for three

seconds. The taillamps will ash when

the setting is saved.

See Keys, Doors and Windows in your Owner Manual.

MAX

Fully open the liftgate.

3/4

Open the liftgate to the programmed height.

OFF

Operate the liftgate manually.

F Optional equipment

auDIo system

See your Infotainment System Owner Manual.

Power/

Volume

HOME

HOME:

Main screen

BACK:

Move back

one level in

the menus

1–6:

Preset

radio

stations

SOURCE:

Select radio

band, CD,

auxiliary source

FAV:

Display pages

of favorite

radio stations

MENU/SEL:

Tune radio

stations/

Open and

select a menu

SEEK:

Previous/

Next radio

station or track

CONFIG:

Congure

system

settings

Phone

Mute

Time

INFO:

Display

available

song

information

Eject

disc

TONE:

Tone and

sound

settings

PLAY/

PAUSE

Standard audio system shown.

Other systems are similar.

Refer to your Owner Manual for important safety information about using the infotainment system

while driving.

auDIo system

Setting the Time

1. Press the Clock button.

2. Touch the Set Time screen button.

3. Touch the + (plus) or – (minus) screen button to adjust the hours, minutes or date.

4. Touch the OK screen button to conrm the setting.

Storing Favorite Stations

Radio stations from all bands (AM, FM or XM♦) can be stored, in any order, on up to six

pages of favorites.

1. Tune in the desired radio station.

2. Press the FAV button to display the page where the station is to be stored.

3. Press and hold one of the six preset screen buttons until a beep is heard.

4. Repeat the steps for each desired station.

Portable Audio Devices

An accessory power outlet, 3.5-mm auxiliary input jack and a USB portFare located in the

center console.

Active Noise Cancellation (4-cylinder models only)

The Active Noise Cancellation (ANC) system monitors and effectively cancels out poten-

tially undesirable vehicle noises at certain vehicle speeds. For optimal ANC performance,

do not block the rear speaker located on the right side of the cargo area.

See your Infotainment System Owner Manual.

F Optional equipment

An iPod®, iPhone®, MP3 Player, a USB

ash drive or a USB mass storage

device can be connected to the USB

port. GMC IntelliLinkFwill read the

device, build a list of voice commands,

and ll in missing song information and

album graphics. Search for music on-

screen or by voice commands.

A portable audio device connected to

the auxiliary input jack can be controlled

only by using the portable device con-

trols. To optimize speaker volume, fully

increase the volume level of the portable

device.

10 FOptional equipment

bluetooth® system

Before using a Bluetooth-enabled device in the vehicle, it must be paired with the in-vehicle

Bluetooth system. Not all devices will support all functions. The pairing process is disabled

when the vehicle is moving. For more information about Bluetooth pairing, device compat-

ibility and text messaging, visit www.gmtotalconnect.com.

Pair a Phone

1. To use voice recognition, press the Push to Talk button on the steering wheel;

after the beep, say “Pair.”

To use the screen buttons, press the CONFIG button and then touch Phone Settings >

Pair Device.

2. Start the pairing process on the phone. Locate your vehicle name or IntelliLink on

the phone.

3. Enter the four-digit code that appears on the touch screen into the phone or conrm the

six-digit code on the phone.

4. If your phone prompts you to accept the connection or phone book download, click “yes”

and always allow.

Text MessagingF

Text messages can be displayed or played back over the audio system; or a predened

message can be sent. Only SMS text messages are supported.

1. Touch the Messages screen button on the home page.

2. Once all messages are retrieved, the Text Message Inbox displays.

3. Select a text message to view (available only if the vehicle is not in motion) or listen to.

A pop-up screen will display when there is an incoming text message.

See your Infotainment System Owner Manual.

auDIo steerIng Wheel controlsF

Next/Previous

Rotate up or down to go to the next or

previous favorite radio station, track or le.

Push to Talk

Press to start voice recognition.

Say OnStar, navigation or an IntelliLink

command.

End Call/Mute

Press to end or reject an OnStar or

a Bluetooth call.

Press to mute the vehicle speakers.

See Instruments and Controls in your Owner Manual.

+ VOL – Volume

Press +or –to adjust the volume.

SRC Source

Press to select an audio source.

Table des matières

Autres manuels GMC Automobile

GMC

GMC 1996 Suburban Manuel utilisateur

GMC

GMC Yukon Denali XL 2005 Manuel utilisateur

GMC

GMC 2011 Sierra Denali Manuel utilisateur

GMC

GMC Sierra 2023 Manuel utilisateur

GMC

GMC 2010 GMC Yukon/Yukon XL Manuel utilisateur

GMC

GMC EXPLORER Manuel utilisateur

GMC

GMC 2015 Sierra Denali HD Manuel utilisateur

GMC

GMC YUKON DENALI 1999 Manuel utilisateur

GMC

GMC 2001 Sonoma Manuel utilisateur

GMC

GMC Defense 2006 Guide de configuration

GMC

GMC Buick Encore 2022 Manuel utilisateur

GMC

GMC 2005 Canyon Manuel utilisateur

GMC

GMC 1999 Sierra 1500 Pickup Manuel utilisateur

GMC

GMC Denali 2004 Manuel utilisateur

GMC

GMC Sierra Denali 2014 Manuel utilisateur

GMC

GMC 2002 Sonoma Manuel utilisateur

GMC

GMC YUKON - BROCHURE 2010 Manuel utilisateur

GMC

GMC Sierra 2008 Manuel utilisateur

GMC

GMC 1994 Safari Manuel utilisateur

GMC

GMC 1996 Jimmy Manuel utilisateur

GMC

GMC YUKON DENALI 2000 Manuel utilisateur

GMC

GMC Terrain Denali 2015 Manuel utilisateur

GMC

GMC YUKON/XL 2023 Instructions de montage

GMC

GMC Sierra Denali 2015 Instructions de montage

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur

Skoda

Skoda FABIA RS - ANNEXE 118 Manuel utilisateur

Seat

Seat toledo Manuel utilisateur

PEUGEOT

PEUGEOT 206 CC Manuel utilisateur

SSANGYONG

SSANGYONG ACTYON 2010.01 Manuel utilisateur

Renault

Renault Master Manuel utilisateur
