GigaDevice Semiconductor GD32130F-START Manuel utilisateur

GigaDevice Semiconductor Inc.

GD32130F-START

User Guide

V3.0

(Nov.20.2019)

User Guide

GD32130F-START

1 /11

Table of Contents

Table of Contents ...............................................................................................................................1

List of Figures.....................................................................................................................................2

List of Tables.......................................................................................................................................3

1. Summary......................................................................................................................................4

2. Function Pin Assign....................................................................................................................4

3. Getting started.............................................................................................................................4

4. Hardware layout overview..........................................................................................................5

4.1. Power supply........................................................................................................................5

4.2. Boot option...........................................................................................................................5

4.3. LED........................................................................................................................................5

4.4. KEY........................................................................................................................................6

4.5. GD-Link.................................................................................................................................6

4.6. Extension..............................................................................................................................6

4.7. MCU.......................................................................................................................................7

5. Routine use guide .......................................................................................................................7

5.1. GPIO_Running_LED ............................................................................................................7

5.1.1. DEMO purpose...............................................................................................................7

5.1.2. DEMO running Result.....................................................................................................7

5.2. GPIO_Key_Polling_mode....................................................................................................8

5.2.1. DEMO purpose...............................................................................................................8

5.2.2. DEMO running Result.....................................................................................................8

5.3. EXTI_Key_Interrupt_mode ..................................................................................................8

5.3.1. DEMO purpose...............................................................................................................8

5.3.2. DEMO running Result.....................................................................................................8

5.4. TIMER_Key_EXTI .................................................................................................................9

5.4.1. DEMO purpose...............................................................................................................9

5.4.2. DEMO running result.......................................................................................................9

6. Revision history ........................................................................................................................10

User Guide

GD32130F-START

2 /11

List of Figures

Figure 4-1 Schematic diagram of power supply................................................................................................5

Figure 4-2 Schematic diagram of boot option....................................................................................................5

Figure 4-3 Schematic diagram of LED function.................................................................................................5

Figure 4-4 Schematic diagram of Key function.................................................................................................6

Figure 4-5 Schematic diagram of GD-Link function.........................................................................................6

Figure 4-6 Schematic diagram of Extension Pin...............................................................................................6

Figure 4-7 Schematic diagram of MCU Pin......................................................................................................... 7

User Guide

GD32130F-START

3 /11

List of Tables

Table 2-1 Pin assignment ........................................................................................................................................4

Table 4-1 Boot configuration..................................................................................................................................5

Table 6-1 Revision history.....................................................................................................................................10

User Guide

GD32130F-START

4 /11

1. Summary

GD32130F-START-V1.0 board uses GD32F130F8P6 as the main controller. As a complete

development platform of GD32F1x0 powered by ARM® Cortex™-M3 core, the board

supports full range of peripherals. It uses mini-USB interface to supply 3.3V power. SWD,

Reset, Boot, User button key, LED and Extension Pin are also included. This document

details its hardware schematic and the relevant applications.

2. Function Pin Assign

Table 2-1 Pin assignment

Function

Description

LED

PA1

LED1

PA2

LED2

KEY

PA0

K1-User Key

RESET

K2-Reset

3. Getting started

The START Board uses mini-USB connecter to get power, the hardware system power is

+3.3V. A mini-USB cable are necessary to down programs. Select the correct boot mode and

then power on, the LED3 will turn on, which indicates the power supply is ready.

There are Keil version and IAR version of all projects. Keil version of the projects are created

based on Keil MDK-ARM 4.74 uVision4. IAR version of the projects are created based on

IAR Embedded Workbench for ARM 7.40.2. During use, the following points should be

noted:

1. If you use Keil uVision4 to open the project, install the GD32F1x0_AddOn.3.2.0.exe to

load the associated files.

2. If you use Keil uVision5 to open the project, there are two ways to solve the "Device

Missing (s)" problem. One is to install GigaDevice.GD32F1x0_DFP.3.2.0.pack. In Project

menu, select the Manage sub menu, click on the “Version Migrate 5 Format...” menu, the Keil

uVision4 project will be converted to Keil uVision5 project. Then add “C:\Keil_v5\ARM\Pack

\ARM\CMSIS\4.2.0\CMSIS\Include” to C/C++ in Option for Target. The other is to install

Addon directly. Select the installation directory of Keil uVision5 software, such as C:\Keil_v5,

in Destination Folder of Folder Selection. Select the corresponding device in Device of

Option for Target and add “C:\Keil_v5\ARM\Pack\ARM\CMSIS\4.2.0\CMSIS\Include” to

C/C++ in Option for Target.

3. If you use IAR to open the project, install IAR_GD32F1x0_ADDON.3.2.0.exe to load the

associated files.

User Guide

GD32130F-START

5 /11

4. Hardware layout overview

4.1. Power supply

Figure 4-1 Schematic diagram of power supply

Vout 2

Vin

U2 LM1117-3.3

16V/10uF,AVX

GND

C11

50V/0.1uF

+3V3

LED3

LED0603

470Ω

TP1

TP +3V3

+U5V P1

SMD1210P005TF

4.2. Boot option

Figure 4-2 Schematic diagram of boot option

10KΩ

JP4

BOOT0

GND BOOT0

+3V3

Table 4-1 Boot configuration

BOOT1

BOOT0

Boot Mode

Default

2-3

User memory

1-2

System memory

Changed by ISP

1-2

SRAM memory

4.3. LED

Figure 4-3 Schematic diagram of LED function

PA1LED1

LED0603

LED

680ΩGND

PA2LED2

LED0603

680ΩGND

User Guide

GD32130F-START

6 /11

4.4. KEY

Figure 4-4 Schematic diagram of Key function

PA0

10KΩ

+3V3

GND

50V/0.1uF

KEY

K-1102B

4.5. GD-Link

Figure 4-5 Schematic diagram of GD-Link function

L_USB_Ctr

C100

50V/20pF

C102

50V/20pF

Y101

HC-49S-8MHz

GND

L_NRST

+3V3

GND

R102

10KΩ

C103

50V/0.1uF

R104

10KΩ

GND

C105

50V/0.1uF

C106

50V/0.1uF

C107

50V/0.1uF

C108

50V/0.1uF

R101

1MΩL_OSC_IN

L_OSC_OUT

L_OSC_IN

L_OSC_OUT

L_NRST

GND

+3V3 GND

JP100

4×1P2.54

+3V3

GND

MCU SWD

Reset

L_TMS/IO

L_TDI

L_TDO/SWO

L_TCK/CLK

L_USB_DP

L_SWDIO

L_SWDCK

L_SWDIO

L_SWDCK

+3V3

L_USB_DM

BOOT0

NRST

OSC_IN/PD0

OSC_OUT/PD1

PA0-WKUP

PA1

PA2

PA3

PA4

PA5

PA6

PA7

PA8

PA9

PA10

PA11

PA12

PA13/JTMS/SWDIO

PA14/JTCK/SWCLK

PA15/JTDI

PB018

PB119

PB2/BOOT1 20

PB3/JTDO 39

PB4/JNTRST 40

PB541

PB642

PB743

PB845

PB946

PB10 21

PB11 22

PB12 25

PB13 26

PB14 27

PB15 28

PC13-TAMPER-RTC 2

PC14-OSC32_IN 3

PC15-OSC32_OUT 4

VBAT

VDD_1

VDD_2

VDD_3

VDDA

VSS_1 23

VSS_2 35

VSS_3 47

VSSA 8

GD32F103C8T6

L_TReset

L_LED1

L_LED2

L_LED1 LED0603

L_LED2 LED0603

R103

10KΩGND

R109 1KΩ

R110 1KΩGND

GND

R105 22R

R106 22R

R108

1MΩC104

50V/4700pF

L_USB_DM

L_USB_DP

GND

R107 1.5KΩL_USB_Ctr

VCC 1

D- 2

D+ 3

ID 4

GND 5

SHELL 6

CN100

Mini_USB

+U5VC10

50V/0.1uF

4.6. Extension

Figure 4-6 Schematic diagram of Extension Pin

Extension Pin

PA4

PA5

PA6

PA7

PA1PB1

PA3

PA2PA9

PA10

PA13

PA14

PA0

+3V3

GND

JP1

HEADER 8

JP2

HEADER 8

GND

User Guide

GD32130F-START

7 /11

4.7. MCU

Figure 4-7 Schematic diagram of MCU Pin

PA4

PA5

PA6

PA7

PA0

PA1

PA3

PA2

PA9

PA10

PB1

50V/20pF

HC-49S-G20SSA-8MHz

GND

NRST

K-1102B

+3V3

GND

10KΩ

50V/0.1uF

BOOT0

50V/0.1uF

10KΩ

1MΩ

10KΩ

OSC_IN

OSC_OUT

GND

+3V3

NRST

PA13

PA14SWCLK

SWDAT

+3V3

SWDAT

SWCLK

GND

NRST

L_TMS/IO

L_TCK/CLK

L_TReset

GDLinkSWD

BOOT0 1

PF0/OSC_IN 2

PF1/OSC_OUT 3

NRST 4

VDDA 5

PA0

PA1

PA2

PA3

PA4

PA5

PA6

PA7

PB1

14 VSS 15

VDD 16

PA9

PA10

PA13

PA14

GD32F130F8P6

OSC_IN

OSC_OUT

+3V3

5. Routine use guide

5.1. GPIO_Running_LED

5.1.1. DEMO purpose

This Demo includes the following functions of GD32 MCU:

Learn to use GPIO for controlling the LED

Learn to use SysTick to generate 1ms delay

GD32130F-START-V1.0 board has two LEDs. The LED1 and LED2 are controlled by GPIO.

This demo will show how to light the LED.

5.1.2. DEMO running Result

Download the program <01_GPIO_Running_LED> to the board, the states of LED1 and

LED2 are toggled every 500ms.

User Guide

GD32130F-START

8 /11

5.2. GPIO_Key_Polling_mode

5.2.1. DEMO purpose

This Demo includes the following functions of GD32 MCU:

Learn to use GPIO control the LED and the KEY

Learn to use SysTick to generate 1ms delay

GD32130F-START-V1.0 board has two keys and two LEDs. The two keys are Reset key and

User key. The LED1 and LED2 are controlled by GPIO.

This demo will show how to use the User key to control the LED1. When press down the

User Key, it will check the input value of the IO port. If the value is 1, wait for 50ms. Then

check the input value of the IO port again. If the value is still 1, indicates that the button is

pressed down successfully, and light the LED1.

5.2.2. DEMO running Result

Download the program <02_GPIO_Key_Polling_mode> to the board, first of all, all the LEDs

will be flashed once for test. Then press down the User Key, LED1 will be turned on. Press

down the User Key again, LED1 will be turned off.

5.3. EXTI_Key_Interrupt_mode

5.3.1. DEMO purpose

This Demo includes the following functions of GD32 MCU:

Learn to use GPIO to control the LED and the KEY

Learn to use EXTI to generate external interrupt

GD32130F-START-V1.0 board has two keys and two LEDs. The two keys are Reset key and

User key. The LED1 and LED2 are controlled by GPIO.

This demo will show how to use EXTI interrupt line to control the LED1. When press down

the User Key, it will produce an interrupt. In the interrupt service function, the demo will

toggle LED1.

5.3.2. DEMO running Result

Download the program <03_EXTI_Key_Interrupt_mode> to the board, first of all, all the

LEDs will be flashed once for test. Then press down the User Key, LED1 will be turned on.

Press down the User Key again, LED1 will be turned off.

User Guide

GD32130F-START

9 /11

5.4. TIMER_Key_EXTI

5.4.1. DEMO purpose

This demo includes the following functions of GD32 MCU:

Learn to use GPIO control the LED and the KEY

Learn to use EXTI to generate external interrupt

Learn to use TIMER to generate PWM

GD32130F-START-V1.0 board has two keys and two LEDs. The two keys are Reset key and

User key. The LED1 and LED2 are controlled by GPIO.

This demo will show how to use the TIMER PWM to trigger EXTI interrupt to toggle the state

of LED2 and EXTI interrupt line to control the LED1. When press down the User Key, it will

produce an interrupt. In the interrupt service function, the demo will toggle LED1.

5.4.2. DEMO running result

Download the program < 04_TIMER_Key_EXTI > to the START board, all the LEDs are

flashed once for test, press down the Wakeup Key, LED1 will be turned on. Press down the

User Key again, LED1 will be turned off. Connect PA6 (TIMER2_CH0) and PA2 with DuPont

line. The LED2 will be toggled every 500ms.

Table des matières

Autres manuels GigaDevice Semiconductor Matériel informatique

GigaDevice Semiconductor

GigaDevice Semiconductor GD-Link Adapter Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32VW553 Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32E503Z-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32150R-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32103B-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32330G-START Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32E507Z-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32E230K-START Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32W515 Series Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32EPRTV-START Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32E503V-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32F310C-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32 Series Instructions d'installation et d'utilisation

GigaDevice Semiconductor

GigaDevice Semiconductor GD32F310G-START Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32L233C-START Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32350G-START Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32103C-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32450Z-EVAL Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32VW553 Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32 Series Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32E502 Series Manuel utilisateur

GigaDevice Semiconductor

GigaDevice Semiconductor GD32A50 Series Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
