Gigabyte Z490 AORUS ELITE AC Manuel utilisateur

For more product details, please visit GIGABYTE's website.

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

Z490 AORUS

ELITE

Z490 AORUS

ELITE AC

Z490 AORUS ELITE AC

Z490 AORUS ELITE

User's Manual

Rev. 1001

12ME-Z49ELTA-1001R

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE

without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in

any form or by any means without GIGABYTE's prior written permission.

Documentation Classications

In order to assist in the use of this product, GIGABYTE provides the following types of

documentations:

For quick set-up of the product, read the Quick Installation Guide included with the product.

For detailed product information, carefully read the User's Manual.

For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV:

1.0" means the revision of the motherboard is 1.0. Check your motherboard revision before

updating motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

Z490 AORUS ELITE (AC) Motherboard Layout ..............................................................4

Z490 AORUS ELITE (AC) Motherboard Block Diagram..................................................5

Chapter 1 Hardware Installation ....................................................................................6

1-1 Installation Precautions....................................................................................... 6

1-2 ProductSpecications ........................................................................................ 7

1-3 Installing the CPU ............................................................................................. 10

1-4 Installing the Memory........................................................................................ 10

1-5 Installing an Expansion Card ............................................................................ 11

1-6 Back Panel Connectors .................................................................................... 11

1-7 Internal Connectors........................................................................................... 14

Chapter 2 BIOS Setup.................................................................................................24

2-1 Startup Screen.................................................................................................. 24

2-2 The Main Menu................................................................................................. 25

2-3 Favorites (F11).................................................................................................. 26

2-4 Tweaker ............................................................................................................ 27

2-5 Settings............................................................................................................. 32

2-6 System Info....................................................................................................... 37

2-7 Boot................................................................................................................... 38

2-8 Save & Exit ....................................................................................................... 41

Chapter 3 Appendix.....................................................................................................42

3-1 ConguringaRAIDSet..................................................................................... 42

3-2 Installing an Intel®Optane™Memory................................................................. 44

3-3 Drivers Installation ............................................................................................ 46

Regulatory Notices...................................................................................................... 47

Contact Us .................................................................................................................. 52

- 4 -

Z490 AORUS ELITE (AC) Motherboard Layout

* The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

Box Contents

5Z490 AORUS ELITE AC or Z490 AORUS ELITE motherboard

5Motherboard driver disc 5Four SATA cables

5User's Manual 5One G Connector

5Quick Installation Guide 5One antennaj

USB20

CPU_FAN

ATX_12V_2X4

ATX_12V_2X2

ATX

F_AUDIO

AUDIO

PCIEX4

DDR4_B2

DDR4_A2

DDR4_B1

DDR4_A1

BAT

F_PANEL

LED_C1

Intel®Z490

CLR_CMOS

M_BIOS

PCIEX1_1

PCIEX16

F_USB1

LGA1200

Z490 AORUS ELITE (AC)

U32_LAN

F_U32

PCIEX1_2

iTE®

Super I/O

F_USB2

USB 2.0 Hub

M2B_CPU (Note)

SATA3 531

420

CPU_OPT

U32G2

HDMI

Realtek®

GbE LAN

D_LED1

SYS_FAN3

SYS_FAN2

SYS_FAN1

U32

LED_C2

F_U32C

CODEC

M2M_SB

80 60 42

D_LED2

CPU DRAM

VGA BOOT

110

M2A_SB

80 60 42

110

THB_C1

THB_C2

QFLASH_PLUS

QFLED

SPI_TPM

CNVI_WIFIj

jOnly for the Z490 AORUS ELITE AC.

(Note) The M.2 connector is reserved only. No functionalities.

- 5 -

Z490 AORUS ELITE (AC) Motherboard Block Diagram

LGA1200 CPU

CPU CLK+/- (100~500 MHz)

PCI Express 3.0 Bus

DMI 3.0

LAN

RJ45

Realtek®

2.5GbE LAN

PCI Express 3.0 Bus

4 USB 2.0/1.1

USB 2.0

Hub

1 PCI Express x16

x16

1 M.2 Socket 3

(M2M_SB)

2 SATA 6Gb/s

(SATA3 4~5)

1 M.2 Socket 3

(M2A_SB)

x4x4

PCI Express 3.0 Bus

4 SATA 6Gb/s (SATA3 0~3)

Switch

LPC Bus iTE®

Super I/O

1 USB Type-C™, with USB 3.2 Gen 1

support

2 USB 3.2 Gen 2

6 USB 3.2 Gen 1

4 USB 2.0/1.1

USB 2.0

Hub

Center/Subwoofer

Speaker Out

Line Out

MIC

Line In

S/PDIF Out

Rear Speaker Out

CODEC

M.2 CNVi

WIFI j

2 PCI Express x1

x1 x4

1 PCI Express x4

jOnly for the Z490 AORUS ELITE AC.

DDR4 3200/2933/2666/2400/2133 MHz

HDMI 1.4

DDI

SPI

Bus

BIOS

TPM

Intel®Z490

Chapter 1 Hardware Installation

1-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read

the user's manual and follow these procedures:

•Prior to installation, make sure the chassis is suitable for the motherboard.

•Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or

warranty sticker provided by your dealer. These stickers are required for warranty validation.

•Always remove the AC power by unplugging the power cord from the power outlet before

installing or removing the motherboard or other hardware components.

•When connecting hardware components to the internal connectors on the motherboard, make

sure they are connected tightly and securely.

•When handling the motherboard, avoid touching any metal leads or connectors.

•It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic

components such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,

keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.

•Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

•Before connecting or unplugging the power supply cable from the motherboard, make sure

the power supply has been turned off.

•Before turning on the power, make sure the power supply voltage has been set according to

the local voltage standard.

•Before using the product, please verify that all cables and power connectors of your hardware

components are connected.

•To prevent damage to the motherboard, do not allow screws to come in contact with the

motherboard circuit or its components.

•Make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

•Do not place the computer system on an uneven surface.

•Do not place the computer system in a high-temperature or wet environment.

•Turning on the computer power during the installation process can lead to damage to system

components as well as physical harm to the user.

•If you are uncertain about any installation steps or have a problem related to the use of the

product,pleaseconsultacertiedcomputertechnician.

•If you use an adapter, extension power cable, or power strip, ensure to consult with its

installation and/or grounding instructions.

- 6 -

1-2 ProductSpecications

CPU Support for 10th Generation Intel®Core™i9 processors/Intel®Core™i7 processors/

Intel®Core™i5 processors/Intel®Core™i3 processors/Intel®Pentium®processors/

Intel®Celeron®processors in the LGA1200 package

(Go to GIGABYTE's website for the latest CPU support list.)

L3 cache varies with CPU

Chipset Intel®Z490 Express Chipset

Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)

of system memory

Dual channel memory architecture

Support for DDR4 3200/2933/2666/2400/2133 MHz memory modules

* To support 3200 MHz, you must use XMP memory.

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in

non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

SupportforExtremeMemoryProle(XMP)memorymodules

(Go to GIGABYTE's website for the latest supported memory speeds and memory

modules.)

Onboard

Graphics

Integrated Graphics Processor-Intel®HD Graphics support:

- 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz

* Support for HDMI 1.4 version and HDCP 2.3.

Maximum shared memory of 512 MB

Audio Realtek®ALC1200 codec

HighDenitionAudio

2/4/5.1/7.1-channel

Support for S/PDIF Out

LAN Realtek®2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)

Wireless

Communication

Modulej

Intel®Wi-Fi AC 9462:

- Intel®CNVi interface 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band

- BLUETOOTH 5

- Support for 1x1 11ac wireless standard and up to 433 Mbps data rate

* Actual data rate may vary depending on environment and equipment.

Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)

* For optimum performance, if only one PCI Express graphics card is to be installed,

be sure to install it in the PCIEX16 slot.

1 x PCI Express x16 slot, running at x4 (PCIEX4)

2 x PCI Express x1 slots

(All of the PCI Express slots conform to PCI Express 3.0 standard.)

Multi-Graphics

Technology Support for AMD Quad-GPU CrossFire™and 2-Way AMD CrossFire™technologies

Storage Interface 2 x M.2 connectors (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe

x4/x2 SSD support) (M2M_SB/M2A_SB)

6 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, RAID 5, and RAID 10

* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA

connectors.

Intel®Optane™Memory Ready

- 7 -

jOnly for the Z490 AORUS ELITE AC.

USB Chipset:

- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel

- 1 x USB Type-C™port with USB 3.2 Gen 1 support, available through the

internal USB header

- 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through

the internal USB header)

Chipset+2 USB 2.0 Hubs:

- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through

the internal USB headers)

Internal

Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x 4-pin ATX 12V power connector

2 x M.2 Socket 3 connectors

6 x SATA 6Gb/s connectors

1 x CPU fan header

1 x water cooling CPU fan header

3 x system fan headers

2 x addressable LED strip headers

2 x RGB LED strip headers

1 x front panel header

1 x front panel audio header

1 x USB Type-C™port, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI

2.0 module only)

2 x Thunderbolt™add-in card connectors

1 x Clear CMOS jumper

1 x Q-Flash Plus button

Back Panel

Connectors

2 x USB 3.2 Gen 2 Type-A ports (red)

4 x USB 3.2 Gen 1 ports

4 x USB 2.0/1.1 ports

2 x SMA antenna connectors (1T1R)j

1 x HDMI port

1 x RJ-45 port

1 x optical S/PDIF Out connector

5 x audio jacks

I/O Controller iTE®I/O Controller Chip

Hardware

Monitor

Voltage detection

Temperature detection

Fan speed detection

Watercoolingowratedetection

Overheating warning

Fan fail warning

Fan speed control

* Whether the fan speed control function is supported will depend on the fan you install.

- 8 -

jOnly for the Z490 AORUS ELITE AC.

BIOS 1x256Mbitash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features Support for APP Center

* Available applications in APP Center may vary by motherboard model. Supported

functionsofeachapplicationmayalsovarydependingonmotherboardspecications.

- @BIOS

- EasyTune

- Fast Boot

- Game Boost

- ON/OFF Charge

- RGB Fusion

- Smart Backup

- System Information Viewer

Support for Q-Flash Plus

Support for Q-Flash

Support for Xpress Install

Bundled

Software

Norton®Internet Security (OEM version)

Realtek®8125 Gaming LAN Bandwidth Control Utility

Operating

System Support for Windows 10 64-bit

Form Factor ATX Form Factor; 30.5cm x 24.4cm

* GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout

prior notice.

Please visit GIGABYTE's website for support lists of CPU, memory

modules, SSDs, and M.2 devices.

Please visit the Support\Utility List page on GIGABYTE's website to download the latest

version of apps.

Z490 AORUS

ELITE

Z490 AORUS

ELITE AC

- 9 -

1-3 Installing the CPU

Read the following guidelines before you begin to install the CPU:

•Make sure that the motherboard supports the CPU.

(Go to GIGABYTE's website for the latest CPU support list.)

•Always turn off the computer and unplug the power cord from the power outlet before installing

the CPU to prevent hardware damage.

•Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you may

locate the notches on both sides of the CPU and alignment keys on the CPU socket.)

•Apply an even and thin layer of thermal grease on the surface of the CPU.

•Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and damage

of the CPU may occur.

•SettheCPUhostfrequencyinaccordancewiththeCPUspecications.Itisnotrecommended

thatthesystembusfrequencybesetbeyondhardwarespecicationssinceitdoesnotmeetthe

standard requirements for the peripherals. If you wish to set the frequency beyond the standard

specications,pleasedosoaccordingtoyourhardwarespecicationsincludingtheCPU,graphics

card, memory, hard drive, etc.

Installing the CPU

Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.

1-4 Installing the Memory

Read the following guidelines before you begin to install the memory:

•Make sure that the motherboard supports the memory. It is recommended that memory of the

same capacity, brand, speed, and chips be used.

(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)

•Always turn off the computer and unplug the power cord from the power outlet before installing

the memory to prevent hardware damage.

•Memory modules have a foolproof design. A memory module can be installed in only one direction.

If you are unable to insert the memory, switch the direction.

DualChannelMemoryConguration

This motherboard provides four memory sockets and supports Dual Channel Technology. After the memory

isinstalled,theBIOSwillautomaticallydetectthespecicationsandcapacityofthememory.EnablingDual

Channel memory mode will double the original memory bandwidth.

Please visit GIGABYTE's website for details on hardware installation.

Do not remove the CPU socket cover before inserting the CPU. It may pop off from the load

plate automatically during the process of re-engaging the lever after you insert the CPU.

Triangle Pin One Marking on the CPU

NotchNotch

LGA1200 CPU

Alignment

Key

Alignment

Key

LGA1200 CPU Socket

Pin One Corner of the CPU Socket

- 10 -

Autres manuels pour Z490 AORUS ELITE AC

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Gigabyte Carte mère

Gigabyte

Gigabyte GA-7VM266 Manuel utilisateur

Gigabyte

Gigabyte MB12-CE0 Manuel utilisateur

Gigabyte

Gigabyte H410M S2H V2 Manuel utilisateur

Gigabyte

Gigabyte GA-8SIMLP Manuel utilisateur

Gigabyte

Gigabyte GA-IMB410M Manuel utilisateur

Gigabyte

Gigabyte GA-6CXC Manuel utilisateur

Gigabyte

Gigabyte GA-Z270N-WIFI Manuel utilisateur

Gigabyte

Gigabyte GA-AB350M-DS3H V2 Manuel utilisateur

Gigabyte

Gigabyte GA-G1975X Manuel utilisateur

Gigabyte

Gigabyte 6BXC Manuel utilisateur

Gigabyte

Gigabyte M5NM1I Manuel utilisateur

Gigabyte

Gigabyte H310M DS2 Manuel utilisateur

Gigabyte

Gigabyte GA-B250M-EVO Manuel utilisateur

Gigabyte

Gigabyte MZ73-LM0 Manuel utilisateur

Gigabyte

Gigabyte GA-H81TN Manuel utilisateur

Gigabyte

Gigabyte GA-Z270X-DESIGNARE Manuel utilisateur

Gigabyte

Gigabyte GA-970A-D3P Manuel utilisateur

Gigabyte

Gigabyte GA - 686LX3 Manuel utilisateur

Gigabyte

Gigabyte 7VM333M-RZ Manuel utilisateur

Gigabyte

Gigabyte GA-MA790FX-DQ6 Manuel

Gigabyte

Gigabyte H610M H DDR4 Manuel utilisateur

Gigabyte

Gigabyte GA-8AENXP Dual Graphic Manuel utilisateur

Gigabyte

Gigabyte GA-G41MT-ES2L Manuel utilisateur

Gigabyte

Gigabyte Z690 A ELITE AX D4 V2 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
