GA-A75-D3H

User's Manual

Rev. 1002

12ME-A75D3H-1002R

Motherboard

GA-A75-D3H

Jun. 13, 2011

Motherboard

GA-A75-D3H

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE with-

out prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

Documentation Classications

In order to assist in the use of this product, GIGABYTE provides the following types of documentations:

For quick set-up of the product, read the Quick Installation Guide included with the product.

For detailed product information, carefully read the User's Manual.

For product-related information, check on our website at:

http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 4 -

Table of Contents

Box Contents...................................................................................................................6

Optional Items .................................................................................................................6

GA-A75-D3H Motherboard Layout ..................................................................................7

GA-A75-D3H Motherboard Block Diagram......................................................................8

Chapter 1 Hardware Installation .....................................................................................9

1-1 Installation Precautions.................................................................................... 9

1-2 Product Specications.................................................................................... 10

1-3 Installing the APU and APU Cooler................................................................ 13

1-3-1 Installing the APU ...................................................................................................13

1-3-2 Installing the APU Cooler........................................................................................15

1-4 Installing the Memory..................................................................................... 16

1-4-1 Dual Channel Memory Conguration .....................................................................16

1-4-2 Installing a Memory ...............................................................................................17

1-5 Installing an Expansion Card ......................................................................... 18

1-6 Setup of the AMD Dual Graphics Conguration............................................. 19

1-7 Back Panel Connectors.................................................................................. 20

1-8 Internal Connectors........................................................................................ 23

Chapter 2 BIOS Setup ..................................................................................................31

2-1 Startup Screen ............................................................................................... 32

2-2 The Main Menu .............................................................................................. 33

2-3 MB Intelligent Tweaker(M.I.T.)........................................................................ 35

2-4 Standard CMOS Features.............................................................................. 40

2-5 Advanced BIOS Features .............................................................................. 42

2-6 Integrated Peripherals.................................................................................... 44

2-7 Power Management Setup............................................................................. 47

2-8 PC Health Status............................................................................................ 49

2-9 Load Fail-Safe Defaults.................................................................................. 51

2-10 Load Optimized Defaults................................................................................ 51

2-11 Set Supervisor/User Password ...................................................................... 52

2-12 Save & Exit Setup .......................................................................................... 53

2-13 Exit Without Saving........................................................................................ 53

- 5 -

Chapter 3 Drivers Installation........................................................................................55

3-1 Installing Chipset Drivers ............................................................................... 55

3-2 Application Software ...................................................................................... 56

3-3 Technical Manuals.......................................................................................... 56

3-4 Contact........................................................................................................... 57

3-5 System ........................................................................................................... 57

3-6 Download Center ........................................................................................... 58

3-7 New Utilities ................................................................................................... 58

Chapter 4 Unique Features...........................................................................................59

4-1 Xpress Recovery2.......................................................................................... 59

4-2 BIOS Update Utilities ..................................................................................... 62

4-2-1 Updating the BIOS with the Q-Flash Utility.............................................................62

4-2-2 Updating the BIOS with the @BIOS Utility .............................................................65

4-3 EasyTune 6 .................................................................................................... 66

4-4 Q-Share.......................................................................................................... 67

4-5 SMART Recovery........................................................................................... 68

4-6 Auto Green..................................................................................................... 69

Chapter 5 Appendix ......................................................................................................71

5-1 Conguring SATA Hard Drive(s) .................................................................... 71

5-1-1 Conguring SATA Controllers ................................................................................71

5-1-2 Installing the SATA RAID/AHCI Driver and Operating System ...............................77

5-2 Conguring Audio Input and Output............................................................... 81

5-2-1 Conguring 2/4/5.1/7.1-Channel Audio...................................................................81

5-2-2 Conguring S/PDIF Out..........................................................................................83

5-2-3 Enabling the Dolby Home Theater Function...........................................................84

5-2-4 Conguring Microphone Recording........................................................................85

5-2-5 Using the Sound Recorder .....................................................................................87

5-3 Troubleshooting.............................................................................................. 88

5-3-1 Frequently Asked Questions ..................................................................................88

5-3-2 Troubleshooting Procedure ....................................................................................89

5-3-3 Regulatory Statements...........................................................................................91

- 6 -

Box Contents

GA-A75-D3H motherboard

Motherboard driver disk

User's Manual

Quick Installation Guide

Four SATA cables

I/O Shield

Optional Items

2-port USB 2.0 bracket (Part No. 12CR1-1UB030-5*R)

2-port SATA power cable (Part No. 12CF1-2SERPW-0*R)

COM port cable (Part No. 12CF1-1CM001-3*R)

3.5" Front Panel with 2 USB 3.0/2.0 ports (Part No. 12CR1-FPX582-0*R)

The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

- 7 -

GA-A75-D3H Motherboard Layout

KB_MS_USB3

CPU_FAN

Socket FM1

ATX

GA-A75-D3H

AUDIO

PCIEX16

DDR3_4

DDR3_2

BAT

F_PANEL

COM

ATX_12V

AMD A75

PCIEX4

USB_ESATA

CODEC

PCI2

Realtek

RTL8111E

VGA_DVI

HDMI_SPDIF

USB30_LAN

PCIEX1_1

M_BIOS

B_BIOS

CLR_CMOS

SATA3_4

SATA3_0

SATA3_3

DDR3_3

DDR3_1

SPDIF_O

F_USB4

F_USB1

iTE

IT8720

SATA3_2

SYS_FAN2

F_AUDIO

SATA3_1

TPM

Etron

EJ168

PCI3

PCIEX1_2

F_USB3

F_USB2 F_USB30

SYS_FAN

PWR_FAN

PCI1

- 8 -

GA-A75-D3H Motherboard Block Diagram

2 USB 3.0/2.0

Etron

EJ168

AMD APU

UMI

APU CLK+/- (100 MHz)

DDR3 2400(O.C.)/1866/1600/1333/1066 MHz

Dual Channel Memory

PCI Express Bus

PCIe CLK

(100 MHz)

1 PCI Express x16

1 PCI Express x4

iTE

IT8720

COM Port

LPC

Bus

Center/Subwoofer Speaker Out

Line Out

MIC

Line In

S/PDIF Out

Side Speaker Out

Surround Speaker Out

CODEC

3 PCI

PCI Bus

PCI CLK

(33 MHz)

Dual BIOS

PCIe CLK

(100 MHz)

PCI Express Bus

PS/2 KB/Mouse

4 USB 3.0/2.0

D-Sub

LAN

RJ45

Realtek

RTL8111E

2 PCI Express x1

x16

10 USB 2.0/1.1

DVI-D

HDMI

Switch

6 SATA 6Gb/s

AMD A75

DISP CLK+/- (100 MHz)

- 9 - Hardware Installation

1-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read

the user's manual and follow these procedures:

• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or

warranty sticker provided by your dealer. These stickers are required for warranty validation.

• Always remove the AC power by unplugging the power cord from the power outlet before

installing or removing the motherboard or other hardware components.

• When connecting hardware components to the internal connectors on the motherboard,

make sure they are connected tightly and securely.

• When handling the motherboard, avoid touching any metal leads or connectors.

• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic com-

ponents such as a motherboard, APU or memory. If you do not have an ESD wrist strap,

keep your hands dry and rst touch a metal object to eliminate static electricity.

•

Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

• Before unplugging the power supply cable from the motherboard, make sure the power sup-

ply has been turned off.

• Before turning on the power, make sure the power supply voltage has been set according to

the local voltage standard.

• Before using the product, please verify that all cables and power connectors of your hard-

ware components are connected.

• To prevent damage to the motherboard, do not allow screws to come in contact with the

motherboard circuit or its components.

• Make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

• Do not place the computer system on an uneven surface

• Do not place the computer system in a high-temperature environment.

• Turning on the computer power during the installation process can lead to damage to sys-

tem components as well as physical harm to the user.

• If you are uncertain about any installation steps or have a problem related to the use of the

product, please consult a certied computer technician.

Chapter 1 Hardware Installation

Hardware Installation - 10 -

1-2 Product Specications

APU FM1 Socket:

- AMD A series processors/AMD E2 series processors

(Go to GIGABYTE's website for the latest APU support list.)

Chipset AMD A75

Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory

* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical

memory is installed, the actual memory size displayed will be less than 4 GB.

Dual channel memory architecture

Support for DDR3 2400(O.C.)/1866/1600/1333/1066 MHz memory modules

* The 1866 MHz (or above) memory speed is supported only when one or two DDR3

1866 MHz (or above) DIMMs are installed. It is not supported when four DIMMs

are installed. (Dual channel memory mode must be enabled when installing two

DIMMs.)

(Go to GIGABYTE's website for the latest supported memory speeds and memory

modules.)

Onboard

Graphics

APU:

- 1 x D-Sub port

- 1 x DVI-D port, supporting a maximum resolution of 2560x1600

* The DVI-D port does not support D-Sub connection by adapter.

The resolution of 2560x1600 is supported only when Dual Link DVI mode is enabled.

- 1 x HDMI port, supporting a maximum resolution of 1920x1200

(All integrated graphics ports do not support Hot plug. If you want to change to

another graphics port when the computer is on, be sure to turn off the computer

rst.)

Audio Realtek ALC889 codec

High Denition Audio

2/4/5.1/7.1-channel

Support for Dolby®Home Theater

Support for S/PDIF Out

LAN 1 x Realtek RTL8111E chip (10/100/1000 Mbit)

Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)

* For optimum performance, if only one PCI Express graphics card is to be installed,

be sure to install it in the PCIEX16 slot.

1 x PCI Express x16 slot, running at x4 (PCIEX4)

2 x PCI Express x1 slots

(All PCI Express slots conform to the PCI Express 2.0 standard.)

3 x PCI slots

Multi-Graphics

Technology

Support for AMD CrossFireX™technology

* The PCIEX16 slot operates at up to x4 mode when AMD CrossFireX™is enabled.

Support for AMD Dual Graphics technology

* Only A series APUs support AMD Dual Graphics.

Autres manuels pour GA-A75-D3H

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Gigabyte Carte mère

Gigabyte

Gigabyte GA-K8N51PVM9-RH Manuel utilisateur

Gigabyte

Gigabyte GA-A320-DS3 Manuel utilisateur

Gigabyte

Gigabyte GA-H110M-S2H Manuel utilisateur

Gigabyte

Gigabyte GA-946GM-DS2 Manuel utilisateur

Gigabyte

Gigabyte GA-K8N51GMF-9 Manuel utilisateur

Gigabyte

Gigabyte GA-7VKML Manuel utilisateur

Gigabyte

Gigabyte GA-6IWFE Manuel utilisateur

Gigabyte

Gigabyte GA-Z97X-UD5H-BK Manuel utilisateur

Gigabyte

Gigabyte B460 HD3 Manuel utilisateur

Gigabyte

Gigabyte GA-H67A-D3H-B3 Manuel utilisateur

Gigabyte

Gigabyte 6VMA Manuel utilisateur

Gigabyte

Gigabyte B360M D3V Manuel utilisateur

Gigabyte

Gigabyte GA-PICO3350 Manuel utilisateur

Gigabyte

Gigabyte R282-Z96 Manuel utilisateur

Gigabyte

Gigabyte GA-H67MA-D2H-B3 Manuel utilisateur

Gigabyte

Gigabyte GA-6RXB Manuel utilisateur

Gigabyte

Gigabyte GA-P41T-USB3L Manuel utilisateur

Gigabyte

Gigabyte GA-D425TU Manuel utilisateur

Gigabyte

Gigabyte GA-Z87M-HD3 Manuel utilisateur

Gigabyte

Gigabyte GA-G33M-DS2R Manuel utilisateur

Gigabyte

Gigabyte GA-5YASV-RH Manuel utilisateur

Gigabyte

Gigabyte GA-F2A78M-D3H Manuel utilisateur

Gigabyte

Gigabyte R121-X30 Manuel utilisateur

Gigabyte

Gigabyte GA-7DXE Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
