Gigabyte B560M D3H Manuel utilisateur

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

B560M D3H

User's Manual

Rev. 1001

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes tothe specications and features in thismanual may be madebyGIGABYTE

without prior notice. No part of this manual may be reproduced, copied, translated, transmit-

ted, or published in any form or by any means without GIGABYTE's prior written permission.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV:

1.0" means the revision of the motherboard is 1.0. Check your motherboard revision before

updating motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

B560M D3H Motherboard Layout....................................................................................4

Chapter 1 Hardware Installation ....................................................................................5

1-1 Installation Precautions....................................................................................... 5

1-2 ProductSpecications ........................................................................................ 6

1-3 Installing the CPU ............................................................................................... 9

1-4 Installing the Memory.......................................................................................... 9

1-5 Installing an Expansion Card ............................................................................ 10

1-6 Back Panel Connectors .................................................................................... 10

1-7 Internal Connectors........................................................................................... 13

Chapter 2 BIOS Setup.................................................................................................22

2-1 Startup Screen.................................................................................................. 22

2-2 The Main Menu................................................................................................. 23

2-3 Smart Fan 6 ..................................................................................................... 24

2-4 Favorites (F11).................................................................................................. 26

2-5 Tweaker ............................................................................................................ 27

2-6 Settings............................................................................................................. 32

2-7 System Info....................................................................................................... 37

2-8 Boot................................................................................................................... 38

2-9 Save & Exit ....................................................................................................... 41

Chapter 3 Appendix.....................................................................................................42

3-1 Installing Intel®Optane™Memory and Storage Management........................... 42

3-2 Drivers Installation ............................................................................................ 43

Regulatory Notices...................................................................................................... 44

Contact Us .................................................................................................................. 45

- 4 -

B560M D3H Motherboard Layout

* The box contents above are for reference only and the actual items shall depend on the product package you ob-

tain. The box contents are subject to change without notice.

Box Contents

5B560M D3H motherboard 5Two SATA cables

5Motherboard driver disc 5M.2 screws

5User's Manual 5I/O Shield

Temperature sensor

F_U32

SATA 3

1 0

3 2

KB_MS_USB

CPU_FAN

LGA1200

ATX

AUDIO

BAT

ATX_12V_2X4

CODEC CLR_CMOS

M_BIOS

DVI

VGA

U32_LAN

PCIEX16

PCIEX1

PCI

PCIEX4

SYS_FAN2

SYS_FAN1

DP_HDMI

SYS_FAN3

F_USB2 F_PANEL

COM F_USB1

F_AUDIO LPT SPI_TPM

PCIe to

PCI Bridge

iTE®

Super I/O

80110 60

M2A_CPU

B560M D3H

Intel®B560

DDR4_A2

DDR4_A1

DDR4_B1

DDR4_B2

U32C

U32

THB_C2

THB_C1

80 60

M2P_SB

Intel®

GbE LAN

USB 2.0 Hub

QFLASH_PLUS

QFLED

LED_C1

D_LED1

Chapter 1 Hardware Installation

1-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read

the user's manual and follow these procedures:

•Prior to installation, make sure the chassis is suitable for the motherboard.

•Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or

warranty sticker provided by your dealer. These stickers are required for warranty validation.

•Always remove the AC power by unplugging the power cord from the power outlet before

installing or removing the motherboard or other hardware components.

•When connecting hardware components to the internal connectors on the motherboard, make

sure they are connected tightly and securely.

•When handling the motherboard, avoid touching any metal leads or connectors.

•It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic com-

ponents such as a motherboard, CPU or memory. If you do not have an ESD wrist strap, keep

yourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.

•Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

•Before connecting or unplugging the power supply cable from the motherboard, make sure

the power supply has been turned off.

•Before turning on the power, make sure the power supply voltage has been set according to

the local voltage standard.

•Before using the product, please verify that all cables and power connectors of your hardware

components are connected.

•To prevent damage to the motherboard, do not allow screws to come in contact with the

motherboard circuit or its components.

•Make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

•Do not place the computer system on an uneven surface.

•Do not place the computer system in a high-temperature or wet environment.

•Turning on the computer power during the installation process can lead to damage to system

components as well as physical harm to the user.

•If you are uncertain about any installation steps or have a problem related to the use of the

product,pleaseconsultacertiedcomputertechnician.

•If you use an adapter, extension power cable, or power strip, ensure to consult with its instal-

lation and/or grounding instructions.

- 5 -

1-2 ProductSpecications

CPU LGA1200 package:

- 11th Generation Intel

Core

™

i9 processors/Intel

Core

™

i7 processors/

Intel

Core

™

i5 processors

- 10th Generation Intel

Core

™

i9 processors/Intel

Core

™

i7 processors/Intel

Core

™

i5 processors/Intel

Core

™

i3 processors/Intel

Pentium

processors/

Intel

Celeron

processors*

* Limited to processors with 4 MB Intel®Smart Cache, Intel®Celeron®G5xx5 family.

(Go to GIGABYTE's website for the latest CPU support list.)

L3 cache varies with CPU

Chipset Intel®B560 Express Chipset

Memory 11th Generation Intel®Core™i9/i7/i5 processors:

Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules

10th Generation Intel®Core™i9/i7 processors:

- Support for DDR4 2933/2666/2400/2133 MHz memory modules

10th Generation Intel®Core™i5/i3/Pentium®/Celeron®processors:

- Support for DDR4 2666/2400/2133 MHz memory modules

4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)

of system memory

Dual channel memory architecture

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in

non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

SupportforExtremeMemoryProle(XMP)memorymodules

(Go to GIGABYTE's website for the latest supported memory speeds and memory

modules.)

Onboard

Graphics

Integrated Graphics Processor-Intel®HD Graphics support:

- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

(Note)

- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz

* The DVI-D port does not support D-Sub connection by adapter.

- 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz

* Support for HDMI 1.4 version and HDCP 2.3.

- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz

* Support for DisplayPort 1.2 version and HDCP 2.3

(GraphicsspecicationsmayvarydependingonCPUsupport.)

Support for up to 3 displays at the same time

Audio Realtek®Audio CODEC

HighDenitionAudio

2/4/5.1/7.1-channel

LAN Intel®GbE LAN chip (1000 Mbit/100 Mbit)

Multi-Graphics

Technology Support for AMD Quad-GPU CrossFire™and 2-WayAMD CrossFire™technologies

Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)

* For optimum performance, if only one PCI Express graphics card is to be installed,

be sure to install it in the PCIEX16 slot.

(The PCIEX16 slot conforms to PCI Express 4.0 standard.) (Note)

(Note) Supported by 11th Generation processors only.

- 6 -

Expansion Slots 1 x PCI Express x16 slot, running at x4 (PCIEX4)

1 x PCI Express x1 slot (PCIEX1)

(The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)

1 x PCI slot

Storage Interface CPU:

- 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2

SSD support) (M2A_CPU) (Note)

Chipset:

- 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/

x2 SSD support) (M2P_SB)

6 x SATA 6Gb/s connectors

* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA

connectors.

Intel®Optane™Memory Ready

SystemAcceleration with Intel

Optane

™

Memory enabled on the M2A_CPU connector only.

USB Chipset:

- 1 x USB Type-C®port on the back panel, with USB 3.2 Gen 1 support

- 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through

the internal USB header)

- 4 x USB 2.0/1.1 ports available through the internal USB headers

Chipset+2 USB 2.0 Hubs:

- 2 x USB 2.0/1.1 ports on the back panel

Internal

Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

3 x system fan headers

1 x addressable LED strip header

1 x RGB LED strip header

6 x SATA 6Gb/s connectors

2 x M.2 Socket 3 connectors

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

2 x Thunderbolt™add-in card connectors

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI

2.0 module only)

1 x serial port header

1 x parallel port header

1 x Clear CMOS jumper

1 x Q-Flash Plus button

(Note) Supported by 11th Generation processors only.

- 7 -

Back Panel

Connectors

1 x PS/2 keyboard/mouse port

1 x D-Sub port

1 x DVI-D port

1 x DisplayPort

1 x HDMI port

1 x USB Type-C®port, with USB 3.2 Gen 1 support

3 x USB 3.2 Gen 1 ports

2 x USB 2.0/1.1 ports

1 x RJ-45 port

6 x audio jacks

I/O Controller iTE®I/O Controller Chip

Hardware

Monitor

Voltage detection

Temperature detection

Fan speed detection

Fan fail warning

Fan speed control

* Whether the fan speed control function is supported will depend on the cooler you

install.

BIOS 1x256Mbitash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features Support for APP Center

* Available applications in APP Center may vary by motherboard model. Supported

functionsofeachapplicationmayalsovarydependingonmotherboardspecications.

- @BIOS

- EasyTune

- Fast Boot

- Game Boost

- ON/OFF Charge

- RGB Fusion

- Smart Backup

- System Information Viewer

Support for Q-Flash Plus

Support for Q-Flash

Support for Xpress Install

Bundled

Software

Norton®Internet Security (OEM version)

cFosSpeed

Operating

System Support for Windows 10 64-bit

Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm

* GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout

prior notice.

Please visit GIGABYTE's website

for support lists of CPU, memory

modules, SSDs, and M.2 devices.

Please visit the Support\Utility List

page on GIGABYTE's website to

download the latest version of apps.

- 8 -

1-3 Installing the CPU

1-4 Installing the Memory

Read the following guidelines before you begin to install the memory:

•Make sure that the motherboard supports the memory. It is recommended that memory of the

same capacity, brand, speed, and chips be used.

(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)

•Always turn off the computer and unplug the power cord from the power outlet before installing

the memory to prevent hardware damage.

•Memory modules have a foolproof design. A memory module can be installed in only one direc-

tion. If you are unable to insert the memory, switch the direction.

DualChannelMemoryConguration

This motherboard provides four memory sockets and supports Dual Channel Technology. After the memory

isinstalled,theBIOSwillautomaticallydetectthespecicationsandcapacityofthememory.EnablingDual

Channel memory mode will double the original memory bandwidth.

Please visit GIGABYTE's website for details on hardware installation.

Read the following guidelines before you begin to install the CPU:

•Make sure that the motherboard supports the CPU.

(Go to GIGABYTE's website for the latest CPU support list.)

•Always turn off the computer and unplug the power cord from the power outlet before installing

the CPU to prevent hardware damage.

•Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you may

locate the notches on both sides of the CPU and alignment keys on the CPU socket.)

•Apply an even and thin layer of thermal grease on the surface of the CPU.

•Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and damage

of the CPU may occur.

•SettheCPUhostfrequencyinaccordancewiththeCPUspecications.Itisnotrecommended

thatthesystembusfrequencybesetbeyondhardwarespecicationssinceitdoesnotmeetthe

standard requirements for the peripherals. If you wish to set the frequency beyond the standard

specications,pleasedosoaccordingtoyourhardwarespecicationsincludingtheCPU,graph-

ics card, memory, hard drive, etc.

Installing the CPU

Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.

Do not remove the CPU socket cover before inserting the CPU. It may pop off from the load

plate automatically during the process of re-engaging the lever after you insert the CPU.

Alignment

Key

Alignment

Key

LGA1200 CPU Socket

Pin One Corner of the CPU Socket Triangle Pin One Marking on the CPU

NotchNotch

LGA1200 CPU

- 9 -

The four memory sockets are divided into two channels and each channel has two memory sockets as following:

Channel A: DDR4_A1, DDR4_A2

Channel B: DDR4_B1, DDR4_B2

RecommandedDualChannelMemoryConguration:

DDR4_A1 DDR4_A2 DDR4_B1 DDR4_B2

2 Modules - - DS/SS - - DS/SS

4 Modules DS/SS DS/SS DS/SS DS/SS

(SS=Single-Sided, DS=Double-Sided, "- -"=No Memory)

Due to CPU limitations, read the following guidelines before installing the memory in Dual Channel mode.

1. Dual Channel mode cannot be enabled if only one memory module is installed.

2. When enabling Dual Channel mode with two or four memory modules, it is recommended that

memory of the same capacity, brand, speed, and chips be used.

1-5 Installing an Expansion Card

Read the following guidelines before you begin to install an expansion card:

•Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

•Always turn off the computer and unplug the power cord from the power outlet before installing

an expansion card to prevent hardware damage.

1-6 Back Panel Connectors

USB 2.0/1.1 Port (Q-Flash Plus Port)

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.Usethisportfor

USB devices. Before using Q-Flash Plus (Note 1),makesuretoinserttheUSBashdriveintothisportrst.

USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

PS/2 Keyboard/Mouse Port

Use this port to connect a PS/2 mouse or keyboard.

D-Sub Port (Note 2)

The D-Sub port supports a 15-pin D-Sub connector and supports a maximum resolution of 1920x1200@60 Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports D-Sub

connection to this port.

DVI-D Port (Note 3)

TheDVI-DportconformstotheDVI-Dspecicationandsupportsamaximumresolutionof1920x1200@60Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports DVI-D

connection to this port.

(Note 1) To enable the Q-Flash Plus function please visit the "Unique Features" webpage of GIGABYTE's

website.

(Note 2) Supported by 11th Generation processors only.

(Note 3) The DVI-D port does not support D-Sub connection by adapter.

- 10 -

Table des matières

Autres manuels Gigabyte Carte mère

Gigabyte

Gigabyte P4 Titan GA-8S650GXM-P-C Manuel utilisateur

Gigabyte

Gigabyte GA-MA790GP-UD3H Manuel utilisateur

Gigabyte

Gigabyte GA-Z68XP-UD3 Manuel utilisateur

Gigabyte

Gigabyte GA-EG41MFT-US2H Manuel utilisateur

Gigabyte

Gigabyte GA-P35-DQ6 Manuel utilisateur

Gigabyte

Gigabyte Z790 AORUS ELITE AX ICE Manuel utilisateur

Gigabyte

Gigabyte H110-D3A Manuel utilisateur

Gigabyte

Gigabyte GA-8VM533 Manuel utilisateur

Gigabyte

Gigabyte MX32-4L0 Manuel utilisateur

Gigabyte

Gigabyte GA-Z68XP-UD3R Manuel utilisateur

Gigabyte

Gigabyte GA-8IRM Manuel utilisateur

Gigabyte

Gigabyte GA-H55M-UD2H Manuel utilisateur

Gigabyte

Gigabyte Z790 AORUS ELITE X WIFI7 Manuel utilisateur

Gigabyte

Gigabyte X570 AORUS ELITE WIFI Manuel utilisateur

Gigabyte

Gigabyte GA-H61M-HD2 Manuel utilisateur

Gigabyte

Gigabyte GA-880GM-D2H Manuel utilisateur

Gigabyte

Gigabyte GA-B85M-D3V Manuel utilisateur

Gigabyte

Gigabyte GA-H81M-D2V Manuel utilisateur

Gigabyte

Gigabyte X570SI AORUS PRO AX Manuel utilisateur

Gigabyte

Gigabyte GA-EP45-DS5 Manuel utilisateur

Gigabyte

Gigabyte GA-H67M-UD2H-B3 Manuel utilisateur

Gigabyte

Gigabyte GA-870A-USB3L Manuel utilisateur

Gigabyte

Gigabyte GA-X79S-UP5 User's Manuel utilisateur

Gigabyte

Gigabyte GA-990FXA-UD5 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
