Congratulations on your purchase of your personal
X1000 3D printer
x
1000
German
RepRap
3D PRINTER MADE IN GERMANY
X1000 3D printer manual
X1000
3D printer manual
German
RepRap
Table of content
1. General information
1.1 specications................................................................................................................................04
1.2 System requirements................................................................................................................05
1.3 Additional options..................................................................................................................... 05
2. 2.Operating modes of the X 1000
2.1 Red/ Stand-by .............................................................................................................................06
2.2 Green/ work mode ....................................................................................................................07
2.3 Two-hand circuit/removal position.....................................................................................07
2.4 Emergency stop ........................................................................................................................ 08
2.5 Maintenance mode...................................................................................................................08
3. Network and printer set up
3.1 Connection via router .............................................................................................................. 09
3.2 Direct connection ...................................................................................................................... 09
3.3 Setup routine...............................................................................................................................11
3.4 How to activate the printer and establish a connection ............................................. 16
4. Workow and operation
4.1 Simplify 3D
4.2 Features.........................................................................................................................................18
4.3 Quick Start Guide.......................................................................................................................19
4.4 The Interface Layout ................................................................................................................. 21
5. Repetier Server
5.1 Web interface .............................................................................................................................. 26
5.2 Dashboard....................................................................................................................................27
5.3 Device panel................................................................................................................................ 28
5.4 Device panel operation ...........................................................................................................28
5.5 EEPROM.........................................................................................................................................31
5.6 LOG-Files .......................................................................................................................................32
5.7 Firmwareupdate ............................................................................................. 33
6. Tool heads and cosumables
6.1 Tool head wiring.........................................................................................................................34
6.2 How to set up the second extruder ....................................................................................35
6.3 How to replace the hot end and the extruder .................................................................36
6.4 How to change the laments.................................................................................................38
7. CO2 extinguishing system
7.1 General information..................................................................................................................42
7.2 7.2 Manual triggering............................................................................................................... 43
7.3 Recommissioning after trigger ............................................................................................. 43
8. Tipps & Tricks
8.1 How to determine the X1000s MAC address.................................................................... 44
8.2 How to update Repetier-Server ........................................................................................... 44
8.3 PVA solution for enhanced adhesion ................................................................................. 45
02/51
X1000
3D printer manual
German
RepRap
9. Download area
10. Important notices
Return shipment/ original package ............................................................................................ 46
Operation.............................................................................................................................................. 46
Miscellaneous...................................................................................................................................... 46
Toxic threat...........................................................................................................................................46
Safety switch........................................................................................................................................ 46
Maintenance........................................................................................................................................ 46
11. Safety notes
Power supply.......................................................................................................................................47
Cleaning ................................................................................................................................................47
Playing children..................................................................................................................................47
Mains voltage......................................................................................................................................47
Humidity, solar radiation, heat, open ames...........................................................................47
Ventilation ............................................................................................................................................ 47
Long absence, tempest, power plug reachability ................................................................. 47
Installation site.................................................................................................................................... 48
Disposal................................................................................................................................................. 48
12. Legal disclaimers
Software modications/ use of applications ........................................................................... 48
Rev.Nr. 0.4
03/51
X1000
3D printer manual
German
RepRap
1. General information
1.1 specications
The X1000 is a professional 3D printer, especially designed for processing various plastic mate-
rials with extra-large work area and optional double extruder. With a layer thickness up to 0.1
mm und a printing surface of 1000x800x600 mm, this 3D printer can produce either big models
or several small objects with the highest precision.
A closed switch gear cabinet, an emergency stop switch and an optional CO2 based dual re
protection system ensure that the requirements derived from an industrial work environment
are completely satised.
specication data
working space ( X - Y - Z) 1000 x 800 x 600 mm
printing speed 10 - 150 mm/s
traverse speed 10 - 300 mm/s
layer thickness (minimal) 0,1 mm (depending on nozzle)
lament/nozzle diameter (standard) 1,75mm / 0,8 mm
material PLA, Performance PLA, Laywood, PVA, PET-G, TPU64D
extruder type DD3 Dual
extruder temperature (max) 290° C
data transfer LC Touch display, WLAN, Ethernet
software Simplify3D
power consumption 2500 W
Operating voltage* three phase AC current 400V (CEE 3L+N+PE)
Ambient temperature 15-26° C
external dimensions (WxDxH) 1725 x 1500 x 1320 mm
weight 400 kg
marking DIN 10218-2
options
Heating bed, dual extruder
CO2 based dual re protection system
available nozzles 0,4 / 0,6 mm
available nozzle material brass, hardened steel
printing technology Fused Filament Fabrication (FFF)
04/51
X1000
3D printer manual
German
RepRap
Note that the minimum system requirements listed below are for Simplify3D and Repetier-server only. These
applications are provided with the printer.
• Intel Pentium 4 or better
• 2GB Ram or more
• USB 1.1 optional
• Windows XP or newer
• Mac OS X 10.6 or newer
• Ubuntu/Debian Linux
• OpenGL 2.0
Please note that you must use one of the following browsers to establish a connection with your X1000 3D
printer.
• Chrome
• Firefox
1.2 System requirements
Microsoft´s Internet Explorer is not supported
1.3 Additional options
In addition to the standard version the following options are available:
• Heating bed
• Dual extruder
• CO2 based dual re protection system
For an inquiry please contact our sales partner from your region.
05/51
X1000
3D printer manual
German
RepRap
Never turn on the heating bed while operating in standby mode!
After some time, the printer will switch into DRY-Run mode, so that you
must restart the device if you want to start a new print job
2. 2. Operating modes of the X 1000
The X1000 provides various modes that enable you to perform dierent functions depending on your
current task.
2.1 Red/ Stand-by
When the X1000 is connected to the mains you can reach the stand-by mode by turning on the printer
using the key. After a short initialization phase the startup screen appears on the LCD display and the red
light will light up.
X1000 Standby
In this mode, you can keep the lid of the X1000 open and heat up the extruder heads and let material
extrude simultaneously. All other functions (like traversing the axis) are blocked for safety reasons. In
addition, the standby mode allows you thread new laments easily, to clean the nozzle or even to replace
it completely. Furthermore, the Repetier server is already booted when operating in standby mode, this
means that you can already upload G-codes to the X1000.
06/51
X1000
3D printer manual
German
RepRap
2.3 Two-hand circuit/removal position
After successfully completing a large 3d print you can lift the printing bed up to access is more easily using
the two-hand circuit.
2.2 Green/ work mode
To switch from standby mode to work mode to w After successfully booting the X1000 you must rst close
its lid. Then you must press the green switch underneath the LCD display.
When the green switch is light up the lid will be locked automatically
and the device is now ready to start a 3D print.
two-hand circuitLCD menu, manual control
To do this, proceed as follows:
• Switch into standby mode by pressing the red button
• Open the maintenance lid
• Execute the order “home z” via LCD display or web browser
• The device will stand completely still
• Now press the two blue buttons shown on the picture above simultaneously
• The axes will traverse as long as both buttons are pushed, but not further than the machine zero
07/51
X1000
3D printer manual
German
RepRap
Allow the building platform to cool down, the object will be much
easier to remove.
The X1000 has two machine zeros. Besides the actual one the other
one is located half way up the building platform. When operating the
two-hand circuit this prevent pushing the printed object into the main-
tenance lid.
2.4 Emergency stop
If you press the emergency stop, the printer will shut down immediately.
Warning: RISK OF BURN:
The heating bed as well as the extruder heads will remain hot even
some time after an emergency shut down!
2.5 Maintenance mode
When operating in maintenance mode, it is possible to work with an open maintenance lid. This mode is
intended for repair and maintenance work only!
The maintenance mode must be set up by a trained professional only!
08/51
X1000
3D printer manual
German
RepRap
3. Network and printer set up
To establish a connection with the X1000 you must rst check your computer´s network settings and adapt
them, if necessary. The you can launch the setup routine and put the printer into operation.
3.1 Connection via router
If necessary, contact your network administrator about integrating the
X1000 into your network.
If your network settings are DHCP based, the X1000 is automatically assigned an IP address. If this is the case
the X100 just has to be connected through a patch cable to your network.
Then you can see the printer´s assigned IP address as well as the MAC address on the LCD display.
3.2 Direct connection
To establish a direct connection between the X1000 and your computer you must proceed as follows:
• In the computer´s control panel navigate to network settings
• Click on the network adapter the X1000 is connected to
Choosing network adapter
09/51
X1000
3D printer manual
German
RepRap
• In the pop up window chose “details”
• In the shown list mark “internet protocol, version 4 (TCP/IP)” and click on properties
Network adapter properties
• Enter the following ip address to establish a connection to the 3d printer:
192.168.1.2
Info:
By using this method you
assign a static ip address
in the same name space
as your 3D printer to your
computer
Entering static IP address
10/51
