Genius SLIM 321C Manuel utilisateur

English

-1-

Slim 321C Features

1 Led indicator

When the Slim 321C is connected the LED

indicator will be turned on.

2 Lens

Adjust the focus by twisting the lens.

3 Adjustable base

The adjustable base allows you to place the

Slim 321C on different LCD monitor sizes.

Installing the Slim 321C

1. Please install the driver first and then connect Slim 321C to

the USB port.

2. Installing the Slim 321C driver

a. Insert the Slim 321C Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install “DirectX”from the CD.

Notice: If theAutorun screen doesn’t start, please follow these steps:

zClick on “Start Menu”.

zType D：\SETUP.EXE, then click “Enter” key.

(Assume your CD-ROM is in Drive D)

English

-2-

3. Insert the Slim 321C’s USB cable to your desktop’s or

laptop’s USB port.

4. Complete software and hardware installation. You can

install the software you would like for video

conferencing or chat with your friends.

NOTE

To remove the driver installation:

Please go to the taskbar and follow “Start” Æ“Program” Æ“Slim

321C”ÆClick “Uninstall”, then follow the on-screen instructions to remove

the driver.

Genius Application (Windows Only)

You can use our software to capture the real-time image, record or

execute the simply security function.

To run the software, please go to the task bar and follow “Start”Æ

Click “Program”ÆChoose “Slim 321C”ÆClick “Slim 321C”. Or you

may execute the software by simply clicking the shortcut of “Slim

321C”.

English

-3-

NOTE

After installing the driver of Slim 321C, the system will automatically create a

file (C:\WINDOWS\Album or C:\WINNT\Album) to save the images you take

using the Genius Application.

1. Description for the major icon

Preview mode

Snapshot mode

Video Clip Mode

Security monitoring system

Exit

Camera Control

NOTE

In the “camera control section”, you can personalize your camera

settings for different circumstances.

English

-4-

1Environment

You may adjust the values for different lighting. The default value is Auto (Auto

White Balance)

2Rotation:

You can flip the image horizontally or vertically

3Extension:

You can select different sizes of image resolution

4Frequency:

Select the correct frequency according to the country where you are using the

web camera.

English

-5-

Video Proc Amp:

In this section, you can adjust different values for the image itself.

-Press “Default” to return to the manufacturer’s settings.

English

-6-

Camera Control:

Select the values of “Exposure” according to the environment where you are using

the web camera.

Before adjusting the values, please unclick the “Auto”.

-Press “Default” to return to the manufacturer’s settings.

English

-7-

2. Preview Mode

You can use the function buttons on the control panel to zoom in/out and

move upward/downward/left/right.

Zoom in the image

Zoom out the image

Move the image upward

Move the image downward

Move the image to the left

English

-8-

Move the image to the right

Resolution Selection

There are 2 categories of resolution: RGB24 and

I420. You can select 5 different image resolutions for

each of them. The file size of I420 will be smaller than

RGB24. So, I420 may be the better choice for

3. SnapShot Mo

transmission.

You can press t tton in the right of the circle to take a

picture right away s.

he Snapshot bu

and share with your friend

Send photo by e-mail

English

-9-

Shoot continuously

Resolution selection

This section shows the resolution you selected in

the “Preview Mode”. If you want to change the

resolution, please click “ ”to go back to the

“Preview Mode” to make the changes.

4. Video Clip Mode

You can record real-time image in this section.

Send photo by e-mail

English

-10-

Convert AVI files into MEPG-1 format

Start recording

Stop recording

Exit the Video Clip Mode

To Create animation

Press to start; Press to stop

Press to return to the video recording mode

This function has to be under the resolution of RGB24 320 x

240 or I420 320 x 240. Please make sure the resolution is

correct before executing this function.

Resolution selection

This section shows the resolution you selected in the “Preview

Mode”. If you want to change the resolution, please click

“”to go back to the “Preview Mode” to make the changes.

5. Security M nitoring Systemo

This function record t of your monitor

automatically. I also record anytime until the HD is full. If there’s no

movement, it will shut down automatically after four seconds otherwise it

will be active when detecting new movement. It’s a great security

s any movements that appear in fron

t can
