Genius ISLIM 320 Manuel utilisateur

English

Table of Contents

iSlim 320 Features 1

Installing the iSlim 320 2

About Genius Application-WebCAM Mate 3

1. Main Menu 3-11

2. Picture Mode 12-14

3. Video Mode 15-16

4. Security Mode 16-19

Using MSN Messenger,Yahoo Messenger,AOL 19-21

CrazyTalk Avatar Creator 21-45

CrazyTalk CamSuite 46-73

Trouble shooting for web camera 74

English

-1-

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

zThis product is designated for separate collection at an appropriate

collection point. Do not dispose of as household waste.

zFor more information, contact the retailer or the local authorities in charge

of waste management.

Experience true plug and play with iSlim 320! Hook it up to a USB port

and start video chatting right away! No drivers are needed for this USB

Video Class web camera.

1.SnapShot Button

You can press the snapshot button

to take images.

2.Manual Lens

Adjust the focus by twisting the

lens.

3.LED Indicator

When iSlim 320 is connected to the

computer's USB port, the LED will

light up when performing video

application.

4.Micro

hone

5.Swivel and Clipping Base

The adjustable clipping base fits

easily to almost anything - notebook

panel, CRT, and LCD monitors.

iSlim 320 Features

English

-2-

iSlim 320 supports UVC (USB Video Class) which can plug and play in

Windows XP SP2, Vista or Mac 10.4.9 and above without using a device

driver.

1. Make sure your PC OS system is Windows XP SP2, Vista or Mac

10.4.9 and above.

2. Plug in the iSlim 320 to a USB port. It is now ready for use with any

application. The web camera can work properly with any video chat

software that supports a video feature.

3. Genius application:

You can use the Genius application software to capture a real-time

image, record or execute simple security functions. The Snapshot

function will work in the Genius application software.

4. In Windows XP SP2 and Vista:

a. Double-click on the My Computer icon. Or click Start ÆMy

Computer.

b. Select “USB Video Device” and double-click, and the video

appears on the screen automatically.

5. In Mac 10.4.9 or above:

Click iChat ÆPreference. Now you can use iSlim 320 for online

chatting.

NOTE

To check if Windows XP system is SP2 (Service Pack 2).

−Click on the My Computer icon on your desktop or in the

Windows Start menu.

−When the menu appears, click Properties.

If your Windows XP system isn’t SP2 (Service Pack 2), go to the

website http://www.microsoft.com to upgrade your version.

Installing the Device

English

-3-

You can use Genius WebCAM Mate software to capture the

real-time image, record or execute the simple security function.

NOTE

After installing the Genius Application software, the system will

automatically create a file (C:\WINDOWS\Album or C:\WINNT\Album)

to save the images you take using the Genius Application.

Genius application is compatible to Windows Vista/XP/2000/Me/98SE

1. Main Menu

About Genius Application-WebCAM Mate

English

-4-

Item Mode Description

Picture Mode Still image capture mode.

Video Mode Video recording mode.

Security Mode Security monitoring mode.

Device

Selection Select different webcam device.

Resolution

Selection

Resolution selections according to

device.

MJPG: 640x480, 352x288, 320x240,

176x144, 160x120

YUY2: 640x480, 352x288, 320x240,

176x144, 160x120

*After installing Advanced Driver:

YUY2: 3360x2520, 1280x960,

800x600, 640x480, 352x288, 320x240,

176x144, 160x120

Property page View your settings and properties.

Exit Exit the Genius UI.

Remark:

* This resolution is by software interpolation.

English

-5-

-Property page (Without installing Driver)

Property page lets you adjust the web cam to your personal liking.

-Video Proc Amp

Item Description

Brightness enables you to adjust the brightness of the displayed

image or video.

Contrast enables you to control the ratio between dark and light.

Hue is any color in the rainbow that you choose to pick.

English

-6-

Item Description

Saturation enables you to set the color reproduction from black

and white to full color image or video.

Sharpness can soften or sharpen images to achieve different

effects.

Gamma enables you to brighten dark areas within the displayed

image or video and visualize more details without over-exposing

already light areas.

You can adjust different values for different circumstances

depending on your environment.

Turn on the backlight compensation to improve the image quality

when you have a scene where the background has a high

illumination level (for instance when you are sitting in front of a

bright light).

English

-7-

-Camera control

Item Description

When resolution is set to 352x288, 320x240, 176x144 and

160x120, you can execute zoom in/out picture function.

English

-8-

-Property page (After installing driver)

-Stream Property

Item Description

- You can flip the image horizontally or vertically by choosing

“Image Mirror” or “Image Flip”.

- When the light is not sufficient, you may click on “Low Light”

to get a clear image.

English

-9-

Item Description

You can adjust different values for different circumstances

depending on the environment.

You may adjust values to improve the image appearance. Before

adjusting values, you have to unclick “Auto” to unlock.

- Press “Reset” to return to the manufacturer’s settings.

- Press “Restore” to return to the previous settings.

Press “Save” to save the values you set up.

Select the correct frequency according to the country where you

are using the web camera. (Before doing this, you will need to

select “Indoor”.)

- If your web camera is located in a backlight position, you may

click “Backlight compensation” to get a sharper image.

You can have a black-and-white photo effect by clicking on “B/W

Mode”.
