Genius EYE 311Q Manuel utilisateur

English

-1-

Eye 311Q Features

1 SnapShot Button

You can press the snapshot button to take

the images.

2 Lens

Adjust the focus by twisting the lens.

3 LED Indicator

4 Swivel and Clipping Base

The flexible base design allows the Eye

311Q to stand easily or clip on the LCD

monitor.

Installing the Eye 311Q

1. Please install the driver first and then connect Eye 311Q to

the USB port.

2. Installing the Eye 311Q driver

a. Insert the Eye 311Q Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install “DirectX”from the CD.

Notice: If the Autorun screen doesn’t start, please follow these

steps:

zClick on “Start Menu”.

zType D：\SETUP.EXE , then click “Enter” key.

English

-2-

(Assume your CD-ROM is in Drive D)

3. Insert the Eye 311Q’s USB cable to your desktop’s or

laptop’s USB port.

4. Complete software and hardware installation. You can

install the software you would like for video

conferencing or chat with your friends.

NOTE

To remove the driver installation:

Please go to the taskbar and follow “Start” Æ“Program” Æ“Eye 311Q”Æ

Click “Uninstall”, then follow the on-screen instructions to remove the

driver.

Genius Application (Windows Only)

You can use our software to capture the real-time image, record or

execute the simply security function.

To run the software, please go to the task bar and follow “Start”Æ

Click “Program”ÆChoose “Eye 311Q”ÆClick “Eye 311Q”. Or you

may execute the software by simply clicking the shortcut of “Eye 311Q”.

English

-3-

NOTE

After installing the driver of Eye 311Q, the system will automatically create a

file (C:\WINDOWS\Album or C:\WINNT\Album)to save the images you take

using the Genius Application.

1. Description for the major icon

Preview mode

Snapshot mode

Video Clip Mode

Security monitoring system

Exit the Genius UI

Camera Control

NOTE

In the “camera control section”, you can personalize your camera

settings for different circumstances.

English

-4-

1-You can flip the image horizontally or vertically by choosing “Image Mirror” or

“Image Flip”.

-When the light is not sufficient, you may click on “Low Light” to get a clear

image.

2You can adjust different values for different circumstances and environment

3When you want a still image capture, you can drag the bar to select a resolution

size you want.

-VGA: 640 x 480;

-SVGA: 800 x 600

-XGA: 1024 x 768

-SXGA1280 x 960

4You may adjust values toward image appearance. Before adjusting values, you

have to unclick “Auto” to unlock.

5-Press “Reset” to return to the manufacturer’s settings.

-Press “Restore” to return to the previous settings.

-Press “Save” to save the values you set up.

English

-5-

6Select the correct frequency according to the country where you are using the

web camera. (Before doing this, you will need to select “Indoor”.)

7-If your web camera is located in backlight position, you may click “Backlight

compensation” to get a sharper image.

-You can have a black-and-white photo effect by clicking on “B/W Mode”.

English

-6-

1There will be 27 different kinds of video effects/frames for you to select. The

effects can also be applied to the video chat software, like MSN Messenger.

You can directly connect to this effect page from the web camera settings in the

video chat software.

2Besides the 27 kinds of video effects/frames in section 1, you also can bring in

your customized frame. Please note that, in the customized frame, you must have

the color in Pantone 255 in the area, where you want your image show up.

English

-7-

3Auto Change: Once you choose this, the 27 kinds of video effects will take turns

from the first one to the last one.

No effects & frame: Once you choose this, the video effects will be determinate.

2. Preview Mode

You can use the function buttons on the control panel to zoom in/out and

move upward/downward/left/right.

Zoom in the image

Zoom out the image

Move the image upward

Move the image downward

English

-8-

Move the image to the left

Move the image to the right

Resolution Selection

There are 2 categories of resolution: RGB24 and

I420. You can select 5 different image resolutions for

each of them. The file size of I420 will be smaller than

RGB24. So, I420 may be the better choice for

transmission.

3. SnapShot Mode

You can press the Snapshot button in the right of the circle to take a

picture right away and share with your friends.

Send photo by e-mail

English

-9-

Shoot continuously

Resolution selection

This section shows the resolution you selected in the

“Preview Mode”. If you want to change the resolution,

please click “ ”to go back to the “Preview Mode” to

make the changes.

4. Video Clip Mode

You can record real-time image in this section.

Send photo by e-mail

Convert AVI files into MEPG-1 format

Start recording

English

-10-

Stop recording

Exit the Video Clip Mode

To Create animation

Press to start; Press to stop

Press to return to the video recording mode

This function has to be under the resolution of RGB24 320 x 240

or I420 320 x 240. Please make sure the resolution is correct

before executing this function.

Resolution selection

This section shows the resolution you selected in the “Preview

Mode”. If you want to change the resolution, please click “ ”to

go back to the “Preview Mode” to make the changes.

5. Security Monitoring S

monitor automatically. It can also record anytime until the HD is fu

there’s no movement, it will shut down automatically after four

seconds or otherwise it will be active when detecting new movem

It’s a great security monitoring system at times when you’re not

around.

ystem

his function records any movements that appear in front of your ll. If

ent.
