Genius EYE 320 Manuel utilisateur

English

Table of Contents

Eye 320 Features 1

Installing the Eye 320 2-3

About Genius Application-WebCAM Mate 3

1. Main Menu 4-8

2. Picture Mode 9-11

3. Video Mode 12-13

4. Security Mode 13-16

Using MSN Messenger,Yahoo Messenger,AOL 16-18

CrazyTalk Avatar Creator 18-40

CrazyTalk CamSuite 41-67

Trouble shooting for web camera 68-69

English

-1-

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

zThis product is designated for separate collection at an appropriate

collection point. Do not dispose of as household waste.

zFor more information, contact the retailer or the local authorities in charge

of waste management.

Experience true plug and play with Eye 320! Hook it up to a

USB port and start video chatting right away! No drivers are

needed for this USB Video Class web camera.

1.SnapShot Button

Press the snapshot button to take

images under the application.

2.Lens

Adjust the focus by twisting the lens.

3.LED Indicator

When Eye 320 is connected to the

computer's USB port, the LED will

light up when performing video

applications.

4.Swivel and Clipping Base

The adjustable clipping base fits

easily to almost anything - notebook

panel, CRT, and LCD monitors.

Eye 320 Features

English

-2-

Eye 320 supports UVC (USB Video Class) which can plug and play in

Windows XP SP2, Vista or above OS without a device driver installed.

1. Make sure your PC OS system is Windows XP SP2, Vista or above.

2. Position the webcam and connect the USB cable to an available

USB port on your computer. Windows automatically detects the

device.

3. Now Eye 320 is ready for running with any application. The web

camera can work properly with any video chat software that

supports a video feature.

4. In Windows Vista:

You can use Genius application software to capture a real-time image,

record or execute the simple security function. The Snapshot function

will work in the Genius application software.

5. In Windows XP SP2:

a. Double-click the My Computer icon.

Alternatively, click Start →My Computer.

b. Select “USB Video Device” and double-click, and the video

appears on the screen automatically.

Installing the Eye 320

English

-3-

NOTE

To check if Windows XP system is SP2 (Service Pack 2).

−Click the My Computer icon on your desktop or in the Windows

Start menu.

−When the menu that appears, click Properties.

If your Windows XP system isn’t SP2 (Service Pack 2), go to the

website: http://microsoft.com to upgrade your version.

You can use Genius WebCAM Mate software to capture the

real-time image, record or execute the simple security function.

NOTE

After installing the Genius Application software, the system will

automatically create a file (C:\WINDOWS\Album or

C:\WINNT\Album)to save the images you take using the Genius

Application.

Genius application available in windows Vista/XP/2000/Me/98SE

About Genius Application-WebCAM Mate

English

-4-

1. Main Menu

Item Mode Description

Picture Mode Still image capture mode.

Video Mode Video recording mode.

Security Mode Security monitoring mode.

Device

Selection Select different webcam device.

English

-5-

Item Mode Description

Resolution

Selection

Resolution selections according to

device.

YUY2: 1280x1024, 1024x768,

800x600, 640x480, 352x288, 320x240,

176x144, 160x120 pixels

Property page Preference setting to view your setting

and properties.

Exit Exit the Genius UI.

English

-6-

Property page

Property page allows user to adjust a person like property of the webcam.

-Video Proc Amp

Item Description

Brightness enables you to adjust the brightness of the displayed

image or video to suit your own preference.

Contrast enables you to control the ratio between dark and light

English

-7-

Item Description

according to your own preference.

Hue is any color in the rainbow that you choose to pick.

Saturation enables you to set the color reproduction from black

and white to a full color image or video according to your own

preference.

Sharpness can soften and sharpen images to achieve different

effects.

Gamma enables you to brighten dark areas within the displayed

image or video and visualize more details without over-exposing

already light areas.

Turn on the backlight compensation to improve the image quality

when you have a scene where the background has a high

illumination level (for instance when you are sitting in front of a

bright light).

Select the correct frequency according to the country where you

are using the web camera. (* )

Remark:

* : This function not available in windows XP SP2 (Service Pack 2).

English

-8-

-Camera control

Item Description

Enable Auto Focus function provides real-time sharp and clear

image quality. No matter how far you sit from the screen, you

always bring in focus. Use the slider to find manual focus setting.

English

-9-

2. Picture Mode

Take a picture right away and share with your friends.

Item Mode Description

Shot Still image capture mode.

Multi-Snapshot Capture continuous still images based

on multi-snapshot number.
