Genius Traveler 9005BT Manuel utilisateur

English

Introduction

Traveler 9005BT is designed for a PC or notebook enabled with a

Bluetooth device. It provides a convenient feature to attach your

mouse when taking your notebook to office meetings.

Hardware Installation

1. Install two AA batteries in the mouse.

2. Stick-N-Go: attach the „Click Mount‟ on

your notebook in a convenient position

first, then you can attach the mouse on

your notebook as shown to avoid dropping

your mouse.

3. Make sure that you have switched on the

power switch underneath the mouse.

Software Installation

1. Make sure the mouse is connected to the

computer.

2. Put the CD driver into the CD drive.

3. Choose and double click „Mouse Driver‟ and follow the

instructions to complete the 4D/8D installation.

English

Factory Settings

1. Left Button: Provides traditional mouse functions like click,

double click and drag.

2. Magic-Roller: Press the

“Magic-Roller” to surf the Internet

and Windows documents.

3. Right Button: Provides traditional

mouse click functions.

4. Flying Scroll: Press and hold on to the button and move the

mouse for multi-direction browsing. It provides more fun and

convenience to office users in scrolling up, down, left, right or

diagonally.

Pairing Process in Vista and Windows XP SP2

1. Open the Windows control panel, then select “Bluetooth

devices”.

2. Click “Add…..”

3. Select “My device is setup and ready to be found”, then click

“Next”.

English

4. Press and hold the “CONNECT” button under the mouse.

5. In “Peripherals (Keyboards, mice, joysticks)”, select Genius

Bluetooth Mouse and click “Next”.

6. Select “Don‟t use a passkey” and click “Next”.

7. Windows will start to connect the Genius Bluetooth Mouse

automatically. Press the finish button after the connection

process is completed.

Pairing Process in Windows 7

1. Mouse over the Bluetooth device icon and click right button of

mouse to open function list, then select “Add a Device”.

2. Press and hold the “CONNECT” button under the mouse.

3. Select Genius Bluetooth Mouse, then click “Next”.

English

4. Windows will start to connect the Genius Bluetooth Mouse

automatically. Press the close button after the connection process

is completed.

Once the connection between the Genius Bluetooth Mouse and your

computer is established, the connection will be kept permanently. That

means the connection will re-establish automatically each time you

run Windows.

Pairing Process in Mac OS X 10.2.8 or later

1. Press and hold the “CONNECT” button under the mouse.

2. Click the Bluetooth icon on the task bar and select “Setup

Bluetooth device”.

3. Click “Continue” when the “Bluetooth Setup Assistant” appears.

4. Choose “Mouse” and press “Continue” to the next step.

5. When Bluetooth finds the “Genius Bluetooth Mouse”, press

“Continue” to the next step.

English

6. Click “Continue” when the “Passkey exchange with your

mouse” appears.

7. The connection is now successful and you can use your Genius

Bluetooth Mouse.

Pairing Process in Mac OS X 10.5 or later

1. Click the Bluetooth icon

on the task bar and click

plus sign to “Setup new

device”.

2. Press and hold the

“CONNECT” button

under the mouse.

3. When Bluetooth finds

the “Genius Bluetooth

Mouse”, press

“Continue” to the next

step.

4. When Mac connects the

Genius Bluetooth Mouse

completely, press “Quit”

and back to Bluetooth

setup screen.

English

5. The connection is now successful and you can use your Genius

Bluetooth Mouse.

Now you can use the Genius Bluetooth Mouse wirelessly with a

Bluetooth enabled Apple computer. Afterwards, the connection of the

Genius Bluetooth mouse will re-establish automatically each time

Mac OS X runs.

Pairing Process in Android 3.0 or later

1. Select the Bluetooth device icon.

2. Press and hold the “CONNECT” button under the mouse.

3. Android will start to connect the Genius Bluetooth Mouse

automatically. Type PIN “0000”for the Genius Bluetooth

Mouse to complete connection process.

English

4. The connection is now successful and you can use your Genius

Bluetooth Mouse.

Remark:

If not in use for a while, the Bluetooth Mouse will go into sleep

mode. Move or click any button on the Bluetooth Mouse to wake

it up, it takes less than three seconds for it to work again.

If not in use for 30 minutes or longer, the Bluetooth Mouse will

disconnect from your computer. Move or click any button on the

Bluetooth Mouse for reconnection, it takes about six seconds for

the mouse to start working normally.

If you feel the mouse does not move smooth as usual, it is

possible the battery has lost its charge so you need to replace it.

Remember to put the battery in the correct direction.
